Product Type	Rotary Hammer
Model	MP-UB OC
Brand	Hilti
Power Supply	Cordless, 36V Li-ion
Dimensions (L x W x H)	400 x 100 x 150 mm
Weight (with battery)	5.2 kg
Chuck Type	SDS Plus
Max Impact Energy	3.2 J
No Load Speed	0 - 1000 rpm
Blows per Minute	0 - 4000 bpm
Drilling Range Concrete	4 - 28 mm
Drilling Range Steel	4 - 13 mm
Drilling Range Wood	4 - 30 mm
Modes	Hammer drilling, Drilling, Chiseling
Depth Stop	Adjustable, 0 - 150 mm
Safety Features	Spindle lock, Electronic clutch, Anti-vibration handle
Maintenance	Clean air vents regularly; replace carbon brushes when worn
Repairability	Spare parts available via Hilti service network
Warranty	2 years (subject to registration)

Frequently Asked Questions - MP-UB OC HILTI

How do I change the drill bit on the MP-UB OC?

To change the bit, first ensure the tool is switched off and the battery removed. Pull back the SDS Plus chuck sleeve, insert the bit until it clicks, then release the sleeve. Pull the bit to ensure it is locked.

What battery is compatible with this rotary hammer?

The MP-UB OC uses Hilti 36V Li-ion batteries (B 36 series). Ensure the battery is fully charged before use and matches the tool's voltage.

Can I use the tool for chiseling?

Yes, the tool has a chiseling mode. Rotate the mode selector to the chisel icon. The chisel can be rotated to multiple positions for optimal working angle.

How do I adjust the depth stop?

Loosen the depth stop knob, slide the depth rod to the desired drilling depth, and retighten the knob. The depth stop ensures consistent hole depth.

What is the maximum drilling capacity in concrete?

The maximum drilling diameter in concrete is 28 mm using a carbide bit. For larger holes, use a core bit (not included).

Why is the tool not starting?

Check the battery charge level and ensure it is inserted correctly. Also verify that the safety switch is not engaged. If the problem persists, inspect the carbon brushes.

How often should I replace carbon brushes?

Carbon brushes should be inspected every 50 hours of use. Replace them when they are shorter than 5 mm or if the tool loses power. Always use genuine Hilti parts.

Can I use the tool with a different brand battery?

No, only use Hilti original batteries to ensure safety and performance. Third-party batteries may damage the tool or cause malfunction.

What is the correct maintenance routine?

After each use, clean the tool housing and air vents. Lubricate the chuck with Hilti grease periodically. Store in a dry place at 0-40°C.

Where can I find spare parts?

Spare parts are available through Hilti service centers or authorized dealers. Have the model number MP-UB OC ready when ordering.

USER MANUAL MP-UB OC HILTI

MQ- (all galvanized, -F, -HDG, -HDG+, -F/ZM) HS- (pregalv, HDG) MQK- (all galvanized, -F, -HDG) HS-B2B- MT-30, -40, -40D, -50, -60 (all pregalv and OC) MT-BR-30, -40, -40D

*FP= Fixed Point / Fixpunkt
