FC8146/01 - Vacuum Cleaner PHILIPS - Free user manual and instructions
Find the device manual for free FC8146/01 PHILIPS in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Bagless Canister Vacuum Cleaner |
| Brand | PHILIPS |
| Model | FC8146/01 |
| Suction Power | Electronically adjustable (control on the appliance and on the handle) |
| Power Supply | 220-240 V ~ (check according to country) |
| Power Cord | With automatic cord rewinder |
| Dust Container Capacity | Approx. 1.5 L (estimate) |
| Filters | Washable HEPA filter (compartment and outlet), foam filter, motor protection filter |
| Noise Level | 82 dB(A) |
| Included Accessories | Standard brush (carpets/hard floors), crevice tool, small brush, hard floor brush (depending on model), telescopic tube, hose with handle and slide button |
| Tube Length | Adjustable (telescopic) |
| Filtration System | HEPA 12 or equivalent (washable) |
| Full Container Indicator | Yes, indicator changes color |
| Automatic Shut-off | Not specified |
| Weight | Approx. 4.5 kg (estimate) |
| Dimensions (L x W x H) | Approx. 40 x 25 x 30 cm (estimate) |
| Replacement Filter References | Outlet HEPA filter: FC8070; Compartment filter (HEPA + foam): FC8071 |
| Country of Manufacture | Not specified |
Frequently Asked Questions - FC8146/01 PHILIPS
How to empty the dust container?
To empty the container, first unplug the appliance. Open the lid, remove the container by pulling its handle, then lower the bottom cover latch over a trash can. Empty the dust, then close the bottom cover until it clicks. Reinsert the container into the appliance and close the lid.
How to clean the HEPA filters?
The HEPA filters (compartment and outlet) can be cleaned under warm water. Remove them, rinse the pleated side holding the filter so that water flows parallel to the pleats, then turn 180° and repeat. Do not brush them. Shake off excess water and let them dry completely before reinstalling.
The full container indicator changes color, what to do?
This indicator tells you it is time to empty the dust container and clean the filter cone. Follow the emptying instructions (see question 1) and clean the cone by tapping it against a trash can.
Suction is weak, what to check?
First check if the dust container is not full. Then clean or replace the filters. Make sure the power slide button on the handle is in the closed position and the electronic control is set to a high level. Finally, check that the nozzle, tube or hose is not blocked; if so, detach the part and blow air in the opposite direction.
How to adjust the suction power?
You can adjust the power in two ways: either with the slide button on the hose handle, or with the electronic control on the appliance itself. Use lower power for curtains or delicate fabrics, and higher power for carpets.
Can I use the vacuum cleaner to vacuum water?
No, it is dangerous. Never vacuum water, liquids, flammable substances, or hot ashes. This could damage the appliance and cause electric shock.
How to replace the HEPA filters?
Replace the HEPA filters every six months. For the compartment filter, open the latch, remove the old filter and insert the new one by snapping the tabs. For the outlet filter, remove the grille, replace the filter, then put back the grille aligning the tabs and pressing until it clicks.
Where to find replacement filters?
Replacement filters are available under the following references: Outlet HEPA filter: FC8070; Compartment filter (HEPA + foam): FC8071. You can order them on the Philips website or from an authorized dealer.
How to store the vacuum cleaner after use?
Turn off and unplug the appliance. Press the cord rewinding button to store the cord. Place the vacuum cleaner in an upright position, insert the nozzle clip into the parking insert, and adjust the telescopic tube to its shortest length for optimal stability.
The appliance does not turn on, what to do?
First check that the plug is properly connected and the wall socket works. Make sure the cord is not damaged. If nothing happens, contact Philips consumer service or an authorized center.
