KYOCERA 1030 & FS-1030D,MV - Laser printer

1030 & FS-1030D,MV - Laser printer KYOCERA - Free user manual and instructions

Find the device manual for free 1030 & FS-1030D,MV KYOCERA in PDF.

📄 449 pages English EN ⬇ Download 💬 AI Question ❓ 13 questions ⚙️ Specs
Notice KYOCERA 1030 & FS-1030D,MV - page 20
20 / 449
View the manual : Français FR English EN
Pick your language and provide your email: we'll send you a specifically translated version.
Printing TechnologyElectrophotographic Laser (ECOSYS)
Single-Sided A4 Print Speed22 pages/minute
Double-Sided Print Speed11 pages/minute
Print Resolution1,200 dpi
Processor266 MHz
Standard RAM Memory32 MB
Maximum RAM Memory288 MB
Automatic DuplexStandard Integrated
Main Paper Tray250 sheets
Manual Feeder50 sheets
Output Tray250 sheets
Standard ConnectivityUSB 2.0 + Bidirectional Parallel Port
Network Connectivity (MV version)Ethernet 10/100 Base TX
Maximum Monthly Volume20,000 pages
Toner Life7,200 pages
Drum/Developer/Fuser Life100,000 pages
Warm-Up Time15 seconds
First Page OutLess than 10 seconds
Weight10.5 kg
Print LanguagePRESCRIBE

Frequently Asked Questions - 1030 & FS-1030D,MV KYOCERA

What is the print speed of the KYOCERA FS-1030D?
The FS-1030D prints at 22 pages per minute in simplex mode on A4 format. In automatic duplex mode, the speed drops to 11 pages per minute. These performances make it a suitable personal laser printer for intensive office use.
Is automatic duplex printing available?
Yes, automatic duplex is standardly integrated on the FS-1030D, without additional accessories. This allows printing on both sides without manually turning the sheets. This function reduces paper consumption by half.
What is the paper tray capacity of the FS-1030D?
The main tray holds 250 sheets and the manual feeder accommodates an additional 50 sheets. By adding an optional cassette, the total capacity can reach 550 sheets. The output tray holds up to 250 printed sheets.
Which toner should be used for the KYOCERA FS-1030D?
The FS-1030D uses an ECOSYS toner cartridge with a lifespan of 7,200 pages. It is recommended to use genuine KYOCERA consumables to maintain print quality and warranty. The exact reference is available on the official KYOCERA website.
What is the drum lifespan on the FS-1030D?
Thanks to ECOSYS technology, the drum, developer, and fuser are designed to last up to 100,000 pages. These long-life components significantly reduce the total cost of ownership. Only the toner cartridge requires frequent replacement.
What is the difference between the FS-1030D and the FS-1030D/MV?
The MV version integrates an Ethernet 10/100 Base TX network card for direct connection to the company’s local network. The standard version (FS-1030D) only offers a USB 2.0 port and a bidirectional parallel port. To share the standard printer on a network, an external print server is necessary.
Can the memory of the KYOCERA FS-1030D be increased?
The FS-1030D comes with 32 MB of RAM as standard. This memory is expandable up to 288 MB via optional memory modules. Adding memory is recommended for large documents or complex high-resolution printing.
What to do in case of a paper jam on the FS-1030D?
Open the front cover and gently remove the jammed paper without tearing it. Ensure the tray is not overloaded and that the paper used is suitable for the printer. Repeated jams may indicate dirty drive rollers that need cleaning.
What is the maximum recommended monthly volume for the FS-1030D?
The maximum supported monthly volume is 20,000 pages. Regularly exceeding this limit may reduce the lifespan of internal components. For greater needs, it is preferable to opt for a higher capacity KYOCERA model.
How long does it take for the KYOCERA FS-1030D to start up?
The warm-up time is 15 seconds after power-up. The first page comes out in less than 10 seconds once the printer is in active standby. These short times limit daily waiting times in the office.
What paper formats does the KYOCERA FS-1030D accept?
The printer supports A4, A5, and B5 formats, as well as envelopes and labels via the manual feeder. The main tray is optimized for the A4 format commonly used in offices. Refer to the product manual for complete specifications of supported paper weights.
How to install the drivers for the KYOCERA FS-1030D?
Drivers for Windows and other systems are available on the official KYOCERA website. Connect the printer via USB 2.0 or over the network (MV version) before starting the installation. In case of difficulty, KYOCERA technical support can assist you.

User questions about 1030 & FS-1030D,MV KYOCERA

1 question about this device. Answer the ones you know or ask your own.

Ask a new question about this device

The email remains private: it is only used to notify you if someone responds to your question.

How to fix a printing offset issue on a KYOCERA FS-1030D laser printer?
Frequently Asked Questions - 04/01/2026
Response Notice-Facile

A printing offset on a KYOCERA FS-1030D laser printer can be caused by several factors. Here’s how to correct this issue:

1. Paper Check

  • Make sure the paper is properly loaded and aligned in the paper tray.
  • Use paper that meets the specifications recommended by KYOCERA.
  • Avoid using crumpled or damp paper.

2. Printer Alignment

  • Access the printer's configuration menu via its control panel.
  • Look for the alignment or calibration option and start the procedure.
  • This operation helps realign the internal components to avoid offsets.

3. Print Settings

  • Check on your computer that the selected paper size matches exactly the size loaded in the printer.
  • Also check the margins and orientation in the print settings.

4. Driver Update

  • Ensure that the printer driver is up to date by downloading the latest version from the official KYOCERA website.
  • An outdated driver can cause printing issues, including offsets.

5. Print Test

  • Print a test page from the printer to check if the offset persists.
  • If the problem continues, it may be necessary to contact a specialized technical service.

By following these steps, you should be able to correct a printing offset on your KYOCERA FS-1030D.
