Product Type AM/FM Analog Radio
Brand EBENCH
Model KH 2247
Frequency Ranges FM: 87.5 – 108 MHz / AM: 540 – 1600 kHz
Dimensions (L × D × H) 191 × 60 × 135 mm
Weight Approximately 416 g
Power Supply 4 AA/LR6 batteries (1.5 V) or 6 V ⎓ power adapter (300 mA, 5 mm cylindrical connector, positive center pin)
Controls On/Off switch with volume control, AM/FM selector, frequency tuning knob
Antenna Telescopic antenna
Headphone Output 3.5 mm jack socket (mutes the speaker)
Built-in Speaker Yes
Carrying Handle Yes, integrated
Operating Temperature 10 °C to 40 °C
Operating Humidity 0 to 80 % (non-condensing)
Cleaning Slightly damp cloth; do not immerse, avoid solvents
Safety Do not open the casing; disconnect the adapter before cleaning; keep out of reach of children; remove batteries during prolonged absence
Warranty 3 years from date of purchase (covers material and manufacturing defects)

Frequently Asked Questions - KH 2247 ANALOGUE FM RADIO EBENCH

How to turn the radio on and off?
Turn the On/Off with volume knob to the right to turn on, and to the left to turn off, until you feel a slight resistance.
How to choose between FM and AM?
Use the AM/FM selector on the side: push it to the left for AM (medium wave) and to the right for FM (short wave).
How to insert the batteries?
Open the battery compartment at the back by removing the cover in the direction of the arrow. Insert 4 AA/LR6 batteries (not included) following the indicated polarity, then close.
Can I use a power adapter?
Yes, plug a 6 V ⎓ / 300 mA power adapter with a 5 mm cylindrical connector (positive center pin) into the DC 6 V socket on the right side.
How to tune a station?
Turn on the radio, select the band (FM/AM), extend the telescopic antenna, then turn the Frequency regulator knob to adjust the frequency on the scale.
Can I use headphones?
Yes, plug a headphone with a 3.5 mm jack plug into the socket on the left side. The speaker is then automatically muted.
How to clean the radio?
Use a slightly damp cloth. Never immerse the device in water or other liquids, and do not use solvents or benzene.
What to do if batteries leak?
Wear protective gloves, remove the batteries and clean the compartment with a dry cloth. Always replace all batteries with batteries of the same type.
Does the radio work on mains power while batteries are inserted?
If a power adapter is plugged in, the battery power is automatically cut off. You can leave the batteries in place, but remove them if you do not use the device for a long time.
What is the warranty on this product?
The radio comes with a 3-year warranty from the date of purchase, covering material and manufacturing defects. Keep your receipt.
