USER MANUAL CRMR60 Hoshizaki
Commercial Series Refrigerated Kitchen Equipment
Models Undercounter, Worktop, Prep Table CRM_27, CRM_36, CRM_48, CRM_60, CRM_72
CONTENTS
Auxiliary Codes....3
Model Codes 12
A. Main Assembly 13
CRMR27 and CRMF27 Undercounter, Worktop, and Prep Table 13
CRMR36 Undercounter, Worktop, and Prep Table 16
CRMR48 and CRMF48 Undercounter, Worktop, and Prep Table 18
CRMR60 and CRMF60 Undercounter, Worktop, and Prep Table 22
CRMR72 Undercounter, Worktop, and Prep Table 26
B. Refrigeration Circuit....30
CRMR27 Undercounter, Worktop, and Prep Table 30
CRMF27 Undercounter and Worktop 32
CRMR36 Undercounter, Worktop, and Prep Table 34
CRMR48 Undercounter, Worktop, and Prep Table 36
CRMF48 Undercounter and Worktop 38
CRMR60 Undercounter, Worktop, and Prep Table 40
CRMF60 Undercounter and Worktop 42
CRMR72 Undercounter, Worktop, Prep Table 44
C. Door-Right Hinged 46
D. Door-Left Hinged 48
E. Drawer 50
F. Accessories & Labels 52
