XRFBD5220-20 BLUPERFORMANCE - XRFbd 5220 - Réfrigérateur-congélateur LIEBHERR - Notice d'utilisation et mode d'emploi gratuit

Type de produit	Réfrigérateur combiné avec congélateur
Capacité totale	500 litres
Dimensions approximatives	Hauteur : 201 cm, Largeur : 70 cm, Profondeur : 65 cm
Poids	90 kg
Classe énergétique	A++
Alimentation électrique	230 V, 50 Hz
Fonctions principales	Froid ventilé, Super congélation, Super refroidissement
Type de réfrigérant	R600a
Entretien et nettoyage	Intérieur à nettoyer avec un chiffon humide, pas de produits abrasifs
Pièces détachées et réparabilité	Disponibilité des pièces détachées selon le modèle
Sécurité	Protection contre les surcharges, sécurité enfant
Compatibilités	Compatible avec les accessoires Liebherr
Garantie	2 ans

FOIRE AUX QUESTIONS - XRFBD5220-20 BLUPERFORMANCE - XRFbd 5220 LIEBHERR

Comment régler la température du réfrigérateur LIEBHERR XRFBD5220-20 ?

Pour régler la température, appuyez sur le bouton 'Température' et utilisez les flèches pour augmenter ou diminuer la température souhaitée. Attendez quelques secondes pour que le réglage soit pris en compte.

Que faire si le réfrigérateur ne refroidit pas correctement ?

Vérifiez que la porte est bien fermée, que le réfrigérateur n'est pas surchargé et que les ventilations ne sont pas obstruées. Si le problème persiste, contactez le service client.

Comment nettoyer l'intérieur du réfrigérateur LIEBHERR ?

Débranchez l'appareil, retirez les étagères et nettoyez-les avec de l'eau savonneuse. Essuyez l'intérieur avec un chiffon humide et un produit nettoyant doux, puis séchez soigneusement.

Le réfrigérateur émet un bruit inhabituel, que faire ?

Vérifiez que l'appareil est de niveau et que rien ne bloque le ventilateur. Si le bruit persiste, il peut être nécessaire de faire appel à un technicien.

Comment activer le mode vacances sur le LIEBHERR XRFBD5220-20 ?

Pour activer le mode vacances, appuyez sur le bouton 'Mode vacances' situé sur le panneau de contrôle. Cela permettra d'économiser de l'énergie lorsque vous n'êtes pas chez vous.

Les lumières à l'intérieur du réfrigérateur ne s'allument pas, que faire ?

Vérifiez si l'appareil est bien branché et si l'ampoule est grillée. Si l'ampoule est défectueuse, remplacez-la par une ampoule compatible.

Quelle est la capacité de stockage du LIEBHERR XRFBD5220-20 ?

Le réfrigérateur a une capacité de stockage d'environ 360 litres, offrant un espace suffisant pour conserver vos aliments frais.

Comment régler les tiroirs à légumes pour une meilleure conservation ?

Les tiroirs à légumes peuvent être réglés en fonction de l'humidité désirée. Assurez-vous de les fermer hermétiquement pour maintenir un niveau d'humidité optimal.

Le réfrigérateur affiche un code d'erreur, que signifie-t-il ?

Consultez le manuel d'utilisateur pour identifier la signification du code d'erreur. Si vous ne parvenez pas à résoudre le problème, contactez le service après-vente.

Comment enlever les odeurs du réfrigérateur ?

Pour éliminer les odeurs, nettoyez l'intérieur avec un mélange d'eau et de bicarbonate de soude. Placez également un ouvert de bicarbonate de soude dans le réfrigérateur pour absorber les odeurs.

Le réfrigérateur a besoin d'un dégivrage, comment procéder ?

Débranchez l'appareil, retirez tous les aliments, et laissez la glace fondre naturellement. Essuyez l'eau avec un chiffon et rebranchez l'appareil une fois le dégivrage terminé.

MODE D'EMPLOI XRFBD5220-20 BLUPERFORMANCE - XRFbd 5220 LIEBHERR

Abstract graphic with icons including a lock, snowflake, power button, and play button (no text or symbols)

User Guide

Quality, Design and Innovation

QR code with speech bubble and smartphone icon containing 'i' symbol

home.liebherr.com/fridge-manuals

Abstract diagram with three gray square icons: a bell, a wind turbine symbol, and a Wi-Fi signal symbol (no text or labels)

Contents

1 The appliance at a glance.... 3
1.1 Delivered contents.... 3
1.2 Appliance and equipment overview.... 3
1.3 Range of appliance use.... 3
1.4 Conformity.... 4
1.5 EPREL Database.... 4

2 General safety instructions.... 4

3 Start-up.... 5

3.1 Turning on the appliance.... 5

3.2 Insert the equipment.... 6

4 Food management.... 6

4.1 Storing food.... 6

4.2 Storage times.... 6

5 Energy saving.... 7

6 Use.... 7

6.1 Controls and displays.... 7

6.1.1 Status display....7

6.1.2 Navigation....7

6.1.3 Operating structure....7

6.1.4 Display symbols....8

6.2 Operating logic.... 8

6.2.1 Activating/deactivating settings....8

6.2.2 Selecting function value.... 8

6.2.3 Activating/deactivating settings....8

6.2.4 Selecting the setting value....8

6.2.5 Calling up the customer menu....9

6.3 Functions.... 9

Temperature....9

Temperature....9

Temperature....9

Temperature....9

Temperature....9

Temperature....9

Temperature....9

Temperature....9

Temperature....9

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

6.4

Settings.... 10

Settings.... 10

Settings.... 10

Settings.... 10

Settings.... 10

Display brightness....11

Door alarm.... 11

Temperature unit.... 11

Info....11

SabbathMode....11

TubeClean*....12

Ice cubes* 12

6.5

6.5.1

6.5.2

6.5.3

7

7.1

7.2

7.5

7.6

8

8.1

8.2

9

9.1

9.2

9.3

9.4

9.5

10

1

11.1

11.2

[Non-Text]

Reminder....12

Reset....12

Turn off appliance....12

Error messages.... 12

Warnings....12

Message.... 13

DemoMode.... 13

Equipment.... 13

Drawers.... 13

Pull-out board with IceTower* 13

VarioSpace.... 16

Accessories.... 16

Maintenance.... 16

Defrosting the appliance.... 16

Cleaning the appliance.... 16

Customer support.... 18

Technical specifications.... 18

Operating noises.... 18

Technical faults.... 19

Customer service.... 20

Rating plate.... 20

Decommissioning.... 20

Disposal.... 20

Preparing appliance for disposal.... 20

Disposing of the appliance in an environmentally friendly manner.... 21

The manufacturer is constantly working to improve all types and models. Therefore, please be aware that we reserve the right to make changes to the shape, equipment and technology.

Symbol

Explanation

Read instructions

Please read the information in these instructions carefully to understand all of the benefits of your new appliance.

Full instructions on the internet

You can find detailed instructions on the internet using the QR code on the front of these instruction or by entering the service number at home.liebherr.com/fridge-manuals.

The service number can be found on the serial tag:

Index / Service Service-Nr./No.Service

Fig. Example illustration

Check appliance

Check all parts for transport damage. If you have any complaints, please contact your agent or customer service.

Differences

These instructions apply to a range of models, so there may be differences. Sections that apply to certain models only are indicated by an asterisk (*).

Symbol	Explanation
	Instructions and resultsInstructions are marked with a ▶. Results are marked with a ▷.
	VideosVideos about the appliances are available on the YouTube channel of Liebherr-Hausgeräte.

These operating instructions apply to:

FN d/e/f	42/46/50/52...
FN c/d	66/70/72...
FN sf e	5227
SFN (bd/sd/sf) e	52...
GNeu	1460-e
LTGN-234

Note

If your appliance has an N in its appliance designation, it is a NoFrost appliance.

1 The appliance at a glance

1.1 Delivered contents

Check all parts for damage during transport. If you have any complaints, please contact the dealer or Customer Service (see 9.4 Customer service).

Delivery contains the following parts:

• Standalone appliance
• Equipment (depending on your model)
• Installation parts (depending on your model)
• "Quick Start Guide"
• "Installation Guide"
• Service brochure

1.2 Appliance and equipment overview

Fig. 1 Example illustration

Equipment

(1) Control elements
(2) Serial tag
(3) Tilting drawer*
(4)SpaceBox*
(5) IceTower*
(6) IceMaker* / EasyTwist-Ice*

(7) Freezer tray ^ , cold storage accumulators ^

(8) Ice cube tray*
(9) Ice cube scoop*

(10) NoFrost

(11) Ventilation slit

(12) VarioSpace

(13) Adjustable feet (front), transport castors (rear), transport handles at the top (rear) and bottom (front)

Note

The shelves, drawers, and baskets are arranged for optimal energy efficiency in the factory configuration. However, changes to the arrangement within the given insertion options – for example the arrangement of shelves in the fridge compartment – have no effect on energy consumption.

1.3 Range of appliance use

Normal use

The appliance is only suitable for cooling food for residential or other similar environments. This includes the following types of uses

• in staff kitchens, bed and breakfasts,
• by guests in country homes, hotels, motels and other types of accommodations,
• for catering and similar wholesale services.

The appliance is not suitable as a built-in unit; All other types of uses are not permitted.

Foreseeable misuse

The following uses are specifically prohibited:

- Storage and cooling of medication, blood plasma, laboratory preparations or similar substances and products in accordance with the Medical Device Directive 2007/47/EC

- Use in areas at risk of explosion

Incorrect appliance use can cause damage to the stored products or cause them to spoil.

Climate ratings

The appliance is set to operate within specific ambient temperature limits according to its climate rating. The climate rating for your appliance is printed on the rating plate

Note

▶ To guarantee trouble-free operation, comply with the indicated ambient temperatures.

Climate rating	for ambient temperatures
SN, N	to 32 °C
ST	to 38 °C
T	to 43 °C

If your appliance has a fixed water connection, then the appliance is guaranteed to function correctly down to a lower ambient temperature of 0 °C .*

If your appliance does not have a fixed water connection, then the appliance is guaranteed to function correctly down to a lower ambient temperature of -15 °C.*

1.4 Conformity

The refrigerant circuit has been tested for leaks. The appliance complies with the applicable safety regulations and with the directives 2014/35/EU, 2014/30/EU, 2009/125/EC, 2011/65/EU, 2010/30/EU and 2014/53/EU.

The full text of the EU Declaration of Conformity is available on the following website: www.Liebherr.com

1.5 EPREL Database

Details about energy labeling and ecodesign requirements will be available on the European product database (EPREL) from March 1, 2021. You can access the product database at the following link: https://eprel.ec.europa.eu/ You will be asked to enter the model ID. You can find the model ID on the type plate.

2 General safety instructions

Please keep these operating instructions in a safe place so you can refer back to them at any time.

If you pass the appliance on, please hand these operating instructions to the new owner.

Read these operating instructions before use in order to use the appliance safely and correctly. Follow the instructions, safety instructions and warning messages included at all times. They are important for ensuring you can operate and install the appliance safely and without any problems.

Dangers for the user:

- This appliance can be operated by children as well as by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they are supervised or have been instructed in the safe use of the appliance and understand the associated risks. Children must not play with the appliance. Cleaning and user maintenance must not be performed by children unless they are supervised. Children between the ages of 3 and 8 may load and unload the appliance. Children under the age of 3 must be kept away from the appliance if they are not constantly supervised.

- The socket must be easily accessible so that the appliance can be disconnected quickly from the electricity in an emergency. It must not be located in the area behind the appliance.

- When disconnecting the appliance from the outlet, always take hold of the plug. Do not pull on the cable.

- Disconnect the power plug or switch off the power if a fault occurs.

- Do not damage the mains power line. Do not operate the appliance from a defective mains power line.

- Repairs and work on the appliance may only be carried out by after sales service or other specifically trained qualified personnel.

- The appliance should only be assembled, connected and disposed of in accordance with the instructions.

- The manufacturer is not liable for damage arising from incorrect connection to the water supply.*

Risk of fire:

- The refrigerant contained within the appliance (specifications on the rating plate) is environ-

mentally friendly, but flammable. Leaking refrigerant can ignite.

• Do not damage the pipes of the refrigerant circuit.
• Do not handle ignition sources inside the appliance.
• Do not use electrical devices inside the appliance (e.g. steam cleaners, heaters, ice cream makers, etc.).

• If refrigerant leaks: Remove naked flames or ignition sources located near the area of the leak. Air the room well. Contact the customer service department.

• Do not store explosive materials or spray cans with flammable propellants, such as e.g. butane, propane, pentane, etc. in the appliance. You can recognize such spray cans by the printed contents or a flame symbol. Any leaking gasses can be ignited by electrical components.

• Keep lit candles, lamps and other objects with naked flames away from the appliance so they do not cause a fire.
• Alcoholic beverages or other containers holding alcohol must always be tightly sealed for storage purposes. Any leaking alcohol can be ignited by electrical components

Tipover hazard:

- Do not stand or climb on the base, drawers, doors, etc. This applies in particular to children.

Risk of food poisoning:

- Do not consume food that has passed its best before date.

Danger of frostbite, feelings of numbness and pain:

- Avoid prolonged skin contact with cold surfaces or chilled/frozen food or take protective measures, e.g. wear gloves.

Risk of injury and damage:

• Hot steam may lead to injuries. Do not use any electrical heating or steam cleaning equipment, naked flames or defrosting sprays for defrosting
• Do not remove ice with sharp objects

Risk of crushing:

- Do not reach into the hinge when opening and closing the door. Fingers may get trapped.

Symbols on the device:

The symbol can be on the compressor. It refers to the oil in the compressor and refers to the following danger: Can be lethal if swallowed or inhaled. This notice only applies for recycling. There is no danger during normal operation.

The symbol is located on the compressor and indicates the danger of inflammable materials. Do not remove the label.

This label or a similar one can be located on the rear of the appliance. It refers to the foamed-in panels in the door and/or the housing. This notice only applies for recycling. Do not remove the label.

Observe the warning messages and other detailed information in the other sections:

	DANGER	indicates a hazardous situation, which if not avoided, will result in death or serious injury.
	WARNING	indicates a hazardous situation, which if not avoided, could result in death or serious injury.
	CAUTION	indicates a hazardous situation, which if not avoided, will result in minor or moderate injury.
	NOTICE	indicates a hazardous situation, which if not avoided, could result in damage to property.
	Note	indicates useful advice and tips.

3 Start-up

3.1 Turning on the appliance

Make sure that the following requirements are met:

☐ Appliance is set up and connected according to installation instructions.
☐ All adhesive strips, adhesive and protective films, as well as transport safety devices in and on the appliance are removed.
☐ All advertising material has been removed from the drawers.

Fig. 2

▶ Switch on the appliance using the control panel next to the display.
▷ The status display appears.

The appliance starts in DemoMode:

If the appliance starts in DemoMode, you can deactivate DemoMode within the next 5 minutes.

Demo 3:14 < > 3s

Fig. 3
▶ Press Confirm next to the display for 3 seconds.
▷ DemoMode is deactivated.

Note

The manufacturer recommends:

▶ Store frozen foods at -18 °C or colder.

3.2 Insert the equipment

▶ Insert the supplied equipment to help you make the most of the appliance.
▶ Purchase the SmartDevice Box and insert it (see smartdevice.liebherr.com).
▶ Install the SmartDevice app (see apps.home.liebherr.com).

Note

You can purchase accessories from the Liebherr household appliance store (home.liebherr.com).

4 Food management

4.1 Storing food

WARNING

Danger of fire

▶ Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

Note

Insufficient ventilation results in an increase in energy consumption and reduction of the refrigerating performance

▶ Always keep the air slots unobstructed.

When storing food, remember these basic rules:

☐ Do not obstruct the air vents on the back wall.
☐ Do not obstruct the air vents on the fan.
□ Food is well sealed.
☐ Raw meat or fish is in clean, sealed containers so that other food cannot be touched or drip on them.
☐ Food is stored spaced apart to ensure good air circulation.

Note

Failure to follow these guidelines can lead to food perishing.

4.1.1 Freezer

This provides a dry, frosty storage climate at -18 °C. A frosty climate is suitable for storing frozen food and goods for several months, preparing ice cubes, or freezing fresh food.

Freezing food

You can freeze as many kilograms of fresh food within 24 hours as indicated on the nameplate (see 9.5 Rating plate) under "freezing capacity ... kg/24h".

To ensure that the food freezes quickly to the core, keep to the following quantities per pack:

• Fruit, vegetables up to 1 kg
• Meat up to 2.5 kg

Before freezing, please note the following:

☐ SuperFrost is activated (see 6.3 Functions) when the amount of food to freeze exceeds approx. 2 kg.
☐ SuperFrost is activated (see 6.3 Functions) when the amount of food to freeze exceeds approx. 2 kg.
☐ With a small volume of frozen goods: SuperFrost is activated approx. 6 hours prior.
☐ With the maximum volume of frozen goods: SuperFrost is activated approx. 24 hours prior.

Arranging the food:

CAUTION

There is a risk of injury from pieces of broken glass!

Bottles and cans containing drinks can split or crack when frozen. This applies in particular to carbonated drinks.

▶ The BottleTimer function must be used when freezing bottles and cans with drinks.

With a small amount of frozen goods:

▶ Place packaged groceries in the top drawer.
▶ If possible, place groceries at the back of the drawer near the rear wall.
With the maximum amount of frozen goods:
▶ Distribute packaged groceries across all drawers, but do not place any groceries in the lowest drawer.
▶ If possible, place groceries at the back of the drawer near the rear wall.
With the maximum amount of frozen goods:
▶ Once SuperFrost activates automatically, place food into the drawer.

Defrosting food

• in the fridge compartment
• in the microwave
• in the oven/fan oven
• at room temperature

WARNING

Danger of food poisoning!

▶ Do not re-freeze defrosted food.

▶ Remove only the food you need for now.
▶ Use defrosted food as quickly as possible

Freezer tray\*

Use the freezer tray for berries, herbs, vegetables and other small goods without them freezing together in the process. The food keeps its shape and is easier to separate into portions later on.

You can also store the freezer packs in the freezer tray to save space.*

▶ Spread food, unsealed, at a good distance apart, over the whole surface of the freezer tray.

4.2 Storage times

The storage times given are guidelines

Food with a “use by” date must still be consumed by the date indicated on the package

Guidelines for storage periods for various foods
Ice cream	at -18 °C	2 to 6 months
Sausage, ham	at -18 °C	2 to 3 months
Bread, bakery products	at -18 °C	2 to 6 months
Game, pork	at -18 °C	6 to 9 months
Fish, fatty	at -18 °C	2 to 6 months
Fish, lean	at -18 °C	6 to 8 months
Cheese	at -18 °C	2 to 6 months
Poultry, beef	at -18 °C	6 to 12 months
Vegetables, fruit	at -18 °C	6 to 12 months

5 Energy saving

• Always ensure good ventilation. Do not obstruct ventilation openings or grilles.
• Never block air slits in the fan.
• Do not install the appliance in direct sunlight or next to a stove, heater or similar heat source.
• Energy consumption depends on installation conditions such as the ambient temperature (see 1.3 Range of appliance use). A warmer ambient temperature can increase the energy consumption.
• Avoid opening the appliance door for any longer then necessary
• The lower the temperature is set the higher the energy consumption.
• All food stored in the appliance should be well wrapped and covered. This prevents frost buildup.
• Insertion of warm foods: first let the food cool down to room temperature.

6 Use

6.1 Controls and displays

The display provides a quick overview of the temperature setting and the status of functions and settings. You can control the functions and settings either by deactivating/activating them or by selecting a value.

6.1.1 Status display

-18 °C

Fig. 4

(1) Temperature display

The Status display shows the set temperatures and is the home display. From there, you can navigate to the options and settings.

6.1.2 Navigation

Navigate in the menu to access the individual functions. An audible signal sounds after confirming a function or setting. If no selection is made after 10 seconds the display switches to the Status display.

The appliance is operated with the buttons next to the display.

Fig. 5

(1) Left/right navigation arrow

(2) Confirm

Left/right navigation arrow Fig. 5 (1):

- Navigating in the menu. After the last menu page, it goes back to the first one.

Confirm Fig. 5 (2):

• Activating/deactivating a function.
• Opening a submenu.
• Confirming a selection. After confirmation the display switches back to the menu.

Back to the Status display: in the fastest possible manner:

• Close and open the door.
• or wait 10 seconds. The display changes to the Status display.

6.1.3 Operating structure

The controls are explained by a template. The display changes depending on the function or settings.

Menu without submenu

Fig. 6

(1) Status deactivated / status activated white bar in the top area
(2) Symbol or selected value

(3) Menu: Function name or menu: Setting name

Menu with submenu

Fig. 7

(1) Menu: Function name or menu: Setting name
(2) Status

(3) Symbol or selected value

(4) Submenu: Function name or submenu: Setting name

(2) Off / On

You can navigate as follows:

• Navigate with the left/right navigation arrow Fig. 5 (1).

• Press Confirm Fig. 5 (2) to go to the submenu Fig. 7 (4).

• Navigate with the left/right navigation arrow Fig. 5 (1).

• Set new level: Press Confirm Fig. 5 (2) to select a deselected value Fig. 6 (1).
• Back to menu: Press Confirm Fig. 5 (2) to select the selected value Fig. 6 (2).

6.1.4 Display symbols

The display symbols provide information about the current appliance status.

Symbol	Appliance status
	StandbyThe appliance or temperature zone is turned off.
	Flashing numberAppliance is working. Temperature flashes, until the set value is reached.
	Flashing symbolAppliance is working. Setting is made.
	Bar grows steadilyFunction is activated.

6.2 Operating logic

6.2.1 Activating/deactivating settings

You can activate/deactivate the following functions:

Symbol	Function
	SuperFrostx
	IceMaker and MaxIcex*
	PartyModex
	E-Saver

* When a function is on, the appliance works harder. This means the appliance could make louder noises and consume more energy.

▶ Press the navigation arrows Fig. 5 (1) until appears.
▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status appears in the menu.
▷ Function is on/off.

6.2.2 Selecting function value

With the following functions you can set a value in the submenu:

Symbol	Function
-18°	Setting the temperatureSwitch the appliance on/off

▶ Press the navigation arrows Fig. 5 (1) repeatedly until the function is displayed.
▶ Press Confirm Fig. 5 (2).
▶ Select the setting value with the navigation arrows Fig. 5 (1).

Setting the temperature

▶ Press Fig. 5 (2) confirm.
▷ You hear the confirmation tone.
▷ Status: on Fig. 6 (1) appears briefly in the submenu Fig. 7 (4).
▷ Display switches back to the menu.

6.2.3 Activating/deactivating settings

You can activate/deactivate the following settings:

Symbol	Setting
	WiFi^1
	Entry lock^2
	SabbathMode^2
	Reminders^1
	Reset^2
	Switch off ^2

▶ Press the navigation arrows Fig. 5 (1) repeatedly until the settings 🎨 are displayed.
▶ Press Confirm Fig. 5 (2).
▶ Press the navigation arrows Fig. 5 (1) repeatedly until the desired setting is displayed.

^1 Activate setting (short press)

▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status appears in the menu.
▷ Setting is activated / deactivated.

^2 Activate setting (long press)

▶ Press Confirm Fig. 5 (2) for 3 seconds.
▷ You hear the confirmation tone.
▷ Status appears in the menu.
▷ Display changes.

6.2.4 Selecting the setting value

With the following settings you can set a value in the submenu:

Symbol	Settings
	Brightness
	Door alarm
	Temp. unit

▶ Press the navigation arrows Fig. 5 (1) repeatedly until the settings 🎨 are displayed.
▶ Press Confirm Fig. 5 (2).
▶ Press the navigation arrows Fig. 5 (1) repeatedly until the desired setting is displayed.

▶ Press Confirm Fig. 5 (2).
▶ Select the setting value with the navigation arrows Fig. 5 (1).
▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status appears briefly in the submenu.
▷ Display switches back to the menu.

6.2.5 Calling up the customer menu

The customer menu provides the following settings:

Symbol	Function
	TubeClean2*
	Ice cube1*
	Software

▶ Press the navigation arrows Fig. 5 (1) repeatedly until the settings 📄 appear.
▶ Press Confirm Fig. 5 (2).
▶ Press the navigation arrows Fig. 5 (1) repeatedly until appliance information 📋 appears in the display.
▶ Press Confirm Fig. 5 (2).
▶ Enter the numerical code 151.
▷ The customer menu appears.
▶ Press the navigation arrows Fig. 5 (1) repeatedly until the desired setting appears.

^1 Select the setting value

▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status appears briefly in the display.
▷ The display switches back to the menu.

^2 Activate setting

▶ Press Confirm Fig. 5 (2) for 3 seconds.
▷ You hear the confirmation tone.
▷ Status appears in the display.
▷ The symbol flashes as long as the appliance is working.

6.3 Functions

Temperature

The temperature depends on the following factors:

• the number of times the door is opened
• The duration the door is opened
• the room temperature of the installation location
• the type, temperature and amount of food

Freezer compartment	Recommended setting
-18°C	-18 °C

Setting the temperature

5 °C 5 °C < > < > 1s

Fig. 8
▶ Set the value. (see 6.2 Operating logic).
▷ The set temperature is shown on the bottom right of the display.

SuperFrost

Select this function for the maximum freezing setting, to reach lower freezing temperatures.

Use:

• To freeze more than 2 kg fresh food a day.
• Freezing fresh food quickly to the core.
• Increasing the cold reserves in the stored goods before defrosting the appliance.

Activating/deactivating settings

With a small volume of frozen goods:

▶ Activate 6 hours before use.
With the maximum volume of frozen goods:
▶ Activate 24 hours before use.
▶ Activating/deactivating (see 6.2 Operating logic).

The function automatically turns off. The appliance goes back to normal mode. The temperature adjusts itself to the set level.

PartyMode

This option offers an assortment of special functions and settings that are useful if you are having a party.

The following functions are activated:

• SuperFrost
• IceMaker and MaxIce*

You can set any functions you like. Your changes are lost when the option is switched off.

Activating/deactivating settings

▶ Activating/deactivating (see 6.2 Operating logic).
▷ On: All functions are activated at the same time.
▶ Deactivated: Previously set temperatures are restored.
The function is automatically switched off after 24 hours.

E-Saver

This function reduces energy consumption. If you activate this function, the cooling temperature increases.

Temperature zone	Recommended setting (see Temperature)	Temperature when E-Saver activated
-18°C	-18 °C	-16 °C

Use:

- Save energy.

Activating/deactivating settings

▶ Activating/deactivating (see 6.2 Operating logic).
▶ Activated: Higher temperatures are set in all temperature zones.
▶ Deactivated: Previously set temperatures are restored.

IceMaker\*

This function activates the production of ice cubes.*

Use:*

- Producing ice cubes

The ice cube size can be set with the ice cube function. (see Ice cubes*) *

You can increase the number of ice cubes produced with the MaxIce function. (see MaxIce*) *

The lines can be cleaned with the TubeClean function. (see TubeClean*) *

Activating the function\*

Make sure that the following requirements are fulfilled:

☐ The water supply is established at the fixed water connection. See Assembly Manual.*
☐ IceMaker is put into operation.
▶ Activate the function. (see 6.2 Operating logic)
▷ It can take up to 24 hours for the first ice cubes to be made.

Deactivating the function\*

▶ Deactivate the function. (see 6.2 Operating logic)
▷ If ice cubes are currently being made, the system completes the process. After that, the IceMaker switches off.

MaxIce\*

Using the MaxIce function, ice cubes can quickly be produced at 1.5 kg of ice cubes in 24 hours.*

Use:*

- Produces many ice cubes in a short period of time.

Activate/deactivate the function\*

▶ Activate/deactivate (see 6.2 Operating logic) .

6.4 Settings

Setting up the WLAN connection

This setting connects the appliance to the internet. The connection is managed in the SmartDevice Box. You can use the SmartDevice-App to add your appliance to a SmartHomeSystem. Use the SmartDevice-App or other compatible partner networks to enjoy advanced options and settings.

Note

The SmartDevice Box is available from the Liebherr Residential Appliances Store (https://home.liebherr.com/shop/de/deu/smartdevicebox.html).

More information about the availability, prerequisites and individual options can be found on the Internet at https://smartdevice.liebherr.com/install.

Use:

• Manage the appliance with the SmartDevice-App or a compatible partner network.
• Enjoy advanced functions and settings.
• Check the appliance status on the SmartDevice-App.

☐ Purchase the SmartDevice Box and insert it (see https://smartdevice.liebherr.com/install).
☐ Install the SmartDevice app (see https://apps.home.liebherr.com/).

Setting up the WLAN connection

Fig. 9

▶ Activate (see 6.2 Operating logic).
The connection is set up: Status: on Fig. 6 (1) and WiFi connecting appears. The symbol flashes.
The connection is set up: Status: on Fig. 6 (1) appears.
The connection failed: Status and Connect appears. The symbol appears permanently.

Disconnecting

▶ Deactivate the setting (see 6.2 Operating logic).

Fig. 10

There is no connection: The symbol is displayed constantly.

Restoring the connection

▶ Restore settings (see 6.2 Operating logic).

Fig. 11

▷ Connection and other settings are restored to factory settings.

Entry lock

This setting avoids accidental operation of the appliance, e.g. by children.

Use:

• Avoid unintentional changing of settings and functions.
• Avoid unintentional switching off of the appliance.
• Avoid unintentional temperature adjustments.

Activating/deactivating settings

▶ Activating/deactivating (see 6.2 Operating logic).

Display brightness

With this setting, you can choose a brightness level for the display.

You can set the following brightness levels:

• 40%
• 60%
• 80%
• 100%

Choosing the setting

▶ Set the level (see 6.2 Operating logic).

Door alarm

Set the time before the door alarm (see Close the door) sounds.

Options are as follows:

• 1 min
• 2 min
• 3 min
• Off

Choosing the setting

▶ Set the level (see 6.5 Error messages).

Temperature unit

This setting allows you to change between Celsius and Fahrenheit as the temperature unit.

Selecting the setting value

▶ Set the value (see 6.2 Operating logic).

Info

This setting allows the appliance information to be read out as well as access to the customer menu.

It provides the following information:

• Model name
• Index
• Serial number
• Service number

View appliance data

▶ Press the navigation arrows Fig. 5 (1) repeatedly until the settings 🎨 are displayed.
▶ Press Confirm Fig. 5 (2).
▶ Press the navigation arrows Fig. 5 (1) repeatedly until the information display appears.
▶ Read the appliance data.

SabbathMode

This setting meets the religious requirements on the Sabbath and Jewish festivals. Turn on SabbathMode to switch off certain controls. This means you can use the appliance without anyone changing any settings.

You can find a list of Star-K-certified appliances at www.stark.org/appliances.

WARNING

Danger of food poisoning!

If there is a power outage when SabbathMode is on, this message is not saved. When the power is restored, the appliance continues in SabbathMode. Afterwards, the temperature display does not show a message about the power outage.

If there was a power outage during SabbathMode:

▶ Check the quality of the food. Do not consume spoiled food!

What happens on the appliance when in SabbathMode:

• The Status display permanently shows SabbathMode.
• The display is locked for all functions apart from turning off SabbathMode.
• Any functions/settings that are already on, remain active.
• The display stays bright when the door is closed.
• Reminders are disabled. The set timer interval is also stopped. The function is no longer executed in SabbathMode.
• Reminders and warnings are not displayed. No acoustic signals are emitted and the display does not show warnings / settings such as temperature alarm or door alarm.
• IceMaker is out of use.*
• The defrost cycle only works for the specified time without taking account of fridge use.
• After a power cut the appliance automatically returns to SabbathMode.

Activating/deactivating SabbathMode

▶ To activate this function, click the arrows next to the display until you see the Settings ✉ menu item and then confirm. The menu shows the available settings.
▶ Click the arrows next to the display until you see the SabbathMode (Menora) symbol. Confirm the symbol.
▷ A white bar appears in the top part of the display.
▷ SabbathMode has been activated.

To deactivate this function, press the confirmation button next to the display for 3 seconds.

SabbathMode has been deactivated.

TubeClean\*

This setting cleans the IceMaker pipes.*

Make sure that the following requirements are met:*

☐ IceMaker cleaning process is ready (see 8.2.6 Cleaning the IceMaker ^* ).

Activate setting\*

▶ Activate the setting in the customer menu (see 6.2 Operating logic).
▷ TubeClean is prepared (max. 60 min.): The symbol flashes.
▷ Water pipes are rinsed: Symbol flashes.
▷ Rinsing process is complete: Function turns off automatically.

Ice cubes\*

With this setting, you can choose the ice cube size.*

Choosing the setting\*

▶ Make your settings in the Customer menu (see 6.2 Operating logic).

Reminder

Reminders are displayed acoustically by a beep and visually by a symbol in the display. The signal gets louder until the alert stops.

Activate setting

▶ Activating/deactivating (see 6.2 Operating logic).

Reset

This function resets all settings to the factory settings. All settings that you have made thus far will be reset to their original values.

Activate the setting

▶ Activating (see 6.2 Operating logic) .

Turn off appliance

This setting turns off the whole appliance.

Switch off whole appliance

Fig. 12

▶ Turning off the IceMaker .*

▶ Activating/deactivating (see 6.2 Operating logic).
▷ Off: Display turns black.

6.5 Error messages

Error messages appear in the display. There are two categories of error message:

Category	Meaning
Message	Reminder of general procedures. You can carry out these procedures to eliminate the message.
Warning	Appears when there are malfunctions. A signal sounds in addition to the display. The signal becomes louder until you acknowledge by tapping the display. You can eliminate simple defects yourself. For more serious defects, you must contact customer service.

6.5.1 Warnings

Close the door

This message appears if the door is open too long.

You can set the time before this message appears.

▶ Stop alarm: Confirm the message.

-or-

▶ Close the door.

Power failure.

This message appears if the freezer temperature rises after a power outage. When the power outage is over, the appliance will continue to operate at the last temperature setting.

▶ Stop alarm: Confirm the message.

▷ Temperature alarm appears (see Temperature alarm).

Temperature alarm

This message appears if the temperature does not match the set temperature.

Temperature differences may be caused by:

• Hot fresh food was placed in the appliance.
• When sorting and removing food from the appliance, too much warm ambient air got in.
• There has been a prolonged power outage.
• The appliance is faulty.

When the cause is eliminated, the appliance will continue to operate at the last temperature setting.

▶ Confirm the display.

▷ Warmest temperature is displayed.

▶ Confirm the display again.

▷ The status display is displayed.

▷ Current temperature is displayed.

Error

This message appears when there is a fault with the appliance. An appliance component has an error.

▶ Open the door.

▶ Take note of the error code.

▶ Confirm the message.

▷ The signal tone stops.

▷ The status display appears.

▶ Close the door.

▶ Contact customer service. (see 9.4 Customer service)

6.5.2 Message

Insert IceMaker drawer\*

This message appears if the IceMaker drawer is open.

▶ Push in the IceMaker drawer.
▷ The message disappears.
The IceMaker produces ice cubes.

6.5.3 DemoMode

If “D” appears in the display, demo mode is on. This feature is designed for retailers. The cooling features are disabled.

Switching off DemoMode

When you see a time counting down:

▶ Confirm within the countdown.
▷ DemoMode is off. If there is no countdown:
▶ Disconnect the power plug.
▶ Reconnect the power plug.
▷ DemoMode is off.

7 Equipment

7.1 Drawers

You can remove the drawers for cleaning.

How the drawers are removed and inserted differs depending on the pull-out system. Your appliance can include a variety of pull-out systems.

Note

Insufficient ventilation results in an increase in energy consumption and reduction of the refrigerating performance.

▶ Leave the bottom drawer in appliance!
▶ Never obstruct the vents on the interior rear wall!

7.1.1 Remove the drawer

Drawer on molded ribs

①↑ ②↓

Fig. 13

▶ Pull drawer out completely.

▶ Lift at the front Fig. 13 (1).

▶ Remove to the front Fig. 13 (2).

Tilting top drawer*

Pure diagram of a mechanical or architectural component with no text, numbers, or symbols

Fig. 14

▶ Pull drawer out completely.

▶ Lift at the front.

▶ Lift from below.

▶ Remove to the front.

7.1.2 Inserting the drawer

Drawer on molded ribs

Pure technical diagram showing a mechanical assembly with no text, numbers, or symbols

Fig. 15

▶ Place drawer on the molded ribs behind the stoppers with the drawer tiled up at the front Fig. 15 ().

▶ Lower drawer.

▶ Slide to the rear.

Tilting top drawer*

Technical diagram showing two views of a mechanical component with numbered annotations indicating parts of each view.

Fig. 16

▶ Guide the drawer around the upper stoppers Fig. 16 (1).

▶ Place the drawer on the molded ribs behind the lower stoppers with the drawer tilted up at the front Fig. 16 (2).

▶ Lower drawer.

▶ Slide to the rear.

7.2 Pull-out board with IceTower\*

Diagram of a storage cabinet with numbered compartments and labeled parts

Fig. 17 Pull-out board with IceTower
(1) IceMaker

(3) Container for pizza or alcoholic beverages, for example

(2) Hang-on tray for ice cubes

(4) Pull-out board

On the pull-out board are two tall containers (IceTower). Ice cubes from the IceMaker are collected and stored in the container Fig. 17 (2). The container Fig. 17 (3) is suitable for storing tall foodstuffs or beverages such as pizzas or alcoholic drinks.

The pull-out board with IceTower is mounted on a glass shelf with pull-out rails. You can dismantle the pull-out board for cleaning.

7.2.1 Dismantling the pull-out board with IceTower

Removing the container

Diagram showing two storage bins with arrows indicating movement, one labeled with number 5 and arrow pointing to the second bin.

Fig. 18
▶ Remove the pull-out board.
▶ Lift the container Fig. 18 (5) at the front.
▶ Remove the container.

Line drawing of a mechanical device with an open lid and handle, showing a numbered component (6) and an upward arrow indicating motion (no text or symbols present)

Fig. 19
▶ Remove the hang-on tray Fig. 19 (6).
▶ If there are ice cubes in the hang-on tray: Empty the hang-on tray.
The container and hang-on tray have been removed and you can clean them. (see 8.2.4 Cleaning the equipment)

Removing the pull-out board

Make sure that the following requirements are fulfilled:

□ Containers have been removed. (see 7.2.1.1 Removing the container)

inhibitor 7 inhibitor 8 10 9

Fig. 20
▶ Slide in the pull-out board. Fig. 20 (7)
▶ Lift the pull-out board at the front left. Fig. 20 (8)
▶ Lift the pull-out board at the front right. Fig. 20 (9)
▷ The pull-out board is detached from the attachment at the front.
▶ Take out the pull-out board to the front. Fig. 20 (10)
The pull-out board has been removed and you can clean it. (see 8.2.4 Cleaning the equipment)

7.2.2 Inserting the pull-out board with IceTower

Inserting the pull-out board

toothlear

Fig. 21
▶ Slide the rails in.

Technical diagram showing a door handle assembly with numbered callouts and directional arrows indicating assembly steps.

Fig. 22
▶ Place the pull-out board in at an angle behind the front lug.
▶ Slide it in at an angle. Make sure that the stop is behind the lug on both sides. Fig. 22 (11)
▶ Lower the pull-out board at the front. Fig. 22 (12)

Technical diagram showing a mechanical assembly with downward arrows indicating motion or force (no text or symbols present)

Fig. 23
▶ Push the pull-out board down at the front.
▷ The pull-out board clicks into place.

Inserting the container

Make sure that the following requirements are fulfilled:

☐ The pull-out board is inserted. (see 7.2.2.1 Inserting the pull-out board)

Diagram illustrating a storage or inventory procedure with numbered steps and directional arrows indicating movement.

Fig. 24

▶ Remove the pull-out board.

▶ Hold the pull-out board with one hand.

Note

The containers are shaped in a way that they cannot be interchanged.

▶ Place the container at an angle on the pull-out board. Fig. 24 (13)

▶ Slide in the container at an angle to the back. Fig. 24 (14)

▶ Place container at the front. Fig. 24 (15)

Diagram showing a storage cabinet with numbered parts and directional arrows indicating assembly or inspection steps.

Fig. 25

▶ Insert hang-on tray Fig. 25 (6) for ice cubes.

▶ Slide in the pull-out board with container (IceTower). Fig. 25 (16)

▷ Pull-out board with IceTower is fully inserted.

EasyTwist-Ice

The EasyTwist-Ice produces ice cubes when the water tank is inserted.

The EasyTwist-Ice is used exclusively for the production of ice cubes in standard household quantities.

Note

Do not change the position of the EasyTwist-Ice.

Make sure that the following conditions are met:*

- The EasyTwist-Ice has been cleaned (see 8.2.5 Cleaning the EasyTwist-Ice*)

- The water tank has been cleaned.

- The EasyTwist-Ice drawer is fully inserted.

7.3.1 Filling the water tank

WARNING

Contaminated water!

Poisoning.

▶ Fill with potable water only.

NOTICE

Sugary liquids!

Damage to the EasyTwist-Ice.

▶ Fill with cold drinking water only.

Note

Using filtered, decarbonized water ensures the best-tasting drinking water for your ice cubes.

This water quality can be achieved using a table water filter of the kind available in trade retail outlets.

▶ Always fill the water tank only with filtered, decarbonized drinking water.

The water for the EasyTwist-Ice is supplied from a water tank.

① ② max

Fig. 26

▶ Lift up the water tank at the rear Fig. 26 (1) and take it out upwards Fig. 26 (2).

▶ Fill with drinking water up to the mark.

▶ Insert the water tank by reversing the steps described above.

7.3.2 Producing ice cubes

The production capacity depends on the freezer temperature. The lower the temperature, the more ice cubes that can be produced in a certain period.

Maximum capacity of the ice cube drawer - 40 cubes (2x ice cube production).

Time required for ice cube production – at least 5 hours.

Releasing the ice cubes

▶ Turn the knob to the right to its stop limit.

▶ If necessary, repeat several times and turn the knob a little more.

IceMaker

The IceMaker is used exclusively for the production of ice cubes in household quantities.

Make sure that the following conditions are fulfilled*

• IceMaker is cleaned (see 8 Maintenance).
• IceMaker drawer is fully inserted.

7.4.1 Producing ice cubes

The production capacity depends on the freezer temperature. The lower the temperature, the more ice cubes can be produced in a certain period

Once IceMaker is switched on for the first time, it can take up to 24 hours to produce the first ice cubes.

▶ Activate the IceMaker (see 6.2 Operating logic).
▶ To make a large quantity of ice cubes: Activate the MaxIce (see 6.2 Operating logic).
▶ Distribute ice cubes evenly in the drawer to increase its capacity.
▶ Close the drawer: The IceMaker starts making ice again.

Note

When a certain level is reached in the IceMaker drawer, it stops making ice cubes. The IceMaker does not fill the drawer to the very top.

7.5 VarioSpace

Pure architectural line drawing of a building facade with vertical dimension lines (no text or symbols)

Fig. 27

You can remove drawers and glass panels from your appliance. This provides more room for large food items such as poultry, joints of meat, large game and bulky baked goods. You can then freeze these items whole for later preparation.

▶ Note the load limits on the drawers and glass panels (see 9.1 Technical specifications).

7.6 Accessories

7.6.1 Freezer packs\*

The freezer packs prevent the temperature from rising too fast in the event of a power failure.

The freezer packs are in the drawer.

You can store the cold storage accumulators in the freezer tray.*

Using the freezer packs

Two gray 3D-rendered square objects with circular holes, no text or symbols present

Fig. 28

When the freezer packs are fully frozen:

▶ Place on the frozen goods in the top, front part of the freezer.

8 Maintenance

8.1 Defrosting the appliance

8.1.1 Defrosting with NoFrost

Defrosting is performed automatically by the NoFrost system. The moisture condenses on the evaporator and is periodically defrosted and evaporated.

The appliance does not have to be defrosted.

Note

Water droplets may collect on the bottom of the appliance. When you decommission the appliance:

▶ Place a towel in front of the appliance to catch any water that may run out. (see 10 Decommissioning)

8.2 Cleaning the appliance

8.2.1 Preparation

WARNING

Danger of electric shock.

▶ Unplug refrigerator or disconnect power.

WARNING

Danger of fire

▶ Do not damage the refrigerant circuit.

▶ Empty appliance.
▶ Pull out the power plug.

8.2.2 Cleaning the housing

NOTICE

Improper cleaning!

Damage to the appliance.

▶ Only use soft cleaning cloths and ph-neutral all-purpose cleaners.
▶ Do not use steel wool or sponges that scour or scratch.
▶ Do not use caustic or abrasive cleaning materials or those containing sand, chloride, or acids.

WARNING

Risk of injury or damage due to hot steam.

Hot steam can cause scalding/burns and damage to surfaces.

▶ Do not use steam cleaners.

▶ Wipe the housing down with soft, clean cloth. If very dirty, use lukewarm water with a neutral cleaner. Glass surfaces can also be cleaned with glass cleaner.

8.2.3 Cleaning the interior

NOTICE

Improper cleaning!

Damage to the appliance.

▶ Only use soft cleaning cloths and ph-neutral all-purpose cleaners.
▶ Do not use steel wool or sponges that scour or scratch.
▶ Do not use caustic or abrasive cleaning materials or those containing sand, chloride, or acids.

▶ Plastic surfaces: clean by hand with a soft clean cloth, lukewarm water and a little detergent.

▶ Metal surfaces: clean by hand with a soft clean cloth, lukewarm water and a little detergent.

8.2.4 Cleaning the equipment

NOTICE

Improper cleaning!

Damage to the appliance.

▶ Only use soft cleaning cloths and ph-neutral all-purpose cleaners.

▶ Do not use steel wool or sponges that scour or scratch.

▶ Do not use caustic or abrasive cleaning materials or those containing sand, chloride, or acids.

Clean with a soft, clean cloth, lukewarm water and a little washing up liquid:

• IceTower pull-out board*
• Drawer

Please note: Do not remove the magnet on the drawer. The magnet ensures that the IceMaker functions.*

- Freezer tray*

Clean in the dishwasher up to 60 °C:

• Ice cube tray*
• Ice cube scoop*
  ▶ Disassemble the equipment: see the relevant section.
  ▶ Clean the equipment.

8.2.5 Cleaning the EasyTwist-Ice\*

Cleaning must be conducted in the following situations:

☐ Operating for the first time
☐ Non-use for longer than 48 hours
☐ When the appliance requires cleaning

When operating for the first time, longer periods of disuse and when the appliance requires cleaning

Technical line drawing of a mechanical device with labeled components (no text or symbols present)

Fig. 29

▶ Take out the water tank Fig. 29 (1) and ice cube drawer Fig. 29 (2).
▶ Take out the freezer drawer with EasyTwist-Ice.

Technical line drawing showing a door opening and internal components, no text or symbols present

Fig. 30

▶ Press the lug Fig. 30 (1), lift up the EasyTwist-Ice at the back and take it out of the freezer drawer.

Technical diagram of a mechanical assembly with labeled components and directional arrows

Fig. 31

▶ Press the lugs Fig. 31 (1) on both sides of the EasyTwist-Ice simultaneously and take off the cover Fig. 31 (2) upwards.

Technical diagram showing a mechanical assembly with labeled components and directional arrows

Fig. 32

▶ Press all lugs Fig. 32 (1) one after another and remove the cover Fig. 32 (2).
▶ Clean the Ice cube drawer, water tank and EasyTwist-Ice with water and a little detergent.
▶ Assemble the EasyTwist-Ice.

Technical diagram of a mechanical device with labeled parts and directional arrows indicating assembly or inspection steps.

Fig. 33

▶ Insert the axles Fig. 33 (1) on the EasyTwist-Ice in the guides and push the rear side Fig. 33 (2) until the lug engages.
▶ Push in the EasyTwist-Ice drawer.

WARNING

Contaminated water!

Poisoning.

▶ Fill with potable water only.

▶ Fill the water tank and insert it. (see 7.3.1 Filling the water tank)

With unfiltered water:

▶ Dispose of ice cubes that were produced within 24 hours of the first ice cube production.

With filtered water:

▶ Dispose of ice cubes that were produced within 48 hours of the first ice cube production.

8.2.6 Cleaning the IceMaker\*

There are various options for cleaning the IceMaker.

We recommend cleaning in the following situations:

☐ Initial commissioning
☐ If out of use for longer than 5 days.*

Make sure that the following requirements are met:

☐ IceMaker drawer is emptied.
☐ IceMaker drawer is fully inserted.
☐ The IceMaker has been activated. (see 6.2 Operating logic)

On first use or if not used for prolonged periods

Clean the IceMaker with TubeClean.

▶ Place a 1.5 l empty container (max. height 10 cm) in the drawer under the IceMaker.
▶ Activate the TubeClean function. (see 6.2 Operating logic)
▷ The rinse process is prepared (max. 60 min.): The symbol flashes.
▷ Water pipes are rinsed: Symbol flashes.

▷ Rinsing process is complete: Function turns off automatically.

▶ Take out the IceMaker drawer and remove the container.

▶ Clean the IceMaker drawer with warm water and a little detergent.

▶ Push in the IceMaker drawer.

▷ Ice cube production starts automatically.

▶ Dispose of any ice cubes that are produced within 24 hours of the first ice cube production.

When cleaning is required

Clean the IceMaker manually.

▶ Remove the IceMaker drawer and clean with warm water and a little detergent.
▶ Push in the IceMaker drawer.
▷ Ice cube production starts automatically.

8.2.7 After cleaning

▶ Wipe dry the appliance and items of equipment
▶ Connect and switch on the appliance.
▶ Activate SuperFrost (see 6.3 Functions). When the temperature is sufficiently cold
▶ Place the food inside.
▶ Repeat cleaning regularly.

9 Customer support

9.1 Technical specifications

Temperature zone
Freezing	-28 °C to -15 °C

Maximum freezing capacity / 24 hrs
Freezer	See nameplate, “Freezing capacity ... / 24h”

Max. equipment capacity
Equipment	Appliance width550 mm(see installation instructions, appliance dimensions)	Appliance width600 mm(see installation instructions, appliance dimensions)	Appliance width700 mm(see installation instructions, appliance dimensions)
Drawer on molded rib	14 kg	19 kg	25 kg
Bottom drawer	--	11 kg	19 kg
Top tilting drawer*	--*	19 kg*	19 kg*

Ice cube production with IceMaker*
Ice cube produc-tion / 24 h	At a temperature of -18 °C: 0.8 kg of ice cubes
Maximum ice cube production / 24 h	When the Maxlce function is active: 1.2 kg of ice cubes

Ice cube production with EasyTwist-Ice*
Time required at -18 °C	approx. 5.5 h
Time required with SuperFrost activated	approx. 3 h

9.2 Operating noises

The appliance makes noises while in operation.

• At less cooling output the appliance saves energy but takes longer to cool items. The volume is lower.
• At a higher cooling output the food cools more quickly. The volume is higher.

Examples:

• Activated functions (see 6.3 Functions)
• Running fan
• Freshly sorted food
  • High ambient temperature
  • Door opened for long periods

Noise	Possible cause	Type of noise
Bubbling and splashing	Coolant is flowing into the cooling circuit.	Normal noise
Spitting and hissing	Coolant is spraying into the cooling circuit.	Normal noise
Humming	The appliance cools. The volume depends on the cooling output.	Normal noise
Whirring and murmuring	The fan is running.	Normal operating noise
Clicking	Components are being switched on and off.	Normal switching noise
Rattling or humming	Valves are active.	Normal switching noise

Noise	Possible cause	Type of noise	How to resolve
Vibration	Unsuitable setup	Error noise	Adjust the feet to make sure the appliance is horizontal.

Noise	Possible cause	Type of noise	How to resolve
Clattering	Equipment, Objects inside the appliance	Error noise	Secure equipment parts.Leave a gap between items.

9.3 Technical faults

Your appliance is designed and manufactured for reliable operation and a long service life. If a malfunction nonetheless occurs during operation, please check whether the malfunction is due to an operating error. In this case, you will have to be charged for the costs incurred, even during the warranty period. You may be able to rectify the following faults yourself.

9.3.1 Appliance function

Defect	Cause	Remedy
The appliance does not work.	→ The appliance is not switched on.	► Switch on the appliance.
	→ The power plug is not properly inserted in the wall socket.	► Check the power plug.
	→ The powerfuse in the wall socket is not OK.	► Check the fuse.
	→ Power failure.	► Keep the appliance closed. ► Protect your food: Lay freezer packs on top of the food or use another freezer if the power is off for a prolonged period. ► Do not re-freeze defrosted food.
	→ The appliance connector is not correctly inserted in the appliance.	► Check the appliance connector.
The temperature is not cold enough	→ This means that the door of the appli-ance is not closed properly	► Close the appliance door
	→ Insufficient ventilation	► Clear and clean the ventilation grille.
	→ The ambient temperature is too high	► Solution: (see 1.3 Range of appliance use) .
	→ The appliance was opened too frequently or for too long	► Wait to see whether the required temperature resets itself by itself. If not, contact Customer Service (see 9.4 Customer service) .
	→ Too much fresh food was placed inside without SuperFrost.	► Solution: (see SuperFrost)
	→ The temperature is incorrectly set	► Set to a colder temperature and check after 24 hours.
	→ The appliance is too near to a heat source (stove, heater etc).	► Change location of appliance or the heat source.
The door seal is defective or should be replaced for other reasons.	→ The door seal is interchangeable. You can replace it without the use of any special tools.	► Contact Customer Service (see 9.4 Customer service) .
The appliance is iced up or conden-sation is building.	→ The door seal may have slipped out of its groove.	► Check the door seal is well placed in the groove.
The outside surfaces of the appliance are hot*.	→ The heat of the refrigerant circuit is used to prevent condensate from forming	▶ This is normal.

9.3.2 Equipment

Defect	Cause	Remedy
The IceMaker cannot be switched on.*	→ The appliance and therefore the IceMaker are not connected.	► Connect the appliance (see Installation Guide).
The IceMaker is not making any ice cubes.*	→ The IceMaker is not switched on.	► Activate the IceMaker.
	→ The drawer of the IceMaker is not properly closed	► Close the drawer properly
	→ The water connection is not open	► Open the water connection*

9.4 Customer service

First check if you can fix the error yourself (see 9 Customer support). If this is not the case, please contact customer service.

Please refer to the enclosed "Liebherr Service" brochure for the address.

WARNING

Unprofessional repair! Injuries.

▶ Repairs and work on the appliance and the power supply cable not described in the Manual (see 8 Maintenance) should only be carried out by a qualified service provider.
A damaged power cable may only be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person.
▶ For appliances with an IEC connector, the change can be made by the customer.

9.4.1 Contact Customer Service

Make sure to have the following appliance information to hand:

☐ Appliance name (model and index)
□ Service no. (service)
Serial no. (S no.)
▶ Showing appliance info on the display (see Info).
-or-
▶ Referring to appliance info on the nameplate (see 9.5 Rating plate).
▶ Take note of the appliance information.
▶ Inform Customer Service: Tell us the problem and the appliance details.
▷ This will help us give you fast and accurate support.
▶ Further instructions from customer service will follow.

9.5 Rating plate

The nameplate is located behind the drawers on the inside of the appliance.

Index Service-Nr./No.Service: Please/Class Class/Class An-Type/AP Type AP-Type/AP Type Buduzinath/Green Capacity Volume Brdt/Capacity Brdt Total volume g/kg / 24 h Nutziniath Net Capacity Tol / R / F / CE / CHLL / ICE Volume Utila / Tsl / R / C / CA / CHLL / GLA Capac Util / Tsl / F / C / BO / CHLL / HID R: www.g A: -8 V Hz Serial-Nr ① ② ③

(1) Appliance name
(2) Service no.
▶ Information from the nameplate.
(3) Serial no.

Fig. 34

10 Decommissioning

▶ Empty appliance.
▶ Switch off the IceMaker .*
▶ Switch off the appliance (see 6.4 Settings).
▶ Pull out the power plug.
▶ Remove the appliance connector if necessary: Pull it out and, at the same time, move it from the left to the right.
▶ Place a towel in front of the appliance to catch any water that may run out.
▶ Clean the appliance (see 8.2 Cleaning the appliance).
▶ Leave the door open to prevent bad smells

11 Disposal

11.1 Preparing appliance for disposal

Li-lon

Liebherr uses batteries in some of its appliances. In the EU, for environmental reasons, legislation obliges the end user to remove these batteries before disposing of the old appliances. If your appliance contains batteries, a corresponding notice is attached to the appliance.

Lamps

If you can remove the lamps yourself without destroying them, also remove these before disposal.

▶ Take the appliance out of operation.
▶ Appliance with batteries: Remove the batteries. For description, see Maintenance chapter.

▶ If possible: Remove lamps without destroying them.

11.2 Disposing of the appliance in an environmentally friendly manner

The appliance still contains valuable materials and must be collected separately from unsorted municipal waste so it can be recycled.

Dispose of batteries separately from the old appliance. You can do this by returning the batteries free of charge to retailers or taking them to recycling centers and collection centers for recyclable materials.

Lamps

Dispose of removed lamps via the respective collection systems.

For Germany:

You can dispose of the appliance free of charge via the class 1 collection containers at the local recycling and recyclable material collection centers. When purchasing a new fridge/freezer, if the sales area > 400 m ^2 , retailers will also take back the old appliance free of charge.

WARNING

Leaking refrigerant and oil!

Fire. The refrigerant contained within the appliance is environmentally friendly, but flammable. The oil contained within the appliance is flammable. Escaping refrigerant and oil can ignite if they are of high enough concentration and are exposed to an external heat source.

▶ Do not damage the pipelines of the coolant circuit and the compressor.
▶ Transport the appliance away without damaging it.
▶ Dispose of batteries, lamps, and the appliance according to the above specifications.

Image showing a QR code and a document icon with an information symbol, likely representing a digital link or information transfer.

home.liebherr.com/fridge-manuals

EN

Freezer

Issue date: 20220707

Part number index: 7088347-00

Abstract graphic with icons including a lock, snowflake, power button, and play button (no text or symbols)

User Guide

Quality, Design and Innovation

QR code with speech bubble and smartphone icon containing 'i' symbol, likely for mobile information access

home.liebherr.com/fridge-manuals

Abstract diagram with three gray square icons: a bell, a wind turbine symbol, and a Wi-Fi signal symbol (no text or labels)

Contents

1 Appliance at a glance.... 3
1.1 Scope of delivery.... 3
1.2 Overview of the appliance and features.... 3
1.3 Appliance range of use.... 3
1.4 Conformity.... 4
1.5 EPREL database.... 4

2 General safety instructions.... 4

3 Putting into operation.... 5

3.1 Switching on appliance.... 5

3.2 Inserting the components.... 5

4 Foods management.... 6

4.1 Storing food.... 6

4.2 Storage times.... 6

5 Saving energy.... 6

6 Controls.... 6

6.1 Controls and displays.... 6

Status display....6

Navigation....6

Operating structure....7

Display symbols....7

6.2 Control concept.... 7

Activating/deactivating the function....7

Selecting function value.... 7

Activating/deactivating settings....8

Selecting the setting value....8

Go to the Customer menu....8

6.3 Functions.... 8

Temperature....8

6.4

SuperCool....9

PowerCool....9

PartyMode* 9

HolidayMode....9

E-Saver....9

Settings.... 9

Connecting to the WLAN....9

Entry lock.... 10

Display brightness....10

Door alarm.... 10

Temperature unit.... 10

Info....10

SabbathMode....10

CleaningMode....11

Reminder....11

6.5 Warnings.... 11

Message.... 11

DemoMode.... 12

7 Features.... 12

7.1 Door rack.... 12

7.2 Shelves.... 12

7.3 Dividing shelf* 13

7.4 VarioSafe* 13

7.5 Drawers.... 13

7.6 EasyFresh-Safe cover.... 14

7.7 Adjusting the moisture levels.... 14

7.8 Pull-out board with bottle basket* 14

7.9 Accessories.... 15

8 Maintenance.... 15

8.1 FreshAir carbon filter.... 15

8.2 Defrosting the appliance.... 16

8.3 Cleaning the appliance.... 16

9 Customer help.... 17

9.1 Technical specifications.... 17

9.2 Operating noises.... 17

9.3 Technical fault.... 17

9.4 Customer Services.... 18

9.5 Model plate.... 19

10 Shutting down.... 19

11 Disposal.... 19

11.1 Preparing appliance for disposal.... 19

11.2 Disposing of the appliance in an environmentally friendly manner.... 19

The manufacturer is continually working on the further development of all types and models. Please be aware that we reserve the right to make changes to the shape, equipment and technology.

Symbol	Explanation
	Read instructionsPlease read the information in these instructions carefully to understand all of the benefits of your new appliance.
	Full instructions on the internetThe detailed instructions are available via the QR code on the front of these instructions, at home.liebherr.com/fridge-manuals or by entering the service number at home.liebherr.com/fridge-manuals.The service number can be found on the serial tag Fig. ().Fig. Example illustration
	Check applianceCheck all parts for transport damage. If you have any complaints, please contact your agent or customer service.
	DifferencesThese instructions apply to a range of models, so differences are possible. Sections that apply to certain models only are marked with an asterisk (*).
	Instructions and resultsInstructions are marked with a ▶.Results are marked with a ▷.
	Installation videosYou can find videos on installing appliances on the Liebherr-Hausgeräte YouTube channel.

Fig. Example illustration

These operating instructions apply to:

R(D) (sf) (e)(f)	42../ 46../ 50../ 52..
Kf/ Ksfe	46../ 52..
SR (sf) (sd) (bd) (e) (h)	52..

Note

If your appliance has an N in the appliance designation, it is a NoFrost appliance.

1 Appliance at a glance

1.1 Scope of delivery

Check all parts for damage during transport. If you have any complaints, please contact your retailer or Customer Services (see 9.4 Customer Services).

Your new appliance comes with the following parts:

• Standalone appliance
• Features (depending on the model)
• Installation materials (depending on the model)
• "Quick Start Guide"
• "Installation Guide"
• Service Brochure

1.2 Overview of the appliance and features

A B C 1 2 3 4 6 5 7 8 9 10 11 12 13 14 12 13

Fig. 1 Example illustration

Temperature range

(A) Fridge compartment(C) Coldest zone	(B) EasyFresh
Features
(1) Controls	(8) EasyFresh safe
(2) Fan with FreshAir activated charcoal filter	(9) Outlet
(3) Separable storage shelf*	(10) Serial tag
(4) Storage shelf	(11) Vegetable drawer*
(5) VarioSafe*	(12) Bottle rack*
(6) Bottle shelf*	(13) Bottle holder
(7) EasyFresh safe cover	(14) Can rack

Note

▶ Shelves, drawers and baskets are arranged for optimum energy efficiency when the appliance is delivered. Changing how the shelves, for example, are inserted in the fridge compartment does not have any impact on energy consumption.

1.3 Appliance range of use

Intended use

The appliance is only suitable for cooling food products in a domestic or household-like environment. This includes, for example, use:

• in staff kitchens, bed and breakfast establishments,
• by guests in country houses, hotels, motels and other accommodation,
• for catering and similar services in the wholesale trade.

The appliance is not suitable for freezing food;

The appliance is not suitable as a built-in unit.

All other types of use are not permitted.

Foreseeable misuse

The following applications are expressly forbidden:

• Storing and refrigerating medicines, blood plasma, laboratory preparations or similar substances and products based on the Medical Device Directive 2007/47/EC
• Use in areas at risk of explosions

Misusing the appliance may lead to damage to the goods stored or they may spoil.

Climate classifications

Depending on the climate classification the appliance is designed to operate in restricted ambient temperatures. The climate classification applying to your appliance is printed on the rating plate.

Note

▶ Keep to the specified ambient temperatures in order to guarantee that the appliance works properly.

Climate classification	for ambient temperatures of
SN	10 °C to 32 °C
N	16 °C to 32 °C
ST	16 °C to 38 °C
T	16 °C to 43 °C

1.4 Conformity

The refrigerant circuit has been tested for leaks. This device complies with the applicable safety regulations and with the directives 2014/35/EU, 2014/30/EU, 2009/125/EC, 2011/65/EU, 2010/30/EU and 2014/53/EU.

The full text of the EU Declaration of Conformity is available on the following website: www.Liebherr.com

1.5 EPREL database

Details about energy labelling and ecodesign requirements will be available on the European product database (EPREL) from 1st March 2021. You can access the product database at the following link: https://eprel.ec.europa.eu/ You will be asked to enter the model ID. You can find the model ID on the name-plate.

2 General safety instructions

Danger for the user:

- This device can be used by children and people with impaired physical, sensory or mental abilities or with a lack of experience and knowledge provided that they are supervised or have received instruction in

the safe use of this device, and about the resulting hazards. Children must not play with this appliance. Cleaning and user maintenance work must not be carried out by children without adult supervision. Children aged between 3 and 8 are allowed to load and unload the appliance. Children below the age of 3 must be kept away from the appliance unless they are under continuous adult supervision.

• When disconnecting the appliance from the supply, always take hold of the plug. Do not pull the cable.
• In the event of a fault pull out the mains plug or deactivate the fuse.
• Do not damage the mains power cable. Do not operate the appliance with a defective mains power cable.
• Only customer service or other specially trained staff may repair or perform other operations on the appliance.
• Only assemble, connect and dispose of the appliance according to the instructions.
• Please keep these instructions in a safe place and pass them on to any subsequent owners.

Fire hazard:

- The coolant used (information on the model plate) is eco-friendly but also flammable. Any leaking coolant may ignite.

• Do not damage the refrigerant circuit pipes.
• Do not handle ignition sources inside the appliance.
• Do not use electrical appliances inside the appliance (e.g. steam cleaners, heaters, ice cream makers, etc.).
• If the refrigerant leaks: remove any naked flames or ignition sources from the vicinity of the leakage point. Properly air the room. Inform customer services.

- Do not store explosives or sprays using combustible propellants such as butane, propane, pentane, etc. in the appliance. To identify these spray cans, look for the list of contents printed on the can, or a flame symbol. Gases possibly escaping may ignite due to electrical components.

- Keep burning candles, lamps and other items with naked flames away from the appliance so that they do not set the appliance on fire.

- Please be sure to store alcoholic drinks or other packaging containing alcohol in tightly closed containers. Any alcohol that leaks out may be ignited by electrical components.

Danger of tipping and falling:

- Do not misuse the plinth, drawers, doors etc. as a step or for support. This applies particularly to children.

Danger of food poisoning:

- Do not consume food which has been stored too long.

Danger of frostbite, numbness and pain:

- Avoid prolonged skin contact with cold surfaces or refrigerated/frozen goods or take protective measures, e.g wear use gloves.

Danger of injury and damage:

• Hot steam can lead to injury. Do not use electrical heating or steam cleaning equipment, open flames or defrosting sprays to defrost.
• Do not use sharp implements to remove the ice.

Risk of crushing:

- Do not hold the hinge when opening and closing the door. Fingers may get caught.

Symbols on the appliance:

The symbol can be located on the compressor. It refers to the oil in the compressor and indicates the following danger: Swallowing or inhaling can be fatal. This is only relevant for recycling. There is no danger in normal operation.

This symbol is found on the compressor and indicates the danger of flammable materials. Do not remove the sticker.

A sticker to this effect may be applied to the rear of the appliance. It refers to the foam-padded panels in the door and/or the housing. This is only relevant for recycling. Do not remove the sticker.

Please observe the specific information in the other sections:

	DANGER	identifies a situation involving direct danger which, if not obviated, may result in death or severe bodily injury.
	WARNING	identifies a dangerous situation which, if not obviated, may result in death or severe bodily injury.
	CAUTION	identifies a dangerous situation which, if not obviated, may result in minor or medium bodily injury.
	NOTICE	identifies a dangerous situation which, if not obviated, may result in damage to property.
	Note	It contains useful instructions and tips.

3 Putting into operation

3.1 Switching on appliance

Ensure that the following conditions are met:

☐ Appliance is set up and connected according to installation instructions.
☐ All adhesive strips, adhesive and protective films as well as transport safety devices in and on the appliance are removed.
☐ All marketing leaflets are removed from the drawers.
▶ Switch on the appliance via the control panel next to the display.

Fig. 2

▶ The status screen appears.
▶ If DemoMode is displayed after switching on the appliance, DemoMode can be deactivated within the next 5 minutes.

Demo 3:14 < > 3s

Fig. 3

▶ Press confirmation next to the display for 3 seconds.
▷ DemoMode is deactivated.

Note

The manufacturer recommends:

▶ Storing food: wait approx. 6 hours for the set temperature to be reached.

3.2 Inserting the components

▶ Insert the supplied components to make the most of your appliance.
▶ Purchase and install the SmartDevice Box (see smartdevice.liebherr.com).
▶ Install the SmartDevice app (see apps.home.liebherr.com).

Note

You can purchase accessories from the Liebherr household appliance store (home.liebherr.com).

4 Foods management

4.1 Storing food

WARNING

Risk of fire

▶ Do not use any electrical appliances in the food area of the appliance unless recommended by the manufacturer.

Note

The energy consumption increases and the cooling power goes down if ventilation is not sufficient.

▶ Always keep air slots clear.

When storing food, always observe the following:

☐ Air vents on the inside rear wall are unobstructed.
☐ Air vents on the fan are unobstructed.
☐ Food is in sealed packaging.
☐ Foods that easily absorb or give off smell or taste are stored in sealed containers or covered.
☐ Raw meat and fish are in clean, sealed containers to prevent them coming into contact with or dripping onto other foods.
☐ Liquids are in sealed containers.
☐ Foods are not stored too closely together, as the air needs to circulate.

Note

Failure to follow these guidelines can lead to food perishing.

4.1.1 Fridge section

The natural air circulation creates a range of temperatures.

Arrange your food as follows:

▶ In the top section and in the door: butter and cheese, preserves and tubes.
▶ In the coldest zone Fig. 1 (C): Perishable foods such as ready-to-eat meals, meat and sausages
▶ On the bottom shelf: Raw meat and fish

4.1.2 EasyFresh-Safe

This compartment is great for non-packaged foods, such as fruit and vegetables.

The air moisture in the compartment depends on the moisture content of the items being stored and the number of times the door is opened. You can adjust the air moisture.

Arrange your food as follows:

▶ Store your loose fruit and vegetables.
▶ Excessive air moisture: Regulate the air humidity (see 7.7 Adjusting the moisture levels).

4.2 Storage times

Refer to the specified storage times as a guide.

In the case of foods with a minimum shelf life, the date indicated on the packaging still applies.

4.2.1 Fridge section

Always follow the best-before date stated on the packaging.

5 Saving energy

• Pay attention to good ventilation. Do not cover ventilation holes or grids.

• Always keep the fan air slits clear.

• Do not install the appliance in direct sunlight, next to an oven, radiator or similar.

• Energy consumption depends on the installation conditions, e.g. the ambient temperature (see 1.3 Appliance range of use). A warmer ambient temperature can increase the energy consumption.
• Open the appliance for as short a time as possible.
• The lower the temperature is set the higher the energy consumption.
• Sort your food: home.liebherr.com/food.
• Keep all food properly packed and covered. This prevents frost from forming.
• Only take food out for as long as necessary so that it doesn't warm up too much.
• Inserting warm food: allow to cool down to room temperature first.
• For longer periods of absence, use HolidayMode (see HolidayMode).

6 Controls

6.1 Controls and displays

The display provides a quick overview of the temperature setting and the status of functions and settings. You can control the functions and settings either by deactivating/activating them or by selecting a value.

6.1.1 Status display

5 °C

Fig. 4
(1) Temperature display of the fridge section

The Status display shows the set temperature and is the home display. From there, you can navigate to the options and settings.

6.1.2 Navigation

Navigate in the menu to access the individual functions. An audible signal sounds after confirming a function or setting. If no selection is made after 10 seconds the display switches to the Status display.

The appliance is operated with the buttons next to the display.

Fig. 5
(1) Navigation arrow left/right
(2) Confirm

Navigation arrow left/right Fig. 5 (1):

- Navigating in the menu. After the last menu page, it goes back to the first one.

Confirm Fig. 5 (2):

- Activating/deactivating a function.

• Open a submenu.
• Confirm a selection. After confirmation the display switches back to the menu.

Back to Status display: in the fastest manner:

• Close and open the door.
• or wait 10 seconds. The display switches to the Status display.

6.1.3 Operating structure

The controls are explained by a template. The display changes depending on the function or settings.

Menus without a submenu

Fig. 6

(1) Status deactivated / status activated white bar in the top area
(2) Symbol or activated value

Menus with a submenu

Name ①

(3) Menu: Function name or menu: Setting name

Fig. 7

(1) Menu: Function name or menu: Setting name
(2) Status
(2) off / on

You can navigation as follows:

• Press the left/right Fig. 5 (1) arrow to navigate.

• Press Confirm Fig. 5 (2) to open the submenu Fig. 7 (4).

• Press the left/right Fig. 5 (1) arrow to navigate.

• Set a new value: Press Confirm Fig. 5 (2) to select an active value Fig. 6 (1).
• Back to the menu: Press Confirm Fig. 5 (2) to select the active value Fig. 6 (2).

6.1.4 Display symbols

Display symbols provide information on the current appliance status:

Symbol	Appliance status
	StandbyThe appliance or temperature zone is switched off.
	Flashing numberAppliance is working. Temperature flashes until the set value is reached.
	Flashing symbolAppliance is working. Setting is made.
	Bar grows steadilyFunction is activated.

6.2 Control concept

6.2.1 Activating/deactivating the function

You can activate/deactivate the following functions:

Symbol	Function
	SuperCoolx
	PowerCoolx
	PartyMode*x*
	HolidayMode
	E-Saver

^x When a function is on, the appliance works harder. This means the appliance could make louder noises and consume more energy.

▶ Press the navigation arrows Fig. 5 (1) until the appears.
▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status appears in the menu.
▷ Function is on/off.

6.2.2 Selecting function value

With the following functions you can set a value in the submenu:

Symbol	Function
5 °C	Setting the temperatureSwitch the appliance on/off

▶ Tap the navigation arrows Fig. 5 (1) repeatedly until the function is displayed.

▶ Press Confirm Fig. 5 (2).

▶ Select the setting value with the navigation arrows Fig. 5 (1).

Setting the temperature

▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status: On Fig. 6 (1) appears briefly in the submenu Fig. 7 (4).
▷ Display switches back to the menu.

6.2.3 Activating/deactivating settings

You can activate/deactivate the following settings:

Symbol	Setting
	WiFi^1
	Entry lock^2
	SabbathMode^2
	Cleaning Mode^2
	Reminders^1
	Reset^2
	Off^2

▶ Tap the navigation arrows Fig. 5 (1) repeatedly until the settings appear.
▶ Press Confirm Fig. 5 (2).
▶ Tap the navigation arrows Fig. 5 (1) repeatedly until the desired setting is displayed.

^1 Activate setting (shortpress)

▶ Press Confirm Fig. 5 (2).

▷ You hear the confirmation tone.

▷ Status appears in the menu.

▷ Setting is on / off.

^2 Activate setting (longpress)

▶ To Confirm Fig. 5 (2), press for 3 seconds.

▷ You hear the confirmation tone.

▷ Status appears in the menu.

▷ Display changes.

6.2.4 Selecting the setting value

With the following settings you can set a value in the submenu:

Symbol	Settings
	Brightness
	Door alarm
	Temp. unit

▶ Tap the navigation arrows Fig. 5 (1) repeatedly until settings 🌿 appears.
▶ Press Confirm Fig. 5 (2).
▶ Tap the navigation arrows Fig. 5 (1) repeatedly until the desired setting is displayed.
▶ Press Confirm Fig. 5 (2).
▶ Select the setting value with the navigation arrows Fig. 5 (1).
▶ Press Confirm Fig. 5 (2).
▷ You hear the confirmation tone.
▷ Status appears briefly in the submenu.
▷ Display switches back to the menu.

6.2.5 Go to the Customer menu

You can see the following settings in the Customer menu:

Symbol	Function
	Software

▶ Press the navigation arrows Fig. 5 (1) repeatedly until the settings appear.
▶ Press Confirm Fig. 5 (2).
▶ Press the navigation arrows Fig. 5 (1) repeatedly until the appliance information 📄 appears in the display.
▶ Press Confirm Fig. 5 (2).
▶ Enter the numerical code 151.
▷ The customer menu appears.
▶ Press the navigation arrows Fig. 5 (1) repeatedly in the customer menu until the desired setting appears.

^1 Select the value

▶ Press Confirm Fig. 5 (2).

▷ You hear the confirmation tone.

▷ Status appears briefly in the display.

▷ Display switches back to the menu.

^2 Activate the setting

▶ ToConfirm Fig. 5 (2), press for 3 seconds.

▷ You hear the confirmation tone.

▷ Status appears on the display.

The symbol flashes as long as the appliance is working.

6.3 Functions

Temperature

The temperature depends on the following factors:

• The amount of times the door is opened
• How long the door is open for
• The room temperature of the installation site
• The type, temperature and amount of food

Temperature zone	Recommended setting
5 °C Fridge section	5 °C

Setting the temperature

5 °C 5 °C < > < > 1s

Fig. 8

▶ Set the value. (see 6.2 Control concept).
▷ Set temperature is shown at the bottom right of the display.

SuperCool

This function selects the lowest cooling temperature. This gives you colder storage temperatures.

This function is relevant to the fridge section Fig. 1 (A)

Use:

- Cool large amounts of food quickly.

Activating/deactivating the function

▶ Using the fridge section: activate the function when you add the goods.
▶ Activating/deactivating (see 6.2 Control concept).

The function automatically turns off. The appliance goes back to normal mode. The temperature adjusts itself to the set level.

PowerCool

This function provides the perfect blanket temperature to cool your food.

This function refers to the fridge section Fig. 1 (A).

Use:

• At higher room temperatures (from approx. 35 °C)
• When humidity is high e.g. on summer days
• When storing moist goods, to avoid condensation building up inside

Activating/deactivating the function

▶ Activating/deactivating (see 6.2 Control concept).

Note

The fan can run even when function is deactivated. This ensures optimal temperature distribution in the appliance.

▷ Function activated: Energy consumption of the appliance is slightly increased.

PartyMode\*

This option offers an assortment of special functions and settings that are useful if you are having a party.

The following functions are on:

- SuperCool

All the functions can be adjusted flexibly and separately. Changes are discarded when the function turns off.

Activating/deactivating the function

▶ Activating/deactivating (see 6.2 Control concept).
▷ On: All functions are activated at the same time.
▶ Deactivated: Previously set temperatures are restored.

After 24 hours the function turns off automatically.

HolidayMode

This function minimises the energy consumption during an extended absence. The temperature of the refrigerator compartment is set to 15 °C and this is displayed on the status screen when the temperature has been reached.

Use:

• Save energy if you plan to be away for a while.
• Avoid coming home to bad smells and mould.

Activating/deactivating the function

▶ Empty everything from the fridge section.

▶ Activating/deactivating (see 6.2 Control concept).
▷ On: Fridge temperature is raised.
▶ Off: the previously set temperature is restored.

E-Saver

This function reduces energy consumption. If you activate this function, the cooling temperature increases.

Temperature zone	Recommended setting (see Temperature)	Temperature when E-Saver activated
5 °C Fridge compartment	5 °C	7 °C

Use:

- Save energy.

Activating/deactivating the function

▶ Activating/deactivating (see 6.2 Control concept).
▶ Activated: Higher temperatures are set in all temperature zones.
▶ Deactivated: Previously set temperatures are restored.

6.4 Settings

Connecting to the WLAN

This setting connects the appliance to the internet. The connection is managed in the SmartDevice-Box. You can use the SmartDevice-App to add your appliance to a SmartHome-System. Use the SmartDevice-App or other compatible partner networks to enjoy advanced options and settings.

Note

The SmartDevice-Box is available from the Liebherr Domestic Appliances Shop (https://home.liebherr.com/shop/de/deu/smartdevicebox.html).

You can find more information about the availability, prerequisites and the individual options on the Internet under https://smartdevice.liebherr.com/install.

Use:

• Manage the appliance with the SmartDevice-App or a compatible partner network.
• Enjoy advanced functions and settings.
• Check the current status of the appliance in the SmartDevice-App.

☐ The SmartDevice Box is purchased and installed (see https://smartdevice.liebherr.com/install).
☐ The SmartDevice app is installed (see https://apps.home.liebherr.com/).

Setting up the connection

Fig. 9
▶ Activating the setting (see 6.2 Control concept).
The connection is set up: Status: on Fig. 6 (1) and WiFi connecting appears. The symbol flashes.
The connection is set up: Status: on Fig. 6 (1) appears.
The connection failed: Status and Connect appears. The symbol appears permanently.

Disconnecting the appliance

▶ Deactivate the setting (see 6.2 Control concept).

Fig. 10

There is no connection: The symbol ● is displayed constantly.
▶ Restore settings (see 6.2 Control concept) .

Restoring the connection

Fig. 11
▷ Connection and other settings are restored to factory settings.

Entry lock

This setting prevents unintentional use of the appliance, e.g. by children.

Use:

• Avoid settings being changed unintentionally.
• Avoid the appliance being switched off unintentionally.
• Avoid the temperature being changed unintentionally.

Activating/deactivating settings

▶ Activating/deactivating. (see 6.2 Control concept)

Display brightness

Set the brightness level of the display.

You can set the following brightness levels:

• 40%
• 60%
• 80%
• 100%

Choose the setting

▶ Set the level (see 6.2 Control concept).

Door alarm

Set the time before the door alarm (see Close door) sounds.

The options are as follows:

• 1 min
• 2 min
• 3 min
• Off

Choose the setting

▶ Set the time (see 6.5 Warnings).

Temperature unit

This setting enables you to switch between Celsius and Fahrenheit as the temperature unit.

Selecting the setting value

▶ Set the value (see 6.2 Control concept).

Info

This setting allows the appliance information to be read out as well as access to the customer menu.

It provides the following information:

• Model name
• Index
• Serial number
• Service number

Show appliance data

Tap the navigation arrows Fig. 5 (1) repeatedly until the settings appear.
▶ Press Confirm Fig. 5 (2).
▶ Tap the navigation arrows Fig. 5 (1) repeatedly until the information is displayed.
▶ Read the appliance info.

SabbathMode

This setting meets the religious requirements on the Sabbath and Jewish festivals. Turn on SabbathMode to switch off

certain controls. This means you can use the appliance without anyone changing the settings.

You can find a list of Star-K-certified appliances at www.star-k.org/appliances.

WARNING

Danger of food poisoning.

If there is a power cut while the appliance is in SabbathMode, this message is not saved. Once power is restored, the appliance continues in SabbathMode. When this mode is over no message about the power cut is displayed on the temperature display.

If there was a power cut during SabbathMode:

▶ Check the food for quality. Do not eat the food if it has thawed.

What happens on the appliance when in SabbathMode:

• The Status display permanently shows SabbathMode.
• The display is locked for all functions apart from turning off SabbathMode.
• Any functions/settings that are already on, remain active.
• The display stays bright when the door is closed.
• Reminders are disabled. The set time intervals are also paused. This function is disabled in SabbathMode.
• Reminders and warnings are not displayed. There are no acoustic signals, and the display does not show warnings or settings such as temperature alarm or door alarm.
• The internal light is off.
• The defrost cycle only works for the specified time without taking account of fridge use.
• After a power cut the appliance automatically returns to SabbathMode.

Activating/deactivating SabbathMode

▶ To activate the function, click the arrows next to the display until you see Settings in the menu and then confirm. The menu changes to show the available settings.
▶ Click the arrows next to the display until you see SabbathMode (Menora) appear. Confirm the symbol.
▷ A white bar appears in the top part of the display.
▷ SabbathMode is activated.

To deactivate this function, press the button for confirmation next to the display for 3 seconds.

SabbathMode is deactivated.

CleaningMode

Use this setting to easily clean the appliance.

This setting refers to the fridge section Fig. 1 (A).

Use:

- Clean the fridge section by hand.

What happens on the appliance when this setting is on:

• The fridge section is switched off.
• The internal light is on.
• Reminders and warnings are not shown. There is no acoustic signal.

Activating/deactivating settings

▶ Activating/deactivating the setting (see 6.2 Control concept).
▷ On: fridge section is off. Light stays on.
▷ Off: preset temperature is restored.

After 60 min the setting turns off automatically. The appliance then continues running in normal mode.

Reminder

Reminders are given out acoustically by a beep and visually by a symbol in the display. The signal gets louder until the alert stops.

Replace FreshAir active carbon filter

This message appears when the air filter needs replacing.

▶ Change the air filter every six months.
▶ Confirm the message with OK.
▷ The service interval resets.
▷ The air filter guarantees the air quality in the fridge.

Activating the setting

▶ Activating/deactivating (see 6.2 Control concept).

Reset

This function resets all settings to the factory settings. All settings that you have made thus far will be reset to their original values.

Activating the setting

▶ Activate (see 6.2 Control concept).

Turn off appliance

This setting turns off the whole appliance.

Switching off the entire appliance

Fig. 12

▶ Activating/deactivating (see 6.2 Control concept).

▷ Off: Display goes black.

6.5 Warnings

Warnings are issued with an acoustic signal and visually with a symbol on the display. The signal gets louder until the alert stops.

6.5.1 Message

Close door

This message appears if the door is open for too long.

You can set how long it takes for this message to appear.

▶ Stop alarm: Confirm the message.

-or-

▶ Close the door.

Error

This message appears if there is a fault with the appliance. An appliance component indicates a fault.

▶ Open the door.
▶ Note down the fault code.
▶ Confirm the message.
▷ The audible signal stops.
The display switches to the Status screen.
▶ Close the door.

▶ Contact Customer Services (see 9.4 Customer Services).

6.5.2 DemoMode

If “D” appears on the display, demo mode is on. This option is designed for retailers, as it turns off all the cooling functions.

Stopping DemoMode

If you see the following running in the display:

▶ Confirm the display within the countdown.
▷ DemoMode is off.

If the timer is not running:

▶ Unplug the appliance.

▶ Plug the appliance in again.

▷ DemoMode is off.

7 Features

7.1 Door rack

7.1.1 Move/remove the door rack

Two identical diagrams showing a metal shelf with directional arrows indicating movement or force (no text or symbols present)

Fig. 13

▶ Slide the rack upwards.
▶ Pull forwards.
▶ Re-insert it in reverse order.

7.1.2 Disassembling the door rack

The door rack can be taken apart for cleaning.

Four technical diagrams showing a mechanical assembly with directional arrows indicating motion (no text or symbols present)

Fig. 14

▶ Disassemble the door rack.

7.2 Shelves

7.2.1 Adjusting/removing the shelves

The shelves are prevented from being pulled out accidentally by pull out stops.

1 3 1 2

Fig. 15

▶ Lift the shelf and pull forward.
▷ Line up the side runner.
▶ Adjust the height of the shelf: Lift or lower it to the desired height and slide it in.

-or-

Diagram illustrating three-step folding or retraction process with numbered arrows and directional arrows indicating movement.

Fig. 16

▶ Remove the shelf completely: Pull it out to the front.
▶ Easier removal: Set the shelf at an angle.
▶ Insert the shelf again: Slide it in all the way.
▷ The pull-out stoppers point downwards.
The pull-out stoppers are behind the front support.

You can also remove the shelf above the EasyFresh compartments.

Diagram showing two views of a storage or rack with arrows indicating direction (no text or symbols)

Fig. 17

Removing the shelf:

▶ Lift the shelf at the front and back.
▶ Pull it out towards you.

Do not store any goods on the compartment cover below! Inserting the shelf:

▶ Place the shelf at an angle, sloping down towards the back.
▷ The pull-out stoppers point downwards.
▶ Slide the shelf into place.

7.2.2 Dismantling the shelves

The shelves can be dismantled for cleaning.

Diagram showing a rectangular panel with a ruler and an arrow indicating direction (no text or symbols)

Fig. 18

▶ Dismantling the shelf.

7.3 Dividing shelf\*

7.3.1 Using the dividing shelf

The shelves are prevented from being pulled out accidentally by pull out stops.

Diagram showing a hand interacting with a device inside a cabinet or enclosure, with no visible text or symbols.

Fig. 19

▶ Push the dividing shelf underneath as shown.

Technical diagram showing structural components with numbered parts and directional arrows labeled L and R

Fig. 20

Adjusting the height:

▶ Pull the glass panels out Fig. 20 (1) from the front, one at a time.
▶ Release the support rails and click in at the height you want.
▶ Slide in the glass panels one at a time.
▷ Flat pull-out stoppers at the front, right behind the support rails.
▷ High pull-out stoppers at the back.

Using both shelves:

▶ Hold the glass panel with one hand and pull it to the front.
▷ The glass panel Fig. 20 (1) and trim strip are at the front.
▷ The stops Fig. 20 (3) point down.

7.4 VarioSafe\*

The VarioSafe provides space for compact foodstuffs and packages, pots and glasses.

7.4.1 Using the VarioSafe

You can remove the drawer and slide it back in at 2 different heights. This is handy for storing taller items in the drawer.

Technical diagram showing two views of a mechanical assembly with labeled components (no text or symbols present)

Fig. 21

▶ Remove the drawer.
▶ Slide back at the height you want Fig. 21 (1) or Fig. 21 (2).

7.4.2 Repositioning the VarioSafe

You can shift the height of the entire VarioSafe.

3D diagram of a mechanical component with two opposing arrows indicating downward motion (no text or symbols)

Fig. 22

▶ Pull forwards.
▷ Line up the side runner.
▶ Lift or lower to the height you want.
▶ Slide to the rear.

7.4.3 Removing the entire VarioSafe

You can remove VarioSafe as a whole unit.

▶ Pull forwards.
▷ Line up the side runner.

Diagram of a mechanical component with an arrow indicating direction, no text or symbols present

Fig. 23

▶ Tip to the side and pull towards you.

7.4.4 Disassembling the VarioSafe

You can take the VarioSafe apart for cleaning.

Technical diagram of a mechanical assembly with numbered components and directional arrows indicating assembly steps.

Fig. 24

▶ Disassembling the VarioSafe

7.5 Drawers

Drawers can be removed for cleaning.

The way to remove/insert the drawers varies depending on the pull-out system. Your appliance can include various pull-out systems.

Note

The energy consumption increases and the cooling power goes down if ventilation is not sufficient.

▶ Always leave the fan air vents clear on the back wall!

7.5.1 Removing the drawer

Drawer on rails

Simple 3D diagram of a rectangular block with an arrow indicating direction, no text or symbols present

Fig. 25
▶ Remove the drawer as shown in the illustration.

7.5.2 Inserting the drawer

Drawer on rails

Pure diagram of a 3D object with an arrow indicating direction, no text or symbols present

Fig. 26
▶ Insert the drawer as shown.

7.6 EasyFresh-Safe cover

You can remove the compartment cover for cleaning.

7.6.1 Removing the compartment cover

1 2 THIS SIDE UP

Fig. 27
When the drawers are removed:
▶ Pull the lid up at the front to the opening in the retaining parts Fig. 27 (1).
▶ Lift from the back and pull it up and out Fig. 27 (2).

7.6.2 Inserting the compartment cover

THIS SIDE UP THIS SIDE UP

Fig. 28

If the text THIS SIDE UP points upwards:

▶ Insert the lip of the cover over the opening of the rear bracket Fig. 28 (1) and click into place Fig. 28 (2).
▶ Position the cover where you want it (see 7.7 Adjusting the moisture levels).

7.7 Adjusting the moisture levels

You can adjust the moisture in the drawer yourself by adjusting the compartment cover.

The compartment lid is attached to the drawer and can be hidden by a shelf or additional drawers.

Illustration of a hand inserting a device into a storage unit (no text or symbols)

Fig. 29

Low air humidity

▶ Open the drawer.
▶ Slide the compartment cover forwards.
▷ With the drawer closed: Gap between the cover and the compartment.
The air moisture in the Safe decreases.

High air moisture

▶ Open the drawer.
▶ Slide the cover back.
▷ With the drawer closed: The cover seals the compartment.
The air moisture in the Safe increases.

If there is too much moisture in the compartment:

▶ Choose the setting "low air moisture".
-or-
▶ Remove any excess moisture with a cloth.

7.8 Pull-out board with bottle basket\*

Removable bottle baskets on the pull-out board offer plenty of space to store bottles. You can remove the bottle baskets to make room for a drinks crate in the pull-out board.

7.8.1 Using the bottle basket

Technical line drawing of a mechanical device with an inset showing internal components (no text or symbols)

Fig. 30

▶ Slide the bottle rack at the edges.
The bottles are prevented from falling over.

7.8.2 Disassembling the pull-out board

The pull-out board is mounted on a glass panel with pull-out rails.

You can dismantle the pull-out board for cleaning.

Removing the pull-out board

▶ Remove the bottle baskets.

Diagram showing a device with labeled components and directional arrows indicating movement or force

Fig. 31
▶ To remove the pull-out board with glass panel: Gently lift the glass panel at the front Fig. 31 (1) and pull out to the front Fig. 31 (2).

Technical diagram showing a mechanical assembly with numbered components and directional arrows indicating motion or assembly.

Technical diagram of a mechanical assembly with no visible text or symbols

Fig. 32

▶ Slide the pull-out board all the way in Fig. 32 (1).

▶ Release the clips at the back Fig. 32 (2).

▶ Remove the pull-out board from the front Fig. 32 (3).

Inserting the pull-out board

Technical diagram showing a mechanical assembly with labeled components and directional arrows indicating motion or force.

Technical diagram showing a mechanical assembly with numbered components and directional arrows indicating assembly steps.

Fig. 33

▶ Place centrally on the rails Fig. 33 (1).

▶ Slide the pull-out board all the way in Fig. 33 (2).

▶ Press down at the back until it clicks into place Fig. 33 (3).

▶ To insert the pull-out board with glass panel: Slide to the rear.

7.9 Accessories

7.9.1 Bottle holder

Using the bottle holder

Diagram illustrating a mechanical or laboratory setup with labeled components and directional arrows indicating movement or force.

Fig. 34

▶ Push the bottle holder onto the bottles.

▷ The bottles are prevented from falling over.

Removing the bottle holder

Diagram of a metal shelf with directional arrows indicating movement or force (no text or symbols)

Fig. 35

▶ Move the bottle holder all the way to the right.

▶ Push the bottle holder to the back to remove.

8 Maintenance

8.1 FreshAir carbon filter

The FreshAir carbon filter is in the compartment above the fan. It guarantees the best air quality.

☐ Replace the carbon filter every 6 months.

With the Reminder setting on, a message on the display prompts you to replace it.

☐ The carbon filter can be disposed of with the regular household waste.

Note

You can purchase the FreshAir carbon filter from the Liebherr household appliance store (home.liebherr.com).

8.1.1 Removing the FreshAir carbon filter

Diagram showing two labeled components: a device with an arrow and a box, and a printer-like device with arrows indicating process.

Fig. 36
▶ Pull out the compartment Fig. 36 (1).
▶ Remove the carbon filter Fig. 36 (2).

8.1.2 Inserting the FreshAir carbon filter

Diagram showing two steps of a printer or printer device: adding a component to a base and adding a back panel, with Chinese labels.

Fig. 37

▶ Insert the carbon filter as shown in the diagram Fig. 37 (1).

▷ The carbon filter clicks into place.

If the carbon filter is pointing downwards:

▶ Push the compartment in Fig. 37 (2).

▷ The carbon filter is now ready for use.

8.2 Defrosting the appliance

WARNING

Improper defrosting of the appliance! Injuries and damage.

▶ Do not use mechanical equipment or other methods to speed up the defrosting process other than those recommended by the manufacturer.
▶ Do not use electrical heating or steam-cleaning appliances, naked flames or defroster sprays to defrost.
▶ Do not use sharp objects to remove ice.

Defrosting is performed automatically. The water from the thawing process drains through the outlet and evaporates.

Water drops or a thin layer of frost or ice can form on the back wall; this is a completely normal part of the appliance's function. This must not be removed.

A layer of frost or ice can from briefly due to the energy-optimised control of the device.

▶ Clean the drain opening regularly (see 8.3 Cleaning the appliance).

8.3 Cleaning the appliance

8.3.1 Ready

WARNING

Danger of electric shock!

▶ Remove the refrigerator connector or interrupt the power supply.

WARNING

Risk of fire

▶ Do not damage the refrigeration circuit.

▶ Empty the appliance.
▶ Remove mains connector.
-or-
▶ Activate CleaningMode. (see CleaningMode)

8.3.2 Clean the housing

NOTICE

Improper cleaning!

Damage to the appliance.

▶ Only use soft cleaning cloths and ph-neutral all-purpose cleaners.
▶ Do not uses abrasive sponges or steel wool which may cause scratches.
▶ Do not use any sharp or abrasive cleaning agents, nor any that contain sand, chloride or acid.

WARNING

Risk of injury and damage as a result of hot steam!

Hot steam can lead to burns and can damage the surfaces.

▶ Do not use any steam cleaners!

▶ Wipe the housing down with soft, clean cloth. If very dirty, use lukewarm water with a neutral cleaner. Glass surfaces can also be cleaned with glass cleaner.

8.3.3 Cleaning the interior

NOTICE

Improper cleaning!

Damage to the appliance.

▶ Only use soft cleaning cloths and ph-neutral all-purpose cleaners.
▶ Do not uses abrasive sponges or steel wool which may cause scratches.
▶ Do not use any sharp or abrasive cleaning agents, nor any that contain sand, chloride or acid.

▶ Plastic surfaces: clean by hand with a soft clean cloth, lukewarm water and a little detergent.
▶ Metal surfaces: clean by hand with a soft clean cloth, lukewarm water and a little detergent.
▶ Drain outlet Fig. 1 (9): remove any deposits with a thin item such as a cotton bud.

8.3.4 Clean the components

NOTICE

Improper cleaning!

Damage to the appliance.

▶ Only use soft cleaning cloths and ph-neutral all-purpose cleaners.
▶ Do not uses abrasive sponges or steel wool which may cause scratches.
▶ Do not use any sharp or abrasive cleaning agents, nor any that contain sand, chloride or acid.

Clean with a soft, clean cloth, lukewarm water and some detergent:

• Door rack
• Shelf
• Dividing shelf*
• VarioSafe*
• Bottle basket and pull-out panel*
• EasyFresh-Safe cover
• Drawer

Wash in the dishwasher up to 60 °C:

• Bottle rack
• Holder of the dividing shelf*
  ▶ To disassemble components: see the relevant section.
  ▶ Clean the components.

8.3.5 After cleaning

▶ Wipe the appliance and the components dry.
▶ Connect and switch on the appliance.

The temperature is cold enough:

▶ Place the food inside.
▶ Repeat cleaning regularly.

9 Customer help

9.1 Technical specifications

Temperature range
Cooling	2 °C to 9 °C

Maximum component capacity
Features	Appliance width550 mm(see installation instructions, appliance dimensions)	Appliance width600 mm(see installation instructions, appliance dimensions)	Appliance width700 mm(see installation instructions, appliance dimensions)
Pull-out board*	20* kg*	20* kg*	20* kg*

Lighting
Class1	Light source
This product contains a light source that meets energy efficiency rating G	LED

1 The appliance may contain light sources with different energy efficiency classes. The lowest energy efficiency class is indicated.

9.2 Operating noises

The appliance makes different noises when it is on.

• At higher temperatures the appliance uses less energy but works for longer. It is quieter.
• At lower temperatures the food is cooled faster. It is louder.

Examples:

• Functions on (see 6.3 Functions)
- Fan running
- Food recently added
• High ambient temperature
- Door open for a while

Noise	Possible cause	Type of noise
Bubbling and splashing	Coolant flowing into the cooling circuit.	Normal operating noise

Noise	Possible cause	Type of noise
Hissing	Coolant sprays into the cooling circuit.	Normal operating noise
Humming	The appliance is cooling. The volume depends on the cooling output.	Normal operating noise
Suction noises	Soft-closing door is being opened and closed.	Normal operating noise
Humming and rustling	The fan is running.	Normal operating noise
Clicking	Components are switched on and off.	Normal switching noise
Rattling or humming	Valves or flaps are working.	Normal switching noise
Faint knocking	The valve is active.	Normal operating noise
Humming or buzzing	The valve is active.	Normal operating noise

Noise	Possible cause	Type of noise	Lifting
Vibration	Improper setup	Defective noise	Level the appliance using the adjustable feet.
Rattling	Components, items inside the appliance	Defective noise	Secure components.Leave enough space between the items.

9.3 Technical fault

Your appliance is designed and built to ensure it works reliably and has a long service life. In the unlikely event that a fault occurs during operation, please check whether it is due to an operating error. If so, you will be charged for the callout and repair costs even if it falls within the warranty period.

You can fix the following faults yourself.

9.3.1 Appliance function

Defect	Cause	Remedy
The appliance is not working.	→ The appliance is not switched on.	▸ Switch the appliance on.
	→ The power plug is not properly plugged into the socket.	▸ Check the power plug.
	→ There is something wrong with the power outlet fuse.	▸ Check the fuse.
	→ Power cut	▸ Keep the appliance closed.▸ Protecting food: Lay freezer packs on top of the food or use another freezer if the power is off for a prolonged period.► Do not re-freeze defrosted food,
	→ The appliance plug does not fit the appliance properly.	► Check the appliance plug.
Temperature is not cold enough.	→ The appliance door is not closed properly.	► Close the appliance door.
	→ Not enough ventilation.	► Keep ventilation grille clear, and clean it.
	→ The ambient temperature is too high.	► Solution: (see 1.3 Appliance range of use).
	→ The appliance was opened too many times or for too long.	► Wait to see if the required temperature corrects itself. If not, contact Customer Service (see 9.4 Customer Services).
	→ The temperature is set incorrectly.	► Turn down the temperature and check after 24 hours.
	→ The appliance is too close to a heat source (oven, radiator, etc).	► Move the appliance or the heat source.
The status display does not light up.	→ The status display is switched off.	► Turn on the status display.
	→ The door is open.	► Close the door.
	→ The appliance is switched off.	► Switch the appliance on.
	→ LED is faulty.	► Contact Customer Services (see 8 Maintenance).
The door seal is defective or needs to be replaced for another reason.	→ The door seal can be replaced. It can be replaced without the need for special tools.	► Contact Customer Services (see 9.4 Customer Services).
The appliance builds up too much ice or condensation.	→ The door seal may have slipped out of its groove.	► Check that the door seal is well fitted in the groove.
The appliance is hot to touch on the outside*.	→ The heat of the refrigeration circuit is used to avoid condensation.	► This is normal.

9.3.2 Features

Defect	Cause	Remedy
The internal light does not come on.	→ The appliance is not switched on.	► Switch the appliance on.
	→ The door was open for longer than 15 minutes.	► Interior lighting turns off automatically after approx. 15 min. with the door open.
	→ The LED light is faulty or the cover is damaged:	WARNINGRisk of injury due to electric shock!There are live electrical parts under the cover.► Only ever have the inside LED light replaced or repaired by customer service or trained personnel.

9.4 Customer Services

First check if you can fix the error yourself (see 9 Customer help). If you can't, contact Customer Services.

Please refer to the enclosed "Liebherr-Service" brochure for the address.

WARNING

Unprofessional repair! Injuries.

▶ Have any repairs and action - not expressly specified - on the appliance and mains cable carried out by service personnel only. (see 8 Maintenance)
A damaged mains cable may only be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person.
▶ In the case of appliances with an IEC connector, the change may be made by the customer.

9.4.1 Contact Customer Services

Make sure you have the following appliance data at the ready:

☐ Appliance name (model and index)
□ Service no. (Service)
Serial no. (S no.)
▶ Look up the appliance information on the display (see Info) . -or-
▶ Referring to appliance info on the nameplate (see 9.5 Model plate).
▶ Note down the appliance information.
▶ Notify Customer Services of the following: Give us the appliance data.
▷ This will help us to provide you with a faster, more accurate service.
▶ Follow any further instructions given by Customer Services.

9.5 Model plate

The model plate is behind the drawers on the inside of the appliance.

Index Service-Nr./No.Service: Klasser-Class Classer/Class Air-Type/AP-Type AP-Type/AP-Tips Nutzelnakt Gen / K / G / KE / HALT / EIS Net-Capacity Tat / R / F / CE / CHLL / ICE Volume-Ubit Tat / R / C / CA / CHLL / GLA Capac: Ubl Tat / F / C / BO / CHLL / HIE Total volume kg / 24 h Gefnerenmogen/Freeding Capacity Povlar de Congel/Capac/Gungeladora Serial-Nr. ① ② ③

Fig. 38
(1) Appliance description
(3) Serial no.
(2) Service no.
▶ Note the data on the model plate.

10 Shutting down

▶ Empty the appliance.
▶ Turn off the appliance (see 6.4 Settings).
▶ Remove mains connector.
▶ Remove appliance connector if required: Remove and move from left to right at the same time.
▶ Clean the appliance (see 8.3 Cleaning the appliance).
▶ Leave the door open to avoid bad smells building up.

11 Disposal

11.1 Preparing appliance for disposal

Li-Ion

Liebherr uses batteries in some of its appliances. In the EU, for environmental reasons, legislation obliges the end user to remove these batteries before disposing of old appliances. If your appliance contains batteries, a corresponding notice is attached.

Lamps

If you can remove the lamps yourself without destroying them, also remove these before disposal.

▶ Take the appliance out of operation.
▶ Appliances with batteries: remove the batteries. For description, see Maintenance chapter.
▶ If possible: remove lamps without destroying them.

11.2 Disposing of the appliance in an environmentally friendly manner

The appliance still contains valuable materials and must be disposed of separately from unsorted municipal waste.

Li-Ion

LI-Ion

Dispose of batteries separately from the old appliance. To do this, you can return the batteries free of charge to retailers as well as recycling centres and collection centres for recyclable materials.

Lamps

For Germany:

Dispose of removed lamps via the respective collection systems.

You can dispose of the appliance free of charge via the class 1 collection containers at the local recycling and recyclable material collection centres. When purchasing a new fridge/freezer, if the sales area > 400 m ^2 , retailers will also take back the old appliance free of charge.

WARNING

Leaking coolant and oil!

Fire. The coolant contained in the appliance is eco-friendly, but also flammable. The oil contained in the appliance is flammable. Escaping coolant and oil can ignite if the concentration is high enough and in contact with an external heat source.

▶ Do not damage the pipelines of the coolant circuit and the compressor.

▶ Transport the appliance without damaging it.
▶ Dispose of batteries, lamps and the appliance according to the above specifications.

Image showing a QR code and a document icon with an information symbol, likely representing a digital link or information transfer.

home.liebherr.com/fridge-manuals

EN

fridge

Issue date: 20220503

Part number index: 7080430-01
