| Product Type | 4-Port VGA Video Switch with Audio |
| Ports | 4 x VGA input, 1 x VGA output, 4 x 3.5mm stereo audio input, 1 x 3.5mm stereo audio output |
| Maximum Resolution | 1920 x 1200 @ 60Hz |
| Video Bandwidth | 350 MHz |
| Audio Support | Stereo audio switching, supports line-level audio |
| Switching Method | Front panel push buttons, IR remote control (optional), RS-232 control |
| Power Supply | External power adapter, 5V DC, 2A |
| Power Consumption | 5W max |
| Dimensions (W x D x H) | 200 x 75 x 45 mm (7.87 x 2.95 x 1.77 in) |
| Weight | 0.5 kg (1.1 lbs) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | 0–80% RH, non-condensing |
| Enclosure Material | Metal chassis |
| Connection Cables | VGA (HD-15) male-to-male, 3.5mm audio cable (not included) |
| Controls | 4 x source selection buttons, 1 x power LED |
| Indicators | LED for power and selected source |
| Compliance | FCC, CE |
| Maintenance | Clean with a soft, dry cloth. Do not use liquids or cleaners. |
| Safety | Keep away from moisture and excessive heat. Use only the supplied power adapter. |
| Repairability | No user-serviceable parts. Contact ATEN technical support for repairs. |
Frequently Asked Questions - VE814A ATEN
How do I connect multiple computers to the VE814A?
Connect each computer's VGA output and audio output to the corresponding input ports on the switch. Then connect the output port to your display and speakers.
What is the maximum resolution supported?
The VE814A supports resolutions up to 1920 x 1200 at 60Hz.
Does the switch support audio?
Yes, it supports stereo audio switching via 3.5mm jacks. Audio follows the selected video source.
How do I switch between sources?
You can press the front panel buttons corresponding to each input, or use an optional IR remote control or RS-232 commands.
Can I use the switch with a projector?
Yes, as long as the projector has a VGA input and supports the resolution, you can use the VE814A.
Does the switch require external power?
Yes, it requires the included 5V DC power adapter. The unit may not work without power.
What cables are needed?
You need VGA cables (HD-15 male-to-male) for video and 3.5mm audio cables. These are not included.
Is the VE814A compatible with Mac or Linux?
Yes, it is platform-independent because it switches analog signals. No drivers required.
How do I clean the device?
Use a soft, dry cloth to wipe the surface. Avoid liquids or abrasive cleaners.
What should I do if the switch is not working?
Check power connection, cable integrity, and ensure the display is set to the correct input. If issues persist, contact ATEN support.
