XWR-1200 - Router Luxul - Free user manual and instructions

Product Type	Wireless Router
Brand	Luxul
Model	XWR-1200
Dimensions (W x D x H)	Approx. 200 x 140 x 30 mm
Weight	Approx. 0.4 kg
Power Supply	12V DC, 1A
Power Consumption	Max 12W
Wireless Standards	IEEE 802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Maximum Data Rate	Up to 1200 Mbps (300 Mbps on 2.4 GHz + 867 Mbps on 5 GHz)
Ethernet Ports	4 x 10/100/1000 Mbps LAN, 1 x 10/100/1000 Mbps WAN
USB Ports	1 x USB 2.0
Antennas	4 x External detachable antennas
LED Indicators	Power, WAN, LAN (4), WLAN, WPS
Wireless Security	WPA/WPA2-PSK, WPA3, WEP
Firewall	SPI, DoS protection
VPN Support	PPTP, L2TP, IPSec
Mounting	Desktop or wall-mountable
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% non-condensing
Certifications	FCC, CE, RoHS
Package Contents	Router, power adapter, Ethernet cable, quick installation guide

Frequently Asked Questions - XWR-1200 Luxul

How do I reset the Luxul XWR-1200 router to factory defaults?

Use a paperclip to press and hold the reset button on the back panel for about 10 seconds until the LEDs flash. The router will reboot and restore factory settings.

What is the default IP address and login credentials for the XWR-1200?

The default IP address is 192.168.1.1, with username admin and password admin (or blank). Check the product label for specifics.

How can I update the firmware on the Luxul XWR-1200?

Download the latest firmware from the Luxul support website. Log into the router's web interface, go to Administration > Firmware Upgrade, and upload the file.

What wireless security options are available on the XWR-1200?

The router supports WEP, WPA/WPA2-PSK, and WPA3-Personal. It is recommended to use WPA2-PSK or WPA3 for best security.

Can I use the XWR-1200 as a wireless range extender?

Yes, the router includes a repeater/bridge mode. Access the web interface and select 'Repeater Mode' under Wireless settings to extend an existing network.

Why is my internet connection intermittent on the XWR-1200?

Check for interference from other devices, update the firmware, or try changing the wireless channel. Also verify that the WAN cable is securely connected.

How do I set up parental controls on the Luxul XWR-1200?

Log into the router admin panel, go to Access Control or Parental Control, and set time limits or block specific websites for connected devices.

What is the maximum range of the XWR-1200 Wi-Fi?

Indoor range is typically up to 100 meters and outdoor up to 300 meters, depending on obstacles and interference. Actual range may vary.

Can I connect a USB printer to the router?

Yes, the USB port supports printer sharing. Configure it via the web interface under USB Settings > Print Server.

How do I locate the MAC address of the XWR-1200?

The MAC address is printed on the label on the bottom of the router. You can also find it under Status > Network in the web interface.

USER MANUAL XWR-1200 Luxul

Black wireless router with two antennas and illuminated ports (no text or symbols visible)

Dual-Band AC1200 Gigabit Router XWR-1200

Includes:

Dual-Band Wireless AC1200 Gigabit Router
Dual Band Antennas (2)
Ethernet Cable
Power Adapter

ROUTER SETUP AND CONFIGURATION

1 Physical Installation

The XWR-1200 Wireless Router is designed for simple and efficient installation. For horizontal installation, install the rubber feet and position the XWR-1200 on a desk or other horizontal surface with adequate room around the device for ventilation. For wall or ceiling mounting, simply follow the directions on the included mounting pattern and use the mounting keyholes on the XWR-1200.

2 Connecting Antennas, Ethernet and Power

Antennas: Ensure all dual-band antennas are installed on the router.

INTERNET Connection: Connect the Ethernet cable from the modem/router equipment provided by your Internet Service Provider (ISP) to the black INTERNET port of the XWR-1200.

AC Power: Connect the included AC Adapter to the XWR-1200 first and then to the AC outlet.

3 Preparing for Access

IP Addressing

The XWR-1200 default LAN IP address is 192.168.0.1. The DHCP server on the XWR-1200 is configured by default to create a 192.168.0.x network.

Both the default LAN IP address and subnet scheme can be changed. However for hassle-free plug-and-play installation of other Luxul hardware, we recommend you use the default IP address if possible.

If your client device is set to obtain an address automatically, no further configuration is required and you can skip to the next step, Access and Setup.

If your computer or device isn't set to obtain an IP address automatically, you'll need to set a temporary static IP address on that device. Set the IP address of your computer to an address in the 192.168.0.X range, then set the Gateway/Router address to 192.168.0.1 (the default IP address of the XWR-1200).

NOTE: Visit http://luxul.com/ip-addressing to learn more about changing your computer's IP address and getting connected.

Access and Setup

Getting Connected

Connecting Via an Ethernet Device: Use an Ethernet cable to connect your computer to one of the green XWR-1200 LAN ports. Ethernet is the preferred method of connection.

Connecting Via a Wireless Device: Connect a wireless client device to one of the XWR-1200 default wireless networks (Luxul1200 or Luxul12005G). Both Wireless networks will run in Open security mode, so a passphrase will not be required until wireless security is configured.

Open a web browser, enter 192.168.0.1, then log in to the router using the default user name and password and proceed with configuration:

Default IP: 192.168.0.1

Username: admin

Password: admin

NOTE: If another device on your network shares the 192.168.0.1 address, you'll need to reassign that device a different IP address to configure the XWR-1200.

NOTE: Only devices that support the 5GHz frequency will see the default Luxul12005G wireless network.

Advanced Configuration

Configuring the XWR-1200 as a Wireless Controller

The XWR-1200 can manage up to two additional access points to enable wireless client roaming and simple configuration. To enable this feature, ensure one or two compatible access points are connected to the same network as the XWR-1200, then select Wireless Controller from the XWR-1200 web configuration interface. Follow the online help to add the access point(s) to the profile.

Caution: Do not manually configure access points you intend to manage with the XWR-1200 for seamless roaming. Doing so will result in standalone AP that the XWR-1200 will not find/manage.

Black wireless router with two antennas, set against a stylized green house graphic (no text or symbols)

XWR-1200 as a Controller

Other Advanced Configuration

For more information on configuring advanced features such as DDNS, VPN, etc., refer to the support resources at luxul.com.

XWR-1200 Front Panel LED Indicators

Indicator Name Status Function
	5GHz ON A 5GHz wireless network is broadcasting.
	2.4GHz ON A 2.4GHz network is broadcasting.
	1-4 LED ON A device is connected to the corresponding Ethernet port.
		FLASHING Data packets are being transmitted to the connected device.
	Internet LED	ON Router is connected to the ISP.
		FLASHING Data packets are being transmitted
	USB LED	ON A USB-enabled device is connected and configured.
	System LED	ON Router is booting.
		FLASHING Router is operating normally.
		OFF Router is not booting.
	Power LED	ON Power is applied to the Router.
		OFF Power is not applied to the Router.

Front Panel

XWR-1200 Front Panel View

Rear Panel

Front view of a network device rear panel showing ports and connectors (no readable text or symbols)

XWR-1200 Rear Panel View

Antenna Ports: 4 RPSMA female antenna ports to connect the included antennas.

NOTE: Both antennas should be installed prior to powering up the XWR-1200 and are required for optimal performance.

▶ Power Input: Power adapter included.

NOTE: To reboot the router, disconnect the power adapter, wait 10 seconds and reconnect the power adapter.

WAN Port: (1) black RJ-45 Ethernet Port for Internet connection.

▶ LAN 1 - 4 Ports: (4) green RJ-45 Ethernet ports for connecting to the local network.

NOTE: A Luxul switch is recommended in conjunction with the XWR-1200 to increase the number of local ports available.

▶ Reset Button: Used to restore factory default settings.

CAUTION: Holding the Reset button longer than 10 seconds will result in a factory reset.

To restore factory defaults, press and hold the Reset button until the System LED stops flashing (approximately 20 seconds). A factory reset will take one minute or more to complete. A successful factory reset is indicated when all of the Port LEDs flash once. When the System LED starts flashing again, the unit is ready.

CAUTION: Resetting the XWR-1200 to factory defaults will remove all custom settings.

Sales

P: 801-822-5450

E: [e-mail]

Technical Support

P: 801-822-5450 Option 3

E: [e-mail]

Copyright and Trademark Notices

No part of this document may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The material in this document is subject to change without notice. Luxul reserves the right to make changes to any product to improve reliability, function, or design. No license is granted, either expressly or by implication or otherwise under any Luxul intellectual property rights. An implied license only exists for equipment, circuits and subsystems contained in this or any Luxul product.

© Copyright 2016 Luxul. All rights reserved. The name Luxul, the Luxul logo, the Luxul logo mark and Simply Connected are all trademarks and or registered trademarks of Luxul Wireless, Inc. All other trademarks and registered trademarks are property of their respective holders.

LUX-QIG-XWR-1200-v8 04101704
