WAK 9460 - Washing machine BAUKNECHT - Free user manual and instructions

Brand	Bauknecht
Model	WAK 9460
Product type	Washing machine
Width	600 mm
Height	825 mm
Depth	600 mm
Water pressure	100 - 1000 kPa (1-10 bar)
Electrical connection	Grounded outlet required, do not use extension cord
Water inlet	Cold water only, 3/4" connection
Drain hose	Connect to siphon or sink edge
Washing capacity	Approximately 7 kg (estimate)
Main functions	Washing, rinsing, spinning, various programs
Child safety	Door locking screw
Detergent drawer	Compartments for prewash, main wash, fabric softener
Filter	Cleanable regularly, access via cover
Water hardness	Adjustable via reminder in drawer
Unbalance detection	Automatic spin correction
Fault display	Numeric error codes or LCD depending on model
Maintenance	Clean body, seal, detergent drawer, water inlet filter
Available accessories	Drawer base, stacking kit, built-in kit
Approximate weight	Approximately 65 kg (estimate)
Energy consumption	Not specified, but typical for a freestanding washing machine

Frequently Asked Questions - WAK 9460 BAUKNECHT

How to install the Bauknecht WAK 9460 washing machine?

After removing the packaging and transport bolts, place the machine on a flat and stable floor. Adjust the four feet to make it level using a spirit level. Connect the water inlet hose to the tap (3/4 inch thread) and the drain hose to the siphon or sink edge. Plug the appliance into a grounded outlet without using an extension cord.

What to do if the machine does not start and no lights come on?

Check that the power plug is properly inserted into a working socket (test with a lamp). If the socket is correct, the problem may be electrical; contact after-sales service.

How to clean the pump filter?

Turn off and unplug the appliance. Open the filter cover using the colored accessory from the detergent drawer. Place a container under the filter, then turn the handle slowly counterclockwise to drain the water. Once water has drained, unscrew the filter completely, clean it and the cavity, then replace it.

Why is the water not draining?

This could be due to a kinked drain hose, clogged filter, or blocked pump. First check the filter (see previous question) and the hose. If the problem persists, error code 'P' and 'F' or 'Fault FP' appears; clean the filter and restart the drain program.

How to activate child safety?

The child safety is inside the door: turn the plastic screw using the rounded corner of the detergent drawer accessory or a coin. In vertical position (vertical slot), the door cannot close; in horizontal, closing is possible.

What to do if the machine vibrates excessively during spinning?

Check that the appliance is level and the four feet are adjusted to the same height. Also ensure the transport bolts have been removed. If the problem persists, there may be an imbalance in the laundry; distribute the clothes evenly in the drum.

How to interpret error codes on the display?

Common error codes: 'H' and 'F' (water inlet fault), 'P' and 'F' (drain problem), 'F4' to 'F31' (electrical failure), 'A' and 'F' (hydrosafety fault). Refer to the fault indicator table in the manual for actions to take.

What type of detergent to use?

Use a detergent suitable for the fabric (cotton, synthetic, wool) and water hardness. For wool, use a specific detergent. Follow the doses indicated on the packaging: full load -> full dose, half load -> 3/4, minimum load (1 kg) -> half. Avoid overdosing to limit foam formation.

How to drain residual water from the machine?

Turn off and unplug the appliance. Open the filter cover, place a container underneath, then turn the filter slowly to drain water. Gently tilt the machine forward to remove remaining water. Replace the filter, close, and plug back in before restarting.

What to do in case of excessive foam formation?

Excessive foam can block spinning. Use a detergent dose appropriate for the load and water hardness. If foam appears, the anti-foam device automatically reduces spin speed. You can also run an additional rinse cycle to remove excess foam.

USER MANUAL WAK 9460 BAUKNECHT

DÉTERGENT ET PRODUITS ADDITIFS

NETTOYAGE DU Filtre

VIDANGE DE L'EAU RÉSIDUELLÉ

NETTOYAGE ET ENTRETIEN

DIAGNOSTIC RAPIDE

SERVICE APRÉS-VENTE

ACCESSIONS

TRANSPORT/DéPLACEMENT

32

40105150bF.fm Page 32 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 32 Friday.July 15,2005 1:03PM

40105150bF.fm Page 32 Friday. July 15, 2005 1:03 PM

Blue spot 45.0^100.0 LPI

AVANT D'UTILISER LE LAVE-LINGE

40105150bF.fm Page 33 Friday.July 15,2005 1:03PM

40105150bF.fm Page 33 Friday.July 15,2005 1:03PM

40105150bF.fm Page 33 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

PRECAUTIONS ET RECOMMANDATIONS GENÉRALES

1. Emballage

40105150bF.fm Page 34 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 34 Friday.July 15,2005 1:03PM

40105150bF.fm Page 34 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

DESCRIPTION DU LAVE-LINGE

40105150bF.fm Page 35 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 35 Friday.July 15,2005 1:03PM

40105150bF.fm Page 35 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

AVANT D'EFFECTUER LE PREMIER CYCLE DE LAVAGE

40105150bF.fm Page 36 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 36 Friday.July 15,2005 1:03PM

40105150bF.fm Page 36 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

DÉTERGENT ET PRODUITS ADDITIFS

40105150bF.fm Page 37 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 37 Friday. July 15, 2005 1:03 PM

40105150bF.fm Page 37 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

40105150bF.fm Page 38 Friday, July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 38 Friday.July 15,2005 1:03PM

40105150bF.fm Page 38 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

NETTOYAGE DU Filtre

40105150bF.fm Page 39 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 39 Friday.July 15,2005 1:03PM

40105150bF.fm Page 39 Friday. July 15, 2005 1:03 PM

Blue spot 45.0^ 100.0 LPI

NETTOYAGE ET ENTRETIEN

40105150bF.fm Page 40 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 40 Friday.July 15,2005 1:03PM

40105150bF.fm Page 40 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

DIAGNOSTIC RAPIDE

40105150bF.fm Page 41 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 41 Friday.July 15,2005 1:03PM

40105150bF.fm Page 41 Friday. July 15, 2005 1:03 PM

Blue spot 45.0^ 100.0 LPI

40105150bF.fm Page 42 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 42 Friday.July 15,2005 1:03PM

40105150bF.fm Page 42 Friday. July 15, 2005 1:03 PM

Blue spot 45.0^ 100.0 LPI

40105150bF.fm Page 43 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 43 Friday.July 15,2005 1:03PM

40105150bF.fm Page 43 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

SERVICE APRÉS-VENTE

TRANSPORT/DéPLACEMENT

40105150bF.fm Page 44 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 44 Friday.July 15,2005 1:03PM

40105150bF.fm Page 44 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI
