| Product Type | World Digital Radio Receiver |
| Brand | EBENCH |
| Model | KH 2023 DIGITAL WORLD RADIO RECEIVER |
| Power Supply | 4 AA batteries (LR6 1.5 V) or external AC adapter 6.0-7.5 V DC |
| Frequency Bands | FM (87.5-108.5 MHz), SW (5.85-15.6 MHz), MW (530-1656 kHz), LW (144-281 kHz) |
| Memory Presets | 40 (10 per band) |
| Display | Interactive LCD screen with time, date, day of week, time zones |
| Alarm Functions | 2 independent alarms (music or tone), snooze (9 min), wake-up by radio or tone |
| Sleep Timer | Up to 90 minutes, adjustable in 10-minute steps |
| Time Zones | 24 world cities with local and world time display |
| Integrated Calendar | Automatic years from 1950 to 2049 |
| Station Search | Manual or automatic (forward/backward), preset search (MEM.SCAN) |
| Antenna | Telescopic for FM and SW, internal ferrite for MW and LW |
| Key Lock | Yes (LOCK switch) |
| Headphone Jack | Yes (external) |
| Stand | Folding stand at the back |
| Dimensions (approx.) | Not specified in the manual, estimate: 150 x 80 x 30 mm |
| Weight (approx.) | Not specified, estimate: 300 g (without batteries) |
| Cleaning | Protect from moisture, do not place on a wet surface |
| Spare Parts | Not available, device not user-serviceable |
Frequently Asked Questions - KH 2023 DIGITAL WORLD RADIO RECEIVER EBENCH
How to set the time on the KH 2023 digital receiver?
In time display mode, press MODE once. The display shows 'CLOCK' and the hours blink. Use UP or DOWN to adjust the minutes (or hold for fast adjustment in 10-minute steps). No action for 15 seconds validates and saves the settings.
How to set the date?
In time mode, press MODE twice. The display shows 'DATE' and the date blinks. Use UP or DOWN to change the day (or hold for fast adjustment by 10 days). The day of the week updates automatically.
How to set alarm 1 or 2?
Press AL. 1 or AL. 2 once. The alarm time blinks. Use UP or DOWN to set the minutes. Press SNOOZE to choose the cycle (daily or week). Press the same alarm key again to select the wake-up type (tone or radio).
How to activate the snooze function?
When the alarm sounds, press SNOOZE/RADIO OFF to postpone it by 9 minutes. The snooze symbol appears. The alarm automatically reactivates after 9 minutes.
How to memorize a radio station?
Tune to the desired station. Press MEMORY (the 'MEM' indicator blinks). Press the desired preset key (1 to 10) once or twice to access the second preset. Press MEMORY again to confirm. The 'MEM' indicator stays on.
How to use the sleep timer?
Press SLEEP/RADIO ON once to see the current setting. Press again to reduce the duration in 10-minute steps (from 90 to 10 minutes). When the desired duration is displayed, stop pressing: it is saved. The radio turns off automatically after the delay.
How to activate automatic station search?
Turn on the radio and select the desired band (FM/SW/MW/LW) using the band selector. Press and hold UP or DOWN to start an automatic search upward or downward. The search stops on the nearest station.
How to display world time?
In time mode, press MODE four times. The display shows 'CITY' and the city code blinks. Use UP or DOWN to select the desired city (see code list). Press SNOOZE to see remaining daylight.
How to lock the keys?
Move the lock switch (②) to the LOCK position to activate locking. In locked mode, all keys are inactive. To unlock, move the switch back to UNLOCK.
What to do if the display shows low battery?
The low battery symbol lights up when the batteries are discharged. Replace the four AA batteries with new ones as soon as possible. The device uses 4 UM3/AA/LR6 1.5 V batteries. Do not mix new and old batteries.
