KC24 - Sink CDA - Free user manual and instructions

Product Type	Sink
Brand	CDA
Model	KC24
Material	Ceramic or Stainless Steel
Dimensions (W x D x H)	Approximately 600 x 450 x 200 mm
Weight	Approximately 8 kg
Power Supply	Not applicable (no electrical components)
Installation Type	Drop-in or Undermount
Number of Bowls	1
Drain Connection	Standard 1.5 inch drain included
Water Supply Connection	Via separate faucet (not included)
Usage	Hand washing and light cleaning
Maintenance	Clean with mild detergent and soft cloth; avoid abrasive cleaners
Safety Precautions	Ensure secure mounting to prevent tipping; do not stand in sink
Spare Parts	Drain assembly and mounting brackets available
Repairability	Drain and faucet components are replaceable
Warranty	Standard manufacturer warranty (varies by region)

Frequently Asked Questions - KC24 CDA

What is the material of the CDA KC24 sink?

The CDA KC24 sink is typically made of ceramic or stainless steel. Check your specific model for details.

What are the dimensions of the KC24 sink?

The approximate dimensions are 600 mm wide, 450 mm deep, and 200 mm high. Always measure your cabinet space before installation.

How do I install the KC24 sink?

Installation can be drop-in or undermount. Ensure the countertop cutout matches the sink dimensions, apply sealant, and secure with brackets. Detailed steps are in the manual.

Does the sink come with a faucet?

No, the CDA KC24 sink does not include a faucet. Faucets are sold separately.

How do I clean the KC24 sink?

Use a mild detergent and a soft cloth. Avoid abrasive cleaners or scouring pads to prevent scratches.

Is the sink resistant to stains and heat?

Ceramic sinks are generally stain-resistant and can withstand moderate heat, but avoid placing hot pans directly on the surface.

What is the weight of the KC24 sink?

The weight is approximately 8 kg (17.6 lbs). Ensure your countertop can support this weight.

Can I replace the drain assembly?

Yes, the drain assembly is replaceable. Standard 1.5 inch drain parts are compatible.

Is the sink suitable for outdoor use?

The CDA KC24 is designed for indoor use. Exposure to extreme weather may damage the finish or structure.

Where can I get spare parts for the KC24?

Spare parts such as drain kits and mounting brackets are available from CDA or authorized dealers. Contact support for specific parts.

USER MANUAL KC24 CDA

Taking Care of your Sink

During installation, protect the sink from scratches, scuffs and other damage.

Do not overtighten or strain plumbing fittings.

The moulding and edges of the sink must be absolutely level so water flows off the drainer.

Your CDA ceramic sink features the natural characteristics of fireclay ceramics. The dimensions may very from the specification due to the manufacturing process, as each sink is made by hand.

Due to the nature of the manufacturing process and the materials from which it is made, small blemishes will be evident on the surface of the ceramic finish. These blemishes are under the glaze; they are inherent properties and are in no way detrimental to the performance of the sink – they are consistent with the traditional appeal of hand-made fireclay sinks.

Your CDA sink is manufactured using material developed specifically to withstand the rigours of everyday kitchen use. However, we advise you to follow these precautions to keep the sink in pristine condition:

• Avoid dropping heavy, sharp or metallic objects into the sink as they may scratch or damage the surface.
• Do not use abrasive liquids, powders or steel pads to clean the sink as they will damage the sink surface and make it more susceptible to staining. The sink may be cleaned with a dilute bleach solution.
• Do not use a plastic washing-up bowl in the sink as grit and other particles may become embedded in the bowl and scratch or erode the sink surface.
• The surface of the sink can be affected by certain chemicals e.g. neat bleach, nail polish remover, paint stripper, solvents, brush cleaner and insecticides. If any of these substances come into contact with the sink, wipe off immediately with a dry cloth, wash with mild detergent and rinse with water.
• Do not use neat bleach or other harsh cleaning agents on the metal sink waste as this may cause tarnishing. This is especially important if the waste is of the brass/brass finish type.
• Do not place very hot objects directly on the sink, place them on a special surface (board) made from wood or plastic, etc.
  • Particularly stubborn organic stains can be removed effectively by soaking the sink in a biological washing-powder solution, dishwasher powder solution or a dilute bleach solution.
  • If the sink comes into contact with acidic materials, rinse immediately with plenty of water and wipe with a soft dry cloth.
• Do not leave rusty objects in contact with the sink. Rust can cause staining, cracking or even permanent damage to the sink surface.
• To avoid staining of the surface do not leave food or other materials with corrosive properties such as juices, salt, vinegar, mustard etc. on the sink for a long time.
  • After using the sink, rinse it clean with warm soapy water and rinse with clean water before wiping dry.

This Guarantee is Valid Providing that

• The product has been installed by a suitably qualified person.
• Installation has been carried out in accordance with instructions and current legislation.
• Proof of purchase can be produced.
• The product has been used for domestic purposes only.
• The product has not been tampered with or repair attempted or modified by any unauthorised person.
• All products have been installed in accordance local water by laws and any building regulations in force

This Guarantee does not Cover

• Damage by misuse, neglect or transit.
• Use of parts not used or recommended by CDA.
• Routine maintenance, general wear ∅ tear and installation faults.
• Products used for commercial or professional purposes.

Your sink is guaranteed against defects in materials and/or workmanship for 5 years. At the discretion of CDA, should a fault arise the sink may be repaired or replaced and agreed refitting may be reimbursed on receipt on a faulty sink/part, once they have been inspected and deemed faulty.
