| Product Type | Digital Scale |
| Brand | Cardinal Detecto |
| Model | APS70 |
| Capacity | 70 kg (154 lb) |
| Readability | 0.1 kg / 0.2 lb |
| Platform Size | 12 x 14 inches (30.5 x 35.6 cm) |
| Display | LCD, 1 inch high digits |
| Power Source | AC adapter (included) or 6 x AA batteries |
| Auto Off | Yes, after 60 seconds of inactivity |
| Tare Function | Yes, subtracts container weight |
| Units | kg, lb, oz |
| Calibration | User calibration with known weight |
| Platform Material | Stainless steel |
| Housing Material | ABS plastic |
| Overall Dimensions | 14 x 16 x 3 inches (35.6 x 40.6 x 7.6 cm) |
| Net Weight | 6.5 lb (2.9 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Cleaning | Wipe with damp cloth; mild detergent |
| Safety | Overload protection, low battery indicator |
| Certifications | NTEP, OIML (varies by region) |
| Replacement Parts | Available via Cardinal Detecto |
| Warranty | 1 year limited |
Frequently Asked Questions - APS70 Cardinal Detecto
How do I calibrate the APS70 scale?
To calibrate, press and hold the CAL button until 'CAL' appears. Place a known weight (e.g., 20 kg) on the platform. The scale will auto-calibrate and return to weighing mode.
What do the error codes mean?
Common errors: Err 1 = overload, Err 2 = unstable weight, Err 3 = low battery. Clear the platform or replace batteries.
Can I use the scale on an uneven surface?
No, the scale must be placed on a flat, hard, level surface for accurate readings. Avoid carpets or soft floors.
How do I change the battery?
Remove the battery compartment cover on the bottom. Insert 6 x AA batteries following polarity marks. Use alkaline for best performance.
Why does the display show 'LO'?
'LO' means low battery. Replace all batteries with fresh ones. If using AC adapter, ensure it's plugged in securely.
How do I clean the scale?
Wipe the platform and housing with a damp cloth and mild soap. Do not immerse in water or use abrasive cleaners. Dry thoroughly.
What is the maximum weight capacity?
The maximum capacity is 70 kg (154 lb). Exceeding this may damage the scale and void warranty.
Can I use the scale for commercial purposes?
Yes, the APS70 is designed for light commercial use. It holds NTEP and OIML approvals where applicable.
How do I switch between kg and lb?
Press the UNIT key to toggle between kilograms (kg), pounds (lb), and ounces (oz). The current unit appears on display.
Where can I get replacement parts or service?
Contact Cardinal Detecto customer service or visit cardet.com for authorized service centers and parts.
