MP450 - Mp3 player SWEEX - Free user manual and instructions

Product type	MP3 Player
Brand	SWEEX
Model	MP450
Dimensions	Approx. 90 x 40 x 12 mm
Weight	Approx. 30 g
Power source	Rechargeable battery via USB
Display	Backlit LCD screen
Storage	Internal memory (capacity not specified)
Audio formats	MP3, WMA
Video formats	AMV (conversion via included software)
Image formats	JPEG
Text formats	TXT
Connectivity	USB 2.0, 3.5 mm headphone jack
Main features	Audio/video playback, photo display, voice recording, text reading
Included accessories	USB cable, CD-ROM with software, earphones
Maintenance	Clean with a dry cloth. Avoid humidity and dust.
Safety	Do not open the device. Avoid shocks and extreme temperatures.
Spare parts	Not available
Repairability	Not user-serviceable (warranty void if opened)
Warranty	2 years in the European Union

Frequently Asked Questions - MP450 SWEEX

How to turn on the device?

To turn on the SWEEX MP450, slide the main switch to 'ON' (on top), then briefly press the O button (Play/Pause).

How to transfer files to the player?

Connect the player to your computer using the included USB cable. It appears as a removable drive named 'Sweeex MP3'. You can then copy music, video, or other files directly via Windows Explorer.

How to change the menu language?

In the main menu, go to 'Setup', then select the third line to access language settings. Choose your language from the list (French, English, German, etc.).

How to record audio?

In the main menu, select 'Record'. Press Menu to choose the recording type (Fine REC, Long REC, etc.). To start recording, press O. Press again to pause, or hold for 3 seconds to stop. Files are saved in the 'Record' folder.

How to play a video?

Make sure the video is in AMV format (use the included software to convert). In the main menu, select 'Movie', then choose the file with the Menu button. Press O to play.

How to adjust the volume?

During playback, press the VOL button, then use the ◀ and ▶ buttons to increase or decrease the volume.

How to charge the battery?

Connect the player to a free USB port on your computer using the included USB cable. The battery charges automatically.

What to do if the device does not turn on?

Check that the main switch is on 'ON'. If the problem persists, recharge the battery via USB. If nothing works, contact SWEEX support (warranty does not cover physical damage).

What file formats are supported?

Audio: MP3, WMA. Video: AMV (after conversion). Image: JPEG. Text: TXT. Recording uses WAV and ACT formats.

How to check warranty conditions?

The standard warranty is 2 years in the EU. To claim it, contact the point of sale where you purchased the product. The warranty is void if the device has been opened or physically damaged. You can register your product at www.sweex.com/productregistration.

USER MANUAL MP450 SWEEX

Sweex Black Coral MP3 Player

Introduction

• Do not expose the Sweex Black Coral MP3 Player to extreme temperatures. Do not place the device in direct sun light or close to heating elements.
• Do not use the Sweex Black Coral MP3 Player in extremely dusty or moist environments.
• Prevent hard shocks or impacts of the device, as this can cause damage to the internal electronics.
• Never try to open the device yourself, this voids the warranty.

Software installation

Software is supplied with the Sweex Black Coral MP3 Player . This software is freeware and Sweex does not give support on it .

With the software several sorts of video files can be converted to AMV, so these can be played on the Sweeex Black Coral MP3 Player; AVI, MPG, MPEG, VOB, RM, MOV, QT.

Install the software by putting the Sweex CD-ROM in the CD-ROM player. The CD-ROM will start automatically. Choose "Install Software Utilities".

Install Software Utilities

1. Press 1 ("add file") to select your video file.
2. Press 2 ("begin") to start converting.

Transferring files to the Sweex Black Coral MP3 Player

Connect the Sweeex MP3 Player with the supplied USB cable to the computer. Windows will detect the device, give it a drive letter, and indicate it as a removable disc with the name "Sweeex MP3". You can now manage your music and video files through windows explorer. You can also save other sorts of files and documents on the Sweeex MP3 Player. This way you can also use it as an USB memory stick.

Operation

Buttons:

Menu : Open menu, select menu option,
Next menu option, fast forward
: Previous menu option, rewind
O :On/off,play/pause
VOL :Volume

Switching on the Sweex MP3 Player.

On the upper side there is a main switch. Switch it to "ON". By briefly pressing the O Button you turn on the Sweex MP3 Player.

After turning on the Sweeep MP3 Player you are in the main menu. To directly enter the main menu at any time press the menu button Menu for three seconds.

The menu

The menu of the Sweex MP3 Player is available in multiple languages. Go to "Setup" and choose the third line by pressing twice ("Language"). The following languages are available: English, Dutch, French, German, Italian, Spanish, Swedish, Polish, Korean, Chinese, Czech, Japanese, Portuguese, Danish, Russian, Thai.

Scroll through the menu with the and buttons. Use Menu to choose the menu option and go one step back by pressing "Exit".

The options in the main menu are:

Setup : Device settings and information

Movie : Play video files

Music : Play music files

Record : Record sound

Voice : Playback sound recordings

Photo : View photos

E-Book : Reading text files

Playback of sound and video files

For music go to the menu option "Music". For movie go to "Movie". Press Menu to access your files. Press to play back. Also use to stop or pause. With the buttons and you can go to the previous or next file.

In pause mode you can enter the menu with the Menu button to select different options such as: deleting files and playing files out of a different folder.

During playback of music you can enter the menu with the Menu button to change different options such as: repeat (repeat function) and equalizer settings.

To change the volume during playback of music or video files press the volume button. Now you can change the volume with the and buttons. When you playback a video there is no indication of the volume level, but you can still adjust the volume after pressing the volume button.

Recording sound

To record sound go the menu option "Record". Press the Menu button to choose "Rec type" in the menu and to determine the format of the recording.

Fine REC = WAV 32 Kbps

Long REC = WAV 8 Kbps

Fine VOR = ACT 32 Kbps

Long VOR = ACT 8 Kbps

To start recording press . To pause and continue recording use the same button. To stop recording press the button for 3 seconds. The recorded files are saved numbered in the "Record" folder of the player. Playing back the recorded files can be done by choosing the option "Voice" in the main menu.

Switching off

Switching off the Sweeck Black Coral MP3 Player is done by pressing the button for 3 seconds. You can use the main switch on the back of the device to prevent the player from being switched off accidentally.

Charging

Charging the Sweex Black Coral MP3 Player is done with the supplied USB cable through a free USB port on your computer.

Warranty

Thank you for purchasing this Sweex product. Sweex devotes ample attention and care to the quality, reliability, functionality, durability and user friendliness of all its products. In this way Sweex distinguishes itself in the market and can we convince you as a buyer to continue purchasing products of the Sweex brand. We wish you a lot of pleasure with your purchase.

An important extra advantage for you is the possibility of product registration.

You can register the product you purchased online on www.sweex.com/productregistration.

By registering your product Sweex offers you a number of important yet equally useful advantages.

For example, if you wish so, you are regularly informed by us of the latest developments in our assortment by means of a digital newsletter.

Where applicable, you also automatically receive the latest drivers and/or firmware from us for the product you purchased to preserve or improve the compatibility and the performance.

Moreover, our support desk can assist you faster in case of possible support questions about the product if you registered the product.

Sweex warranty conditions.

2-year standard warranty within the EU

• In a standard manner a warranty period of 2 years as from the purchase date is available for this Swee x product within the EU.
• Should you wish to invoke this warranty within the first 2 years after the purchase then you can directly apply to the point of sale where you purchased the product for the conditions and procedures.

Matters that are excluded from the warranty

• The warranty of Sweex only covers manufacturing defects. Excluded from the warranty are accessories like batteries, rechargeable batteries and also supplied software, where applicable.
• The liability of Sweex is limited to the costs of repair and/or replacement of the product covered by the warranty.
• The standard warranty is null and void if the product has been opened, changes have been made, physical damage was caused to the product and if the product is used for another purpose than for which it is originally meant.

All brand names and associated rights mentioned in this manual are and remain the sole property of the rightful claimant.
