USER MANUAL IP-380D Imarflex

imarflex®

Electronic Airport

Exterior view of a modern rice cooker with a glass cup beside it (no visible text or symbols)

SPECIFICATION

Model No : IP-380D

Rated Voltage : 230Va.c. \~ 60Hz

Power Consumption : 750 Watts

Capacity : 3.8 Liters

IMPORTANT SAFEGUARDS

1. Read all instruction carefully.
2. Check the condition of the unit after taking out from the box. Ensure that all parts are in good conditions.
3. Before using the unit, check if the voltage indicated corresponds with the convenience outlet (230Va.c.).
4. Do not use two-way socket with other appliance.
5. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be replaced with the same type and size or bring the unit to the nearest authorized service center.
6. Do not attempt to repair, adjust or replace parts in the unit, it must be check and repair by authorized lmarflex technicians or by similar qualified person in order to avoid electrical hazard.
7. Do not place the unit near gas stove or electric burner.
8. Children should be supervised to ensure that they do not play with the appliance.
9. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliances by person responsible for their safety.
10. Do not close or cover the steam vent.
11. Do not use the airport other than its intended use.
12. Always place the airport in an open area, in order to allow steam to vaporize.
13. Do not push the Pressure Pump forcibly, as it may cause the hot water to flow out which can cause burns.
14. To prevent electric shock do not operate the unit by wet hands.
15. For household use only.
16. Save this instruction manual for future reference.

DESCRIPTION OF PARTS

Manual-pump Control Panel Lid Opening Button Water Level Indicator

HOW TO USE

1. Open the lid and pour in water. Do not fill the airport over the full water level indicator.

2. Plug the unit in the convenience outlet (230Va.c.). The Reboil indicator will turn ON and the water starts to heat up. If the Reboil indicator turns OFF, the Keep Warm indicator turns ON, it means the airport is in the state of preserving heat.

3. Before dispensing water, set the safety switch to OPEN position. After use, be sure to set the safety switch to CLOSE position.

4. To dispense water: 3 water dispensing to choose from:

a. Manual Pump: for manual water dispensing.

- Turn the Pressure Pump button to ON position and push it gently to dispense water, and then turn it to OFF position after use.

Note: Do not press the push Pressure Pump forcibly, as it may cause the hot water to flow out which can cause burns.

b. Auto Pump: for easy water dispensing.

c. Insta-pump: for one hand cup/mug dispensing.

Note: This airport has an automatic lock features. To dispense water press the Lock/Unlock button before pressing the auto pump or Insta-pump button.

CLEANING AND MAINTENANCE

1. Unplug the unit from the convenience outlet. Let it cool and remove any remaining water from the unit.

2. Remove the Lid and wash it with soap and water.

3. Discoloring of water tank:

This is caused by oxidizing of iron content in tap water. It can be removed by using nylon brush and follow these simple steps:

a. Fill the airport with water and 1/3 of vinegar up to max level.
b. Let the mixture remain inside the airport for overnight.
c. Discard the mixture and rinse the airport thoroughly.
d. Pour the airport with water and let it boil. Discard the water to remove the odor of the vinegar.
e. Rinse the airport thoroughly.
f. Repeat the procedures "d" and "e" until the odor of the vinegar completely remove.

1. Do not allow the Control Panel to become wet.
2. Wipe the Body and the Control Panel using damp cloth and wipe it dry.
3. Do not use abrasive materials to avoid scratches.
4. Do not immerse the unit in water or other liquids.
