WAE 85852 - Washing machine BAUKNECHT - Free user manual and instructions

Product type	Washing machine
Brand	Bauknecht
Model	WAE 85852
Width	600 mm
Height	825 mm
Depth	600 mm
Loading type	Front-loading (porthole)
Child safety	Yes, by porthole lock screw
Anti-unbalance system	Yes, automatic detection and correction
Leak protection	Hydraulic safety (safety hose)
Drain filter	Accessible, cleaning recommended 2-3 times per year
Drain pump	With removable filter
Detergent drawer	3 compartments (prewash, main wash, softener)
Liquid detergent accessory	Included, to be placed in the main compartment
Water inlet	Cold water only
Recommended water pressure	100-1000 kPa (1-10 bar)
Electrical connection	See rating plate inside the porthole
Porthole type	Double glazing or single depending on version
Adjustable feet	Yes, for leveling
Transport bolts	Mandatory removal before use
Packaging materials	Recyclable (plastic, polystyrene)

Frequently Asked Questions - WAE 85852 BAUKNECHT

How to install the Bauknecht WAE 85852 washing machine?

After removing the packaging and checking for damage, remove the transport bolts. Place the appliance on a flat, stable floor, adjust the feet to make it level. Connect the cold water inlet hose (pressure 100-1000 kPa) to the 3/4 inch tap. Connect the drain hose to the siphon or the edge of a sink. Plug the appliance into an earthed power socket.

How to remove the transport bolts?

The transport bolts are located at the back of the machine. They must be removed before first use to avoid damage. Follow the instructions in the manual to unscrew and remove them completely. Keep them for future transport.

Which detergent to use and how to dose?

Use a detergent suitable for the fabric type, color, and temperature. Follow the dosages indicated on the packaging according to the load and water hardness. For wool, use a special detergent. For liquid detergent, remove the colored accessory from the detergent drawer and place it in the main compartment. Do not exceed the 'Max' mark.

How to clean the drain filter?

Turn off and unplug the appliance. Open the filter cover using the colored accessory. Place a container under the filter. Unscrew slowly counterclockwise until water flows out. Wait for the water to drain, then remove the filter completely. Clean it and check that the pump impeller rotates freely. Reinsert and tighten until the stop (handle horizontal). Pour 1 liter of water into the detergent drawer to reactivate the economy system.

What to do in case of drainage problem?

If water does not drain, check that the drain hose is not bent or blocked. Clean the drain filter and ensure the pump is not stuck. If the spin speed indicator flashes or the digital display shows 'P' and 'F', drain manually via the filter. If the problem persists, contact After-Sales Service.

What to do in case of water inlet problem?

Check that the tap is fully open and the pressure is sufficient. Ensure the inlet hose is not bent or frozen. Clean the water inlet connection filters. If the 'Tap closed' indicator lights up or the display shows 'H' and 'F', the problem is detected. If the safety hose has a red indicator, replace it.

How to activate child safety?

The child safety is located inside the porthole. Turn the plastic screw using the rounded corner of the colored accessory or a coin. In vertical position, the porthole cannot be closed. In horizontal position, the porthole can be closed normally.

How to perform the first wash cycle?

Open the tap, close the porthole. Pour about 30 ml of detergent into the main compartment (II). Select a short cycle and start it. This cycle removes the manufacturer's test water.

How to maintain the detergent drawer?

Press the release lever located in the prewash compartment and remove the drawer. Remove the accessories (softener siphon and liquid accessory). Wash all parts under running water. Reassemble and reinsert the drawer into the machine.

What to do if the appliance vibrates during spin?

Check that the appliance is level and that all four feet are resting properly on the floor. Ensure that the transport bolts have been removed. An unbalanced load detection system may reduce speed if bulky items are washed. Add more clothes if necessary.

USER MANUAL WAE 85852 BAUKNECHT

Black-and-white photo collage showing a nurse in uniform sitting on a bed, a man and a child at a table, and a woman with a bensai tree in a room (no visible text or symbols)

Mode d'emploi

Black-and-white photo collage showing a woman in traditional attire sitting in a room, two men seated at a table with food, and a woman in a bokni tree on a small table (no visible text or symbols)

Mode d'emploi

4fr15151.fm Page 30 Thursday, January 30, 2003 10:54 AM

Three black-and-white photos showing people in a home setting, one seated with a turban, two sitting at a table with food and drinks, and one standing indoors near a bonsai tree (no visible text or symbols)

Black-and-white photo of three people in a modern living room, one seated with a sofa, two standing, and one writing at a table with a small biny tree (no visible text or symbols)

Mode d'emploi

4fr15151.fm Page 31 Thursday, January 30, 2003 10:54 AM

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 31 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 31 Thursday, January 30, 2003 10:54 AM

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 32 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 33 Thursday, January 30, 2003 10:54 AM

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 33 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 33 Thursday, January 30, 2003 10:54 AM

Description du lave-linge

Hublot

Top-down view of a circular mechanical component with internal cavity and mounting bracket (no visible text or symbols)

Circular object with internal dark structure and light streaks, no visible text or symbols

Sécurité enfants

Close-up of a hand holding a small mechanical component (no visible text or symbols)

INTELLIGENT DIALOGUE

Bauknecht

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 34 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 35 Thursday, January 30, 2003 10:54 AM

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 35 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 35 Thursday, January 30, 2003 10:54 AM

Close-up of a hand holding a small electronic device with an arrow pointing to it, labeled 'A' (no readable text or symbols beyond the label)

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 36 Thursday, January 30, 2003 10:54 AM

Close-up of a white plastic component with three vertical arrows pointing to features (no text or symbols visible)

Compartiment

• Assouplissant
• Amidon liquide

4fr15151.fm Page 37 Thursday, January 30, 2003 10:54 AM

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 37 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 37 Thursday, January 30, 2003 10:54 AM

Nettoyage du filtre

Close-up of a hand pressing down on a circular button (no text or symbols visible)

Hand holding a white cylindrical object with a circular opening, next to a wall (no text or symbols visible)

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 38 Thursday, January 30, 2003 10:54 AM

Close-up of a white appliance drawer with black arrows indicating flow or movement (no text or symbols)

Close-up of a metallic mechanical component with a cylindrical shaft and flange (no visible text or symbols)

Close-up of a metallic industrial valve or connector component (no visible text or symbols)

4fr15151.fm Page 39 Thursday, January 30, 2003 10:54 AM

Cyan process 75.0° 100.0 LPI

4fr15151.fm Page 39 Thursday, January 30, 2003 10:54 AM

4fr15151.fm Page 39 Thursday, January 30, 2003 10:54 AM

Guide Diagnostic rapide
