Product type	Micro hi-fi system
Brand	Panasonic
Model	HC212EG-K
Dimensions (W x H x D)	400 mm x 197 mm x 107 mm
Weight	1.9 kg
Power supply	AC 220-240 V, 50 Hz
Power consumption (operation)	14 W
Power consumption (standby) (Bluetooth OFF)	0.2 W
RMS output power	2 x 10 W (8 Ω, 1 kHz, 10% THD)
Speakers	2 × 8 cm full-range speaker
Audio sources	CD, USB, Bluetooth, FM, DAB/DAB+
Supported formats	CD-DA, MP3 (CD/USB)
Bluetooth version	4.2
USB port	DC 5 V / 500 mA, USB 2.0
FM range	87.5 - 108 MHz
DAB+ range	Band III (174,928 - 239,200 MHz)
Equalizer	Presets (Heavy, Soft, Clear, Vocal, Flat) and customizable MY SOUND
Timers	Sleep timer, play timer (alarm)
Playback functions	Random playback, repeat, search, skip
Care and cleaning	Soft, dry cloth. Do not use alcohol, thinner, or benzene.
Safety	Do not expose to rain, moisture, or flames. Do not open the unit. Use recommended accessories.
Spare parts and repairability	No user-serviceable parts. Contact a qualified technician or authorized dealer.
Included accessories	Power cord, indoor DAB antenna, remote control (battery included)
Remote control code	Adjustable: REMOTE 1 or REMOTE 2

Frequently Asked Questions - HC212EG-K PANASONIC

How to pair a Bluetooth device with the system?

Select the BLUETOOTH source on the unit. Press PLAY MENU to choose PAIRING or press and hold 8 - PAIRING on the main unit until PAIRING appears. On your device, select SC-HC212 in the Bluetooth list. If a code is requested, enter 0000.

How to preset FM stations?

Press RADIO to select FM. For automatic presetting, press PLAY MENU, choose A. PRESET, then select LOWEST or CURRENT and confirm. For manual presetting, select TUNE MODE > MANUAL, tune to a station, press OK, then choose a preset number.

How to set the alarm timer?

Make sure the clock is set. Press SETUP repeatedly to select TIMER ADJ. Set the start and end times, then the source (CD, USB, DAB+, or FM). To activate, select TIMER SET > SET. The unit must be in standby for the timer to work.

What to do if sound is distorted or missing?

Check the volume. If the problem persists, turn off the unit, identify the cause (excessive volume, hot environment) and turn it back on. Make sure the speakers are not obstructed and that the cables are away from sources of interference.

How to clean the unit?

Unplug the power cord. Use a soft, dry cloth. Never use alcohol, paint thinner, or benzene. If you use a chemically impregnated cloth, read the instructions carefully.

Can I play MP3 files from a USB flash drive?

Yes, connect the USB flash drive to the front port. Select the USB source with the USB/CD button. The unit plays MP3 files (.mp3 extension) from USB devices up to 32 GB in FAT12/16/32.

How to activate auto power off?

Press SETUP repeatedly until AUTO OFF. Choose ON to activate standby after 20 minutes without sound. To deactivate, select OFF. This function does not apply to radio or when Bluetooth is connected.

The remote control does not work. What to do?

Check that the battery is correctly installed with the correct polarity. Point the remote at the sensor within 7 m and at an angle of about 30°. If the problem persists, change the remote control code (see manual).

How to set the clock?

Press SETUP repeatedly to select CLOCK. Use the , buttons to set the time (24h cycle) and press OK. For automatic update via DAB, select AUTO CLOCK ADJ in the DAB menu.

What does the display 'F77' or 'F703' mean?

F77: Unplug the power cord and contact your dealer. F703: Check the Bluetooth connection, disconnect the device, turn the system off and on. If the error persists, consult a technician.

USER MANUAL HC212EG-K PANASONIC

Conservare Anything for the future.

10 W per channel (8 Ω), 1 kHz, 10% THD

RMS-Gesamtleistung

20 W

Tunerteil

Borned'antenne 75Ω (asymétriques)

Section DAB

Mémoires DAB 20 canaux

Condition minimum -98 dBm

Antenne externe DAB

32 kHz, 44,1 kHz, 48 kHz

Taille du mot audio 16 bits

m = 311

To set the code to "REMOTE 1"

Aansluiting F-Connector (75Ω)

Disc

m = 311 ;
