Supra X (2022) - Motorrad Honda - Kostenlose Bedienungsanleitung

Produkttyp	Motorroller
Marke	Honda
Modell	Supra X (2022)
Kategorie	Motorrad
Motor	4-Takt, 125 cm³
Leistung	6,8 kW (9,2 PS)
Kraftstoffart	Benzin (Blei-frei)
Tankinhalt	4,5 Liter
Getriebe	Automatik (CVT)
Startsystem	Elektro- und Kickstarter
Bremsen	Vorne Scheibenbremse, hinten Trommelbremse
Reifengröße vorne	80/90-17
Reifengröße hinten	90/90-17
Sitzhöhe	765 mm
Radstand	1.245 mm
Leergewicht	107 kg (vollgetankt)
Zuladung	150 kg
Höchstgeschwindigkeit	ca. 95 km/h
Kraftstoffverbrauch	ca. 2,5 l/100 km
Bordspannung	12 V
Batterie	12 V / 5 Ah
Öltyp	10W-30
Ölwechselintervall	Alle 4.000 km oder jährlich
Zündkerze	NGK CR6HSA
Wartung	Regelmäßige Kontrolle von Reifen, Bremsen, Kette

Häufig gestellte Fragen - Supra X (2022) Honda

Welchen Kraftstoff benötigt die Honda Supra X (2022)?

Wie oft muss das Motoröl gewechselt werden?

Was ist die Sitzhöhe der Honda Supra X?

Wie stelle ich den Leerlauf ein?

Welche Reifengröße hat die Honda Supra X?

Wie starte ich das Motorrad bei kaltem Motor?

Was ist die maximale Beladung?

Wie reinige ich den Luftfilter?

Welche Zündkerze wird verwendet?

Wie pflege ich die Kette?

BEDIENUNGSANLEITUNG Supra X (2022) Honda

SUPRA X 125 (AFX125SF / AFX125CRF)

PT Astra Honda Motor TECHNICAL SERVICE DIVISION

Dipublikasikan oleh :

Honda Motor Co., Ltd.

Dicetak di Indonesia

ID.XXX.XXXX.2022.XX.22

13K41B2AJ (10K41K12)

TIPE SPOKE 2019 (AFX125SF4) TIPE SPOKE 2022 (AFX125SF4) TIPE CW 2019 (AFX125CRFN) TIPE CW 2022 (AFX125CRFN)

PARTS CATALOG 2

15 Honda Motor Co., Ltd. 2022

DAFTAR ISI

PETUNJUK PEMAKAIAN

KELOMPOK MESIN

KELOMPOK RANGKA

INDEKS NOMOR PART

INDEKS NAMA PART

Instruksi penggunaan parts catalog

- Parts catalog ini telah dibuat pertanggal 01 Februari 2022.

• Setelah tanggal ini, mungkin terjadi perubahan pada parts di dalam catalog ini, dan parts tertentu diganti dengan parts lain atau dihapus (tidak dijual lagi).
• Bacalah parts catalog news untuk revisi yang dilakukan setelah 01 Februari 2022.

- Selalu beritahu nomor part sewaktu memesan part.

• Periksa model, tipe, nomor seri, warna, pabrik pembuat, dan ukuran seperlunya sebelum memesan part.
• Perhatikan bahwa ilustrasi (gambar part) dapat berbeda dalam bentuknya dari part sebenarnya. Ilustrasi hanya diberikan untuk membantu anda mencari parts tersebut.

- Sewaktu terjadi modifikasi atau penambahan pada parts catalog ini, maka akan diterbitkan edisi yang direvisi pada waktu yang sesuai, yang memuat nomor revisi yang berurutan pada sampulnya. Kami menganjurkan agar anda mendapatkan revisi-revisi tersebut supaya parts catalog anda tetap mengikuti perkembangan mutakhir setiap waktu. Untuk mengetahui apakah revisi parts catalog telah diterbitkan, hubungi distributor Honda anda.

Tanggal versi penerbitan pertama

10 Januari 2019

Honda Motor Co., Ltd.

DAFTAR ISI

Halaman

• Instruksi penggunaan parts catalog 1
• Cara mencari informasi part 2
• Struktur parts catalog 3
• Jika parts telah direvisi 5
• Singkatan-singkatan yang dipakai di dalam parts catalog .... 5
• Blok part dan pengecekan nomor seri 6
• Model, kode parts catalog dan nomor seri yang berlaku 7
• Tabel warna 8
• Selang bahan bakar, selang untuk keperluan umum dan selang vinyl 16
• FLAT RATE SERVICE TIME 20
• Indeks gambar 25
• KELOMPOK MESIN 32
• KELOMPOK RANGKA 54
  • INDEKS NOMOR PART....109
  • INDEKS NAMA PART 113
