Achilles E3 L - Chair Gamdias - Free user manual and instructions

Brand	Gamdias
Model	Achilles E3 L
Product Type	Gaming Chair
Color	Black (assumed)
Material	PU Leather, High-density foam, Metal frame
Dimensions (Assembled)	Approx. 125 cm (H) x 70 cm (W) x 55 cm (D)
Seat Height Range	45 cm - 55 cm (adjustable)
Weight Capacity	Up to 150 kg
Net Weight	Approx. 25 kg
Armrests	3D adjustable (height, angle, width)
Recline Angle	90° - 155° (with tilt lock)
Gas Lift Class	Class 4
Base Material	Aluminum alloy
Caster Wheels	60 mm PU coated, silent
Lighting	RGB LED via USB (customizable with software)
Power Supply	USB (computer) or external power bank
Connectivity	USB cable for lighting
Software Support	Gamdias Software (downloadable)
Package Contents	Seat, Backrest, Base, Gas lift, Casters, Armrests, Screws, Allen key
Assembly Required	Yes (instructions and video available)
Warranty	2 years (typical)

Frequently Asked Questions - Achilles E3 L Gamdias

How do I assemble the Gamdias Achilles E3 L chair?

Follow the included assembly instruction sheet. Attach the backrest to the seat using the provided screws. Install the armrests, then attach the gas lifter and base. Finally, insert the caster wheels. A video demonstration is available on the Gamdias website.

How can I adjust the seat height?

Locate the height adjustment lever under the seat. While seated, lift the lever to raise the chair or push down to lower it. Release the lever to lock the desired height.

How do I use the recline function?

Pull up the recline lever located on the right side of the seat. Lean back to your desired angle (up to 155°) and release the lever to lock. To lock the chair in an upright position, push the lever forward.

Can I customize the RGB lighting?

Yes, connect the chair to your PC via USB and download the Gamdias software from www.gamdias.com. The software allows you to adjust lighting colors, effects, and brightness. A power bank can also be used as an external power source.

How do I clean and maintain the chair?

Wipe the PU leather with a soft, damp cloth. Avoid harsh chemicals. Regularly check and tighten screws. Lubricate moving parts with silicone spray if needed.

What is the weight capacity?

The chair supports up to 150 kg (330 lbs). Ensure the gas lift is rated accordingly for safety.

Are replacement parts available?

Yes, you can order replacement parts such as gas lifts, casters, and armrests from Gamdias customer service or authorized resellers.

How do I adjust the armrests?

The armrests are 3D adjustable. Lift the button under the armrest to adjust height, slide to change angle, and move side to side for width adjustment. Release to lock.

Is assembly required?

Yes, the chair comes unassembled. The package includes all necessary parts and tools. Assembly typically takes 20-30 minutes.

Where can I download the software and manual?

Visit www.gamdias.com and navigate to the support section. Search for 'Achilles E3 L' to find the latest software, manual, and assembly video.

USER MANUAL Achilles E3 L Gamdias

Assembly demonstration video

Gamdias Multifunction PC Gaming Chair

Line drawings of an office chair with front and side views (no text or symbols)

Package Contents

Seat Back

Assembly Instruction

GAMDIAS Technology Co., Ltd. www.GAMDIAS.com
7F, No.113, Jian 2nd Rd., Jhonghe Dist., New Taipei City 23585, Taiwan (R.O.C.)

© 2017 GAMDIAS Technology Co., Ltd. All rights reserved. All GAMDIAS trademarks and logos are registered trademarks of GAMDIAS Technology Co., Ltd. All other trademarks and logos presented in this material are the property of their respective owners. GAMDIAS Technology Co., Ltd. reserves the right to revise the specifications mentioned on this packaging.
