AFS8009 - Sandwich maker BESTRON - Free user manual and instructions

USER MANUAL AFS8009 BESTRON

Line drawing of a small electronic device with a handle and top panel (no text or symbols)

Nederlands

Sandwich maker user's instructions

Italiano

Technical diagram of a grating with labeled parts including an open waffle, a side sink, and plug.

WERKING - SANDWICHES TOASTEN

Technical diagram of a grating with labeled parts including an open waffle, a side sink, and plug.

Handwritten signature or scribble on a line, possibly a signature or artistic mark

R. Neyman

Qualitätskontrolle

Technical diagram of a toaster oven with labeled parts including grating, air conditioner, and power plug

CONDITIONS DE GARANTIE

DÉCLARATION DE CONFORMITÉ CE

Handwritten signature or scribble on a line, likely a personal autograph or document

R. Neyman

SAFETY INSTRUCTIONS - General

• Please read these instructions carefully and retain them for reference.
• Use this appliance solely in accordance with these instructions.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Children should be supervised to ensure that they do not play with the appliance.
  • Have any repairs carried out solely by a qualified electrician. Never try to repair the appliance yourself.

SAFETY INSTRUCTIONS - Electricity and heat

Certain parts of the appliance may get hot. touch these parts to prevent burning yourself.

• Verify that the mains voltage is the same as that indicated on the type plate on the appliance before use.
  • Make sure that you always use an earthed wall socket to connect the appliance.
  • Always remove the plug from the socket when the appliance is not in use.
• Remove the plug from the wall socket by pulling the plug, not the power cord.
• Check the appliance's power cord regularly to make sure it is not damaged. Do not use the appliance if the power cord is damaged. Have a damaged power cord replaced by a qualified repair service.
• When using an extension lead always make sure that the entire cable is unwound from the reel.
  • Use solely approved extension leads.
  • Certain parts of the appliance may get hot. Do not touch these parts to prevent burning yourself.
• The appliance needs space to allow heat to escape, thereby preventing the risk of fire. Make sure that the appliance has sufficient space around it, and does not come in contact with flammable material. The appliance must not be covered. Make sure the air vents are not covered or blocked.
• Never use the appliance in the vicinity of flammable materials.
• Make sure that the appliance, the power cord or the plug do not make contact with hot surfaces, such as a hot hob or naked flame.
  • Make sure that the appliance, the power cord and plug do not make contact with water.

SAFETY INSTRUCTIONS - During use

• Never use the appliance outdoors.
• Never use the appliance in humid rooms.
- Place the appliance on a stable, flat, heat-resistant and splash-proof surface where it cannot fall.
- Do not let the power cord hang over the edge of the draining board, worktop or table.
• Make sure that your hands are dry when you touch the appliance, the power cord or the plug.
• Never use the appliance without the baking plates.
- Never use the appliance in the vicinity of a bird cage. Fumes released from the non-stick coating when the baking plates are hot can cause stress to birds.
- Do not touch the appliance if it has fallen into water. Remove the plug from the wall socket immediately. Do not use the appliance any more.
• Make sure that the appliance has sufficient ventilation whilst in use.
- Clean the appliance thoroughly after use (see "Cleaning and maintenance").
• Never immerse the appliance, the cord or the plug in water or any other liquid.
• This appliance may not be used through an external timer or by means of a remote control.

TECHNICAL INFORMATION

Type: AFS8009

Output: 750W

Power supply: 220-240V \~ 50Hz

OPERATION - General

The appliance is intended only for domestic use, not for professional use.

Technical diagram of a waffle and its internal components with labeled parts

1. Baking plates
2. Latch for opening and closing
3. Handle
4. a. Red indicatoin light "power"
   b. Green indicatoin light "heating"
5. Power cord with plug

OPERATION - Before the first use

1. Remove the sandwich maker from the packaging, and remove all packaging materials.
2. Clean the baking plates before using them for the first time (see 'Cleaning and maintenance').

OPERATION - Preparation

1. Put the plug in the wall socket. The "power" indicator lamp (red) will illuminate to show that the appliance is on.
2. Take four slices of bread that fit in the sandwich maker. Cut the edges off slices that are too large, so that they fit in the appliance.
3. Allow the sandwich maker to heat up in the closed position.

4. Lay two slices of ham and/or cheese on two slices of bread, and cover with the other two slices of bread. Make sure that the ham and/or cheese does not project from the sandwich.

5. Do not use butter; you do not need butter to prepare a delicious toasted sandwich. The non-stick coating will ensure that the sandwich does not stick to the baking plates.

6. Try varying the ingredients. You can use herbs, fruit, and various types of cheese and meat to make delicious sandwiches.

You can also make just one sandwich. You just leave the other baking plate empty.

OPERATION - Toasting sandwiches

1. Wait until the green indicator light goes on. The baking plates are now at the correct temperature and the sandwich maker is ready for use.

During use the heating element will switch on and off to keep the temperature of the baking plate constant. Consequently the indicator light will also occasionally be illuminated.

The appliance may emit a little smoke and a characteristic smell when you switch it on for the first time. This is normal, and will soon stop. Make sure the appliance has sufficient ventilation. If necessary, toast the first sandwiches without ham or cheese and throw them away.

1. Open the latch and lift the cover by the handle.
2. Place the prepared sandwiches in the forms in the baking plate.
3. Close the cover and click the latch closed.

If you cannot close the cover and you cannot close the latch, there is too much ham or cheese on the sandwich. Do not try to close the cover with force; instead, remove some ham and/or cheese from the sandwich.

1. Toast the sandwich until it turns golden-brown. With experience, you will find the correct baking time for your type of bread and ham or cheese.
2. Open the cover and remove the sandwiches from the baking plate with a wooden or plastic spatula.

Never use a metal spatula, knife or fork. These will damage the non-stick coating.

1. If you do not want to toast any more sandwiches, remove the plug from the wall socket and allow the appliance to cool.

Enjoy your meal!

CLEANING AND MAINTENANCE

1. Make sure the plug has been removed from the wall socket and that the appliance has cooled completely.
2. Clean the baking plates with a damp cloth, if necessary with an additional couple of drops of washing-up liquid. Make sure no traces of detergent remain on the plates. Dry the baking plates thoroughly.
3. Clean the housing with a damp cloth, and then dry thoroughly.

4. The appliance can now be stored either horizontally or vertically, on its back.

5. Never use metal implements or scourers to clean the baking plates; these could damage the non-stick coating on the baking plate.

6. Never immerse the appliance, power cord or plug in water. Never place the appliance in a dishwasher.
7. Never use corrosive or scouring cleaning agents or sharp objects (such as knives or hard brushes) to clean the appliance.

THE ENVIRONMENT

- Dispose of packaging material, such as plastic and boxes, in the appropriate waste containers. When this product reaches the end of its useful life do not dispose of it by putting it in a dustbin; hand it in at a collection point for the reuse of electrical and electronic equipment. Please refer to the symbols on the product, the user's instructions or the packaging.

• The materials can be re-used as indicated. Your help in the re-use, recycling or other means of making use of old electrical equipment will make an important contribution to the protection of the environment.
• Contact your municipality for the address of the appropriate collection point in your neighbourhood.

GUARANTEE TERMS

The importer guarantees the appliance against defects caused by manufacturing and/or material faults for 60 months from the date of purchase, subject to the following conditions.

1. No charges will be made for labour costs or materials during the warranty period. Any repairs carried out during the warranty period do not extend the warranty period.
2. The importer automatically becomes the owner of any faulty parts that he replaces or a faulty appliance (in the event of replacement of the appliance).
3. All claims submitted under warranty must be accompanied by the original bill of sale.
4. Claims under warranty must be submitted to the dealer where the appliance was purchased or to the importer.

5. The warranty is issued solely to the first purchaser and cannot be transferred.

6. The warranty does not cover damage caused by:

a. Accidents, incorrect use, wear and/or neglect.
b. Faulty installation and/or use in a manner contravening the prevailing legal, technical or safety regulations.

c. Connection to a mains voltage other than the voltage specified on the type plate.

d. Unauthorized modifications.

e. Repairs carried out by third parties.

f. Careless transport, i.e. without suitable packaging materials or protection.

1. No claims may be made under this warranty for:

a. Losses incurred during transport.

b. The removal or changing of the appliance's serial number.
8. The guarantee does not cover power cords, lamps or glass parts.
9. No claims can be submitted under this warranty for damage other than the repair or replacement of faulty parts. The importer can never be held responsible for any consequential loss or damage or any other consequences, resulting either directly or indirectly from the appliance supplied by the importer.
10. In case of claims under guarantee you can contact your dealer where the appliance is purchased. Bestron offers you also the possibility to send the appliance directly to our Service Department. Do not send your appliance without consulting us. The package may be refused and any any costs will be for your account. Please contact the Service Department and they will tell you how to pack and send the appliance.
11. This appliance is not suitable for professional use.

SERVICE

If a fault should occur please contact the BESTRON service department:

THE NETHERLANDS:

BESTRON NEDERLAND BV

Bestron Service

Moeskampweg 20

5222 AW 's-Hertogenbosch

Tel: +31 (0) 73 - 623 11 21

Fax: +31 (0) 73 - 621 23 96

Email: [e-mail]

Internet: www.bestron.com

CE DECLARATION OF CONFORMITY

This product conforms to the essential requirements of the following EU safety directives:

• EMC Directive 2004/108/EC
• Low Voltage Directive 2006/95/EC

###

R. Neyman
Quality control

Handwritten signature or scribble on a line, possibly a signature or artistic mark

Line drawing of a portable food grater with lid and buttons (no text or symbols)

BESTRON®

AFS8009

v 210214-08
