USER MANUAL KSNMBPUG KitSound

Do not dispose of Lithium Polymer batteries with general waste. Please return it to battery recycling collection point

Li-PO

JB. 2587 / Made in China. © KitSound™ 2013 Christchurch, Dorset. BH23 4FL

KITSOUND

MINI BUDDY PORTABLE SPEAKER

Manual

Close-up of a multi-pin electronic circuit board with black and silver components (no visible text or symbols)

We are craftspeople. We are musicians. We are KitSound ^TM

And we all commit ourselves to achieving one shared goal: Bringing people closer to their music. By truly understanding music we stay true to its craft. Pure, rich, incredible sound. We'll settle for nothing less.

At KS we believe your music deserves to be showcased on great quality products that don't cost the earth. We might not all share the same taste in music (the ferocious disputes on music forums prove that), but whether it's Irish folk, death metal or any number of obscure genres which seem to be multiplying by the minute, the artists responsible for connecting with you through their craft have bared their souls to do so. And we think that's worth celebrating.

Crowd silhouettes raising hands at a concert with dramatic lighting (no text or symbols visible)

Close-up of hexagonal cells with a honeycomb pattern, no text or symbols visible

Like the musicians we're honouring, we're obsessed with our craft; fine-tuning and tweaking our products to make sure we constantly deliver full-bodied, symphonic sound. So from a single note played on a piano, to the full impact of a bass guitar, you can rest assured that you'll always be doing justice to your music.

Box contents

• Mini Buddy
• USB charge cable
  • Keyring attachment
• Instruction manual

Charging the battery

The Mini Buddy has a built-in rechargeable lithium battery. Before charging, make sure that the Mini Buddy is switched off. Connect one end of the USB power cable to the charging port of the Mini Buddy and connect the other end to your PC or USB mains adaptor. The battery will start charging automatically.

Note:

• It takes 3 hours to fully charge the battery
• Whilst charging, the LED will show blue
• When fully charged, the LED will not change colour. However a 3 hour charge is sufficient to fully charge the battery

using the speaker

1. Plug the 3.5 mm cable that is attached to the Mini Buddy into the 3.5 mm socket of your device
2. Switch on the speaker
3. Use your connected device to play music/video and to control volume level

Buddy pairing

If you have more than one Mini Buddy speaker, you can pair them together for greater sound. To do this:

• Connect the 3.5 mm cable from one Mini Buddy speaker to the 3.5 mm socket on another Mini Buddy speaker. This can be repeated as many times as you like
• Connect the remaining 3.5 mm cable to your device to play your music/video's through all connected Mini Buddies

Other information

Your device will have an internal amplifier and if it is playing digital files like MP3's it will also have an integrated DAC (Digital Audio Converter). If you turn the volume up to 100%, your device will be sending a distorted signal. To avoid this and get the best quality from the speaker, we recommend you do not run your device any higher than 95% volume. Some devices output higher than others so you may need to reduce the volume if you experience distortion.

Care and maintenance

Wipe the unit with a soft dry dust cloth.

Do not use any wax, spray polish or abrasive cleaners on them.

Caution:

Never allow any water or other liquids to get inside the unit while cleaning.

Specifications

• Frequency response: 100 hz–20 kHz
- Driver unit: 36 mm
- Impedance: 4 ohms
- Battery type: Li-Po rechargeable
- Jack plug: 3.5 mm

Troubleshooting

We hope you've now got all the information you need to get started, but if you're having problems with anything, please feel free to contact us at: [e-mail]
