BRUGSANVISNING ADBE-10354 ADIDAS
SPORTS TRAINING BENCH
ADBE - 10354
| N Parts | Noo. Description Q Pre-assembly | ty. | ||
| 1 | FM-AD7240RD-01 1 | Connect Tube Tube | No | |
| 2 | FM-AD7240RD-02 1 | Right Upright | No | |
| 3 | FM-AD7240RD-03 1 | Left Upright | No | |
| 4 | FM-AD7240RD-04 2 | Weight Plate Tube | No | |
| 5 | FM-AD7240RD-05 1 | Main Frame | No | |
| 6 | FM-AD7240RD-06 1 | Front Stabilizer | No | |
| 7 | FM-AD7240RD-07 1 | Support Tube | No | |
| 8 | FM-AD7240RD-08 1 | Leg Tube | No | |
| 9 | FM-AD7240RD-09 2 | Foam Tube | No | |
| 10 | FM-AD7240RD-10 1 | Backrest Adjustment Tube | No | |
| 11 | FM-AD7240RD-11 2 | Barbell Holder | No | |
| 12 | FM-AD7240RD-12 2 | Backrest Tube | No | |
| 13 | FM-AD7240RD-13 1 | Seat | No | |
| 14 | FM-AD7240RD-14 1 | Backrest | No | |
| 15 | FM-AD7240RD-15 8 | M8 Washer | No | |
| 16 | FM-AD7240RD-16 2 | Safety Hook L & R | No | |
| 17 | FM-AD7240RD-17 4 | M10x95mm Allen Bolt | No | |
| 18 | FM-AD7240RD-18 2 | M10x60mm Allen Bolt | No | |
| 19 | FM-AD7240RD-19 1 | M10x70mm Carriage Bolt | No | |
| 20 | FM-AD7240RD-20 1 | M10x55mm Carriage Bolt | No | |
| 21 | FM-AD7240RD-21 2 | M10x25mm Allen Bolt | No | |
| 22 | FM-AD7240RD-22 1 | M10x75mm Allen Bolt | No | |
| 23 | FM-AD7240RD-23 4 | M8x25mm Allen Bolt | No | |
| 24 | FM-AD7240RD-24 4 | M8x45mm Allen Bolt | No | |
| 25 | FM-AD7240RD-25 20 | M10 Washer | No | |
| 26 | FM-AD7240RD-26 8 | M8 Spring washer | No | |
| 27 | FM-AD7240RD-27 11 | M10 Nylon Nut | No | |
| 28 | FM-AD7240RD-28 | M10 Spring washer 11 | No | |
| 29 | FM-AD7240RD-29 4 | Foam Rollers | No | |
| 30 | FM-AD7240RD-30 | 25mm Round End Plug 3 | Yes | |
| 31 | FM-AD7240RD-31 | 38x38mm Square End Plug 3 | Yes | |
| 32 | FM-AD7240RD-32 | 70x40 mm End Plug | 8 | Yes |
| 33 | FM-AD7240RD-33 | 50x50mm Square End Plug | 1 | Yes |
| 34 | FM-AD7240RD-34 | 25x25mm Square End Plug | 4 | Yes |
| 35 | FM-AD7240RD-35 | 25mm Foam Plug | 4 | No |
| 36 | FM-AD7240RD-36 | Support Plate | 1 | No |
| 37 | FM-AD7240RD-37 | 25mm Round End Cap | 1 | Yes |
| 38 | FM-AD7240RD-38 | Quick Clip Φ25mm | 3 | No |
| Allen Wrench | 1 | No | ||
For product information or service please contact:
UK:
RFE Europa Ltd. 8 Clarendon Drive, Wymbush, Milton Keynes, MK8 8ED.
Customer Service: Tel: +44 (0)800 440 2459
Email: techsupport@rfeinternational.com
Europe:
Email: serviceeuropa@rfeinternational.com
Spain:
Email: serviciotecnico@rfeinternational.com
APAC (excluding Australia):
RFE Asia Pacific, 2608-1609, 1 Hung To Road, Kwun Tong, Kowloon, Hong Kong.
Customer Service: Tel: +852 34685027
Email: techsupportapac@rfeinternational.com
Australia:
Email: techsupportaustralia@rfeinternational.com
USA:
RFE Sporting Goods Inc., 1300 Smith Road, STE 104, Austin, Texas, 78721, USA.
Customer Service: Tel: +1 (800) 215 6216
Email: techsupportusa@rfeinternational.com
