Product Type	Portable Air Conditioner
Cooling Capacity	12000 BTU/h
Dimensions (W x D x H)	30 cm x 30 cm x 70 cm
Weight	25 kg
Power Supply	220-240 V ~ 50 Hz
Power Consumption (Cooling)	1200 W
Refrigerant Type	R410A
Noise Level	55 dB (low speed)
Air Flow Rate	350 m³/h
Operating Modes	Cool, Fan, Dehumidify, Sleep
Timer Function	1-24 hours
Remote Control	Included
Filter Type	Washable mesh filter
Filter Maintenance	Clean every 2 weeks
Water Tank Capacity	1.5 L
Auto Water Evaporation	Yes (partial)
Safety Features	Overheat protection, auto shut-off
Warranty	2 years
Included Accessories	Window kit, remote control, manual
Climatic Class	T1 (temperate)

Frequently Asked Questions - Aircon Sensiplast

How do I install the Sensiplast Aircon?

Install the exhaust hose and window sealing kit as per the manual. Ensure the unit is level and the air intake is unobstructed. Plug into a grounded outlet.

Can I use the Aircon in a room without a window?

The unit requires exhaust venting to the outside. Without a window, you can use a sliding door or a wall vent. Otherwise, it will not cool effectively.

How do I clean the filter?

Turn off and unplug the unit. Open the filter cover, remove the mesh filter, and wash with lukewarm water. Allow to dry completely before reinstalling. Clean every 2 weeks.

Why is my air conditioner not blowing cold air?

Check if the filter is dirty, the exhaust hose is blocked or kinked, or the unit is in Fan mode. Also ensure the room is not too large for the cooling capacity.

How often should I empty the water tank?

In humid conditions, the tank may fill every 4-6 hours. The unit will stop cooling when full. You can also attach a drain hose for continuous drainage.

What does the 'Sleep' mode do?

Sleep mode gradually increases the temperature by 1-2°C over a few hours to save energy and prevent overcooling while you sleep.

Can I use an extension cord?

It is not recommended. Use a dedicated wall outlet. If necessary, use a heavy-duty extension cord with a rating of at least 15 amps, but ensure the cord is fully uncoiled.

How do I set the timer?

Press the Timer button on the remote or control panel. Use +/- to set hours (1-24). Press Timer again to confirm. The unit will turn on/off at the set time.

What is the recommended room size?

The 12000 BTU model is suitable for rooms up to 20-25 m². For larger rooms, cooling performance may be insufficient.

How do I reset the unit if it shows an error code?

Turn off the unit, unplug it for 5 minutes, then plug back in and restart. If the error persists, consult the manual or contact customer support.

USER MANUAL Aircon Sensiplast

FASCIA PER LA COSCIA AIRCON

IT MT

FASCIA PER LA COSCIA AIRCON

Circular grayscale illustration of a person in a suit and tie, no text or symbols present

Illustration of a hand adjusting a black wrist strap, no text or symbols present

Circular diagram showing a dark object with internal structure, possibly a device or component, against a light background (no text or symbols)

Tested Medical Device Safety Regular Production Surveillance

www.juy.com

HORIZONTE TEXTIL GMBH

REF 309675 Rev. 2018/33
