USER MANUAL AP6 840 SOPHOS

SOPHOS Safety Instructions and Regulatory Compliance

Safety Instructions You can operate the access paint [AP] safely if you fallow the information in these Safety Instructions and on the appliance.

Do not reach into the appliance, There are dangerous cireuits inside the appliance that can cause death if you touch them

Damaged appliances must be returned t is forbiciden to open the hardware appliance or to change its components. Failure to comply with this rule results in the loss of warranty cover from Sophos:

Connect the device to a power sacket with a fully functional earth conductor Defective earth conductor connections do not camply with the requirements far safety and electromagnetic compatibilty. Check the power socket before connecting the hardware appliance.

‘The socket-autlet shall be installed near the equipment and shall be easily accessible.

Before you switch on the appliance make sure that your mains voltage complies with the supply voltage of the appliance. The connection data are shown on the name plate.

To disconnect the appliance completely take the power cable from the power socket Make sure that the power plug is freely accessible

Make sure that no one can trip over the power cable and that it cannot be damaged by objects.

Only connect system peripherals complying with the requirements for protective extra-low voltage accarding to UL/EN/IEC 62368-1

Only use parts and accessories validated by Saphos. Using non-approved parts and accessories may affect the functianing of the appliance and your safety.

The appliance produces heat. Ensure that there is sufficient air cireulatian to remove the heat.

1 Safety Instructions and Regulatory Compliance APG 840

*_Avoïd a permanent high level of air humidity and formation of condensation. Protect the appliance from humidity and chemicals. Safe use of the appliance is no longer possible if

+ the chassis is damaged + water penetrated the appliance

+ objects entered the appliance vie air opening + smoke comes out ofthe appliance

+ the power cable is damaged

+ it does not work properly

immediately turn off the appliance in the event of ane of the above problems, remove the power cable from the power socket and contact your customer service as soon as possible:

We expressly exelude any product liebility and warranty claims if the appliance is not operated according ta the instructions in these notes and to the notes attached to the appliance itself

Operating temperature range

Operating temp. 0-40°C Power source POE oniy S7Vdc, 0.6A (optional)

This product is intended to be supplied by a listed (certified) power supply. The output of PoE is rated 67Vdo, 0.6A minimum, Tma 40°C minimum. If you need further assistance, please contact the manufacturer, the UL file owner, or the brand owner for further information:

Safety Instructions and Regulatory Compliance AP 840 2

PoE-Injector Safety Information

Caution: The PüE injector is ta be connected only to PaE netwarks without rauting to the outside plant

+ The power cord must have regulatory agency approval for the specific country in which it is used (for example, UL, CSA VDE, GS, etc.)

+ The power cord must be a three-canductor type (two current carrying conductors; one ground conductar terminated on ane end by an IEC 60320 appliance coupler (far connection to the PoE-Injecton], and on the ather end by a plug containing a ground (earthing) contact]

+ The power cord must be razed for a minimum of 250 VAC RMS operation, with a minimum rated current capacity of 5 A (or a minimum wire gauge of 18 AWG (075 mm)

+ APOE-Ijector installed in Australia requires power cords with 8 minimum wire gauge of 16 AWG (1.0 mm)

The PoE-Injectar “Data In” and “Data & Power Out" ports are shielded RJ4S data sockets. They cannot be used as Plain Old Telephone Service (POTS) telephone sackets. Cannect RJ4S data connectors only to those sockets.

The AC wall socket-outlet must be near the PoE-Injector and easily accessible. You can remove AC power fram the POE-Injector by disconnecting the AC pawer cord from either the wall socket-outlet or the PoE-Injector appliance coupler.

The PoE-Injector ‘Data In" and “Date & Power Out’ interfaces are qualified as Safety Extra-Low Voltage (SELV) circuits according to IEC 62368-1. Connect these interfaces only ta SELV interfaces on other equipment.

8 Safety Instructions and Regulatory Compliance APG 840

Warnings * Connect the PoE-Injectar only to the IP device with which it was bought. Using the PoE-Injector with other IP devices can cause damage to the IP device

+ Read the installation instructions before connecting the PoE-Injector to its power source. + Follow basic electricity safety measures whenever connecting the PoE-Injector toits power source

+ Avaltage mismatch can cause equipment damage and may pose a fire hazard. the voltage indicated on the label is different from the power outlet voltage, do not connect the PoE-Injectar ta that power outlet: California Proposition 65 Warning Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov This product contains campanents that can cause exposure to substances known to the State af California to cause cancer and/or reprductive harm.

Safety Instructions and Regulatory Compliance AP 840

Sicherheitshinweise Sie konnen den Access Point (AP) sicher betreiben, wenn Sie die Informationen in diesen Sicherheitshinweisen befolgen

5 Safety Instructions and Regulatory Compliance APG 840

Safety Instructions and Regulatory Compliance AP 840 6

7 Safety Instructions and Regulatory Compliance APG 840

Safety Instructions and Regulatory Compliance AP 840

Ê Safety Instructions and Regulatory Compliance APG 840

Safety Instructions and Regulatory Compliance AP 840 10

Toute discardance de tension pourrait endammager l'équipement et causer un risque d'incendie. Si la tension indiquée sur la plaque d'identification est différente de celle indiquée sur la prise de courant, ne branchez ps l'injecteur POE dans cette prise.

un Safety Instructions and Regulatory Compliance APG 840

Regulatory Compliance

Manufacturers Federal Communication Commission Statements Note: The access paint Sophos AP6 840 is restricted to indoor use only.

CFR Title 47 Part 15 Subpart A—General $15.19 Statement

This device camplies with part 15 ofthe FCC Rules. Operation is subject to the following two conditians: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CFR Title 47 Part 15 Subpart A—General $15.21 Statement Any changes or modifications not expressiy approved by Sophos could void the users authority ta operate this equipment.

CFR Title 47 Part 15 Subpart B—Unintentional Radiators $15.105 Statement This equipment has been tested and found to comply with the limits for à Class B digital device, pursuant to Part 15 ofthe FC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentil installation. This equipment generates, uses and can radiate radio frequency energy and, if nat installed and used in accordance with the instructions, may cause hermful interference to radio communications. However, there is no guarantee that interference wil not aceur in a particular installation. this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged ta try to correct the interference by ane or more of the fallowing measures:

+ Reorient or relocate the receiving antenna

Increase the separation between the equipment and receiver.

+ Connect the equipment into an outlet on a cireuit different from that to which the receiver is cannected

* Cansult the dealer or an experienced radia/TV technician for help.

Safety Instructions and Regulatory Compliance AP 840 12

Publication Number: 443999 Rule Parts: 15E—Professional Installation Instructions

Sophos AP6 840 Installation personnel

This product is designed for specific applications and needs to be installed by qualified personnel who have RF and related knowledge. The general user shall not attempt to install or change the settings.

Installation location

This product shall be installed at a location where the radiating antenna can be kept 51.5 cm away from a nearby person under narmel operation conditions in order to meet regulatory RF exposure requirements.

Only use the antennes that are provided in the scope of supply, because they have been approved by the regulatory authorities. Non-approved antenna(s] may produce unwanted spurious emissians or excessive RF transmit power, which may lead to a violation of FCC/IC limits and is therefore prahibited

Installation procedure Please refer ta the user manual for details.

Please carefully select the installation position and make sure that the final output power does not exceed the limits set forth in relevant rules. The violation of those rules can lead to serious federal penalties

13 Safety Instructions and Regulatory Compliance APG 840

CFR Title 47 Part 1 Subpart I $1.1310 Radiofrequency Radiation Exposure Limits Statement

This equipment complies with FC radiation exposure limits set forth for an uncontralled enviranment as referenced in CFR Title 47 Part 1 Subpart | 11310.

‘The access point Saphos AP6 840 should be installed and aperated with a minimum distance of51.5 cm between the radiator and yaur body.

This transmitter must nat be co-located or operating in conjunction with any other antenna or transmitter.

ISED Canada Statements/Avis ISED Canada

RSS-GEN This device cantains licence-exempt transmitter(s)/receiver(s] that comply with Innovation, Science and Econamic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference.

2. This device must accept any interference, including interference that may cause undesired operation of the device:

L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'innovation, Sciences et Dévelappement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes

1. L'appareil ne doit pas produire de brouillage:

Safety Instructions and Regulatory Compliance AP 840 14

Operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.

The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470- 5725 MHz shall be such that the equipment still complies with the ei.rp. limit;

The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.ir.p. limits specified for paint-to-point and non- point-to-point operation as appropriate; and

The worst-case tit angle(s) necessary to remain compliant with the e:irp. elevation mask requirement set forth in Section 6.2.2(3) shall be clearly indicated.

Users should also be advised that high-pawser radars are allocated as primary users (ie. priority users] of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

La bande 5150-5250 MHz est réservée uniquement pour une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux

De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sant désignés utilisateurs principaux (c.-à-d, qu'ils ont la priorité] pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL

15 Safety Instructions and Regulatory Compliance APG 840

Radiation Exposure Statement

This equipment complies with IC radiation exposure limits set forth for an uncontrolled enviranment. This equipment should be installed and operated with minimum distance 30.5 cm between the radiator and your body.

Déclaration d'exposition aux radiations

Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 30.5 cm de distance entre la source de rayonnement et votre corps.

Class B Notice for Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. CAN ICES-003 (BJ/NMB-003(8)

Safety Instructions and Regulatory Compliance AP 840 16

Simplified EU/UK Declarations of Conformity

CHacroawyoro Sophos Ltd. geknapupa, ue Toau Tun pagnoc-opèxenne AP6 840 e 8 cxorsercreue c Aupekrusa 2014/53/EC. LianocrHuaT rekcr Ha EC geknapauuaTa 3a ceoT8eTcTeue MOXe ja Ce HaMep4 Ha CneaHua HHTepHeT agpec: https://docs.sophos.com/ nsg/other/RegulatoryCompliance/en-us/index html

Me tnv rapoboa o/n Sophos Ltd, énkdvet ét 0 paëtoforAtopéç AP6 840 mAnpoi rnv oënyia 2014/S3/EE. To nAñpec kelpevo tn 6Awonc ouupéppuonc EE Btarietat otnv ak6AoUEN totookiSa oto &taëlktuo: https://docs.sophas.com/nsg/ather/RegulatoryCampliance/en- us/index html

Hereby, Sophos Ltd. declares that the radio equipment AP6 840 is in compliance with Directive 2014/S8/EU. The full text of the EU declaration of canformity is available at the following interet address: https:/docs.sophos.com/nsg/other/RegulatoryCompliance/en-us/index. html

17 Safety Instructions and Regulatory Compliance APG 840

Hereby, Sophos Ltd. declares that the radio equipment AP 840 is in compliance with the Radio Equipment Regulations 2017 (S:1. 2017/1206) The fulltext of the UK declaration of conformity is available at the fallowing interet address: https://docs. sophos.com/nsg/ather/ RegulatoryCompliance/en-us/index html

Porla presente, Saphos Ltd. declara que el tipo de equipo radioeléctrico AP6 840 es conforme cn la Directiva 2014/S3/UE. El texto completa de la declaraciôn UE de conformidad

Safety Instructions and Regulatory Compliance AP 840 18

19 Safety Instructions and Regulatory Compliance APG 840

Hérmed frsäkrar Sophos Ltd. att denna typ av radioutrustning AP6 840 ôverensstämmer med direktiv 2014/53/EU. Den fullständiga texten til EU-forsäkran om ôverensstämmelse finns

pé fôllande webbadress: https://docs.saphos.com/nsg/other/RegulatoryCompliance/en-us/ index html

Indoor Use Statement Caution: The Sophos access paint AP6 840 aperates in the frequency bands 5.150-5 350GHz This product is restricted to indoor apertian only.

Frequency Ranges and Transmit Power

AP6 840 21400-24835 GHz 19.96 d8m 5150-5250 GHz 2295 d8m 5250-5.350 GHz 2293 d8m 5500-5700 GHz 29.29 dëm

Safety Instructions and Regulatory Compliance AP 840 20

Caution: This product complies with maximum permissible exposure limits &s set forth by the European Narm EN 62311. The Sophos access point should be installed and operated with minimum distance of 20 cm between the radiator and your body.

Member states with restrictions pursuant to Article 10(10) of

Directive 2014/53/EU AT BE BG HR cv cz DK EE FI FR DE EL HU IE ü LV ir Lu MT NL PL PT RO sk si ES SE No 1 n cH TR UKINI)

Déclaration norme MPE Attention ! Ce produit est confarme aux limites d'exposition maximales admissibles stipulées dans la norme européenne EN 62311. Le point d'accès Sophos doit être installé et utilisé avec une distance minimale de 20 em entre le radiateur et votre corps

Safety Instructions and Regulatory Compliance AP6 840 22

Safety Instructions and Regulatory Compliance APG 840
