LUNA 600 WA - Washing machine WALTHAM - Free user manual and instructions

Product Type	Freestanding Washing Machine
Brand	Waltham
Model	LUNA 600 WA
Capacity (Wash)	6 kg
Maximum Spin Speed	1000 rpm
Number of Programs	15
Programs	Cotton, Synthetics, Delicates, Quick 30', Wool, Hand Wash, Rinse & Spin, Spin Only, Drum Clean
Energy Efficiency Class	A+++
Annual Energy Consumption	180 kWh
Annual Water Consumption	9000 L
Noise Level (Wash/Spin)	56 dB / 76 dB
Dimensions (H x W x D)	85 cm x 60 cm x 55 cm
Weight	62 kg
Power Supply	220-240 V ~ 50 Hz
Power Consumption	2000 W
Water Connection	Cold water inlet
Display Type	LED
Delay Start	Up to 24 hours
Child Lock	Yes
Overflow Protection	Yes
Drum Material	Stainless steel
Door Opening	Left hinged
Self-Cleaning System	Drum clean program
Spare Parts Availability	7 years after model discontinuation
Repairability Index	7.5 / 10

Frequently Asked Questions - LUNA 600 WA WALTHAM

How do I install the washing machine?

Remove all packaging and transport bolts, level the machine using the adjustable feet, connect the water inlet hose to a cold water tap, and insert the drain hose into a standpipe or sink. Ensure the machine is on a stable surface and plugged into a 220-240 V outlet.

How do I select a washing program?

Turn the program dial to the desired cycle (e.g., Cotton, Synthetics, Delicates). The display shows the estimated time. You can adjust temperature and spin speed if needed, then press the Start button.

What does the 'Child Lock' feature do?

Child Lock prevents accidental button presses during operation. Activate it by pressing and holding the relevant button (usually the 'Temp' or 'Spin' button) for 3-5 seconds. The display shows a padlock icon.

Why is my washing machine not draining?

First, check the drain hose for kinks or blockages. Then, clean the drain pump filter located at the bottom front of the machine. If the problem persists, the pump might be faulty and require replacement.

How often should I clean the drum?

Run the 'Drum Clean' program once a month to remove detergent residues and prevent odors. Alternatively, you can run a 90°C cotton cycle with an empty drum and some vinegar or cleaning agent.

What do the error codes mean?

Common codes: E01 (water supply issue), E02 (drain problem), E03 (door not closed). Refer to the manual for a full list. If the error persists, turn off the machine and unplug it for 5 minutes before restarting.

Can I wash delicate fabrics in this machine?

Yes, use the 'Delicates' program which uses gentle tumbling and a lower spin speed (max 600 rpm). Place items in a mesh laundry bag for extra protection.

How do I clean the detergent drawer?

Pull the drawer out fully until it stops. Press the lever inside to release it. Rinse under warm water to remove powder or liquid residues. Use a brush to clean the softener compartment. Dry and reinsert.

What is the maximum load for a quick wash?

For the Quick 30' program, the maximum load is 3 kg of lightly soiled laundry. Overloading may result in poor cleaning or an unbalanced load.

How do I obtain spare parts or repair service?

Contact Waltham customer service or an authorized service center. Common spare parts like belts, pumps, and door seals are available through online retailers. The machine has a repairability index of 7.5/10, indicating good access to spare parts.

USER MANUAL LUNA 600 WA WALTHAM

Fig. 1

Fig. 2

Fig. 3

REGLAGE DES PIEDS

Fig.4

Fig.5

RACCORDEMENT ELECTRIQUE

Fig.6

Fig. 7

RACCORDEMENT DU TUYAU DE VIDANGE

Fig. 10

Fig.11

FILTRE DE POMPE DE VIDANGE

Fig. 12

Fig. 13

BAC A PRODUITS

Fig 14
