F854M21WR - Washer dryer DARTY - Free user manual and instructions
Find the device manual for free F854M21WR DARTY in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Washer-dryer |
| Brand | Darty |
| Model | F854M21WR |
| Washing capacity | 8 kg |
| Drying capacity | 5 kg |
| Dimensions (W x D x H) | 600 x 550 x 850 mm |
| Depth with door open | 1005 mm |
| Net weight | 65 kg |
| Power supply | 220-240 V~, 50 Hz |
| Water pressure | 50 - 800 kPa |
| Maximum spin speed | 1400 rpm |
| Number of programs | 10 washing programs + 3 drying programs |
| Main programs | Cotton, Eco 40-60, Mix, Synthetics, White Universal, Quick 30 min, Rinse+Spin, Dry cycle, Low temp., Timer |
| Options | Prewash, Delay End, Child Lock, Drum Clean |
| Smart functions | LG ThinQ (Wi-Fi), Sound Diagnosis |
| Energy class | Not specified (ref. EU regulation 2019/2023) |
| Water consumption (Eco 40-60 cycle full load) | 59 L |
| Energy consumption (Eco 40-60 cycle full load) | 1.180 kWh |
| Program duration Eco 40-60 (full load) | 3h38min |
| Maintenance and cleaning | Drum clean, drain pump filter, water inlet filter, detergent drawer |
| Spare parts available | Yes, spare parts for 10 years (EU regulation 2019/2023) |
| Safety | Child lock, door safety, leak protection |
| Included accessories | Water inlet hose, wrench, transport bolt caps, anti-slip pads, drain hose elbow bracket |
Frequently Asked Questions - F854M21WR DARTY
How to install the Darty F854M21WR washer-dryer correctly?
Ensure the appliance is installed on a firm, level floor. Remove the transport bolts using the provided wrench. Adjust the feet so it is perfectly level. Connect the water inlet hose (pressure between 50 and 800 kPa) and the drain hose (do not exceed 100 cm from the floor). Plug the power cord into a grounded outlet.
What washing programs are available on this model?
Programs include: Cotton (up to 95°C), Eco 40-60, Mix 40°C, Synthetics, White Universal, Quick 30 min, Rinse+Spin, as well as drying programs: Dry cycle, Low temp., and Timer.
What to do if error code 'IE' appears?
The IE code indicates a water supply problem. Check that the water inlet tap is fully open, the hose is not kinked, and the inlet filter is not clogged. Clean the filter if necessary.
How to clean the drain pump filter?
Unplug the appliance and open the hatch at the bottom right. Pull out the drain hose, remove the cap, then unscrew the filter. Clean it under warm water and remove debris. Replace the filter and screw the cap back on.
Why does the drum not open after a cycle?
The door remains locked for safety until the internal temperature drops. Wait for the lock icon to turn off. If the problem persists, check that the program is fully finished or contact customer service.
What is the maximum drying capacity?
The drying capacity is 5 kg. For efficient drying, do not load more than this amount, and for a wash followed by drying, reduce the wash load to a maximum of 5 kg.
How to use the 'Drum Clean' function?
Empty the drum, add a descaling powder to the main compartment, then press the Delay End and Prewash buttons simultaneously for 3 seconds. Then press Start/Pause. Leave the door open after the cycle to dry the inside.
What to do if the appliance does not drain water?
Check that the drain hose is not kinked or blocked. Clean the drain pump filter. Make sure the end of the hose is not more than 1.2 m above the floor.
How to activate child lock?
Press the Spin and Temperature buttons simultaneously for 3 seconds. 'CL' appears on the screen. To deactivate, repeat the same procedure.
Where to find spare parts for this model?
Spare parts are available from the LG Electronics service center. Refer to the warranty card or visit www.lg.com. According to EU regulation 2019/2023, parts are available for 10 years.
User questions about F854M21WR DARTY
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Washer dryer in PDF format for free! Find your manual F854M21WR - DARTY and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. F854M21WR by DARTY.
USER MANUAL F854M21WR DARTY
MANUEL DU PROPRIÉTAIRE
LAVE-LINGE
Smart Diagnosis (Diagnostic intelligent) 42
MAINTENANCE
- Charge minimale: 1/3 charge.
