| Product type | Cooker hood |
| Brand | ROSIERES |
| Model | RHV93 |
| Mode of use | Extracting (external venting) or recirculating (internal recycling) |
| Control type | Touch controls |
| Number of motor speeds | 3 speeds + intensive function (10 min) |
| Timer | Programmable automatic shut-off (15 min) |
| Clean Air function | Automatic operation 10 min/hour at first speed |
| Lighting | Halogen lamps (replaceable) |
| Grease filters | Metallic, washable (every 2 months, even in dishwasher) |
| Charcoal filters | Not washable, replace every 4 months (supplied) |
| Minimum safety distance (between hood and cooking surface) | 65 cm |
| Electrical class | Class II (double insulation, no earth connection) |
| Power supply | 220-240 V, 50/60 Hz |
| Connection type | Cable with plug or direct connection via omnipolar switch |
| Filter saturation indicator | Flashing of key A (grease) or indicator F (charcoal) |
| Indicator reset | Press key A for 5 seconds |
| Exterior maintenance | Cloth dampened with denatured alcohol or neutral non-abrasive detergent |
| Usage precautions | Do not flambé under the hood, monitor frying, disconnect before maintenance |
| Intended use | Domestic only |
| Warranty and support | Note the serial number (16 characters, starting with 3) for technical service |
Frequently Asked Questions - RHV93 ROSIERES
What is the installation mode of the RHV93 hood?
The hood can be installed in extracting mode (air exhausted to the outside) or recirculating mode (air recycled in the room using charcoal filters). Installation must be carried out by a professional.
How to clean the grease filters and how often?
Grease filters should be washed at least every 2 months, by hand or in the dishwasher. After several washes, they may change color, which is normal.
When and how to replace the charcoal filters?
Charcoal filters are neither washable nor renewable. They must be replaced at least every 4 months. Replacement is simple: unclip the old one and insert the new one.
What does the flashing of key A or indicator F mean?
If key A flashes every 2 seconds, the grease filters need cleaning. If it flashes every 0.5 seconds, the charcoal filters need replacing. Indicator F flashes for grease filters. After maintenance, press key A for 5 seconds to reset.
How to use the Clean Air function?
Press the E key (or F depending on model) for 2 seconds when the hood is off (or on) to activate the function. The motor then runs 10 minutes per hour at the first speed to renew the air. To deactivate, press any key except lighting.
How to replace the halogen lamps?
Remove the protective glass by levering in the slots, then replace the lamp with one of the same type. Do not touch the lamp with bare hands, use a cloth.
What is the minimum distance between the hood and the hob?
The minimum distance between the cooking surface and the lowest part of the hood must be at least 65 cm.
What to do if the hood does not work?
First check that the plug is properly inserted into the socket. If the problem persists, turn off the appliance and contact technical support. Do not attempt to repair it yourself.
Where is the product serial number located?
The serial number (16 characters starting with the number 3) is on the warranty certificate or on the rating plate inside the hood. It is required for any support request.
Can I use the hood with gas or induction hobs?
Yes, the hood is compatible with all types of cooking, provided the safety distance of 65 cm is respected. Warning: never flambé under the hood and monitor frying to avoid fires.
