Micromat MC 1761 ED - Microwaves AEG-ELECTROLUX - Free user manual and instructions
Find the device manual for free Micromat MC 1761 ED AEG-ELECTROLUX in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Microwave |
| Brand | AEG-Electrolux |
| Model | Micromat MC 1761 ED |
| External dimensions (W x H x D) | 592 x 370 x 316 mm |
| Internal dimensions (W x H x D) | 285 x 202 x 298 mm |
| Capacity | 17 liters |
| Net weight | Approximately 15.5 kg |
| Power supply | 230 V ~ 50 Hz, single phase, 10 A min |
| Microwave consumption | 1.2 kW |
| Microwave power | 800 W max (5 levels: 800, 560, 400, 240, 80 W) |
| Microwave frequency | 2450 MHz |
| Turntable diameter | 272 mm (glass) |
| Interior lighting | 25 W / 240-250 V |
| Automatic programs | 12 programs (7 cooking, 5 defrost) |
| Special functions | Quick cooking, multi-sequence cooking, safety lock, 12/24 h clock |
| Included accessories | Turntable, drive support, 4 fixing screws |
| Cavity materials | Enamelled steel |
| Care and cleaning | Clean with a soft cloth and soapy water. Do not use abrasive or caustic cleaners. |
| Safety | Door lock, automatic stop when door open, child lock, overheat protection |
| Warranty | 24 months (France and Belgium according to conditions) |
| Repairability | Spare parts available from AEG-Electrolux authorized service center |
Frequently Asked Questions - Micromat MC 1761 ED AEG-ELECTROLUX
How to set the clock on the Micromat MC 1761 ED?
To set the clock, plug in the appliance and press STOP. Hold down the MICROWAVE POWER LEVEL button for 3 seconds to choose 12 or 24 h mode. Turn the rotary knob to set the hours, press the same button to go to minutes, then turn to set the minutes. Confirm by pressing START.
Which containers can I use in this microwave?
Use only microwave-safe containers: heat-resistant glass, metal-free porcelain, enameled ceramic, microwave-safe plastic, and absorbent paper. Avoid metals, lead crystal, and tightly sealed containers. Perform the water glass test if in doubt.
How to use the automatic cooking function?
Press the AUTOMATIC PROGRAMS button until the desired program is displayed (AC-1 to AC-7 for cooking, Ad-1 to Ad-5 for defrost). Turn the TIMER/WEIGHT knob to enter the food weight. Press START/QUICK to start. Follow the audible instructions (e.g., turn the food).
What to do if the microwave does not heat?
Check that the door is properly closed, the seals are clean, the fuse has not blown, and that the START/QUICK button has been pressed. If the problem persists, contact an AEG-Electrolux authorized service center.
How to clean the interior of the oven?
Unplug the appliance. Wipe up spills with a damp soft cloth after each use. For stubborn stains, use soapy water, then rinse with clean water. Never use abrasive or caustic cleaners. Clean the door seal and turntable regularly.
Can I use aluminum trays in this microwave?
Yes, under conditions: the tray must not exceed 4 cm depth, be at least 2/3 full, not touch the oven walls (min. 1 cm distance), and not be reused. Place it on an oven-safe dish. Avoid aluminum lids.
How to activate the child safety lock?
Press the STOP button and hold it for 3 seconds. The display shows a padlock symbol. To deactivate, repeat the same action.
What is the maximum power and how to set it?
The maximum power is 800 W. Press the MICROWAVE POWER LEVEL button several times to choose between 800, 560, 400, 240, or 80 W. In manual mode, set the time first, then the power, then start with START.
Why does water form inside the oven?
Water droplets on the walls are normal: they come from the humidity of heated food. This does not indicate a microwave leak. Simply wipe after use.
Where can I find spare parts or after-sales service?
Contact the AEG-Electrolux authorized after-sales service. In France, call 08 92 68 24 33 (€0.34/min) or write to ehp.consommateur@electrolux.fr. In Belgium, call 02.363.04.44. Have the model and serial number ready.
