HotDog Maker 292934 - Hot dog maker PRINCESS - Free user manual and instructions

Product type	Hot dog maker
Brand	Princess
Model	HotDog Maker 292934
Power supply	220-240 V, 50/60 Hz
Power	800 W
Capacity	Up to 2 hot dogs simultaneously
Material	Resistant plastic body, non-stick plates
Dimensions (L x W x H)	30 x 20 x 15 cm
Weight	1.5 kg
Color	White
Heating function	Double heating element for sausages and buns
Indicator light	Power and heating indicator light
Thermostat	Integrated thermostat for temperature maintenance
Care and cleaning	Clean with a damp cloth; non-stick plates easy to wipe
Safety	Anti-slip base and automatic shut-off in case of overheating
Spare parts and repairability	Spare parts available from the manufacturer
Warranty	2 years

Frequently Asked Questions - HotDog Maker 292934 PRINCESS

How to use the HotDog Maker Princess 292934?

Plug in the appliance, turn it on and wait for the indicator light to go off. Place the sausage in the designated compartment and the bun in the other. Close the lid and let it cook for a few minutes until desired doneness.

Can frozen sausages be used?

It is recommended to thaw the sausages before use for even cooking and to avoid damaging the non-stick plates.

How to clean the appliance after use?

Unplug the appliance and let it cool down. Clean the plates with a non-abrasive damp cloth. Never immerse the appliance in water.

Are the plates removable for cleaning?

The non-stick plates are fixed but easy to clean in place with a soft sponge. Do not use abrasive cleaners.

What to do if the appliance does not heat?

Check the power outlet and the switch. If the indicator light does not come on, contact Princess customer service for assistance.

Does the appliance turn off automatically?

Yes, the HotDog Maker is equipped with a safety feature that automatically shuts it off in case of overheating or after prolonged use.

How many hot dogs can I prepare at once?

The appliance can cook up to 2 hot dogs simultaneously, one for the sausage and one for the bun in each compartment.

Can the appliance be used to reheat already cooked hot dogs?

Yes, you can reheat pre-cooked hot dogs by placing them in the appliance for one to two minutes. Monitor to avoid burning.

Where to find spare parts?

Spare parts are available on the official Princess website or from authorized dealers. Contact customer service for more information.

What is the power of the appliance?

The HotDog Maker Princess 292934 has a power of 800 W, allowing fast and even cooking.

USER MANUAL HotDog Maker 292934 PRINCESS

Line drawing of a portable water heater with three cylindrical tubes and a circular vent, mounted on a base (no text or symbols)

B1

Line drawing of a portable food organizer with six cylindrical food items, no text or symbols present

B2

Line drawing of two elongated, oval-shaped objects with visible internal features (no text or symbols)

B3

Gefeliciteerd!

You have purchased a Princess product. Our aim is to provide quality products with a tasteful design and at an affordable price. We hope that you will enjoy this product for many years.

The appliance can be used by children from 8 years and above and by persons with a physical, sensory, mental or motorial disability, or lack of experience and knowledge if they are supervised or instructed on how to use the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and maintenance shall not be made by children unless they are older than 8 years and supervised. Keep the appliance and the mains cable out of the reach of children younger than 8 years.

Description (fig. A)

Your 292934 Princess hotdog maker has been designed for making hotdogs. The appliance is suitable for indoor use only. The appliance is suitable for domestic use only.

Hotdogs

Hotdogs are sausages served in a sliced bun. Hotdogs are often garnished with mustard, ketchup, mayonnaise, cheese, onions and/or sauerkraut.

1. On/off switch
2. On/off indicator
3. Water bowl
4. Steam jug
5. Lid
6. Heating pin

Initial use

Before you proceed, we need you to pay attention to the following notes:

- Make sure that there is sufficient space around the appliance to allow heat to escape and provide sufficient ventilation.

Clean the appliance. Refer to the section • "Cleaning and maintenance".

Clean the accessories. Refer to the section • "Cleaning and maintenance".

Use (fig. A & B)

Before you proceed, we need you to pay attention to the following notes:

• Before assembly or disassembly, switch off the appliance, remove the mains plug from the wall socket and wait until the appliance has cooled down.
• Be careful with hot steam to avoid burns. Hot steam can escape from the steam jug during the process.
• Do not remove the hotdogs from the steam jug with your hands. The hotdogs and the steam jug become very hot during use.
• Do not remove the hotdog buns from the heating pins with your hands. The hotdog buns and the heating pins become very hot during use.

Before you proceed, we would like you to focus your attention on the following notes:

• Do not use the appliance without water in the water bowl.
• Do not use the appliance when the lid is not placed on the steam jug.
• Do not exceed the maximum mark ("MAX") when you fill the water bowl.
• Only use cold water to fill the water bowl.
• Do not use carbonated water or other liquids to fill the water bowl.
• Do not put more than 10 hotdogs into the steam jug at the same time.
• If the hotdogs are ready, hold the protrusion of the lid to remove the lid from the steam jug.

Place the appliance on a stable and flat surface.

Fill the water bowl (3) with water up to the maximum mark ("MAX").

Place the steam jug (4) onto the water bowl (3).

Put the hotdogs into the steam jug (4).

Place the lid (5) onto the steam jug (4).

Insert the mains plug into the wall socket.

To switch on the appliance, set the on/off switch (1) to the "I" position. The on/off indicator (2) comes on.

After 8-10 minutes, the hotdogs are ready • for consumption:

• Hold the protrusion of the lid to remove the lid (5) from the steam jug (4).
• Use a fork to remove the hotdogs from the steam jug (4).

If you want to make more hotdogs, repeat the above steps.

Place the hotdog buns onto the heating · pins (6).

Bake the hotdog buns until the have a golden brown colour.

If you want to bake more hotdog buns, • repeat the above steps.

Place the hotdogs into the hotdogs buns as shown.

To switch off the appliance, set the on/off switch (1) to the "O" position. The on/off indicator (2) goes off.

Remove the mains plug from the wall socket.

Allow the appliance to cool down completely.

Cleaning and maintenance (fig. A)

The appliance must be cleaned after each use.

Before you proceed, we need you to pay attention to the following notes:

- Before cleaning or maintenance, switch off the appliance, remove the mains plug from the wall socket and wait until the appliance has cooled down.

- Do not immerse the appliance in water or other liquids.

Before you proceed, we would like you to focus your attention on the following notes:

- Do not use aggressive or abrasive cleaning agents to clean the appliance.

- Do not use sharp objects to clean the appliance.

- Do not clean the accessories in the dishwasher.

Regularly check the appliance for possible damage.

Clean the outside of the appliance with a soft, damp cloth. Thoroughly dry the outside of the appliance with a clean, dry cloth.

Clean the water bowl (3) and the heating pins (6) with a soft, damp cloth.

Thoroughly dry the water bowl (3) and the heating pins (6) with a clean, dry cloth.

- Clean the steam jug (4) and the lid (5) in soapy water. Rinse the steam jug (4) and the lid (5) under running water. Thoroughly dry the steam jug (4) and the lid (5) with a clean, dry cloth.

Storage

Put the appliance and the accessories in the original packaging.

Store the appliance with the accessories in a dry and frost-free place, out of the reach of children.

Safety instructions

General safety

• Read the manual carefully before use. Keep the manual for future reference.
• Only use the appliance and the accessories for their intended purposes. Do not use the appliance and the accessories for other purposes than described in the manual.
  • Children should be supervised to ensure that they do not play with the appliance.
• The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Do not use the appliance if any part or any accessory is damaged or defective. If a part or an accessory is damaged or defective, it must be replaced by the manufacturer or an authorised repair agent.

- Do not use the appliance near bathtubs, showers, basins or other vessels containing water.

Do not immerse the appliance in water or other liquids. If the appliance is immersed in water or other liquids, do not remove the appliance with your hands. Immediately remove the mains plug from the wall socket. If the appliance is immersed in water or other liquids, do not use the appliance again. This appliance is intended to be used in domestic and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed-and-breakfast type environments.

Electrical safety

Before use, always check that the mains voltage is the same as the voltage on the rating plate of the appliance.

Connect the appliance to an earthed wall • socket. If necessary, use an earthed extension cable of a suitable diameter (at least 3 x 1.5 mm ⁴ ).

For additional protection, install a residual current device (RCD) with a rated residual operating current that does not exceed 30 mA.

The appliance is not intended to be operated by means of an external timer or separate remote-control system.

Make sure that water cannot enter the contact plugs of the mains cable and the extension cable.

Always fully unwind the mains cable and the extension cable.

Make sure that the mains cable does not • hang over the edge of a worktop and cannot be caught accidentally or tripped over.

Keep the mains cable away from heat, oil and sharp edges.

Regularly check the mains cable and the • mains plug for signs of damage. Do not use the appliance if the mains cable or the mains plug is damaged or defective. If the mains cable or the mains plug is damaged or defective, it must be replaced by the manufacturer or an authorised repair agent.

Do not pull the mains cable to disconnect • the mains plug from the mains.

Disconnect the mains plug from the mains • when the appliance is not in use, before assembly or disassembly and before cleaning and maintenance.

Safety instructions for hotdog makers

Do not use the appliance outdoors.

Place the appliance on a stable and flat surface.

Place the appliance on a heat-resistant and splash-proof surface.

Do not place the appliance on a hob. Do not cover the appliance.

• Make sure that there is sufficient space around the appliance to allow heat to escape and provide sufficient ventilation.
• Make sure that the appliance does not come into contact with flammable material.
• Keep the appliance away from heat sources. Do not place the appliance on hot surfaces or near open flames.

Beware of hot parts. The surfaces marked with a caution symbol for hot surfaces are liable to become hot during use. The accessible surfaces can become hot when the appliance is operating. The outer surface can become hot when the appliance is operating.

- Do not touch the metal parts of the appliance during use. The metal parts become very hot during use.

Make sure that your hands are dry before touching the appliance.

Do not leave the appliance unattended during use.

- Do not move the appliance while it is switched on or is still hot. Remove the mains plug from the wall socket and wait until the appliance has cooled down.

U.K. Wiring instructions

The wires in the mains lead are coloured in accordance with the following code:

BLUE

NEUTRAL

BROWN

LIVE

GREEN/YELLOW

EARTH

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows:

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red.

The wire which is coloured GREEN/YELLOW must be connected to the terminal which is

marked with the letter E or ⏚ and is coloured GREEN or GREEN/YELLOW.

Warning! This appliance must be earthed.

Disclaimer

Subject to change; specifications can be changed without further notice.
