Z35 - Headphones SAMSON - Free user manual and instructions

Product Type	Over-ear closed-back headphones
Brand	Samson
Model	Z35
Driver Size	40 mm
Frequency Response	20 Hz - 20 kHz
Impedance	32 ohms
Sensitivity	96 dB SPL/mW
Cable Length	1.2 m (3.9 ft) straight cable
Connector Type	3.5 mm gold-plated with 1/4 inch adapter
Weight	220 g (7.8 oz)
Dimensions (W x H x D)	170 x 190 x 80 mm
Power Source	Passive (no battery required)
Main Functions	High-fidelity audio monitoring, comfortable fit for extended use
Adjustable Headband	Yes, with padded headrest
Ear Cushions	Soft leatherette, replaceable
Folding Design	Yes, for portability
Accessories Included	1/4 inch adapter, user manual
Care and Cleaning	Wipe with a soft, dry cloth; avoid liquids
Safety	Do not expose to high volumes for prolonged periods
Spare Parts and Repairability	Replaceable ear cushions and cable
General Information	Professional studio headphones for accurate sound reproduction

Frequently Asked Questions - Z35 SAMSON

What are the main features of the Samson Z35 headphones?

The Samson Z35 are over-ear closed-back headphones designed for monitoring. They feature 40mm drivers, a frequency response of 20 Hz to 20 kHz, and a lightweight design for comfort.

Are the ear cushions replaceable?

Yes, the ear cushions are made of soft leatherette and are replaceable. You can order spare parts from Samson or authorized dealers.

Does the Samson Z35 come with a carrying case?

The Samson Z35 typically does not include a carrying case. However, it is foldable for easy storage and transport.

Can I use the Samson Z35 with a smartphone?

Yes, the Z35 has a 3.5mm connector with a gold-plated plug, making it compatible with most smartphones, tablets, and laptops.

What is the impedance of the Samson Z35?

The impedance is 32 ohms, which allows it to be driven easily by portable devices without an external amplifier.

Are the Samson Z35 suitable for gaming?

While not specifically designed for gaming, the Z35's closed-back design and good sound isolation can enhance the gaming experience. However, they lack a built-in microphone.

How do I clean my Samson Z35 headphones?

Wipe the headphones with a soft, dry cloth. For stubborn dirt, slightly dampen the cloth with water. Avoid using harsh chemicals or submerging the headphones in water.

What cable is included with the Samson Z35?

The Z35 comes with a 1.2m (3.9ft) straight cable. A 1/4 inch adapter is also included for use with audio interfaces or amplifiers.

Is the Samson Z35 foldable?

Yes, the Z35 features a folding design that makes it portable and easy to store.

Where can I find the user manual for the Samson Z35?

The user manual is available for free download on the official Samson website or through authorized dealers. It provides detailed instructions on setup and use.

USER MANUAL Z35 SAMSON

Black and white photo of a foam headphones with attached audio jack (no visible text or symbols)

Close-up of a black SAMSON headphones resting on a flat surface (no visible text or symbols)

Close-up of a woman wearing sunglasses and an orange headphones, with blurred background text (no visible signage or symbols)

Black SAMSON headphones with gold connector, no visible text or symbols on the device itself

POSITIONING

Samson's Z35s are closed-back, over-ear studio headphones that share a clarity and presence found throughout the Z Series. Their natural, flat response stems from Samson's experience in studio monitor design. Ideal for listening to music and field audio, the Z35s feature convenient, collapsible 90^ rotating ear cup with high-quality protein leather ear pads for enhanced comfort and portability.

FEATURES

Comfort

Sound quality means little if your headphones aren't completely comfortable. Compared to the Z25s, the Z35s come standard with higher-grade protein leather ear pads. An adjustable cushioned headband also adds to a comfortable experience when listening on the go or in the studio.

Sound

Samson's goal when designing the Z35s was to create a pair of headphones that aren't overly hyped, but play to aspiring audio enthusiasts. The response of the Z35s is noticeably flat and natural, with clarity representative of the entire Z Series line. These headphones don't trade audio quality for cost or convenience.

Design

Both durable and lightweight, the Z35 headphones sport a sleek, low-profile modern design. As closed-back style headphones, the Z35s provide effective sound isolation by limiting unwanted background noise. For added portability and convenience, the Z35s feature collapsible, 90° rotating ear cups that allow the headphones to sit completely flat when being transported, or be folded up and placed in the included carry pouch.

APPLICATIONS

• Music monitoring
• Recording
  • Field audio, ENG (Electronic News Gathering)

SPECIFICATIONS

Type ...... Over-ear, closed-back dynamic

Sensitivity (@1kHz) db/W....94dB

Driver Size....40mm

Max Input Power @1kHz 500mW

Frequency Response 20Hz–20kHz

Impedance 32Ω

Voice Coil Wire Type...... Copper-clad aluminum

Ear Pads ...... High-protein leather

Cable 8' (2.5m), hardwired straight

Accessories.... 1/4" adapter, carry pouch

Product Weight 0.6lb (273g)

Gift Box Dimensions .... 8.75" x 9.75" x 4.5" (222mm x 248mm x 114mm)

Gift Box Weight 1.5lb(685g)

Master Carton Quantity....6

UPC (US only) 809164018698

SKU (US only)....SAZ35
