| Product Type | Inductive Proximity Sensor |
| Brand | IFM |
| Model | IGS710 |
| Sensing Range | 4 mm (flush mount) |
| Housing | Threaded barrel, M12 × 1 |
| Diameter | 12 mm |
| Length | 50 mm (including M12 connector) |
| Housing Material | Brass with nickel plating |
| Operating Voltage | 10–36 V DC |
| Output Configuration | PNP, normally open (NO) |
| Switching Frequency | 1 kHz |
| Protection Class | IP67 |
| Ambient Temperature | -25 to +70 °C |
| LED Indication | Yellow LED (output active) |
| Electrical Connection | M12 male connector, 4-pin |
| Mounting Style | Flush (sensing face not exposed) |
| Weight | approx. 30 g |
| Detectable Materials | Ferrous and non-ferrous metals |
| Maintenance | Clean with a dry, lint-free cloth; inspect for physical damage periodically |
| Safety Precautions | Do not exceed voltage rating; avoid mechanical shock; ensure proper wiring polarity |
| Spare Parts & Repairability | Non-repairable; replace unit if faulty |
| General Information | Designed for industrial automation, position detection, and object presence sensing |
Frequently Asked Questions - IGS710 IFM
How do I wire the IGS710 sensor?
Connect the brown wire to positive (+), blue wire to negative (-), and black wire to the signal input (PNP normally open). Do not reverse polarity.
What does the yellow LED indicate?
The yellow LED lights up when the sensor detects a target within its sensing range and the output is active.
Can the IGS710 detect aluminum?
Yes, it can detect non-ferrous metals like aluminum, but the sensing range may be slightly reduced compared to steel.
What is the maximum sensing distance?
The rated sensing distance is 4 mm for a standard target. The actual distance depends on target material and size.
How do I clean the sensor?
Wipe the housing with a dry, lint-free cloth. Avoid solvents or abrasive cleaners that could damage the housing.
Can the sensor be mounted flush in metal?
Yes, the IGS710 is designed for flush mounting in metal without significant derating.
What is the operating temperature range?
The sensor operates reliably from -25°C to +70°C.
Does the sensor have short-circuit protection?
Yes, it features built-in short-circuit protection.
What type of connector does it use?
It uses a M12 male connector with 4 pins. A mating cable is required.
How can I test if the sensor is working?
Apply power (10-36 V DC) and bring a metal object near the sensing face. The yellow LED should turn on, and the output should switch.
