USER MANUAL 46201 HAMILTON BEACH

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs. Care must be taken

as burns can occur from touching hot parts or from spilled, hot liquid.

To protect against electric shock, do not place cord, plug, or coffeemaker in water or other liquid.

4. Close supervision is necessary when any appliance is used by or

Unplug from outlet when either the coffeemaker or clock is not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

6. Coffeemaker must be operated on a flat surface away from the edge

of counter to prevent accidental tipping.

7. Do not operate any appliance with a damaged cord or plug, or after

the appliance malfunctions or is dropped or damaged in any manner. Call our toll-free number for information on examination, repair, or adjustment.

8. The use of accessory attachments not recommended by the appliance

manufacturer may result in fire, electrical shock, or personal injury.

Use only the carafe provided with the appliance.

10. Do not use outdoors.

11. Do not let cord hang over edge of table or counter or touch hot

surfaces, including stove.

The carafe is designed for use with this coffeemaker. It must never be used on a range top or in a microwave oven

14. Do not use a cracked carafe or one with a loose or weakened handle.

15. Do not clean carafe with cleansers, steel wool pads, or other

16. Be certain carafe lid is securely in place during brew cycle and when

pouring coffee. Do not use force when placing lid on carafe.

17. Do not place coffeemaker on or near a hot gas or electric burner or

18. To disconnect coffeemaker, turn controls to OFF and then remove

plug from wall outlet.

19. WARNING! To reduce the risk of fire or electric shock, do not

remove the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.

20. Do not use appliance for other than intended use.

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following: SAVE THESE INSTRUCTIONS!

OTHER CONSUMER SAFETY INFORMATION

This appliance is intended for household use only. WARNING! Shock Hazard: This appliance has a polarized plug (one wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adaptor. If the plug does not fit, reverse the plug. If it still does not fit, have an electrician replace the outlet. The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over. To avoid an electrical circuit overload, do not use another high-wattage appliance on the same circuit with your coffeemaker. 840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 23 Parts and Features Clock and Controls Filter Basket Swivel Filter Basket Holder Keep-Warm Plate Swivel Filter Basket Button Removable Water Reservoir Carafe Optional Accessories Water Filter To Order, Call:

1.800.851.8900 (U.S.)

Burn Hazard. To avoid hot coffee overflowing from the filter basket:

• When using decaffeinated coffee, do not exceed the coffee manufacturer’s recommended serving amount.

• Ensure swivel filter basket is completely closed. If filter basket overflow occurs, unplug coffeemaker and allow coffee in filter basket to cool before removing filter basket. w WARNING BEFORE FIRST USE: Wash unit. See “Cleaning With Vinegar.” Place OPTIONAL water filter and water filter base into water reser- voir (see “Optional Accessories”).

Press HOUR button to set current hour with AM or PM. Press MINUTE button to set current minutes.

For each cup of coffee being made, place one level tablespoon of ground coffee into filter. A permanent filter may also be used with the filter basket. Select your brew option and keep-warm settings (see “How to Use the Brew Option and Keep-Warm Features”).

Press ON/OFF button once to turn the coffeemaker on. If storing coffeemaker, the cord can be pushed into a special cord storage area in the back of the unit. When finished, press ON/OFF button once and unplug. NOTE: If the coffeemaker is not turned off manually, it will auto- matically shut off in two hours.

Filter Basket With Paper Filter Filter Basket With Permanent Filter Close swivel filter basket holder before brewing, and do not open until brewing cycle is complete and unit is cool.

While holding PROGRAM button, press HOUR and MINUTE buttons until desired brewing time is reached.

Once desired brewing time has been reached, release PROGRAM and current time is displayed. Press and release PROGRAM again to activate automatic brew. NOTE: Green LED will illuminate to indicate PROGRAM is activated. Green LED light will turn off when the unit begins to brew at the preprogrammed time. Tips for Best-Tasting Coffee

• All coffees are made from either arabica beans or robusta beans, or some combination of both. Arabica beans are slightly more expensive, but tend to produce better-tasting coffee.

• Ground coffee will become stale much faster than whole beans. If buying preground coffee, chose a package with the latest expiration date or a smaller quantity.

• If grinding whole beans, set your coffee grinder on a fine/ medium grind. This will yield the best-tasting grounds. Try to use freshly ground coffee within about a week of grinding.

• Using a water filter, filtered water, or bottled water will yield better-tasting coffee than tap water.

• Use approximately 1 tablespoon of grounds for each cup of coffee being made. To avoid overflow, use about 1/3 less grounds when brewing decaf or flavored coffees.

• Make sure your coffeemaker is clean. See “Cleaning With Vinegar” section. 840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 67

For stronger coffee, hold the BREW OPTIONS button until “BOLD” is illuminated; then release. How to Use the Brew Option and Keep-Warm Features BREW OPTIONS Your coffeemaker will default to the “Regular” strength coffee setting when brewing. NOTE: Using the brew strength options will increase the length of brewing time slightly.

For small amounts, use the 1–4 cup setting by holding the BREW OPTIONS button until “1–4 CUPS” is illuminated; then release.

Then, press the ON/OFF button or set the Automatic Brew to start the coffeemaker after your brew option has been selected.

Adjust the keep-warm setting by pressing the KEEP WARM button until your desired temperature setting is displayed; then release. KEEP WARM This unit is equipped with an adjustable keep-warm feature and will default to the highest (warmest) temperature setting. NOTE: If adjusting the keep-warm temperature after brewing, allow approximately 15 minutes for the coffeemaker to adjust its temperature setting. 840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 78 Water Filter (optional accessory)

For better-tasting coffee, use a water filter. Filter replacement is recommended every 60 cycles. To Order Water Filter Kit, Call:

1.800.851.8900 (U.S.)

15 min. This symbol alerts you to the potential danger for personal injury if you fail to read and follow these safety precautions.

• Do not use a cracked carafe or a carafe having a loose or weakened handle.

• This carafe is designed to be used only on the keep-hot plate of your coffeemaker. Do not use on a gas or electric rangetop, or in a microwave or conventional oven.

• To avoid breakage, handle carafe with care. Avoid impact. Glass will break as a result of impact. Use care when filling with water to avoid hitting faucet.

• Do not place hot carafe on cool or wet surface. Allow to cool before washing or adding liquids.

• Do not set empty carafe on a hot heating surface.

• Do not clean with steel wool pads, abrasive cleanser, or any other materials that may scratch.

• Do not place hands inside carafe. When handling, be careful if wearing any hand jewelry, especially diamond rings. Jewelry can scratch the glass, which increases possibility of breakage.

• Do not bump, scratch, or boil dry.

• Discard carafe if it is cracked, scratched, or heated while empty for an extended period of time.

• To avoid accidents, do not pour in the direction of people.

• If stirring in the carafe, use only wooden, plastic, or rubber utensils. Do not use metal utensils.

• Follow the above safety precautions carefully to avoid serious burn injuries which may result if breakage occurs while carafe holds heated liquids. Carafe Safety Precautions This symbol reminds you that glass is fragile and can break which could result in personal injury. 840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 89 Cleaning With Vinegar

Remove water filter and water filter base (see “Water Filter”). Pour 1 pint (2 cups/500 ml) white vinegar into water reservoir. Press the ON/OFF button once. After 30 seconds, turn OFF. Wait 30 minutes to allow vinegar to clean. Then turn ON again. When brew cycle is finished, wait for unit to cool. All coffeemakers should be cleaned at least once a month (once a week for areas with hard water).

Run 2–3 more brew cycles with CLEAN WATER only. Allow to cool between cycles.

DISHWASHER-SAFE (top rack)

840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 910 PROBLEM Filter basket overflows or coffee brews slowly. Coffee not brewing/unit will not turn on. PROBABLE CAUSE

• The “BOLD” or 1–4 cup brew option is recommended for brewing decaffeinated coffee.

• Excessive amounts of coffee.

• Coffee ground too finely (not automatic drip grind).

• Carafe not securely placed on keep-warm plate or swivel filter basket holder not closed completely.

• Carafe removed during brewing for more than 20 seconds and not placed securely back on keep- warm plate.

• Coffeemaker needs cleaning.

• Coffee grounds between paper filter and filter basket.

• Paper filter not open and in proper position.

• Press the seamed edges of paper filter before inserting into basket.

• Rinse filter basket before inserting paper filter so the edges will remain pressed against the sides of the basket.

• Poor-quality paper filter.

• Water reservoir is empty or not properly placed onto back of unit.

• Power surge. Unplug; then plug the unit back in.

• Clock requires reset after power outage. Troubleshooting 840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 1011 Limited Warranty This warranty applies to products purchased in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value. This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use. We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you. To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance. 840183101 ENv2.qxd:Layout 1 3/5/10 11:40 AM Page 1112

1.800.851.8900 (U.S.)
