Type de produit	Imprimante photo compacte
Dimensions (L x P x H)	23 x 15 x 9 cm
Poids	1,3 kg
Alimentation	Adaptateur secteur 100-240 V, 50/60 Hz
Consommation électrique	30 W en impression, 5 W en veille
Technologie d'impression	Jet d'encre thermique HP
Résolution d'impression maximale	4800 x 1200 dpi optimisés
Formats de papier supportés	10 x 15 cm, 13 x 18 cm, 21,6 x 27,9 cm
Connectivité	USB 2.0, PictBridge, lecteur de cartes mémoire
Fonctions principales	Impression sans PC, impression directe depuis cartes mémoire, écran LCD 2,4 pouces
Capacité du bac papier	20 feuilles (photo)
Entretien et nettoyage	Nettoyage des têtes d'impression via le logiciel HP, utiliser des feuilles de nettoyage
Sécurité	Ne pas utiliser sous la pluie, débrancher avant nettoyage
Pièces détachées et réparabilité	Cartouches d'encre HP, adaptateur secteur, batterie en option
Informations générales	Marque : HP, Modèle : Photosmart A610, Catégorie : Imprimante photo, Sortie : 2005

FOIRE AUX QUESTIONS - PHOTOSMART A610 HP

Comment imprimer directement depuis mon appareil photo ?

Connectez votre appareil photo à l'imprimante via le port PictBridge (USB) ou insérez la carte mémoire dans le lecteur. Sélectionnez les photos sur l'écran LCD et appuyez sur Imprimer.

Que faire si l'imprimante ne s'allume pas ?

Vérifiez que l'adaptateur secteur est bien branché et que la prise fonctionne. Assurez-vous que le bouton d'alimentation est enfoncé pendant 2 secondes. Si le problème persiste, contactez le support HP.

Comment nettoyer les têtes d'impression ?

Depuis le logiciel HP Photosmart, allez dans Outils puis Nettoyer les têtes d'impression. Vous pouvez également utiliser une feuille de nettoyage spéciale.

Quels types de papier puis-je utiliser ?

L'imprimante accepte le papier photo au format 10x15 cm, 13x18 cm et le papier A4. Utilisez de préférence du papier photo HP pour une qualité optimale.

Comment remplacer la cartouche d'encre ?

Ouvrez le capot avant, attendez que le chariot se positionne au centre. Retirez la cartouche vide et insérez la nouvelle cartouche HP 60 (noir) ou HP 60 tricolore. Refermez le capot.

L'imprimante affiche 'erreur de papier'. Que faire ?

Retirez le papier coincé délicatement. Assurez-vous que le papier est correctement aligné et que le bac n'est pas trop plein. Réinitialisez l'imprimante en l'éteignant et en la rallumant.

Puis-je utiliser l'imprimante sans ordinateur ?

Oui, grâce au lecteur de cartes mémoire intégré et au port PictBridge, vous pouvez imprimer directement depuis une carte mémoire ou un appareil photo compatible.

Comment économiser l'encre ?

Utilisez le mode Brouillon pour les impressions quotidiennes. Sélectionnez une résolution plus basse dans les paramètres d'impression. Imprimez plusieurs photos sur une même feuille si possible.

Que signifie le voyant clignotant ?

Un voyant orange clignotant indique généralement un niveau d'encre faible ou un bourrage papier. Consultez la notice pour les codes de voyants spécifiques.

Où puis-je trouver la dernière version du pilote ?

Rendez-vous sur le site support.hp.com, recherchez 'Photosmart A610' et téléchargez le pilote compatible avec votre système d'exploitation (Windows, macOS).

MODE D'EMPLOI PHOTOSMART A610 HP

HP Jetdirect External USB Compatibility

December 2008

hp

Introduction

There have been some questions from customers about the compatibility of printers and the HP Jetdirect External Print Server Products. This white paper addresses those questions and provides a list of supported printers with the USB External Print Servers that are currently on the Corporate Price List (CPL).

Over the years, many things have changed regarding external print servers and printers they connect to. In the past, an external print server was the only way to place these printers on a network. In contrast, many printers today come with their own embedded networking and the USB port is used almost exclusively for direct connection to PCs. As a result, some printers have implemented cost effective USB modes that are very difficult for an external print server to support on the network.

Current Support Strategy

HP currently has four external USB products on the CPL:

J6035G 175X 10/100TX USB 1.1 External Print Server

J7988G en1700 10/100TX USB 2.0 External Print Server

J7951G ew2400 10/100TX & 802.11b/g USB 2.0 External Print Server

J7942G en3700 10/100TX USB 2.0 External Print server

In 2009, the J6035G 175X print server will be discontinued. This print server has been popular, but is not upgradeable and it does not support Hi-Speed USB. The 175x supports

USB 1.1 and USB 1.1 does not include Hi-Speed. USB 2.0 added Hi-Speed and is fully backward compatible with USB 1.1 in Full-Speed. As a result, some of the newer USB printers cannot be supported. Its eventual replacement is currently available as the en1700, an upgradeable solution that supports Hi-Speed USB and also supports IPv6. The ew2400 and the en3700 which are USB 2.0 Hi-Speed will remain on the CPL for a while as they are respectively HP's wireless value line external print server and HP's full featured external print server.

Scanning on AIO and MFP's

The HP Jetdirect External print servers do not support scanning on Laserjet MFP's. They are currently a print only solution. The 175x, ew2400, and en3700 supported scanning through the embedded web server for the Laserjet AIO's and Officejet Pro's. Many devices have their own networking scanning software and no longer rely on HP JetDirects web scan capability and in many cases no longer support it. As a result, the web scanning capability has been removed from the en1700.

Supported Printer lists

Due to various product limitations, not all USB external print servers support the same set of printers. This section breaks down the supported printers for each HP USB Jetdirect print server. As always, be sure your firmware on both the printer and print server is at the latest available version.

HP Jetdirect en1700

Supported with these USB network-capable HP printers, AIO's, and MFP's:

HP Business Inkjet 2300, 2600, 2800, and 3000;

HP Color LaserJet CP1515, CP1518, CP3505, CP3525, CP4005, CP6015, 2500, 2550, 2600, 2605, 2700, 3000, 3600, 3700, 3800, 4610, 4650, 4700, 5550, 2820mfp, and 2840mfp;

HP Designjet Z2100, Z3100, 30, 70, 90, 110+, 130, 500, 510, 800, and 820mfp;

HP Deskjet 5550, 5650, 6940, 6980, and 9800 series;

HP LaserJet P2014, P2015, P2035, P2055, P3005, P4014, P4015, P4515, 1010, 1012, 1015, 1022, 1160, 1200, 1300, 1320, 2200, 2300, 2410, 2420, 2430, 3015, 3020, 3030, 3052, 3055, 3300, 3380, 3390, 3392, 4240, 4250, 4350, and 5200 series;

HP Officejet Pro K550, K850, K5300, and K5400

Print and Windows based scanning:

HP Color LaserJet CM1015mfp and CM1017mfp

Print only:

HP Color LaserJet CM3530mfp, CM4730mfp, CM6030mfp, CM6040mfp, 4730mfp;

HP LaserJet M3027mfp, M3035mfp, M4345mfp, M5025mfp, M5035mfp, M9040mfp, M9050mfp, 3050, and 3050z;

HP Officejet Pro K8600, L7300, L7500, L7600, L7700, 6200, and 9100 series

Supported with these USB network-capable HP printers:

HP Business Inkjet 1000, 1100, 1200, 2280, 2300, 2600, 2800, 3000; HP Color Inkjet cp1160 and cp1700; HP Color LaserJet CP1515, CP1518, CP3505, CP3525, CP4005, CP6015, 1500, 2500, 2550, 2605, 2700, 3000, 3500, 3550, 3600, 3700, 3800, 4610, 4650, 4700, 5550 series; HP Designjet 30, 70, 90, 110+, 130, 500, 800, and 820mfp; HP Deskjet 1180c, 1220c, 1280, 5150, 5550, 5650, 6122, 9300c, 9600c, 9650, 9670, 9680, and 9800 series; HP LaserJet P2014, P2015, P2035, P2055, P3005, P4014, P4105, P4514, 1015, 1022, 1150, 1160, 1200, 1300, 2200, 2300, 2410, 2420, 2430, 3015, 3020, 3030, 3052, 3055, 3200, 3300, 3380, 3390, 3392, 4240, 4250, 4350, and 5200 series; HP Officejet D, G series, K80/K80xi, and 9100 series; HP Officejet Pro K550, K850, K5300, K5400, K8600, L7300, L7500, L7600, and L7700

Also works with these USB network-capable HP printers:

HP Color LaserJet CM1015/1017mfp*, CM3530mfp*, CM4730mfp*, CM6030mfp*, CM6040mfp*, 4730mfp*, 9500mfp*;
HP Deskjet 895 Cse/Cxi;
HP LaserJet M3027mfp*, M3035mfp*, M4345mfp*, M5025mfp*, M5035mfp*, M9040mfp*, M9050mfp*, 3050*;
HP Officejet 6100 series*;
HP Photosmart 1100, 1200, 1300, 7000**, and 8000 series;
HP PSC 2110*, 2210*, 2400*, 7350, and 7550 All-in-One

* printing only; no webscan ** except HP Photosmart 7200 series

HP Jetdirect ew2400

Supported with these USB network-capable HP printers:

HP Business Inkjet 1000, 1100, 1200, 2280, 2300, 2600, 2800, 3000; HP Color Inkjet cp1160 and cp1700; HP Color LaserJet CP1515, CP1518, CP3505, CP3525, CP4005, CP6015, 1500, 2500, 2550, 2605, 2700, 3000, 3500, 3550, 3600, 3700, 3800, 4610, 4650, 4700, 5550 series; HP Designjet 30, 70, 90, 110+, 130, 500, 510, 800, and 820mfp; HP Deskjet 1180c, 1220c, 1280, 5150, 5550, 5650, 6122, 9300c, 9600c, 9650, 9670, 9680, and 9800 series; HP LaserJet P2014, P2015, P2035, P2055, P3005, P4014, P4015, P4515, 1015, 1022, 1150, 1160, 1200, 1300, 2200, 2300, 2410, 2420, 2430, 3015, 3020, 3030, 3052, 3055, 3200, 3300, 3380, 3390, 3392, 4240, 4250, 4350, and 5200 series; HP Officejet D, G series, K80/K80xi, and 9100 series; HP Officejet Pro K550, K850, K5300, K5400, K8600, L7300, L7500, L7600, and L7700

Also works with these USB network-capable HP printers:

HP Color LaserJet CM1015/1017mfp*, CM3530mfp*, CM4730mfp*, CM6030mfp*, CM6040mfp*, 4730mfp*, 9500mfp*;
HP Deskjet 895 Cse/Cxi;

HP LaserJet M3027mfp*, M3035mfp*, M4345mfp*, M5025mfp*, M5035mfp*, M9040mfp*, M9050mfp*, 3050*;

HP Officejet 6100 series ^* ;

HP Photosmart 1100, 1200, 1300, 7000**, and 8000 series;

HP PSC 2110*, 2210*, 2400*, 7350, and 7550 All-in-One;

HP CM 8060 Color MFP with Edgeline Technology*

* printing only; no webscan

** except HP Photosmart 7200 series

HP Jetdirect 175x

Supported with these USB network-capable HP peripherals:

HP Business Inkjet 1000, 1100, 1200, 2280, 2300, 2600, 2800, 3000;

HP Color Inkjet cp1160 and cp1700;

HP Color LaserJet CP4005, 1500, 2500, 2550, 3000, 3500, 3550, 3600, 3700, 3800, 4610, 4650, 4700, and 5550 series;

HP Designjet 30, 70, 90, 110+, 130, 500, and 800;

HP Deskjet 1180c, 1220c, 1280, 5150, 5550, 5650, 6122, 9300c, 9600c, 9650, 9670, 9680, and 9800 series;

HP LaserJet 1015, 1022, 1150, 1160, 1200, 1300, 2200, 2300, 2410, 2420, 2430, 3015, 3020, 3030, 3200, 3300, 3380, 4240, 4250, 4350, and 5200 series;

HP Officejet D, G series, K80/K80xi, and 9100 series;

HP Officejet Pro K550, K850, K5300, K5400, L7300, L7500, L7600, and L7700

Also works with these USB network-capable HP peripherals:

HP Color LaserJet 4730mfp*, 9500mfp*;

HP Deskjet 895 Cse/Cxi;

HP LaserJet M3027mfp*, M3035mfp*, M4345mfp*, M5025mfp*, M5035mfp*, 3050*, 3052*, 3055*, 3390*, 3392*;

HP Officejet 6100 series ^* ;

HP Photosmart 1100, 1200, 1300, 7000**, and 8000 series;

HP PSC 7350, and 7550 All-in-One

* printing only; no webscan

** except HP Photosmart 7200 series printers
