DVD7325 - Portable DVD Player Reflexion - Free user manual and instructions

Product Type	Portable DVD Player
Brand	Reflexion
Model	DVD7325
Display Technology	LCD/TFT
Screen Size	7 inches (17.7 cm)
Screen Format	16:9
Resolution	480 x 234 pixels
Contrast Ratio	300:1
Brightness	130 cd/m²
Display Colors	16.7 million
Viewing Angle (H/V)	70° / 65°
Response Time	25 ms
Picture Refresh Rate	50 Hz
Video Color Systems	PAL / NTSC
TV Tuner (DVB-T)	Yes, 1000 channels
Teletext (DVB-T)	999 pages
Main Unit Connections	USB, SD Card Slot, AV Out, Coaxial, DVB-T Antenna Jack, Earphone Output, DC 9-12 V Input, DC 9-12 V Output
Slave Unit Connections	AV In, Earphone Output, DC 9-12 V Input
Audio Output	2 x 1 Watt
Gross Weight	1.15 kg
Power Requirement	DC 9-12 V, 1.5 A; AC 110-240 V, 50/60 Hz
Max Power Consumption	15 W
Power Consumption (ON)	10 W
Battery Type	Li-Ion, 1200 mAh
Maintenance	Clean with a soft, dry cloth. Avoid liquids and abrasive cleaners.

Frequently Asked Questions - DVD7325 Reflexion

What disc formats does the Reflexion DVD7325 support?

The DVD7325 plays DVD, CD, and compatible formats like MP3 and JPEG. Refer to the manual for a full list.

What is the battery life of the DVD7325?

With a 1200 mAh Li-Ion battery, typical playback time is about 2-3 hours, depending on usage brightness and volume.

Can I connect the portable DVD player to a TV?

Yes, use the AV OUT port on the main unit with an AV cable (not included) to connect to a TV. The slave unit has AV IN for input.

How do I use the DVB-T tuner?

Connect the DVB-T antenna to the jack, then select TV mode and scan for channels. The player supports up to 1000 channels and teletext.

What should I do if the screen is blank?

Check if the battery is charged or the device is plugged in. Ensure the power switch is on. If still blank, try resetting or contact support.

Can I play content from a USB drive or SD card?

Yes, insert a USB drive or SD card in the corresponding slots. The player can play media files such as videos, music, and photos.

Is the DVD7325 region-locked?

Portable DVD players often have region code 0 or region-free support, but verify your unit's settings. If locked, you may need to change the region code via the manual.

How do I clean the screen?

Use a soft, dry microfiber cloth to gently wipe the screen. Do not use water, alcohol, or abrasive cleaners.

Can I use headphones?

Yes, plug headphones into the earphone output jack on either the main or slave unit for private listening.

What accessories are included in the box?

Typically, the box includes the main unit, slave unit, car charger, AC adapter, AV cable, remote control, and user manual. Check your package for details.

USER MANUAL DVD7325 Reflexion

Four black left-pointing arrows arranged in a scattered pattern on a white background (no text or symbols)

Computer desktop interface with icons for TV, monitor, printer, and folder (no text or symbols)

Computer desktop interface with monitor, tower, and printer icons (no text or symbols)

Computer monitor and desktop icons (no text or symbols)

Computer desktop interface with icons for TV, monitor, keyboard, and folder (no text or symbols)

O

▶

▲

↑↓

		:1 Vp_p (75Ω)

Computer desktop interface with icons for TV, monitor, printer, and folder (no text or symbols)

Computer desktop interface with icons for TV, monitor, printer, and folder (no text or symbols)

Computer desktop interface with icons for TV, monitor, folder, and email (no text or symbols)

Computer desktop interface with icons for TV, laptop, and printer (no text or symbols)

Item		Standard requirement
		:1 Vp-p (75Ω)

Technical details DVD7325

Display technology LCD/TFT
Screen size, visible 7 Inch (17,7 cm)
Screen format 16:9
Resolution 480 x 234
Minimum contrast ratio 300:1
Minimum brightness 130 cd/m2
Display colors 16.7 M colors
Minimum viewing angle 70° (horizontal) / 65° (vertical)
Maximum response time 25 ms
Picture repetition rate 50 Hz
Video color systems PAL / NTSC
TV Functions	Chanels (DVB-T) 1000
	Videotext (DVB-T) 999 Pages
Connections Main unit	USB	1
	SD CARD SLOT	1
	AV OUT	1
	COAXIAL	1
	DVB-T ANT. JACK	1
	EARPHONE OUTPUT	1
	DC 9-12 V INPUT	1
	DC 9-12 V OUTPUT	1
Connections Slave unit	AV IN	1
	EARPHONE OUTPUT	1
	DC 9-12 V INPUT	1
Audio output		2 x 1 Watt
Gross weight		1.15 KG
Power requirement DC 9-12V, 1.5A,		AC 110~240V, 50Hz/60Hz
Power consumption maximum		15 W
Power consumption „ON" for EN 62087		10 W
Peak luminance ratio in %		50 %
Accu		LI-ION / 1200mAh

Energyefficiency

vironment protection

Instructions on en

Electric and electronic equipment and included batteries contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen below. This symbol signifies that electric and electronic equipment and batteries should not be disposed of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the appropriate and designated facility. In this manner you make sure that the batteries are recycled in accordance with legislature and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and batteries can either be submitted free of charge at recycling stations and other collection sites, or be collected from the households. Additional information is available at the technical department of your city.

Please fill the blank with the model number of this player for future reference
