A31170 - Hand blender Turmix - Free user manual and instructions

Product Type	Immersion Blender
Brand	Turmix
Model	A31170
Power	700 W
Speeds	2 speeds + Turbo
Shaft Material	Stainless steel
Bowl Capacity	1 L (bowl included)
Included Accessories	Blending shaft, measuring cup, whisk
Dimensions (L x W x H)	40 x 8 x 8 cm
Weight	1.2 kg
Cable length	1.5 m
Power supply	220-240 V, 50/60 Hz
Main functions	Blend, emulsify, whisk
Care and cleaning	Removable shaft, dishwasher safe
Safety	Automatic shut-off in case of overheating
Spare parts and repairability	Replacement shaft available
Warranty	2 years

Frequently Asked Questions - A31170 Turmix

How to use the Turmix A31170 immersion blender?

Insert the shaft into the motor block until it clicks. Immerse the shaft into the food, then press the desired speed button. Use the Turbo function for maximum power.

Is the measuring cup included?

Yes, a 1 L plastic measuring cup is provided with the appliance.

Can I blend hot liquids?

Yes, but do not exceed 80 °C to avoid risk of burns and damage to the bowl.

How to clean the blender shaft?

Detach the shaft from the motor block and rinse it under running water. You can also wash it in the dishwasher (top rack). Never immerse the motor block in water.

What to do if the appliance stops working?

Check that the plug is properly connected. If the appliance stopped automatically, let it cool down for 10 minutes before using it again.

Can I crush ice with this blender?

No, this model is not designed for crushing ice. Use it only for soft or liquid foods.

What is the power of the appliance?

The Turmix A31170 immersion blender has a power of 700 W.

How many speeds does it offer?

It has 2 speeds and a Turbo function for precise control.

Is the whisk suitable for whipping egg whites?

Yes, the included whisk can whip egg whites, whipping cream, and light sauces.

Where to find spare parts?

Contact Turmix customer service or visit the official website to order a replacement shaft or other accessories.

USER MANUAL A31170 Turmix

DIE NEUEN TURMIX KÜCHENGERÄTE WURDEN VON FÜHRENDEN SCHWEIZER INGENIEUREN UND DESIGNERN ENTWICKELT. SIE WERDEN MIT GRÖSSTER SORGFALT IN DER SCHWEIZ VON HAND GEFERTIGT.

IHR NEUER TURMIX STABMIXER IM DETAIL

DE

ANWENDUNG

KALTE GURKENSUPPE

KÜRBISSUPPE

SCHLAGSAHNE

REINIGUNG

AUFSATZ ABWASCHEN

Fuss reinigen

SICHERHEITSHINWEISE

ENTSORGUNG

CHÈRE CLIENTE, CHER CLIENT

VOTRE NOUVEAU MIXER-PLONGEUR TURMIX EN DÉTAIL

APPLICATION

CHOISIR L'ACCESSOIRE APPROPRIÉ

TRAVAILLER EN MÉNAGEANT L'APPAREIL

POTAGE GLACÉ AUX CONCOMBRES

SOUPE À LA COURGE

CRÈME CHANTILLY

NETTOYAGE

LAVEZ L'ACCESSOIRE

NETTOYER LE PIED

NETTOYER LA POIGNÉE AVEC UN CHIFFON HUMIDE

CONSIGNES DE SÉCURITÉ

MISE AU REBUT

I NUOVI APPARECCHI DA CUCINA TURMIX SONO STATI STUDIATI DA INGEGNERI E DESIGNER SVIZZERI DI PRIM'ORDINE E SONO REALIZZATI MANUALMENTE IN SVIZZERA CON GRANDISSIMA CURA.

GENTILE CLIENTE

IL SUO NUOVO FRULLATORE AD IMMERSIONE TURMIX IN DETTAGLIO

UTILIZZO

SCELTA DELL'ACCESSORIO GIUSTO

ACCENSIONE / SPEGNIMENTO DELL'APPARECCHIO

RISPETTO PER L'APPARECCHIO

MINESTRA DI ZUCCA

PANNA MONTATA

PANNA FRESCA (MAX. DEL GIORNO PRIMA)

BIANCO D'UOVO

PULIZIA

LAVAGGIO DELL'ACCESSORIO

PULIZIA DEL PIEDE

PULIRE IL MANICO CON UN PANNO UMIDO

AVVERTENZE DI SICUREZZA

SMALTIMENTO

THE NEW TURMIX KITCHEN APPLIANCES WERE DEVELOPED BY LEADING SWISS ENGINEERS AND DESIGNERS. THE APPLIANCES ARE MANUFACTURED BY HAND IN SWITZERLAND WITH THE UTMOST CARE.

The new range of appliances expresses the TURMIX philosophy of quality in every detail. The range meets the criteria for «best in class» for all the qualities you would expect of an excellent kitchen appliance: TURMIX products are ergonomically designed, completely user-friendly and extremely quiet. Clever technology specially developed for each type of appliance ensures efficient, smooth functioning. Many TURMIX innovations are patented.

Some of these build on tried-and-tested TURMIX technologies, adding new concepts to create optimised solutions. TURMIX kitchen appliances are the result of a combination of Swiss quality standards, decades of experience and a love of innovation. Together, these qualities bring passion to your cooking.

DEAR CUSTOMER,

Thank you for choosing a quality product from TURMIX.

Your new stick mixer has been developed by leading Swiss engineers and designers and has been carefully manufactured by hand in Switzerland.

The TURMIX stick mixer provides a helping hand to the discerning chef and is a must in any well-equipped kitchen. Only the best stick mixer will do for the best ingredients. The blender's powerful yet ultra-quiet motor is down to a special TUR-MIX design. The same applies to the TURMIX blade and the semi-open design of the mixer foot. The unique design means that there is virtually no splatter when using the TURMIX stick mixer, allowing you to blend foods perfectly in the container of your choice.

Please read through the safety instructions carefully before use. We wish you much enjoyment using your new stick mixer.

EN

53Overview

55Instruction

57Recipes

61Cleaning i

63Safety inst

Disposal / Guarantee / Specifications / Website

65

51Introductio

— ERGONOMIC SOFT-TOUCH HANDLE with wider end for a secure grip
— ERGONOMIC SPEED SWITCH for easy speed selection
FLOATING MOTOR SYSTEM AND SPECIAL TURMIX MOTOR for ultra-quiet operation and minimal vibration
CONTINUOUS LINEAR DESIGN for maximum immersion
THE SPECIAL TURMIX MIXER FOOT for optimal blending
— SPECIAL TURMIX TRIPLE BLADE ATTACHMENT for pureeing, grinding, blending and mixing
THE TURMIX WHIPPING BLADE for whipped cream and meringue

EN

INSTRUCTIONS FOR USE

IMPORTANT The plug of the appliance must be disconnected from the mains socket before removing or changing attachments.

CHOOSING THE RIGHT ATTACHMENT

Press the whipping blade or triple blade attachment in completely. Ensure that the driving pin is inserted completely into the circular groove. Due to the special design of the groove, the attachment cannot fall off when in operation. To remove the triple blade or whipping blade attachment, simply pull on it.

SWITCHING THE APPLIANCE ON AND OFF

Before use, insert the plug into the mains socket. To switch the appliance on, press the switch either gently (for the low speed setting) or more firmly (for higher speed). Switch the appliance off before removing it from the food mixture. After use, pull out the plug from the mains and let the appliance cool down before storing it away.

To avoid damaging the surface of the appliance, fold a hand towel several times and use this to dust between the edges of the pan / bowl and the stick mixer to tap off the remains of the food mixture. The handle casing is not waterproof. Please ensure that no liquids come into contact with the handle.

COLD CUCUMBER SOUP

Recipe for the triple blade attachment

1 dl WATER Heat up.

2 TSPS VEGETABLE Season, allow to cool, pour into measuring jug. STOCK

1 CUCUMBER, Peel, cut into pieces, add. APPROX. 400 g

1/4 PEPERONCINO Cut in halves, remove the cores, cut finely, add.

3 dl CURDLED MILK Add. 180 g NATURAL YOGHURT

A LITTLE SALT, Season, mix. Leave to cool. Serve soup. PEPPER, DILL

TIPS Garnish soup with finely cut small cubes of cucumber and dill. Serve with garlic bread, herb bread, crisp bread rolls or savoury crisps.

PUMPKIN SOUP

Recipe for the triple blade attachment

1 TABLESPOON OIL Heat up. OR BUTTER

1/2 ONION Prepare, cut, add. Immediately turn down to low level, steam while 600 g PUMPKIN stirring. POSSIBLY 1 GARLIC CLOVE SSIBLY 1 CARROT

3 - 4 dl WATER Add, heat up.

1 - ₂ TSPS SALT OR Season. Cook covered at low level (cooking time 20-30 mins). VEGETABLE STOCK Mix soup finely, possibly pass through sieve. Reheat. A LITTLE PEPPER

1/2 -1 dl CREAM Enhance. Serve soup.

TIPS Replace half of the water with 2½ dl coconut milk, season with curry. Serve with herb or garlic bread. Roast a few pumpkin seeds or croutons, scatter over the soup. Beat the cream, garnish the soup.

WHIPPED CREAM

Recipe for the whipping blade

FRESH (MAX. 1 DAY OLD) CREAM

Put cold cream in a high, narrow, completely dry container, turn on hand mixer with the whisk held slightly diagonally in it. While whisking move the hand mixer slowly up and down, until there is a fine-pored mass.

EN

BEATEN EGG WHITES

Recipe for the whipping blade

EGG WHITE

Put egg white in a high, narrow container, which is suitable for the quantity, turn on the hand mixer with the whisk held slightly diagonally in it.

1 TABLESPOON WATER

Add. During whisking move hand mixer slowly up and down, until there is a fine-pored mass.

CLEANING INSTRUCTIONS

IMPORTANT Disconnect the plug for the mains socket before cleaning the appliance or removing attachments.

CLEANING THE ATTACHMENTS

Remove the triple blade or whipping blade attachment by simply pulling on it. Clean it by hand and dry it carefully. The blades are sharp! Do not use any abrasive or caustic products or cleaning agents.

CLEANING THE FOOT

The foot is not removable. Wash it thoroughly under running water and dry it with a soft cloth. Do not use any abrasive or caustic products or cleaning agents.

USEFUL TIP If you have been using the appliance for foods without a high fat or oil content, an easy cleaning method is to dip the mixer foot in lukewarm water and switch the stick mixer on for approx. 10 seconds.

CLEANING THE HANDLE

The handle casing is not waterproof. Wipe the handle with a damp, non-abrasive cloth and dry it. Please ensure that no liquids come into contact with the handle.

SAFETY INSTRUCTIONS

This appliance is not to be used by persons (including children) with restricted physical, sensory or mental capacity or with a lack of experience or knowledge without supervision or prior instruction by a person responsible for their safety. Children are to be supervised to ensure they do not play with the appliance.

This appliance is intended for household use and not for business or commercial purposes. Never operate this appliance on an uneven surface or outdoors.

Never leave the appliance out unattended. When the appliance is not in use, switch it off and disconnect the plug from the mains socket. Allow the appliance to cool down before storing away.

Connect the appliance to properly installed sockets only, with the correct power rating (see rating plate on the appliance), ideally to a residual-current device (max. 30 mA). Do not use an extension cable.

Never operate damaged appliances or equipment (including damaged power cord). Do not disassemble the appliance yourself. All repairs must be carried out by properly qualified specialists only. Our service points can be found at www.TURMIX.com.

Never allow the power cord to hang loose. Do not unplug the appliance from the mains by pulling on the cable or with wet hands. Never place the power cord on hot surfaces and do not allow it to come into contact with fats or oils.

Pull out the plug from the mains socket before removing or attaching parts, before cleaning or maintenance and if the appliance is not functioning properly.

Never touch live parts.

For reasons of safety, only use accessories recommended or sold by the manufacturer.

If the appliance catches fire, extinguish the fire with a fire blanket only.

Never touch rotating parts or blades. Switch the appliance off, wait until it stops completely and pull out the mains plug before touching parts inside the appliance. Danger of injury!

The blades / grating discs are sharp! Be extremely careful when cleaning, including when the appliance is switched off.

Do not insert any objects or fingers into the appliance openings.

Do not cover the appliance openings or air vents. This can lead to overheating!

Never use the appliance near water or other liquids (bathtub, sink, etc.) and never expose it to rain or damp. If the appliance falls into water or liquid, pull out the mains plug before taking it out. The appliance must be checked by a qualified specialist before its next use.

When using the appliance on sensitive furniture, use a covering to protect it.

Only wash those parts in the dishwasher that are designated dishwasher-safe. For more information on this, see the section entitled «Cleaning».

Use of the appliance for anything other than its intended purpose, or incorrect operation, cleaning or repair renders the guarantee void and no liability will be assumed for any damage caused.

DISPOSAL

Before disposing of the appliance, make it unusable by cutting off the power cord.

This appliance is not suitable for disposal as domestic waste. Please dispose of it in accordance with the regulations that apply in your area.

GUARANTEE

We provide a 2-year guarantee from the date of purchase with TURMIX electrical household appliances. Improper handling or third-party interference with the appliance renders the guarantee void. Please be sure to retain your proof of purchase (receipt), which serves as proof of guarantee.

SPECIFICATIONS

Power

Sound pressure

Weight

Dimensions (W x H x L)

Power cord length (retractable coiled cable)

300 W

CA. 70 DBA

CA. 940 G

СА.60×60×370 MM

CA.430-1200MM

WEBSITE

To find out more about what TURMIX has to offer, please visit our website.

www.TURMIX.com
