Brand	SAMSUNG
Model	C139ST (also C139STB, C139STT, C139STF)
Product type	Combination microwave oven with grill and convection
Exterior dimensions (W x H x D)	556 x 557 x 324 mm
Interior dimensions (W x H x D)	369 x 391.7 x 252 mm
Oven capacity	37 liters
Net weight	Approximately 24 kg
Shipping weight	Approximately 30 kg
Power supply	230 V ~ 50 Hz AC
Maximum power consumption	3100 W
Microwave power	1400 W (output: 100 to 900 W, 6 levels)
Grill power	1300 W
Convection power	1700 W
Operating frequency	2450 MHz
Cooking functions	Microwave, grill, convection, combined (microwave+grill, microwave+convection), auto defrost, auto cook, auto reheat, kid/snack meal, cafeteria, +30s, stand time, preheat
Included accessories	Turntable, turntable ring, coupler, upper and lower rack, square wire rack, square metal tray, supports, rotisserie spit (depending on model), glass casserole dish, crisp plate (depending on model), multi-spit
Display	Digital display with language selection
Controls	Rotary knob, touch keys, turntable on/off button
Safety	Child lock, auto shut-off in case of overheating, door safety
Cleaning and maintenance	Clean with a soft sponge and soapy water; turntable is dishwasher safe; avoid abrasive products
Repairability	Repairs only by a SAMSUNG authorized technician; do not disassemble the oven
General information	Warranty included (see terms); consumer service: 0825 65 65 65; website: www.samsung.fr

Frequently Asked Questions - C139ST - INTRODUCTION SAMSUNG

How to use the auto defrost function?

Turn the knob to the auto defrost symbol. Select the food type by pressing the Select button, then set the weight with the rotary control. Press Start. Halfway through, turn the food over when the oven beeps.

Can I use metal utensils in the microwave?

No, metal utensils can cause sparks and damage the oven. Use glass, ceramic, or microwave-safe plastic dishes.

What to do if the oven does not heat?

Check that the door is properly closed, the cooking time is set, and the Start button has been pressed. Make sure the electrical circuit is not overloaded. If the problem persists, contact customer service.

How to set the oven clock?

Press the Clock button once for 12h format, twice for 24h. Turn the rotary control to set the hours, press Clock again, set the minutes, then press Clock to confirm.

What accessories are included with the oven?

The oven comes with a turntable, turntable ring, coupler, upper and lower rack, square wire rack, square metal tray, supports, and depending on the model: a rotisserie spit, glass casserole dish, crisp plate, and multi-spit.

How to clean the inside of the oven?

Clean with a soft sponge and soapy water. For odors, heat a cup of water with lemon juice for 10 minutes at maximum power. The turntable is dishwasher safe.

How to use the crisp plate?

Preheat the plate in combined (grill or convection) mode for 3 to 5 minutes. Place food on the hot plate. Do not use metal utensils. Clean with hot water and mild detergent.

Can I grill without microwave?

Yes, turn the knob to the grill symbol, set the time and press Start. Use the upper rack for best results.

What does the 'E3' message on the display mean?

The 'E3' message indicates overheating inside the cooking compartment. Let the oven cool down, then press the Stop button to reset.

The oven clicks during defrosting, is this normal?

Yes, it is normal. The clicks are due to changes in electrical power. No concern.

USER MANUAL C139ST - INTRODUCTION SAMSUNG

Specifications techniques. 45

(250°C (temperature)

Specifications techniques
