IP-320D - Kitchen Appliances Imarflex - Free user manual and instructions

Product Type	Hot Water Dispenser (Airpot)
Brand	Imarflex
Model	IP-320D
Capacity	3.2 Liters
Rated Voltage	230 V a.c., 60 Hz
Power Consumption	750 Watts
Water Dispensing	Auto-pump and instant pump
Keep Warm Function	Yes (automatic after boiling)
Reboil Function	Yes (one-touch reboil button)
Indicators	Power/Boil indicator, Keep Warm indicator
Lid	Removable for cleaning
Steam Vent	Do not cover
Cleaning	Descale with vinegar; wash lid with soap; wipe body with damp cloth
Safety	Do not immerse in water; do not use with wet hands
Usage	Household use only
Recommended Descaling	Overnight soak with water and 1/3 vinegar
Water Level	Do not fill above maximum level indicator
Cord	Replace with same type if damaged

Frequently Asked Questions - IP-320D Imarflex

How do I dispense water from the IP-320D?

Place your cup under the spout. For auto-pump, press the Dispense button gently. For instant pump, touch the cup to the instant pump switch. Water will automatically dispense.

What does the Keep Warm function do?

After the water boils, the Keep Warm indicator turns on and the unit maintains the water temperature, keeping it hot for serving.

Can I reboil the water?

Yes, press the Reboil button. This will turn off the Keep Warm indicator and restart the boiling process.

How should I clean the airpot?

Unplug the unit and let it cool. Remove the lid and wash it with soap and water. For the water tank, use a mixture of water and 1/3 vinegar, let it sit overnight, then rinse thoroughly. Wipe the body and control panel with a damp cloth.

Why is my water tank discolored?

Discoloration is caused by oxidation of iron in tap water. Clean with a vinegar solution as described in the cleaning section to remove stains.

Can I use the IP-320D for beverages other than water?

No, this appliance is designed for water only. Using other liquids may damage the unit or cause safety hazards.

Is the lid removable?

Yes, the lid is removable for thorough cleaning. Simply lift it off after unplugging and cooling.

What should I do if the power cord is damaged?

If the cord is damaged, it must be replaced with the same type and size. Bring the unit to an authorized service center for repair.

Can children use this appliance?

This appliance is not intended for use by children or persons with reduced capabilities without supervision. Keep out of reach of children and supervise them if near the unit.

How can I prevent damage to the airpot?

Always do not cover the steam vent, avoid immersing the unit in water, use on a flat surface, and do not operate with wet hands.

USER MANUAL IP-320D Imarflex

SPECIFICATION

Model No : IP-320D

Rated Voltage : 230Va.c. 60Hz

Power Consumption : 750 Watts

Capacity : 3.2 Liters

IMPORTANT SAFEGUARDS

1. Read all instruction thoroughly.
2. Check the condition of the unit after taking out from the box. Ensure that all parts are in good condition.
3. Before using the unit, check if the voltage indicated corresponds with the convenience outlet (230Va.c.).
4. Do not use two-way socket with other appliance.
5. Do not use any appliance with a damaged cord or plug. If the cord is damaged, it should be replaced with the same type and size or bring the unit to the nearest authorized service center.
6. Do not attempt to repair, adjust or replace parts in the unit, it must be checked and repaired by an authorized lmarflex technician or by a similar qualified person in order to avoid electrical hazard.
7. Do not place the unit near gas stove or electric burner.
8. Children should be supervised to ensure that they do not play with the appliance.
9. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliances by person responsible for their safety.
10. Do not close or cover the steam vent.
11. Do not use the airport other than its intended use.
12. Always place the airport in an open area, in order to allow steam to vaporize.
13. To prevent electric shock do not operate the unit with wet hands.
14. For household use only, not intended for any business purpose.
15. Save this instruction manual for future reference.

HOW TO USE

1. Open the lid and pour in water. Do not fill the airport over the full water level indicator.

2. Plug the unit in the convenience outlet (230Va.c.). The Power and Boil indicator will turn ON and the water will start to heat up. If the Boil indicator turns OFF, the Keep Warm indicator will turn ON, it means the airport is in the state of preserving heat. If Reboil button is pressed, Keep Warm Indicator will turn OFF and the Boil indicator will turn ON.

3. To dispense water: 2 water dispensing options to choose from:

a. Auto-pump: for easy water dispensing.

1. Place the cup under the spout.
2. Press the Dispense button gently. Water will automatically dispense.

b. Instant Pump: for one hand cup/mug dispensing.

1. Place the cup under the spout touching the instant pump switch.

2. Water will automatically dispense.

3. Place the cup under the spout touching the instant pump switch.

4. Water will automatically dispense.

CLEANING AND MAINTENANCE

1. Unplug the unit from the convenience outlet. Let it cool and remove any remaining water from the unit.

2. Remove the Lid and wash it with soap and water.

3. Discoloring of water tank:

This is caused by oxidizing of iron content in tap water. It can be removed using nylon brush and by following these simple steps:

a. Fill the airport with water and 1/3 of vinegar up to max level.

b. Let the mixture remain inside the airport for overnight.

c. Discard the mixture and rinse the airport thoroughly.

d. Pour the airport with water and let it boil. Discard the water to remove the odor of the vinegar.

e. Rinse the airport thoroughly.

f. Repeat the procedures "d" and "e" until the odor of the vinegar is completely removed.

1. Do not allow the Control Panel to become wet.

2. Wipe the Body and the Control Panel using damp cloth and wipe it dry.

3. Do not use abrasive materials to avoid scratches.

4. Do not immerse the unit in water or other liquids.
