SMDWB/E07-941 - Microphone Lectrosonics - Free user manual and instructions
Find the device manual for free SMDWB/E07-941 Lectrosonics in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Wireless Microphone System - Bodypack Transmitter |
| Brand | Lectrosonics |
| Model | SMDWB/E07-941 |
| Wireless Technology | UHF Digital Hybrid Wireless |
| Frequency Range | 470.100 – 607.900 MHz (Block 07) |
| RF Output Power | 100 mW (selectable to 50 mW) |
| Battery Type | 2 x AA Alkaline or rechargeable (Lithium-ion optional) |
| Battery Life | Up to 8 hours with alkaline batteries |
| Audio Input | Servo bias lavaliere or headset microphone with locking TA5F connector |
| Dimensions | 3.1 x 2.4 x 0.8 inches (79 x 61 x 20 mm) |
| Weight | 4.5 oz (128 g) with batteries |
| Modulation | Digital Hybrid (compatible with analog receivers) |
| Frequency Selection | 256 selectable frequencies per block |
| Operating Range | Up to 300 feet (90 m) line of sight |
| Audio Frequency Response | 50 Hz – 20 kHz (±1 dB) |
| Dynamic Range | 108 dB (A-weighted) |
| Power Output | 100 mW (max) |
| Compatibility | Compatible with Lectrosonics Venue, SR, and 200 series receivers |
| Included Accessories | Belt clip, antenna, and manual |
Frequently Asked Questions - SMDWB/E07-941 Lectrosonics
How do I synchronize the SMDWB/E07-941 transmitter with my receiver?
Press the SYNC button on the receiver while holding the transmitter within 3 feet. The receiver will automatically set the frequency and compatibility mode.
What type of batteries does the SMDWB/E07-941 use?
It uses two AA alkaline batteries. For longer life, you can use rechargeable NiMH or optional lithium-ion battery packs.
Can I use this transmitter with a non-Lectrosonics receiver?
The SMDWB uses Lectrosonics' Digital Hybrid technology, but can operate in analog mode for compatibility with many analog UHF receivers. Check receiver compatibility.
How do I adjust the audio gain on the transmitter?
Use a small screwdriver to adjust the GAIN control on the side of the unit. It is calibrated in dB increments for precise setting.
What is the maximum operating range of this transmitter?
Under optimal conditions, the range is up to 300 feet (90 meters) line of sight. Actual range depends on obstacles and interference.
How do I change the frequency on the SMDWB?
Turn off the unit, then press and hold the SET button while powering on. Use the arrow keys to select a frequency from the 256 available channels.
Is the SMDWB/E07-941 waterproof?
No, it is not waterproof. It has a weather-resistant housing, but should be protected from rain and moisture.
What lavaliere microphones are compatible?
It accepts any servo bias lavaliere with a TA5F connector, such as the Lectrosonics M152 or DPA 4060 series.
How do I clean the transmitter?
Wipe the exterior with a dry, soft cloth. Do not use solvents or immerse in water. Clean the connectors with a dry toothbrush.
What does the 'E07-941' in the model number mean?
'E07' indicates the frequency block (Block 07: 470-518 MHz) and '941' is a factory preset frequency within that block.
