WAK Symphony 1465 - Washing machine BAUKNECHT - Free user manual and instructions

Product type	Washing machine
Brand	Bauknecht
Model	WAK Symphony 1465
Dimensions (W x H x D)	600 x 825 x 600 mm
Water pressure	100 - 1000 kPa (1 - 10 bar)
Water supply	Cold water only, 3/4" connection
Wash programs	Cotton, synthetics, delicates, wool, etc.
Child safety	Yes (screw lock on the door)
Safety systems	Hydrosafety, imbalance detection
Drain filter cleaning	Recommended 2 to 3 times per year
Detergent drawer cleaning	Wash under running water after unlocking
Door gasket cleaning	Damp cloth, check the folds
Water inlet filter	Clean regularly (depending on model)
Transit bolts	Must be removed before use
Included accessories	Detergent drawer, colored accessory for liquid detergent
Water hardness	Adjustable via reminder in the drawer (soft to very hard)

Frequently Asked Questions - WAK Symphony 1465 BAUKNECHT

What to do if the washing machine does not start?

Check that the plug is connected, that the socket works (test with a lamp), that the door is properly closed (child safety deactivated), and that a program is selected. Press the Start/Pause button.

How to clean the drain filter?

Turn off and unplug the appliance. Open the filter cover, place a container underneath, slowly unscrew the filter counterclockwise until water drains. Once water is drained, remove the filter completely, clean it and the cavity. Reinsert by screwing until it stops (handle horizontal), then pour 1 liter of water into the detergent drawer and close.

How to activate child safety?

Turn the plastic screw located inside the door using the colored accessory from the detergent drawer or a coin. Vertical slot = locked (door cannot close), horizontal slot = unlocked.

What to do in case of a water inlet error?

Check that the tap is fully open, that the water inlet hose is not kinked, that the filters in the connection are not clogged (clean them if necessary), and that the hose is not frozen. If the appliance is equipped with a safety hose and the red indicator appears, replace the hose with a new one.

What to do if water does not drain?

Check that the drain hose is not kinked or blocked, that the drain filter is not clogged (clean it as indicated), and that the water in the hose is not frozen. If the problem persists, run a drain program or contact after-sales service.

How to use the detergent drawer?

The drawer has three compartments: prewash (I), main wash (II) and fabric softener (III). Pour powder or liquid detergent into the appropriate compartments. For liquid detergent, remove the colored accessory and place it in compartment II. Do not exceed the Max mark for fabric softener.

What types of detergent to use?

Use only detergents suitable for automatic washing machines, depending on the fabric type (cotton, synthetics, wool) and water hardness. Follow the dosages indicated on the packaging. For wool, use a specific detergent. Avoid solvents and flammable products.

How to install the washing machine correctly?

Place the appliance on a flat and stable floor. Remove the transit bolts. Connect the water inlet hose (pressure 1-10 bar) and the drain hose. Plug into a grounded socket. Adjust the feet so that the appliance is level (using a spirit level).

What to do in case of excessive vibrations during spinning?

Check that the appliance is horizontal and that the four feet are adjusted to the same height. Make sure the transit bolts have been removed. If the problem persists, it could be an imbalance (large items): the appliance automatically reduces the spin speed, this is normal.

How to maintain the door gasket?

Clean the gasket regularly with a damp cloth. Check that no debris (coins, pins) gets lodged in the folds of the gasket, as this could damage the gasket or laundry.

USER MANUAL WAK Symphony 1465 BAUKNECHT

DÉTERGENT ET PRODUITS ADDITIFS

NETTOYAGE DU Filtre

VIDANGE DE L'EAU RÉSIDUELLÉ

NETTOYAGE ET ENTRETIEN

DIAGNOSTIC RAPIDE

SERVICE APRÈS-VENTE

ACCESSIONS

TRANSPORT/DEPLACEMENT

32

40105150bF.fm Page 32 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 32 Friday.July 15,2005 1:03PM

40105150bF.fm Page 32 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

AVANT D'UTILISER LE LAVE-LINGE

40105150bF.fm Page 33 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 33 Friday.July 15,2005 1:03PM

40105150bF.fm Page 33 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

PRECAUTIONS ET RECOMMANDATIONS GENÉRALES

1. Emballage

40105150bF.fm Page 34 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 34 Friday.July 15,2005 1:03PM

40105150bF.fm Page 34 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

DESCRIPTION DU LAVE-LINGE

40105150bF.fm Page 35 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 35 Friday.July 15,2005 1:03PM

40105150bF.fm Page 35 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

AVANT D'EFFECTUER LE PREMIER CYCLE DE LAVAGE

40105150bF.fm Page 36 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 36 Friday.July 15,2005 1:03PM

40105150bF.fm Page 36 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

DÉTERGENT ET PRODUITS ADDITIFS

40105150bF.fm Page 37 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 37 Friday. July 15, 2005 1:03 PM

40105150bF.fm Page 37 Friday. July 15, 2005 1:03 PM

Blue spot 45.0^ 100.0 LPI

40105150bF.fm Page 38 Friday, July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 38 Friday.July 15,2005 1:03PM

40105150bF.fm Page 38 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

NETTOYAGE DU Filtre

40105150bF.fm Page 39 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 39 Friday.July 15,2005 1:03PM

40105150bF.fm Page 39 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

NETTOYAGE ET ENTRETIEN

40105150bF.fm Page 40 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 40 Friday.July 15,2005 1:03PM

40105150bF.fm Page 40 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

DIAGNOSTIC RAPIDE

40105150bF.fm Page 41 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 41 Friday.July 15,2005 1:03PM

40105150bF.fm Page 41 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

40105150bF.fm Page 42 Friday. July 15, 2005 1:03 PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 42 Friday.July 15,2005 1:03PM

40105150bF.fm Page 42 Friday. July 15, 2005 1:03 PM

Blue spot 45.0^ 100.0 LPI

40105150bF.fm Page 43 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 43 Friday, July 15, 2005 1:03 PM

40105150bF.fm Page 43 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI

SERVICE APRÉS-VENTE

TRANSPORT/DéPLACEMENT

40105150bF.fm Page 44 Friday.July 15,2005 1:03PM

Red spot 45.0^100.0 LPI

40105150bF.fm Page 44 Friday.July 15,2005 1:03PM

40105150bF.fm Page 44 Friday.July 15,2005 1:03PM

Blue spot 45.0^100.0 LPI
