DO9173J - Citrus juicers DOMO - Free user manual and instructions

Product Type	Juice press
Brand	DOMO
Model	DO9173J
Housing Material	Stainless steel
Power Supply	Mains, 220-240 V, 50/60 Hz
Anti-drip Function	Yes, swivel spout with anti-drip system
Pressing Cone	Included, adaptable to different fruits
Strainer	Included, filters pulp
Press Mould	Included, with ergonomic handle
Collecting Cup	Included, collects juice
Cleaning	Removable parts washable in warm soapy water; wipe housing with a dry cloth
Safety	Do not immerse body, use on solid dry surface, do not use with external timer
Warranty	2 years
Spare Parts	Available on DOMO webshop (http://webshop.domo-elektro.be)
Usage	Domestic

Frequently Asked Questions - DO9173J DOMO

How to use the juice press DO9173J?

Unwind the cord and plug in. Place a glass under the spout. Cut the fruit in half. Lower the spout, lift the handle, place the fruit on the cone and press. Press for about 15 seconds, then let it rest for 15 seconds. Raise the spout before removing the glass.

How to clean the parts of the juice press?

Unplug the appliance. Lift the handle, remove the press mould, strainer and cone. Rinse under running water. Remove the collecting cup. Wash all removable parts in warm water with a mild detergent. Wipe the housing with a dry cloth. Never immerse the housing.

What to do if the appliance does not work when I press on the cone?

Check that the cord is properly plugged in and that the voltage matches the mains. Make sure the appliance is correctly assembled. If the problem persists, contact your distributor or after-sales service.

How to avoid drips after removing the glass?

Use the anti-drip system: before removing the glass, click the spout upward. This prevents dripping.

Can I press fruits with the skin on?

Yes, simply cut the fruit in half. The skin can remain, but make sure the fruit is clean. The strainer will filter out pulp and seeds.

How long should I press a fruit?

Press for about 15 seconds, then let it rest for 15 seconds. This ensures good yield without overheating the appliance.

What to do if the power cord is damaged?

The cord must be replaced by the manufacturer, its after-sales service, or a qualified person to avoid any risk of accident. Do not use the appliance until the cord is repaired.

Where can I buy spare parts for the DO9173J?

Domo accessories and spare parts are available online on the DOMO webshop (http://webshop.domo-elektro.be) or at the store where you purchased the appliance.

Does the appliance heat up normally during use?

Slight warming is normal. However, if the appliance becomes very hot, stop it and contact after-sales service. Respect the 15-second pauses between each fruit.

What is the warranty for the juice press DO9173J?

The appliance has a warranty of 2 years from the date of purchase, covering manufacturing defects. Keep your receipt. The warranty does not cover damage due to misuse or normal wear.

USER MANUAL DO9173J DOMO

Exterior view of a stainless steel coffee maker with a black handle and white base (no visible text or symbols)

GARANTIEVOORWAARDEN

CONDITIONS DE GARANTIE

This appliance has a two year warranty period. During this period the manufacturer is responsible for any failures that are the direct result of construction failure. When these failures occur the appliance will be repaired or replaced if necessary. The warranty will not be valid when the damage to the appliance is caused by wrong use, not following the instructions or repairs executed by a third party. The guarantee is issued with the original till receipt. All parts, which are subject to wear, are excluded from the warranty.

If your device breaks down within the 2-year warranty period, you can return the device together with your receipt to the shop where you purchased it.

CONDICIONES DE GARANTÍA

RECYCLAGE-INFORMATIE

Recycling symbol icon with three chasing arrows forming a triangle (no text or labels)

RECYCLING INFORMATIONEN

RECYCLING INFORMATION

This symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it must be brought to the applicable collection point for recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. The packaging is recyclable. Please treat the packaging ecologically.

Warning symbol and recycling icon with crossed-out bins and recycling symbol

INFORMACE O RECYKLACI ODPADU

From now on, accessories and parts of Domo appliances can also be ordered online from the Domo webshop*:

http://webshop.domo-elektro.be

You can reach the webshop through the Domo website as well: www.domo-elektro.be. The accessories and parts can also still be obtained at the store where you bought the appliance.

CZ

If the power supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard.

Labeled diagram of a stainless steel coffee maker with numbered parts for identification.

from www.vand ④ ⑤ ⑥ ⑦

REINIGING VOOR HET EERSTE GEBRUIK

from www.vande

PROBLEEMOPLOSSING

Labeled diagram of a stainless steel coffee maker with numbered parts for identification.

from www.vand ④ ⑤ ⑥ ⑦

NETTOYAGE PREMIÈRE UTILISATION

ed from why. under

PROBLÈME:

red from why. van de

PROBLEMBESEITIGUNG

This appliance may be used by children from the age of 16 and up, and also by persons with a physical or sensory limitation, as well as mentally limited persons or persons with a lack of experience and knowledge. But only on the condition that these persons have received the necessary instructions on how to use this appliance in a safe way and know the dangers that can occur by using this appliance.

Children cannot be allowed to play with the appliance.

Maintenance and cleaning of the appliance may not be done by children, unless they are older than 16 years old and are under supervision.

Keep the appliance out of reach of children younger than 16 years old.

This appliance is suitable to be used in a household environment and in similar surroundings such as:

• Kitchen for personnel of shops, offices or other similar professional surroundings

• Farms

• Hotel or motel rooms and other surroundings with a residential character

• Guest rooms or similar

Attention: This appliance cannot be used with an external timer or a separate remote control.

• Read all instructions before use.
• Before use, check if the voltage stated on the appliance corresponds with the voltage of the power net at your home.
• Do not let the cord hang on a hot surface or on the edge of a table or counter top.
• Never use the appliance when the cord or plug is damaged, after malfunction or when the appliance itself is damaged. In that case, take the appliance to the nearest qualified service center for check-up and repair.
• Close supervision is necessary when the appliance is used near or by children.
• The use of accessories that are not recommended or sold by the manufacturer can cause fire, electrical shock or injuries.
• Unplug the appliance when it is not in use, before assembling or disassembling any parts and before cleaning the appliance. Never

unplug by pulling the cord.

• Do not leave a working appliance unattended.
• Never place this appliance near a gas stove or electrical stove or in a place where it may come into contact with a warm appliance.
• Do not use the appliance outdoors.
• Only use the appliance for its intended use.
• Always use the appliance on a steady, dry and level surface.
• Only use the appliance for domestic use. The manufacturer can not be held responsible for accidents that result from improper use of the appliance or not following the instructions described in this manual.
• All repairs should be carried out by the manufacturer or its aftersales service.
• Never immerse the appliance, the cord or the plug in water or any other liquid.
• Make sure that children do not touch the cord or appliance.
• Keep the cord away from sharp edges and hot parts or other heat sources.
• Before use, remove all packaging materials and any promotional stickers.

COMPONENTS

1. Handle with soft grip
2. Mould
3. Juice outlet with anti-drip system
4. Head
5. Sieve
6. Dish
7. Stainless steel body

Labeled diagram of a coffee maker with numbered parts for identification

from www.vand ④ ⑤ ⑥ ⑦

CLEANING PRIOR TO FIRST USE

Prior to using the appliance, it is recommended that the parts be washed first in order to remove any residues of the production process

USE

1. Unwind the electrical cord and plug in the unit.
2. Place a glass or bowl under the juice outlet for the juice.
3. Cut the fruit in the centre.
4. Press down the juice outlet for opening and the juice can flow out.
5. Raise the handle with the mould.
6. Place the fruit on the head and press it down.
7. Press for 15 sec. than let the unit rest for 15 sec.
8. Click the juice outlet up before removing the glass. Now the drips can't flow out anymore.

CLEANING

• When the operation has finished, unplug the unit.
• Raise the handle and push the mould out of the handle via the recess provided. Remove the sieve and the press cone as well.
  • Clean the parts under running water.
• Remove the dish.
• Clean the mould, the sieve and the dish in warm water with a mild detergent.
  • Clean the outside of the unit with a soft dry cloth.
  • Never immerse the unit in water.

Follow the next steps to re-install the juicer:

1. Put the mould in the handle.
2. Put the head in the sieve and put them together in the dish.
3. Put these components completely in the juicer with a diagonal movement.

Close-up of a kitchen mixer being poured into a pan, with a hand holding the lid (no visible text or symbols)

PROBLEM SHOOTING

When problems occur with the unit check below problems and their solutions. If the problem isn't solved, get in contact with the distributor or his after sales service.

PROBLEM :

The unit doesn't operate when pressing the head.

PROBABLE CAUSES:

1. The plug isn't properly plugged in.
2. The voltage of the unit doesn't correspond with the voltage at your home.
3. The unit isn't correctly assembled.

SOLUTIONS

1. Plug in the plug.
2. Check the voltage.
3. Disassemble and reassemble the unit.

Get in contact with the distributor or his after sales service.

PRECAUCIONES IMPORTANTES

Labeled diagram of a coffee maker with numbered parts for identification

from kww.vam ④ ⑤ ⑥ ⑦

LIMPIAR ANTES DEL PRIMER USO

Close-up of a kitchen mixer with a grater being poured into the air (no visible text or symbols)

ed from w. y. vande

PROBLEM:

Diagram of a stainless steel coffee maker with numbered parts labeled 1, 2, and 3.

from www.vand ④ ⑤ ⑥ ⑦

POUŽITIE

1. Rozviňte celý prívodný kábel a zapojte prístroj do el. siete
2. Pod výlevku postavte dostatočne vel'kú nádobu.
3. Prekrojte citrusy na polovice.
4. Výlevku zatlačte smerom dole, aby sa otvorila a šťava tak mohla vytekat'.
5. Zdvihnite páku s prítlačnou hlavou.
6. Na lisovacie hlavu namáčkněte polku ovocia a pomocou páky vylisujte.
7. Vždy tlačte a lisujte striedavo 15 sekúnd a 15 sekúnd nechajte odpočinút'.
8. Na konci lisovania zdvihnite výlevku hore, tým ju uzavrite a šťava už nebude kvapkat'. Plný pohár si môžete odobrat'.

ČISTENIE

Close-up of a kitchen mixer with a grater being poured into it (no visible text or symbols)

PROBLEM:

QR code image containing encoded data, no visible human-readable text
