Product Type	LED TV
Screen Size	32 inches (81 cm)
Resolution	1366 x 768 (HD Ready)
Refresh Rate	60 Hz
Dimensions (without stand)	73.5 x 43.5 x 9.5 cm
Dimensions (with stand)	73.5 x 47.0 x 19.5 cm
Weight (without stand)	5.2 kg
Weight (with stand)	5.5 kg
VESA Mount Pattern	200 x 200 mm
Power Consumption (typical)	50 W
Standby Power Consumption	<0.5 W
Input Voltage	100-240 V, 50/60 Hz
Connectivity	2x HDMI, 1x USB, 1x SCART, 1x Antenna
Tuner	DVB-T/C
Audio Output	2 x 8 W speakers
Remote Control	Included (batteries not included)
Wall Mountable	Yes (VESA compatible)
Cleaning Instructions	Wipe with a dry, soft cloth. Do not use solvents.
Safety Warning	Do not block ventilation holes. Keep away from heat sources.
Spare Parts Availability	Remote control and stand available from IKEA

Frequently Asked Questions - UPPLEVA 32 IKEA

How do I mount the UPPLEVA 32 TV on a wall?

Use a VESA 200x200 mm wall mount (not included). Ensure the wall can support the TV's weight. Refer to the mounting instructions in the manual.

What remote control does the UPPLEVA 32 use?

The TV comes with an IKEA-specific remote control. If lost, you can order a replacement from IKEA or use a universal remote compatible with IKEA TVs.

How do I clean the TV screen?

Turn off the TV and let it cool. Use a dry, soft microfiber cloth to gently wipe the screen. Do not use any liquids or cleaning sprays.

Can I connect external speakers to the UPPLEVA 32?

Yes, you can connect external speakers via the headphone jack or use an audio receiver via HDMI ARC if supported.

Why is there no picture but sound is working?

Check that the correct input source is selected. Try pressing the 'Source' button on the remote. If issue persists, check HDMI cable connections or try a different device.

How do I perform a factory reset?

Go to Menu > Settings > System > Factory Reset. Confirm with the remote. This will erase all custom settings.

What is the warranty period for UPPLEVA 32?

IKEA offers a 2-year warranty from the date of purchase. Keep your receipt for claims.

Can I use the TV without the stand?

Yes, you can wall mount the TV. Remove the stand by unscrewing the screws at the bottom. Keep the stand for future use.

How to update the TV firmware?

This model does not have internet connectivity. Firmware updates are not available. Features are as shipped.

What are the energy efficiency class and consumption?

The UPPLEVA 32 is rated energy class A. Typical power consumption is 50 W, standby less than 0.5 W.

USER MANUAL UPPLEVA 32 IKEA

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

ENGLISH 4

DANSK 24

SUOMI 44

SVENSKA 64

Important information Safety

Ensure that your domestic mains supply voltage matches the voltage indicated on the identification sticker located at the back of your set. Where the mains plug or an appliance coupler is used as disconnect device, the disconnect device shall remain readily operable.

On certain models, the light indicator is located at the side of the TV set. The absence of a light indication at the front does not mean that the TV set is fully disconnected from the mains. To disconnect the TV set completely, the mains plug must be pulled out.

The TV set's components are sensitive to heat. The maximum ambient

temperature should not exceed 35°

Celsius. Do not cover the vents at the back or sides of the TV set. Leave sufficient space around it to allow adequate ventilation.

Install the appliance away from any source of heat (fireplace, etc.) or appliances creating strong magnetic or electric fields.

Moisture in rooms where the set is installed should not exceed 85% humidity.

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. Moving the set from a cold place to a warm one can cause condensation on the screen (and on some components inside the TV set). Let the condensation evaporate before switching the TV set on again.

WARNING

To prevent the spread of fire, keep candles or other open flames away from this product at all times.

The ⏻ or POWER/⌘ button on the TV set or the ⏻ button on the remote control can be used to switch it on and put it into standby mode. If you are not going to be watching the TV for a lengthy period of time, switch it off completely by removing the plug from the mains power socket.

During thunderstorms, we recommend that you disconnect the TV set from the mains and aerial so that it is not affected by electrical or electromagnetic surges that could damage it. For this reason, keep the mains and aerial sockets accessible so they can be disconnected, if necessary.

Unplug the TV set immediately if you notice it giving off a smell of burning or smoke. You must never, under any circumstances, open the TV set yourself, as you run the risk of an electric shock in doing so.

TV screen

The TV screen used in this product is made of glass. Therefore, it can break when the product is dropped or impacted upon by other objects.

The TV screen is a very high technology product, giving you finely detailed pictures. Occasionally, a few nonactive pixels may appear on the screen as a fixed point of blue, green or red. This does not affect the performance of your product.

Care

Use a glass-cleaning product to clean the screen and a soft cloth and mild detergent to clean the rest of the set.

Important: Using strong detergents, alcohol-based and abrasive products may damage the screen.

Dust the vents at the back and sides regularly. Using solvents, abrasive or alcohol-based products could damage the TV set. If an object or liquid enters inside the appliance, unplug it immediately and have it checked by an authorized engineer. Never open the appliance yourself since this may put you at risk or damage the appliance.

Hanging the TV set on the wall

WARNING: This operation requires two people.

To ensure a safe installation, observe the following safety notes:

• Check that the wall can support the weight of the TV set and wall mount assembly.
• Follow the mounting instructions provided with the wall mount. For certain models, make sure to screw the hexagonal VESA wall mounting screw bosses (and screws) provided with the set into the nuts for the wall mount at the back of your set before your wall mounting. — The TV set must be installed on a vertical wall. — Make sure to use only screws suitable for the material of the wall. — Make sure that the TV set cables are placed so that there is no danger of tripping over them.

All other safety instructions about our TV sets are also applicable here.

Handling the TV set on the table

Before setting up your television set, make sure that the surface you want to put the set on can support its weight.

Don't place the set on an unstable surface (e.g. moving shelf, very edge of a unit) and make sure that the front of the television set does not overhang the surface it is sitting on.

This product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste to prevent potential negative consequences for the environment and human health. Please, dispose of this equipment at your local community waste collection/recycling centre. In the European Union there are separate collection systems for used electrical and electronic product. Please, help us to conserve the environment we live in!

Remote control functions

Most of your TV's functions are available via the menus that appear on the screen. The remote control supplied with your TV can be used to navigate through the menus and to configure all the general settings.

1. ⏻ Standby / quit standby.
2. To switch the remote for TV use.
3. BACK To return to the previous menu. To return to the previous channel.
4. <> To navigate through the menus. To set functions and change values. > can also be used to open the corresponding submenu.
5. EXIT/ To exit the menu structure or Teletext; to stop some functions.
6. To fast forward or reverse (press and hold in Media function); and to move to the previous or next photo, song or video.
7. CH+/- To change channels.
8. Colour buttons To select tasks or Teletext pages. The red button can also be used for MHEG function.
9. MUTE To switch the sound off and back on again.
10. REC To record programme.
11. IPTV No function.

12.SUBT

To select a subtitle language available for selected digital TV programme.

13. GUIDE

To toggle the Electronic Programme Guide on or off (only available for digital channels).

14.0-9

To enter channel numbers. To enter a letter, a digit or a symbol in some functions.

15. DISK MENU

No function.

16.SOUND

To select a preset sound mode.

17.

To switch the remote for sound system use.

18. MENU

To access the main menu. To access or exit the virtual keyboard in smart TV function.

19. OK

To confirm an entry or selection. To freeze/unfreeze the picture in digital TV mode.

20. ∧∨

To navigate through the menus. To select menu options.

21. SMART TV

To display the smart TV homepage.

22.

To play/pause.

23. VOL+/-

To control the volume.

24. Ⓞ LANG

To select a sound type available for selected Analogue TV programme. To select an audio language available for selected digital TV programme.

25. OPTION

To display the function menu. To perform certain operations. To display the Teletext page in different modes.

26. SOURCE

To select connected devices.

27. ECO

To select desired power saving mode.

28. INFO

To display programme information, if available.

29. CH.LIST

To display the channel list.

To toggle Teletext on or off.

31. REPEAT

No function.

32.

To select the picture format. Note: We recommend you use the full screen mode. Do not use the display mode with black bars on both sides of the picture (such as 4:3) for a prolonged period of time; this may result in permanent damage to the TV screen.

Connect the power and antenna

To switch on the TV after connecting the power cord, press ⏻ or POWER/⏻. Note: The location of the power socket varies depending on the TV model. On some models, you have to turn on the power switch first.

Game console, PC

Note: Before connecting a PC, set the PC monitor refresh rate to 60Hz.

Network connection

DVD player, home theatre system

Blu-ray Disc player, headphones, HD game console & HD camcorder

Notes:

• USB connectors are for data input from USB storage devices. Only USB 1 port can be connected to your USB memory stick.
• Exposure to excessive sound levels from earphones and headphones can result in hearing loss. — Number of HDMI may vary. — ARC (Audio Return Channel) function is only supported on HDMI 4 (ARC) port. It is recommended to connect your home theatre to the HDMI ARC connector to send sound from the TV to the sound system via an HDMI cable.

DVD player, cable receiver Note:

Remove the power cord before connecting devices.

Notes:

— These illustrations are for reference only. Your model may differ in appearance or may not include all connections shown. — The location of the power socket on the TV may vary depending on the model. — The location and names of the function buttons and connectors on the TV may vary depending on the model.

Important:

If the remote control is not used for a long period, remove the batteries and store them properly. Handle damaged or leaking batteries carefully. If your remote control has two batteries, do not mix new and old batteries. Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to manufacturer's instructions. Refer to your local recycling or waste disposal rules and contact a local waste disposal vendor to dispose of used batteries. If the batteries in your remote control are run down you can use the buttons on your TV. In TV mode, they have the same functions as the corresponding buttons on the remote control. In the menus they have the following functions:

CH^	^
CH∨	∨
VOL>	>
VOL<	<
MENU/≡MENU
OK/→	OI

Switch the TV on and off

1. When powered on, the TV will be turned on directly or be in standby mode. If the TV is in standby mode, press the ⏻ or POWER/💡 button on the TV or the ⏻ button on the remote control to turn it on.
2. To put the TV into standby mode, press the ☑ or POWER/☑ button on the TV or the ⏻ button on the remote control. The TV remains powered up, but with low energy consumption.
3. To switch the TV off, unplug the mains plug from the mains outlet. (*On certain models, you have to turn on the power switch first.)

Initial setup

Initial setup involves selecting all the settings required to be able to search for and store all the Analogue and digital channels you can receive.

Make sure the TV is switched on and follow all the steps below in the order given.

Note: If the channel search retrieved only the analogue channels it could be caused by weak broadcasting signals and therefore is not covered by the manufacturer warranty. Manufacturers cannot be held responsible for the lack of or weak broadcasting signals that can be found in some areas.

The first time you switch the TV on, the Initial Setup wizard opens, which guides you through the initial setup process. (Refer to Figure 1.) Press OK to start your initial setup.

1. Press ✗ to select your language, then press OK/> to enter the next step.
2. Press ✗ to select your country, then press OK/> to enter the next step.

Note: If you select France, you will have to enter the Password Setting menu here in order to set a password. Use the digit buttons to enter a four-digit number for your password. (0000 is too simple to be set as your password.) Re-enter the same code to confirm the password. After that, you will enter the next step automatically. (In this step, you can only press BACK to return to the previous step.)

1. Press ✗ √ to select your tuner mode Antenna or Cable or Satellite. (Note: For some models, this option may not be available.)

— Select Antenna.

- Press OK to enter.

- Select Digital & Analogue, Digital or Analogue, then press OK.

- Press ∧/∨ to select Scan, then press OK to start the automatic search for all DVB-T digital and/or analogue channels. - Select Cable.

- Press OK to enter.

- Select Digital & Analogue, Digital or Analogue, then press OK.

- Press ∧/∨ to select Scan, then press OK to directly start your initial setup or enter below step.

- Select Full if available to search for and store all DVB-C digital and analogue channels.

- You may select another advanced scan mode if available (for example, Advanced), then configure proper cable information as described below. Use the digit buttons to adjust the values for frequency, symbol rate and network ID.

Use ◀ to select a modulation mode.

- Press OK to start initial setup relating to all DVB-C digital and analogue channels. Note: For some models, this option may not be available.

- Select Satellite.

• Press OK to enter.
• Press ∧/∨ to select Scan, then press OK to enter the next step to configure proper information relating to satellite and antenna.
• Press OK to start initial setup relating to all satellite channels.

Note: To prevent the channel setup process from being interrupted, wait for the message indicating that the setup is complete.

1. Before starting the scanning, you can also select Skip Scan to skip the initial setup process.
2. During the setup, you can follow the instructions at the bottom of the screen and return to the previous step by pressing BACK. Or press EXIT to exit or interrupt the search halfway.
3. Once the automatic search ends, the TV enters the next step automatically. Press \mathcal{N} to select your location Shop or Home. Press OK/> to confirm your selection and enter the last step.

7.

• In this step, you can press OK to exit the initial setup. The channels are arranged in a preset order. If you wish to skip channels, modify the preset order or rename channels, select SETUP > Organiser and press OK/> to enter. — In this step, you can also press BACK to return to the previous step.

Automatically install channels

This section describes how to search and store channels automatically. Instructions are for both analogue and digital channels.

1. Press MENU on the remote control and select SETUP > Language > Menu Language. Press </> to select your desired menu language.
2. Press BACK to return to SETUP, press ^/V to select Country, then press <//> to select your country. The TV installs and arranges channels according to your country.
3. Press ✗ to select Tuner Mode, then press ✕ to select Antenna, Cable or Satellite.

(For some models, this option may not be available.)

— Select Antenna.

- Press ∧/∨ to select Channel Install, and press OK/> to enter.

- Select Automatic Search (Refer to Figure 2.), then press OK/> to display Automatic Search.

- Press OK to skip the country selection and enter the next step. Or use \blacktriangleleft to reselect your country, then press OK to enter.

- Select Digital & Analogue, Digital or Analogue, then press OK/> to start the automatic search, which relates to all DVB-T digital and/or analogue channels. - Select Cable.

- Press ∧/∨ to select Channel Install, and press OK/> to enter.

- Select Automatic Search, then press OK/> to display Automatic Search.

- Press OK to skip the country selection and enter the next step. Or use ◄ to reselect your country, then press OK to enter.

- Select Digital & Analogue, then press OK/> to enter. Select your scan mode if available and configure proper cable information in the same way as in Initial setup. Select Scan and press OK/> to start your automatic search relating to all DVB-C digital and analogue channels.

- Select Digital, then follow the same process as above to start your automatic search relating to all DVB-C digital channels.

- Select Analogue, then press OK/> to start your automatic search relating to all analogue channels. - Select Satellite.

Note: For some models, this option may not be available.

• Press ∧/∨ to select Satellite Setup, and press OK/> to enter.
• Press ∧/∨ to select a proper satellite or add new satellites if needed, then press OK to enter and configure proper information relating to satellite and antenna.
• Select SETUP > Channel Install > Automatic Search, then press OK/> to enter.
• Select Country, and use ◄/► to reselect your desired country, if necessary.
• Select Satellite Tuning, press

OK/> to display the SATELLITE

TUNING menu. Configure the proper information. Select Scan, and press OK/> to start initial setup relating to all satellite channels.

Note: For some models, this option may not be available.

1. The search may take a few minutes. During the process, you can press EXIT to abort halfway.
2. Once the automatic search ends, press BACK to return to the previous step or press OK to restart your channel search.
3. After the automatic search, channels are arranged in a preset order. You can skip channels, modify the preset order or rename channels.

Use your TV

Access channels

Using the digit buttons: press the corresponding digit buttons to access the channels.

Using the CH+/- or CH ↗ Buttons:

scroll through the channels.

Watch connected devices

Repeatedly press SOURCE on the remote control or OK on the TV to toggle between TV and other input sources. To resume TV viewing, press any digit button to enter the channel, while CH+/- will cycle through all TV channels and other input sources.

Note: Not all models have an OK button on the TV.

Volume

Volume control: use the VOL+/- buttons on the TV or VOL+/- buttons on the remote control to increase or decrease the volume. Sound mute: press the MUTE button to temporarily mute the sound. Press this button again or the VOL+ button to restore it.

Use TV menus

1. Press MENU to display the main menu. (Refer to Figure 3.)
2. Press the navigation buttons to select the desired item, then press OK to open the corresponding submenu.
3. In submenus, use the navigation buttons to select menu options, use the adjustment buttons to set functions or change values. Use OK to activate a setting. Use OK to open the corresponding submenu.
4. Press BACK to return to the previous menu.
5. Press EXIT to close the menu.

Note: Some options may not be available for certain signal sources.

Select menu language

You can choose your preferred menu language following the instructions below.

1. Press MENU to display the main menu.
2. Press ∧/∨/<> to select SETUP, then press OK to enter.
3. Select Language and press OK/> to enter.
4. Select Menu Language and press <//> to select your desired language to display the menus.
5. Press EXIT to close the menu.

Use more of your TV

Setup your favourite channels

You can create a list of your favourite TV channels.

1. Press CH.LIST.
2. Press the yellow button to enter CHANNEL LIST SELECTION. Press ∧/∨ to select the favourite list and press OK to enter.
3. Press the blue button to start editing your favourite list. Press ∧/∨ to scroll through the channel list and press OK to select or deselect it.
4. Repeat this procedure to setup other favourite channels.
5. Press CH.LIST/EXIT to exit.

Energy Saving

1. Press MENU on the remote control and select PICTURE > ECO Settings > Energy Saving.
2. Press ✦ to select the desired power saving mode to achieve the desired power saving effect.
3. Press EXIT to close the menu.

Shortcut operation: Press ECO on the remote control to select the desired power saving mode directly.

PAP function

To display pictures from different source inputs side by side. Note that one window is for both analogue and digital TV inputs, the other is for VGA, HDMI, and CMP inputs.

(Note: Not available for AV-Scart on both windows.)

1. Press MENU to display the main menu.
2. Select PAP and press OK to enter.
3. Select the PAP option, and press </> to turn on/off the PAP function.
4. Select TV Position, press ↕ ↗ to reposition the TV window.
5. Press ◀ to toggle the focus window.
6. When the focus is on the TV window, the digit buttons and CH+/- work in TV. When the focus is on the other window, CH+/- switches available external sources.

Use subtitles

You can enable subtitles for each TV channel. Subtitles are broadcast via Teletext or DVB-T/DVB-C digital broadcasts. With digital broadcasts, you have the additional option of selecting a preferred subtitle language.

Turn on/off subtitles

1. Press MENU on the remote control and select OPTIONS > Subtitle.
2. Press OK/> to enter. (Refer to Figure 4.)
3. Select the Subtitle option, and press <//> to select On/Off to turn on/off subtitles.

Enable subtitle languages on digital TV channels

1. Press MENU on the remote control and select OPTIONS > Subtitle > Digital Subtitle Language.
2. Press ✦ to select a subtitle language as your preferred language.
3. Press ✗ to select Digital Subtitle Language 2nd.
4. Press ✗ to select a secondary subtitle language.
5. Press EXIT to close the menu.

Shortcut operation: Press SUBT on the remote control to directly select a subtitle language available for the selected digital TV programme.

Select a subtitle type on digital TV channels

1. Press MENU on the remote control and select OPTIONS > Subtitle > Subtitle Type.
2. Press ✦ to select a subtitle type. You can select Hearing Impaired to display the hearing impaired subtitles with your

selected language.

Select decoding page language in Teletext

Press MENU on the remote control and select OPTIONS > Teletext > Decoding Page Language. Select a proper type of language in which Teletext will display.

Digital Teletext language

For digital TV channels, your TV could zap to a service with multiple initial Teletext pages in different languages. This function allows you to select an available language as primary language, which relates to different initial Teletext pages.

Press MENU on the remote control and select OPTIONS > Teletext > Digital Teletext Language. Press ◄ to select.

SPDIF type

Connect to an audio device through the SPDIF output. Press MENU on the remote control and select OPTIONS > SPDIF Type. Select a proper sound type from the list for digital programmes.

• If the current programme outputs sound in Dolby D format, then either PCM or Dolby D can be selected.
• If the current programme does not output sound in Dolby D format, only PCM can be selected. Otherwise no sound will be output.
• Select Off to turn off the audio output from the audio device connected to the SPDIF output.

Note: The options you may choose depend on the programme you are watching. If you select PCM and the sound is ahead of the picture, you can select SPDIF Delay from the OPTIONS menu and press ◄ to adjust the delay time to synchronize the sound with the picture.

T-Link

To search for CEC devices connected to the HDMI sockets in your TV and enable one-touch play and one-touch standby between CEC devices.

Enable or disable T-Link

1. Press MENU on the remote control, then select OPTIONS > T-Link.
2. Press </> to select On or Off.

Use one-touch play

One-touch play enables you to press the play button on, for example, your DVD remote control. This starts playback on your DVD device and automatically switches your TV to the correct source, displaying DVD content.

Use system standby

System standby enables you to press the ⏻ button on, for example, your TV remote control. This switches your TV and all connected HDMI devices to standby mode.

Network update

Press MENU on the remote control, then select OPTIONS > Network Update.

Select On/Off to enable or disable the Network update function.

• When this function is on, the TV will automatically update channels if your DTV service provider updates his DTV network.
• When this function is off, you need to run the channel search again to get new channels or remove unavailable channels if your DTV service provider adds or removes channels from their DTV network.

Common interface

Encrypted digital TV channels can be decoded with a common interface module and a card provided by a digital TV service operator.

The common interface module may enable several digital services, depending on the operator and services you choose (for example, pay TV). Contact your digital TV service operator for more information about services and terms.

Use the common interface module WARNING: Switch off your TV before inserting a common interface module. Be sure to follow the instruction described below. Wrong insertion of a common interface module may damage both the module and your TV.

1. Following the directions printed on the common interface module, gently insert the module into the common interface slot on the TV.
2. Push the module in as far as it will go.
3. Turn on the TV and wait for the common

interface function to be activated. This may take several minutes.

Note: Do not remove the common interface module from the slot. Removing the module will deactivate the digital services.

Access common interface services

After inserting and activating the common interface module, press MENU on the remote control and select OPTIONS > Common Interface.

This menu option is only available if the common interface module is correctly inserted and activated. On-screen applications and content are provided by your digital TV service operator.

Software update

Press MENU on the remote control and select OPTIONS > Software Update.

Press OK/> to enter.

• Current Version: Checks the current version of the software.
• Product Name: Displays the product name of your TV.
• Serial Number (if available): Displays the serial number of your TV.
• By Network: Enables you to download and install the latest software version from the Internet. Make sure to set up a wired or wireless network connection first, then select By Network and press OK/> to enter. Follow the on-screen instructions to continue. Note: Connect a USB device to your TV before you start software update. — By Channel: Enables you to install the latest version of the software if available. Select By Channel and press OK/> to enter.

- Use </> to select Yes under Auto Download to automatically download the latest software if available. After the software has been downloaded successfully, you will be prompted to decide if you want to install it right now. If yes, follow the on-screen instructions to complete your installation. You can also select to ignore the installation here.

- Select No under Auto Download to decline the automatic download.

- Select Manual Download and press OK/> to start manual scanning for the latest software. Follow the on-screen

instructions to complete. During the scan, press OK/EXIT to cancel or exit the process.

Change to Shop or Home mode

1. Press MENU on the remote control and select OPTIONS > Location.
2. Press <//> to select your location: Shop or Home.
3. Press EXIT to exit.

Note: According to the regulation of European Commission 2009/125/EC, in Home mode the TV will be put into standby mode automatically if there is no operation in 4 hours. This feature can be deactivated in OPTIONS menu.

MHEG function

Some digital TV broadcasters offer dedicated digital text or interactive services (for example, BBC1). These services work like normal Teletext with the addition of number, colour and navigation buttons.

1. Press MENU on the remote control and select OPTIONS > Subtitle > Subtitle.
2. Press </> to set Subtitle to Off.

Note: MHEG and subtitles are mutually exclusive and cannot coexist on the same screen. If Subtitle is set to On, MHEG will not appear.

1. Press the red button or TEXT on the remote control.
2. Press ✗ ∗/ select or highlight items.
3. Press OK to confirm or activate.
4. Press one of the colour buttons to select an option.
5. Press TEXT or EXIT to exit.

View photos, play music and watch videos from a USB memory stick

Your TV is fitted with a USB connector that enables you to view photos, listen to music or watch videos stored on a USB storage device.

Supported file formats:

Photo JPEG

Music MP3

Video AVI, MP4, MPG, MPEG, TS, DIVX, MKV...

Notes: Some USB keys and USB products like digital cameras or mobile phones are not fully compatible with USB 2.0 standard so they may not work with the TV multimedia player. Not all USB keys or devices are

compatible with the USB function. Not all above formats are supported. The encoding formats of your files will determine whether or not they can be used.

When a USB device is detected, it enters the MEDIA menu directly. (Alternative: Select MEDIA in the main menu and press OK to enter.)


To display photos, if available.

1. Select MEDIA > PHOTO, then press OK to enter the main file content browser.
2. In the main file content browser, use the arrow keys to select a photo or an inner file folder.
3. Select an inner file folder, press OK to enter a sub file content browser.
4. Use the arrow keys to select a photo in either main or sub file content browser, press MENU to display the photo menu in folder mode.
5. Sort: Sort folders and photos by modification Date or Name.
6. Edit: Copy, paste or delete a selected photo.

- Parser: You can select Recursive to display photos from all sub file folders.

1. Select a photo, press OK to watch, and a slide show begins from the selected photo. Press ▶ to pause the photo if you want to rotate the paused photo. Press MENU to display the photo menu in the browser mode. You can play, pause or rotate the photo, select different play modes and displaying effects, etc.
2. Press the related buttons on the remote control to perform the available functions shown on the function bar at the bottom of the TV screen.

Music

To playback music, if available.

1. Select MEDIA > MUSIC, then press OK to enter the main file content browser.
2. Use ∧/∨/<> to select a song in either main or sub file content browser in the same way as in photo display function, press MENU to display the music menu in folder mode.
3. Sort: Sort folders and songs by Name, Genre, Artist or Album.
4. Edit: Copy, paste or delete a selected song.

— Parser: You can select Recursive to

Display songs from all subfolders.

1. Select a song, press OK to play, and automatic playback begins from the selected song. Press MENU to display the music menu in the browser mode. You can play or pause the song, select different play modes, etc. — Show Lyrics: This option is available for songs with lyrics. Select it and use </> to turn on/off synchronized lyrics display. — Audio Only: Select and press OK to listen to the music with the screen turned off. Any key press will turn the screen on.
2. Press the related buttons on the remote control to perform the available functions shown on the function bar at the bottom of the TV screen.

Video

To watch videos, if available.

1. Select MEDIA > VIDEO, then press OK to enter the main file content browser.
2. Use //<> to select a video in either main or sub file content browser in the same way as in photo display function, press MENU to display the video menu in folder mode.
3. Sort: Sort folders and videos by Type, modification Date or Name. — Edit: Copy, paste or delete a selected video.

— Parser: You can select Recursive to display videos from all subfolders. 3. Select a video, press OK to watch, and automatic playback begins from the selected video. Press MENU to display the video menu in the browser mode. You can play or pause the video, select different play modes, screen modes and preset picture settings, etc. 4. Press the related buttons on the remote control to perform the available functions shown on the function bar at the bottom of the TV screen.

DivX video

(* not available for some models) ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more

information and software tools to convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies.

Obtain your registration code:

• Press MENU on the remote control.
• Select OPTIONS > DivX(R)

Registration.

- Press OK> and your registration code will be displayed.

Go to vod.divx.com for more information on how to complete your registration.

Deregister your TV:

If you wish to deregister your TV,

• Press MENU on the remote control.
• Select OPTIONS > DivX(R)

Deregistration.

- Press OKY and a message will guide you. DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.

Time detection

You can detect the time from digital channels through the following operations.

1. Press MENU on the remote control and select OPTIONS > Timer > Clock > Auto Synchronization.
2. Press <//> to select On.

Assign a channel decoder

Decoders that decode analogue channels can be connected to the AV connector. Assign the TV channel as a channel to be decoded. Then assign the connection where the decoder is connected.

1. Press MENU on the remote control and select SETUP > Decode.
2. Press OK/> to enter the list.
3. Press ✗ to select the channel to decode.
4. Press OK to select or unselect the channel.
5. Press BACK to return to the previous menu.

Diagnostics on digital TV channels

1. Press MENU on the remote control and select SETUP > Diagnostics.
2. Press OK/× to display some signal information on the current digital channel, such as signal strength, frequency, etc.

Time Shift

Allows you to pause, rewind and forward in a programme. The first time you use this function, make sure to connect a USB memory stick.

Note: Due to specific country requirements, the Time Shift function is not available for Finland.

1. Press MENU on the remote control and select SETUP > Time Shift.
2. Press </> to select On to switch on the Time Shift function, then press EXIT to close the menu.
3. Press OPTION on the remote control and select Time Shift, then press OK to confirm.
4. Follow the directions on the screen to do the setup.
5. After the disk setup is done, press OPTION and select Time Shift.
6. Press OK to display the Time Shift menu.

- Press the ▶ button to pause the picture and begin the Time Shift.

- Press the ▶ button to play the recorded part.

- When the Time Shift menu disappears and only the timing of the Time Shift remains on the screen, you can press the ▶ button or OK to access the Time Shift menu.

- Press the ◀ button to fast backward or the ▶ button to fast forward.

- Press the button to quit the Time Shift function.

Notes:

- Before you connect the USB memory stick to the TV, make sure you have backed up the data in the device to avoid the risk of losing important data due to unforeseen malfunction.

- We recommend you use a USB device with free capacity above 1GB and disk speed faster than 5.0MB/sec.

- The bigger the file size for Time Shift, the longer the recording time.

- If you change the channel in Time Shift mode, a message prompts you to select Yes or No. You can select Yes to exit the Time Shift function and execute the channel change.

- If you change the channel in Time Shift mode, a message prompts you to select Yes or No. You can select Yes to exit the Time Shift function and execute the channel change.

Reset shop

Allows you to reset the TV to factory default settings.

1. Press MENU on the remote control and select SETUP, then press OK to confirm.
2. Select Reset Shop and press OK/> to enter.
3. Use the digit buttons to enter the password.
4. Press </> to select OK and press OK to confirm.
5. The Initial Setup menu appears. Follow the related instructions.

Customising the input settings

Allows you to configure your TV for external input devices, such as a set-top box, Blu-Ray player, computer or game console.

1. Press MENU on the remote control and select SETUP > Input Settings.
2. Press OK/ to enter Input Settings.
3. Press ✗ to select the port the input device is connected to.
4. Press ◀ to select the type of device. Press ◀ to assign a name to the device.
5. Press BACK to return to the SETUP menu.

After configuring, the selected source label will be displayed after the name of the related connector in the source list when pressing SOURCE on the remote control or OK on the TV.

Use Electronic programme guide

EPG is an on-screen guide that displays scheduled TV programmes. You can navigate, select, view and record programmes.

1. Press GUIDE on the remote control, the Now and Next EPG menu will appear, which allows you to get information about the current or next programme playing on each channel. Navigate through the different programmes using the navigation buttons on the remote control.
2. Use the colour buttons to view the 8 Days EPG.

- Prev Day (Red): List the previous day's EPG.

- Next Day (Green): List the next day's EPG.

- View Detail (Yellow): Display the description of this programme if available.

- Type Filter (Blue): Programme guide filter for digital TV programmes.

- Press the blue button to display the programmes' type and subtype lists.

- Navigate through the different types and subtypes using the navigation buttons on the remote control.

- Select one or more types that you want to highlight from the Type list. Press OK to select (or deselect). A checkmark will appear to the left of the type when selected. When you select a type, all its subtypes will be selected accordingly.

- Also, you can select some desired subtypes without selecting any type first.

- Press the blue button to exit the type and subtype list.

- After filtering, all your desired digital TV programmes will be highlighted.

- Add Schedule (Option): Press OPTION on the remote control to bring up the Schedule List menu. For details on scheduled recording, refer to the Schedule List section.

1. Press GUIDE/EXIT to exit the EPG and switch to the selected channel.

PVR (Personal Video Recorder)

Allows you to record your favourite TV programme. Before you use the function, connect a USB memory stick to the set first. Note: Due to specific country requirements, the PVR function is not available for Finland.

1. Press OPTION on the remote control and select QUICK ACCESS > PVR.
2. Press OK/ > to enter.

Shortcut operation: Press REC on the remote control to enter the PVR menu directly.

1. Press:

- Press the REC button to start recording. The recorded file is saved in a PVR folder under MEDIA > VIDEO.

- Press the button to stop recording manually. If the recording duration ends, the recording will stop automatically.

- Use ∧/∨/</> to adjust the recording duration.

1. While recording, a PVR mini pane will appear on the screen to show the recording progress.
2. To watch the recorded program, exit PVR mode first and go to MEDIA > VIDEO. Select the PVR folder, then choose the relevant recording file. Press OK to play. (The same applies if you record a digital radio program.)

Notes:

- When a CI+ card is used, the PVR function will be disabled.

- Only available for digital channels.

- Only supports USB memory devices formatted as FAT32.

- Before connecting the USB memory stick to the TV, make sure you have backed up the data on the device to avoid the risk of losing important data due to unforeseen malfunctions.

- The larger the USB memory stick's capacity for the PVR function, the longer the recording time.

- If you want to change channels or signal sources during recording, save the recording data before changing the channel or source.

- The TV cannot play files normally if the file parameters exceed system limitations, the file format is unsupported, the file is damaged, or the file cannot be decoded.

- Do not disconnect the USB memory stick when the system is reading a file or transmitting data, otherwise the system or the device may be damaged.

Schedule List

This function is used to perform scheduled recording.

1. Press OPTION on the remote control and select QUICK ACCESS > Schedule List.
2. Press OK to display the Schedule List.
3. To add a schedule into your schedule list, press the red button first to display Schedule List. Then,

- Channel Number: use </> to select the channel number.

- Start Date: use the digit buttons to set the recording date.

- Start Time: set the starting time of the recording.

- Stop Time: set the stopping time of the recording.

- Schedule Type:

• Set Reminder to be reminded that you can switch to the scheduled programme when the time you have set comes. When time is out and you do not execute any operation, the dialog box will disappear and no further operation will be executed.
• Set Record to check if you really want to start your scheduled recording when the time you have set comes. When time is out and you do not execute any operation, scheduled recording will start automatically.
• Repeat Type: set different repeat modes for the recording.
• Press ∧/∨/<> to select Add, then press OK to add the schedule you set into your schedule list.
• Press the red button to repeat above procedures to add another schedule.
• If you wish to edit or delete a schedule, select it and press OK to enter.
• Press EXIT to close the menu.

Network connection

You can set up your TV so that it can access the Internet through your local area network (LAN) using a wired or wireless connection.

Connecting to a wired network

You can attach your TV to your LAN using cable in three ways:

• You can attach your TV to your LAN by connecting the LAN port on your TV to an external modem using a Cat 5 cable.
• You can attach your TV to your LAN by connecting the LAN port on your TV to an IP Sharer, which is connected to an external modem. Use Cat 5 cable for the connection.
• Depending on how your network is configured, you may be able to attach your TV to your LAN by connecting the LAN port on your TV directly to a network wall outlet using a Cat 5 cable. Note that the wall outlet is attached to a modem or router elsewhere in your house.

Select SETUP > Network > Settings > Interface, then select Ethernet to connect to a wired network.

Connecting to a wireless network

To connect your TV to your network wirelessly, you need a wireless router or modem and a Wi-Fi adapter, which you will have to buy separately. Connect the Wi-Fi adapter to your TV's USB 1 port.

1. Select SETUP > Network > Settings > Interface, then select Wireless to connect to a wireless network.
2. Select Wireless Setting and press OK/> to enter.
3. Connection Methods: You can set up the wireless network connection in three ways.

- Scan

• Select Wireless Setting > Scan, then press OK/>. The TV will scan all access points within range. The access points found by the TV will be displayed.
• Select an available access point, then press OK/> to connect the TV.

Notes:

• If you select a protected access point, you will have to enter the corresponding password. Press OK on the remote control to display the virtual keyboard to enable you to enter the password. — This TV has a memory function for available access points, which enables your TV to be connected to the network even if you switch on the TV after power off.

- Manual

Select Wireless Setting > Manual, then press OK/>. You will be prompted to enter the correct SSID of an available wireless router to set up the connection.

- Auto

If your AP supports WPS (Wi-Fi Protected Setup), you can connect to the network via PIN (Personal Identification Number) or PBC (Push Button Configuration). WPS will automatically configure the SSID and WPA key in either mode.

Select Wireless Setting > Auto, then press OK/> to enter.

• PIN: Select PIN and press OK/> to enter. Generate a random PIN code. Make sure this code is installed on the AP. (For the procedures, refer to your router manual.) Press OK/> again to set up the connection.
• PBC: If your router has a PBC push button, select PBC, then press OK/> to enter. Press the PBC push button on your router within 2 minutes after you press OK/> again. Your TV will automatically acquire all the network setting values it

needs and connect to your network.

Network setup

1. Press MENU on the remote control and select SETUP > Network > Settings > Internet Connection. Press </> to select On. Wait until the connection is automatically established.
2. Select SETUP > Network > Settings > Connection Test, then press OK/> to check the Internet connectivity. If it does not work, follow below steps to make sure of the connectivity.
3. Select SETUP > Network > Settings > IP Setting, then press OK/> to enter the IP Setting menu.

- Set Address Type to Auto, it will acquire and enter the needed IP address automatically. - You can follow below steps to enter your IP address manually.

- Set Address Type to Manual, then press √ to go to the first entry field.

- Enter the IP Address, Subnet Mask, Default Gateway, Primary DNS and Secondary DNS values. Use the digit buttons to enter numbers and the arrow buttons to move from one entry field to another.

- After setting, select Setup > Network > Settings > Connection test to check the Internet connectivity again.

1. Select SETUP > Network > Settings > Information, then press OK/> to display the information on current connection, such as Interface, Address type, IP address, etc.

Browse PC through Share & See

If you have photos, videos or music files stored on a computer connected through a home network, you can play your files on your TV.

Connecting to your PC

Make sure to set up a wired or wireless connection from your TV to a router first. Then connect your PC to your router either through a network cable or wirelessly.

Also make sure SETUP > Network > Settings > Internet Connection is On and your computer firewall won't block the connection.

Enabling Share & See function

Select SETUP > Network > Applications > Share & See, and set it to On.

Follow the steps in turn specified hereafter.

Adding media from your PC for sharing Install a Share & See media server on your PC. The simple and familiar server you may install is Microsoft Windows Media Player 11. Allow your TV to share the designated files on your PC.

1. Open the Microsoft Windows Media Player 11.

- Select Library > Media sharing.

- Check the checkbox Share my media to.

- Select the icon of the TV connected to your PC.

- Select Allow to allow the TV to access your PC, and select OK to enable your allowing.

Note: Use the Settings button to customize your desired settings.

2.

- Select Library > Add to Library.

- Select your personal folders or folders of other users that you can access for sharing.

- Select Add and press OK to enable your adding.

Share & See application

Select MEDIA in the main menu and press OK to enter media center. Then you can view photos, listen to music or watch videos, which are stored on your PC.

Smart TV

Allows you to enjoy internet applications (Apps), specially adapted internet websites for your TV. You can control the Apps with the TV remote control.

WARNING:

- Configure the network settings before using Smart TV.

- Slow responses and/or interruptions may occur, depending on your network conditions.

- If you experience a problem using an application, please contact the content provider.

- According to circumstances of the contents provider, an application's updates or the application itself may be

discontinued.

- Depending on your country's regulations, some applications may have limited service or not be supported.

Access Smart TV Applications (Apps)

1. Select SMART TV in the main menu and press OK to display the smart TV home page.

Shortcut operation: Press SMART TV on the remote control to display the smart TV home page directly.

1. Use X N/< to select an App and press OK to enter.

HbbTV

Some broadcasters of digital channels offer interactive HbbTV (Hybrid Broadcast Broadband TV).

With HbbTV, broadcasters combine their normal TV programme with all kinds of information or entertainment. You can browse this information interactively. To fully enjoy HbbTV, you need to connect your TV to the internet.

Note: You cannot download files to your TV with this feature.

Access HbbTV

When you tune to a TV channel that offers HbbTV, press the red button to open the interactive pages. Then use / navigate the HbbTV pages and press OK to confirm.

Notes for password in Parental Control Lock function:

— The default password is 1234. You can change it to a new one. — The super password is 0423. If you forget your code, enter the super password to override any existing codes.

Screen resolution:

-1920X1080

Contact IKEA

If you have any questions regarding your new UPPLEVA TV or Sound System or need service or support, contact IKEA Customer Service at www.IKEA.com.

To be sure we can give you the best possible assistance, please read the manual carefully before contacting us. And have the article number for your purchase at hand when you call. You'll find this 8-digit article number on your receipt or on the back of your UPPLEVA TV or Sound System.

Game console, PC

Note!

Common interface, CI

- Select Library > Add to Library.

Remote control functions

Game console, PC

Comment:

OPTIONS > Teletext > Digital Teletext
