ATX970W - Antenne télévision UNIDEN - Free user manual and instructions

Product Type	Indoor/Outdoor TV Antenna
Model	ATX970W
Brand	Uniden
Frequency Range	VHF (174-230 MHz) and UHF (470-862 MHz)
Gain	Approximately 15-20 dBi
Impedance	75 Ohms
Polarization	Horizontal
Maximum Range	Up to 60 miles (96 km) under optimal conditions
Dimensions (Antenna)	Approximately 45 x 30 x 10 cm (17.7 x 11.8 x 3.9 in)
Weight	Approximately 0.5 kg (1.1 lbs)
Power Source	Passive (no external power required)
Connector Type	Coaxial F-type female
Cable Length Included	Approximately 3 meters (9.8 ft)
Mounting Type	Desk stand or wall mount bracket
Material	ABS plastic with metallic elements
Water Resistance	IPX4 (splash-proof) for outdoor use
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Main Functions	Receives digital TV signals (DVB-T/T2) for free-to-air channels
Maintenance	Clean with dry cloth; avoid water ingress; check connections periodically
Safety Warnings	Do not install near power lines; use caution when mounting at height
Spare Parts Available	Replacement mounting brackets, cables, and stands
Repair Information	Contact Uniden support or authorized service center for repairs

Frequently Asked Questions - ATX970W UNIDEN

How do I install the Uniden ATX970W antenna?

Place the antenna on a flat surface or mount it on a wall using the included bracket. Connect the coaxial cable to the antenna and your TV, then scan for channels on your TV's settings.

Does the ATX970W work for both VHF and UHF signals?

Yes, the ATX970W supports both VHF (174-230 MHz) and UHF (470-862 MHz) frequencies, allowing reception of most digital TV channels.

Do I need a power source for this antenna?

No, the ATX970W is a passive antenna and does not require any external power. It operates solely by receiving over-the-air signals.

What is the maximum range of the ATX970W?

Under optimal conditions, the antenna can pick up signals from up to 60 miles (96 km) away. Actual range depends on terrain, obstructions, and broadcast tower power.

Can I use this antenna indoors?

Yes, the ATX970W can be used indoors, but performance may be better when placed near a window or in an attic. It is also suitable for outdoor use due to its IPX4 water resistance.

How do I clean the antenna?

Use a soft, dry cloth to wipe the antenna. Avoid using water or cleaning agents, especially if installed outdoors. Ensure the connector is kept dry.

What should I do if I get poor reception?

Try repositioning the antenna, rotating it for optimal orientation. Ensure the coaxial cable is securely connected. Obstructions like walls and metal structures can weaken the signal.

Is the ATX970W compatible with all TVs?

Yes, it works with any TV equipped with a digital tuner (DVB-T/T2) and a coaxial input. Most modern TVs have this built-in.

Can I connect multiple TVs to one antenna?

Yes, you can use a signal splitter to connect multiple TVs, but note that signal strength may decrease with each split. A preamplifier may be needed for long cable runs.

Where can I get spare parts for the ATX970W?

Spare parts such as mounting brackets, cables, and stands can be obtained by contacting Uniden support or authorized retailers. Check the manufacturer's website for availability.

USER MANUAL ATX970W UNIDEN

dequary vulana w##d#k#

The following table is presented in the following table:

This, an important way, how is what more time, therefore and minds to a way of help as

Coastal landscape with a coastal road, hills, and vintage cars (no visible text or symbols)

Uniden®

APRUMG
