Type de produit	Sèche-linge à condensation
Capacité de chargement	7 kg
Classe énergétique	B
Dimensions approximatives	85 x 60 x 60 cm
Poids	37 kg
Alimentation électrique	220-240 V, 50 Hz
Puissance	2 300 W
Fonctions principales	Programmes de séchage variés, départ différé, affichage du temps restant
Entretien et nettoyage	Filtre à peluches à nettoyer après chaque utilisation, réservoir d'eau à vider régulièrement
Pièces détachées et réparabilité	Disponibilité des pièces détachées via le service après-vente
Sécurité	Système de sécurité anti-surchauffe, verrouillage enfant
Informations générales	Garantie de 2 ans, notice d'utilisation incluse

FOIRE AUX QUESTIONS - TKF 7431 A BLOMBERG

Comment puis-je résoudre un problème de bruit excessif lors du fonctionnement de mon BLOMBERG TKF 7431 A ?

Vérifiez que l'appareil est bien nivelé et que rien ne bloque les roues. Assurez-vous également que les vêtements sont bien répartis dans le tambour.

Que faire si mon BLOMBERG TKF 7431 A ne démarre pas ?

Vérifiez que l'appareil est correctement branché et que la prise fonctionne. Assurez-vous également que la porte est bien fermée et que le fusible n'est pas sauté.

Pourquoi mon sèche-linge BLOMBERG ne chauffe-t-il pas ?

Cela peut être dû à un filtre à peluches obstrué ou à un condenseur sale. Nettoyez les filtres et vérifiez le condenseur pour garantir un bon fonctionnement.

Comment nettoyer le filtre à peluches de mon BLOMBERG TKF 7431 A ?

Ouvrez le panneau du filtre à peluches, retirez le filtre et nettoyez-le sous l'eau chaude. Assurez-vous qu'il est complètement sec avant de le remettre en place.

Quel est le programme le plus adapté pour sécher les vêtements délicats ?

Utilisez le programme 'Délicats' pour sécher les vêtements sensibles à la chaleur. Cela garantit un séchage en douceur sans endommager les tissus.

Mon BLOMBERG TKF 7431 A affiche un code d'erreur, que dois-je faire ?

Consultez le manuel d'utilisation pour identifier le code d'erreur. En général, cela peut indiquer un problème de drainage ou de surchauffe. Si le problème persiste, contactez le service après-vente.

Quelle est la capacité maximale du tambour de mon sèche-linge BLOMBERG ?

Le BLOMBERG TKF 7431 A a une capacité maximale de 7 kg pour le séchage.

Comment puis-je réduire la consommation d'énergie de mon sèche-linge ?

Utilisez des programmes à basse température et évitez de surcharger l'appareil. Privilégiez également les cycles de séchage à la fin de la journée lorsque l'énergie est moins chère.

MODE D'EMPLOI TKF 7431 A BLOMBERG

Dryer

TKF 7431

User manual

Blomberg

Please read this user manual first!

Dear Customer,

Thank you for preferring a Blomberg product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference. If you transfer the product to someone else, give its manual as well. Pay attention to all details and warnings specified in the user manual and follow the instructions given therein.

Use this user manual for the model indicated on the cover page.

Explanation of symbols

Throughout this user manual the following symbols are used:

i	Important information or useful hints about usage.
!	Warning for hazardous situations with regard to life and property.
5	Warning against electric shock.
SSS	Warning against hot surfaces.
	Warning against fire hazard.
	Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations.

Do not dispose of the packaging wastes with the domestic waste or other wastes, discard them to the dedicated collection points designated by the local authorities.

TABLE OF CONTENTS

1 Important safety and environmental instructions

1.1 General safety 4
1.1.1 Electrical safety. 5
1.1.2 Product safety 6
1.2 Mounting over a washing machine 8
1.3 Intended use 9
1.4 Child safety 9
1.5 Compliance with the WEEE regulation and disposing of the waste product 10
1.6 Compliance with RoHS Directive: 10
1.7 Package information 10
1.8 Technical specifications 11

2 Your Dryer 12

2.1 Overview 12
2.2 Package contents 13

3 Installation 14

3.1 Appropriate installation location 14
3.2 Removing the transportation safety assembly ...14
3.3 Connecting to the drain 14
3.4 Adjusting the feet 15
3.5 Electrical connection 15
3.6 Transportation of the dryer 15
3.7 Changing the illumination lamp 15

4 Electrical Connection 16

4.1 Attention! 16
4.2 Electrical requirements 16
4.3 Fitting a different plug 16
4.4 Washer/dryer combination 16

5 Preparation 17

5.1 Laundry suitable for drying in the dryer 17
5.2 Laundry not suitable for drying in the dryer.....17
5.3 Preparing laundry for drying 17
5.4 Things to be done for energy saving 17
5.5 Correct load capacity. 18

6 Selecting a Programme and Operating Your Machine 19

6.1 Control panel 19
6.2 Preparing the machine 20
6.3 Programme selection 20
6.4 Main programmes 20
6.5 Timer Programmes 21
6.6 Programme selection and consumption table....22
6.7 Auxiliary function 23
6.8 Drying degree 23
6.9 Anti-creasing 23
6.10 Changing the contrast 23
6.11 Warning indicators 23
6.12 Changing the delay time 24
6.13 Cancelling the time delay 24
6.14 Starting the programme 24
6.15 Progress of programme 24
6.16 Changing the programme after the programme has started 25
6.17 Adding/removing laundry in standby mode ....25
6.18 Child-proof lock 25
6.19 Ending the programme through cancelling ....26
6.20 End of programme 26

7 Maintenance and cleaning 27

7.1 Cleaning Lint Filter / Loading Door Inner Surface27
7.2 Cleaning the sensor 28
7.3 Draining the water tank 28
7.4 For the condenser 29

8 Suggested solutions for problems 30

9 Guarantee 31

10 Service 32

9.1 What is covered? 31
9.2 What is not covered? 31
9.3 Important notes 31

1 Important safety and environmental

instructions

This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty.

1.1 General safety

• The dryer can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. Children should not play with the product. Cleaning and maintenance works should not be performed by children unless they are supervised by someone.
• Children of less than 3 years should be kept away unless continuously supervised.
• Adjustable feet should not be removed. (See 2.1 Overview) The gap between the dryer and the floor should not be reduced with materials such as carpet, wood and tape. This will cause problems with the dryer.
• Always have the installation and repairing procedures carried out by the Authorised Service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorised persons.
• Never wash the dryer by spraying or pouring water onto it! There is the risk of electric shock!

Important safety and environmental instructions

1.1.1 Electrical safety

Electrical safety instructions should be followed while electrical connection is made during the installation.

• Connect the dryer to a grounded outlet protected by a fuse at the value specified on the type label. (See 2.1 Overview) Have the grounding installation performed by a qualified electrician. Our company shall not be liable for any damages that will arise when the dryer is used without grounding in accordance with the local regulations.
• The voltage and allowed fuse protection is stated on the type label plate. (See 2.1 Overview)
• The voltage specified on the type label must be equal to your mains voltage. (See 2.1 Overview)
• Unplug the dryer when it is not in use.
• Unplug the dryer from the mains during installation, maintenance, cleaning and repair works.
• Do not touch the plug with wet hands! Never unplug by pulling on the cable, always pull out by grabbing the plug.
• Do not use extension cords, multi-plugs or adaptors to connect the dryer to power supply in order to decrease the risk of fire and electric shock.
• Power cable plug must be easily accessible after installation.

Damaged mains cable should be changed by an Authorised Service agent.

If the dryer is faulty, it must not be operated unless it is repaired by an authorised service agent! There is the risk of electric shock!

Important safety and environmental instructions

1.1.2 Product safety

Points to be taken into consideration for fire hazard: Below specified laundry or items must not be dried in the dryer because of fire hazard. ·Unwashed laundry items ·Items soiled with oil, acetone, alcohol, fuel oil, kerosene, stain removers, turpentine, paraffin or solvents must be washed in hot water with plenty of detergent before being dried in the dryer.

Below specified laundry or items must not be dried in the dryer due to the fire hazard: ·Garments or pillows bolstered with rubber foam (latex foam), shower caps, water resistant textiles, materials with rubber reinforcement and rubber foam pads. ·Clothing cleaned with industrial chemicals. Items such as lighters, matches, coins, metal parts, needle etc. may damage the drum set or may lead to functional problems. Therefore check pockets off the laundry that you will load into your dryer. Never stop your dryer before the programme completes. If you must do this, remove all laundry quickly and lay them out to dissipate the heat.

Clothes that are washed inadequately may ignite on their own and even may ignite after drying ends.

• You must provide enough ventilation in order to prevent gases exiting from devices operating with other types of fuels including the naked flame from accumulating in the room due to the back fire effect.

Important safety and environmental instructions

!	Clothing that contains metal reinforcements should not be dried in the dryer. Dryer may be damaged if metal reinforcements come loose and break off during drying.
i	Use softeners and similar products in accordance with the instructions of their manufacturers.
i	Always clean the lint filter before or after each loading. Never operate the dryer without the lint filter installed.

• Never attempt to repair the dryer by yourself. Do not perform any repair or replacement procedures on the product even if you know or have the ability to perform the required procedure unless it is clearly suggested in the operating instructions or the published service manual. Otherwise, you will be putting your life and others' lives in danger.
• There must not be a lockable, sliding or hinged door that may block the opening of the loading door in the place where your dryer is to be installed.
• Install your dryer in a suitable place that is dry, well ventilated and unlikely to get below 5 degrees Centigrade.
• Make sure that pets do not enter the dryer. Check the inside of the dryer before operating it.
• Do not lean on the loading door of your dryer when it is open, otherwise it may fall over.
• The lint must not be allowed to accumulate around the tumble dryer

Important safety and environmental instructions

1.2 Mounting over a washing machine

• A fixing device should be used between the two machines when installing the dryer above a washing machine. The fitting device can be obtained through spare part suppliers.
• Total weight of the washing machine and the dryer -with full load- when they are placed on top of each other reaches to approx. 180 kilograms. Place the products on a solid floor that has sufficient load carrying capacity!

Washing machine cannot be placed on the dryer. Pay attention to the above warnings during the installation on your washing machine.

Installation Table for Washing Machine and Dryer
Dryer Depth	Washing Machine Depth
	62cm	60 cm	54 cm	50 cm	49 cm	45 cm	40 cm
54 cm	Can be stacked	Can be stacked	Can be stacked	Can be stacked	Can be stacked	Can be stacked	Cannot be stacked
60 cm	Can be stacked	Cany be stacked	Can be stacked	Can be stacked	Can be stacked	Cannot be stacked	Cannot be stacked

Important safety and environmental instructions

1.3 Intended use

• Dryer has been designed for domestic use. It is not suitable for commercial use and it must not be used out of its intended use.
• Use the dryer only for drying laundry that are marked accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or transportation.
• Original spare parts will be available to repair the dryer for a period of 10 years.

1.4 Child safety

• Packaging materials are dangerous for the children. Keep packaging materials away from children.
• Electrical products are dangerous for the children. Keep children away from the product when it is operating. Do not let them tamper with the dryer. Use the child-proof lock in order to prevent the children to tamper with the dryer.

Child-proof lock is on the control panel. (See Child lock)

• Keep loading door closed even when the dryer is not in use.

Important safety and environmental instructions

1.5 Compliance with the WEEE regulation and disposing of the waste product

This product does not contain the harmful and prohibited substances which are specified in the "Control of the Waste Electrical and Electronic Equipment" as published by Republic of Turkey Ministry of Environment and Urbanization. It complies with the WEEE Directive.

This product was made of high quality items and materials which are recyclable and reusable. Therefore, do not dispose of the product at the end of its service life with the domestic and other wastes. Take it to a collection point for the recycling of electrical and electronic equipment. Please consult your local authorities to learn the nearest collection point. Help protect the environment and natural resources by recycling used products. For children's safety, cut the power cable and break the locking mechanism of the door, if any, so that it will be non-functional before disposing of the product.

1.6 Compliance with RoHS Directive:

The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

1.7 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

Please visit the following website to get more information on the product.

www.blomberguk.com

Important safety and environmental instructions

1.8 Technical Specifications

EN

Height (Min./Max.)	84,6 cm / 86,6 cm*
Width	59,5 cm
Depth	53 cm
Capacity (max.)	7 kg**
Weight (net)	36 kg
Voltage	See type label***
Rated power input
Model code

• Min. height: Height with adjustable feet are closed. Max. height: Height with adjustable feet are opened maximum.

** Dry laundry weight before washing.
*** For the location of the type label on the dryer (see 2.1 Overview.)

i	Technical specifications of the dryer are subject to specification without notice to improve the quality of the product.
i	Figures in this manual are schematic and may not match the product exactly.
i	Values stated on markers on the dryer or in the other published documentation accompanying with the dryer are obtained in laboratory in accordance with the relevant standards. Depending on operational and environmental conditions of the dryer, these values may vary.

2.1 Overview

1- Control panel

5-Rating plate

2- Kick plate opening tab

6- Fluff filter

3-Adjustable feet

7- Power cord

4-Kick plate

2.2 Package Contents

1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*

*It can be supplied with your machine depending on its model.

3 Installation

Before the calling the nearest Authorised Service for the installation of the dryer, ensure that electrical installation and water drain is appropriate referring to the user's manual. (See 3.3 Connecting to the drain and 3.5 Electrical connection) If they are not suitable, contact a qualified electrician and technician to make necessary arrangements.

Preparation of the dryer's location as well as the electrical and waste water installations is under customer's responsibility.

Prior to installation, visually check if the dryer has any defects on it. If the drier is damaged, do not have it installed. Damaged products cause risks for your safety.

3.1 Appropriate installation location

Install the dryer on a stable and level surface.
- Dryer is heavy. Do not move it by yourself.
- Operate your dryer in a well ventilated, dust-free environment.
- The gap between the dryer and the surface should not be reduced by the materials such as carpet, wood and tape.
- Do not cover the ventilation grills of the dryer.
- There must not be a lockable, sliding or hinged door that may block the opening of the loading door in the place where your dryer is to be installed.
- Once the dryer is installed, it should stay at the same place where its connections have been made. When installing the dryer, make sure that its rear wall does not touch anywhere (tap, socket, etc.).
- Place the dryer at least 1 cm away from the edges of other furniture.
- Your dryer can be operated at temperatures between +5^ and +35^ . If the operating conditions fall outside of this range, operation of the dryer will be adversely affected and it can get damaged.
- The rear surface of the tumble dryer shall be placed against a wall.

Do not place the dryer on the power cable.

3.2 Removing the transportation safety assembly

Remove the transportation safety assembly before using the dryer for the first time.

• Open the loading door.
• There is a nylon bag inside the drum that contains a piece of styrofoam. Hold it from its section marked with XX XX.
• Pull the nylon towards yourself and remove the transportation safety assembly.

Check that no part of the transportation safety assembly remains inside the drum.

3.3 Connecting to the drain

In products equipped with condenser unit, water accumulates in the water tank during the drying cycle. You should drain accumulated water after each drying cycle.

You can directly drain accumulated water through the water drain hose supplied with the product instead of periodically draining the water collected in the water tank.

Installation

Connecting the water drain hose

1-2 Pull hose at the behind of the dryer by hand in order to disconnect it from where it is connected. Do not use any tools to remove the hose.
3 Connect one end of the drain hose supplied with the dryer to the connection point from where you removed the hose of the product in previous step.
4 Connect the other end of the drain hose directly to the wastewater drain or to the washbasin.

Hose connection should be made in a safe manner. Your house will be flooded if the hose comes out of its housing during water discharge.

Water drain hose should be attached to a height of maximum 80 cm.

Make sure that the water drain hose is not stepped on and it is not folded between the drain and the machine.

3.4 Adjusting the feet

In order to ensure that the dryer operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Turn the feet to left or right until the dryer stands level and firmly.

Never unscrew the adjustable feet from their housings.

3.5 Electrical connection

For specific instructions for electrical connection required during installation (see 1.1.1 Electrical Safety)

3.6 Transportation of the dryer

Unplug the dryer before transporting it.

Drain all water that has remained in the dryer.

If direct water drain connection is made, then remove the hose connections.

We recommend carrying the dryer in upright position. If it is not possible to carry the machine in the upright position, we recommend carrying it by tilting towards the right side when looked from the front.

3.7 Changing the illumination lamp

In case an illumination lamp is used in your laundry dryer To change the Bulb/LED used for illumination of your tumble dryer, call your Authorised Service.

The lamp(s) used in this appliance is not suitable for household room illumination. The intended purpose of this lamp is to assist the user to place laundry in the tumble dryer in a comfortable way.

4 Electrical Connection

Make sure that you have an earthed power outlet socket rated at 13 amps (minimum).

4.1 Attention!

When installed, the socket must be reachable after installation, or a separate switch (which can disconnect the two poles) must be used in the installation. Check for suitability.

For a permanent connection, a master switch with at least 3mm contact clearance and minimum 13 A rating must be used.

4.2 Electrical requirements

Before you insert the plug into the wall socket make sure that the voltage and the frequency shown in the rating label corresponds to your electricity supply.

We recommend that this appliance be connected to the mains supply via a suitable switched and fused socket in a readily accessible position.

Should the mains lead of the appliance become damaged or need replacing at any time, it must be replaced by a special purpose made mains lead which can only be obtained from a Authorised Service Agent.

Warning

This appliance must be earthed

If the fitted moulded plug is not suitable for your socket, then the plug should be cut off and an appropriate plug fitted.

The moulded plug on this appliance incorporates a 13A fuse. Should the fuse need to be replaced an ASTA approved BS1362 fuse of the same rating must be used. Do not forget to refit the fuse cover. In the event of losing the fuse cover, the plug must not be used until a replacement fuse cover has been fitted. Colour of the replacement fuse cover must be the same colour as that visible on the pin face of the plug. Fuse covers are available from any good electrical store.

In order to avoid hazards, damaged supply cord should be replaced by the manufacturer, its service agent or similarly qualified people.

Built-under installation

This appliance can be installed under a worktop.

Do not operate without the top cover fitted. Risk of injury.

Important

4.3 Fitting a different plug

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals on your plug, proceed as follows:

1 Connect the green - yellow or green (earth) wire to the terminal in the plug marked 'E' or with the symbol or coloured green and yellow or green.

2 Connect the blue (neutral) wire to the terminal in the plug marked 'N' or coloured black.

3 Connect the brown (live) wire to the terminal in the plug marked 'L' or coloured red.

With the alternative plugs a 13A fuse must be fitted either in the plug or adaptor or in the main fuse box. If in doubt contact a qualified electrician.

4.4 Washer/dryer combination

Do not stack washing machine on top of the tumble dryer. This would damage both appliances and guarantees would become void. It is also unsafe to stack an appliance on top of another without using a suitable and approved stacking kit obtained from the manufacturer of the appliances.

• A special stacking kit is required as an optional extra please contact customer service.

5 Preparation

5.1 Laundry suitable for drying in the dryer

• Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are suitable for drying in a dryer and make sure that you select the appropriate programme.

LAUNDRY DRYING SYMBOLS
Drying Symbols	Suitable for dryer		No Iron		Sensitive / Delicate dry		Do not dry with dryer		Do not dry		Do not dry-clean
Drying Settings	At any temperature	At high temperature	At medium temperature	At low temperature	Without heating	Hang to dry	Lay to dry	Hang wet to dry	Lay in shadow to dry	Pry-cleanable
Iron -			...		...	...	...	...	...	...
Dry or Steam			Iron at high temperature		Iron at medium temperature	Iron at low temperature		Do not iron		Iron without steam
Maximum temperature			200 °C		150 °C	110 °C

5.2 Laundry not suitable for drying in the dryer

Delicate embroidered fabrics, woolen, silk garments, delicate and valuable fabrics, airtight items and tulle curtains are not suitable for machine drying.

5.3 Preparing laundry for drying

• Laundry may be tangled with each other after washing. Separate the laundry items before placing them into the dryer.
• Dry garments having metal accessories such as zippers, inside out.
• Fasten the zippers, hooks and buckles and button sheets.

5.4 Things to be done for energy saving

Following information will help you use the dryer in an ecological and energy-efficient manner.

• Spin your laundry at the highest speed possible when washing them. Thus, the drying time is shortened and energy consumption is reduced. Sort out the laundry depending on their type and thickness. Dry the same type of laundry together. For example thin kitchen towels and table clothes dries earlier than thick bathroom towels.
• Follow the instructions in the user manual for programme selection.
• Do not open the loading door of the machine during drying unless necessary. If you must certainly open the loading door, do not to keep it open for a long time.
• Do not add wet laundry while the dryer is in operation
• Clean the lint filter before or after each drying cycle
• Clean the condenser regularly at least once every month or after every 30 drying cycles.
• Ventilate the room, where the dryer is located, well during drying.

5.5 Correct load capacity

Follow the instructions in the "Programme selection and consumption table". Do not load more than the capacity values stated in the table.

It is not recommended to load the dryer with laundry exceeding the level indicated in the figure. Drying performance will degrade when the machine is overloaded. Furthermore, dryer and the laundry can get damaged.

Following weights are given as examples.

Laundry	Approximate weights (g)*
Cotton quit covers (double)	1500
Cotton quit covers (single)	1000
Bed sheets (double)	500
Bed sheets (single)	350
Large tablecloths	700
Small tablecloths	250
Tea napkins	100
Bath towels	700
Hand towels	350
Blouses	150
Cotton shirts	300
Shirts	250
Cotton dresses	500
Dresses	350
Jeans	700
Handkerchiefs (10 pieces)	100
T-Shirts	125

*Dry laundry weight before washing.

6 Selecting a Programme and Operating Your Machine

6.1 Control panel

1. Washing machine spin speed*/ Timer programme selection

Spin speed used to spin the laundry in the washing machine / Indicates the time for timer programmes.

1. Display

Indicates the status of the machine.

1. Start/Pause/Cancel button

Used to start, pause or cancel the programme.

1. Programme selection knob

Used to select a programme.

1. On/Off button

Used to turn on and off the machine.

1. Anti-creasing

Prevents the laundry from creasing after the machine completes its programme.

1. Dryness level

Used to adjust the required dryness level.

1. Cancel audio warning

Used to cancel the audio warning given at the end of the programme.

1. Time delaying buttons

Used to set the time delay.

IBBD Spin speed / Timer programmes ★

Operation icon

Pause icon

Water tank full warning icon

Filter cleaning warning icon

Condenser cleaning warning icon

Remaining time indicator

Spin speed is used to show the remaining time more accurately.

It does not affect the performance of your machine.

Child-proof lock warning icon

Time delaying mode

Door open warning icon

Anti-creasing mode

Audio warning level / Cancel audio warning

Drying degree

Anti-creasing is activated

Selecting a Programme and Operating Your Machine

6.2 Preparing the machine

1. Plug in your machine.
2. Place the laundry in the machine.
3. Press the "On/Off" button.

Pressing the "On/Off" button does not necessarily mean that the programme has started. Press "Start/Pause/Cancel" button of the machine to start the programme.

6.3 Programme selection

Decide the appropriate programme from the table below which includes drying temperatures in degrees. Select the desired programme with the programme selection knob.

Extra dry	Drying at high temperature only for cotton laundry. Thick and multi layered laundry (E.g.: towels, linens, jeans) are dried in a way that they do not require ironing before placing in the wardrobe.
Cupboard dry	Normal laundry (E.g.: tablecloths, underwear) are dried in a way that they do not require ironing before placing in the wardrobe.
Iron dry	Normal laundry (E.g., Shirts, dresses) are dried ready to be ironed.

For further programme details, see, "Programme Selection Table"

6.4 Main programmes

Depending on the type of laundry, the following main programmes are available:

Cottons

You can dry your durable laundry with this programme. Dries at high temperature. It is recommended to use for your cotton items (such as bed sheets, quilt cover, underclothing, etc.).

Synthetics

You can dry your less durable laundry with this programme. It dries at a lower temperature compared to the cottons programme. It is recommended for your synthetic laundry (such as shirts, blouses, synthetic/cotton blended laundry, etc.).

Do not dry curtains and lace in your machine.

Special programmes

For special cases, there are also extra programmes available:

Additional programmes may differ according to the model of your machine.

Express 35

You can use this programme to dry your cotton laundry that you have spun at high speeds in your washing machine. This programme dries 2 kg cotton laundry (2 Shirts / 5 T-shirts) in 35 minutes.

To obtain better results from your dryer, your laundry must be washed at suitable programmes and spun at the recommended spin speeds in the washing machine.

Shirts

This programme dries the shirts more sensitively and creases them less and thus, helps to iron them more easily.

There may be a little humidity on your shirts at the end of the programme. We recommend you not to leave the shirts in the dryer.

- Jeans

You can use this programme to dry your jeans that you have spun at high speeds in your washing machine.

Review the relevant section in the programme table.

Mix

Used to dry synthetic and cotton laundry that do not release colour. Used for laundry that is suitable for drying.

- Sportswear

Used to dry the laundry that are made of synthetic, cotton or mixed fabrics and have a tag indicating that they are suitable for drying.

Wool Refresh

You can use this function to ventilate and soften your woollen laundry that can be washed in the washing machine. Do not use this function to dry your laundry completely. Take out your laundry and ventilate them immediately after the programme is over.

Daily Quick

This programme is used to dry cottons and synthetics daily, and lasts for 59 minute.

Baby Clothing

This programme is used for baby clothes that bear machine dryable approval on its label.

Selecting a Programme and Operating Your Machine

Delicates

You can dry your highly delicate laundry that are suitable for drying or laundry which is advised to be hand-washed at a lower temperature.

It is recommended to use a cloth bag to prevent certain delicate laundry from getting creased or damaged. Take your laundry immediately out of the dryer and hang them after the programme ends in order to prevent them being creased.

Refresh

Only ventilation is performed for 10 minutes without blowing hot air. You can air your clothes that have been kept at closed environments for a long time and deodourise unpleasant odours thanks to this programme.

- Timer programmes

You can select one of the 10 min., 20 min., 30 min., 40 min., 50 min., 60 min., 80 min., 100 min., 120 min., 140 min. and 160 min. timer programmes to achieve the desired final drying level at low temperatures. Programme dries at the selected time regardless of the drying temperature.

6.5 Timer Programmes

The display shows the time remaining for the programme to complete while a programme is running. Time is displayed in hours and minutes as "02:30". The exemplary display image shows the dryer when it is running and child-proof lock is active.

Programme duration may differ from the values in the consumption table subject to the changes in the water hardness and temperature, ambient temperature, type and amount of laundry, auxiliary functions selected, and changes in the supply voltage.

Selecting a Programme and Operating Your Machine

6.6 Programme selection and consumption table

EN

Programmes		Capacity (kg)	Spin speed in washing machine (rpm)	Approximate amount of remaining humidity	Drying time (minutes)
Cottons / Coloreds
	Extra dry	7	1000	% 60	131
	Cupboard dry	7	1000	% 60	121
	Iron dry	7	1000	% 60	90
Express 35'		2	1200	%50	35
Shirts		1.5	1000	%50	40
Jeans		4	1200	%50	80
Delicates		1.75	600	%40	40
Mix		4	1000	%60	83
Sportswear		4	1000	%60	90
Wool Refresh		1.5	600	%50	6
Daily Quick		4	1200	%50	59
Baby clothing		3	1000	%60	65
Synthetics
	Cupboard dry	3.5	800	% 40	50
Energy consumption values
Programmes		Capacity (kg)	Spin speed in washing machine (rpm)	Approximate amount of remaining humidity	Energy consump- tion value kWh
Cottons cupboard dry		7	1000	% 60	4,15
Cottons iron dry		7	1000	% 60	3,25
Synthetics cupboard dry		3.5	800	% 40	1,42
Power consumption of the off-mode for the standard cotton programme at full load, PO (W)					0,3
Power consumption of the left-on mode for the standard cotton programme at full load, PL (W)					1,0

"Cotton cupboard dry programme" used at full and partial load is the standard drying programme to which the information in the label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry and that it is the most efficient programme in terms of energy consumption for cotton.

*: Energy Label standard programmes (EN 61121:2012)

All values given in the table have been fixed according to EN 61121:2012 Standard. These values may deviate from the table according to the laundry type, laundry spin speed, environmental conditions and voltage fluctuations.

Selecting a Programme and Operating Your Machine

6.7 Auxiliary function

Audio Warning

Cancel audio warning

Audio warning level 1

Audio warning level 2

Audio warning level 3

Your dryer will give an audio warning when the programme comes to an end. If you do not want to hear this buzzing or want to change the volume level, you need to press the "Volume level" button. No audio warning will be given when "x" appears on the screen.

You can select this function either before or after the programme starts.

6.8 Drying degree

Used to adjust the required dryness level. More drying is performed compared to the default settings when "+" sign appears and less drying is performed when " - " sign appears. Programme duration can change depending on the selection.

This function must be selected before the programme starts.

6.9 Anti-creasing

A 2-hour anti creasing programme to prevent laundry from creasing will be activated if you do not take the laundry out after the programme is over. This programme rotates the laundry in 600-second intervals to prevent creasing. Press "Anti-creasing" button to activate.

Anti-creasing is activated but the programme is running in the first example above. Drying is over and the first step of anti-creasing has started in the second example.

6.10 Changing the contrast

Contrast can be adjusted in order to make the symbols on the display appear clearer. It may particularly be necessary to change the contrast setting of the display when the dryer is installed over a washing machine.press and

Press and hold the Spin Speed/Time button for 3 seconds.

When the contrast is changed at the end of 3 seconds, all symbols on the display will become visible for 3 seconds in order to indicate that the process is complete.

Perform the same procedure to revert back to the previous contrast setting.

6.11 Warning indicators

Warning indicators may differ according to the model of your machine.

Filter cleaning

A warning symbol will appear to remind filter cleaning after the programme finishes.

If the filter cleaning symbol flashes continuously, please refer to "Suggested solutions for problems".

Water tank

A warning symbol will turn on at the end of the programme or when the tank is full with water. The machine stops operating if the warning symbol turns on when a programme is running. To restart the machine, please drain the water in the water tank. Press "Start/ Pause/Cancel" button to start the programme after you have emptied the water tank. The warning symbol turns off and the programme resumes operating.

Cleaning the condenser

Selecting a Programme and Operating Your Machine

Warning symbol turns on with certain intervals to remind that the condenser needs cleaning.

Door open

Dryer door open symbol lights up.

Time delay

With the "Time delay" function you can delay the programme start up to 24 hours.

1. Open the loading door and put the laundry in.
2. Set the drying programme and spin speed, and if required, select the auxiliary functions.
3. Press "Time delaying" buttons "+" and "- to set the desired time delay. The time delay symbol will flash.
4. Press "Start/Pause/Cancel" button. Then the time delay starts to count down. The Time delay symbol lights up. Start symbol lights up.

The “:” in the middle of the displayed time delay will start flashing.

More laundry may be loaded or taken out during the time delay period. At the end of the time delay countdown process, time delay symbol fades, drying process starts and the programme duration is displayed. The time on the display is the total of normal drying time and delay time. Time delay is started by pressing the start/pause/cancel button in the example above.

6.12 Changing the delay time

If you want to change the time during the countdown:

1. Press "Start/Pause/Cancel" button for 3 seconds to cancel the programme. Time delay function must be set again for the required time.
2. Press Time delay buttons “+” or “-” to set the desired time delay.

3. Press "Start/Pause/Cancel" button. The Time delay symbol lights up. Pause symbol fades. Start symbol lights up.

4. The “:” in the middle of the displayed time delay will start flashing.

6.13 Cancelling the time delay

If you want to cancel the time delay countdown and start the programme immediately:

1. Press "Start/Pause/Cancel" button for 3 seconds to cancel the programme.
2. Then, press "Start/Pause/Cancel" button to start the desired programme.

6.14 Starting the programme

1. Press "Start/Pause/Cancel" button to start the programme.
2. "Start/Pause" symbol will light up to indicate that the programme has started and "::" symbol between the remaining time will continue flashing.

6.15 Progress of programme

The progress of a running programme is shown through a number of symbols on the screen.

At the beginning of each programme step, the relevant symbol in the series of symbols will light up and thus, all symbols will remain lit up at the end of the programme. The symbol that is lit up at the far right of the series of symbols indicates the step that is being carried out.

"Drying":

• Lights up in all programmes apart from drying and ventilation.

"Iron Dry":

• Starts to illuminate when the drying degree reaches "iron dry" step and remains illuminated until the next step.

"Skim?":

Starts to illuminate when the drying degree reaches "wardrobe dry" step, and remains illuminated until the next step.

"Wardrobe Dry Extra":

Starts to illuminate when the drying degree reach to "wardrobe dry extra" step.

"Freshen up":

• Illuminates when the programme ends.

Anti-creasing icon will light up at the end of the programme if anti-creasing function is active.

6.16 Changing the programme after the programme has started

You can use this feature to dry your laundry in a different programme after your machine has started to run.

For example;

Press and hold the "Start/Pause/Cancel" button for about 3 seconds to "Cancel" the programme in order to select "Extra Dry" programme instead of "Iron Dry" programme. Select the "Extra Dry" programme by rotating the programme knob. Press "Start/Pause/Cancel" button to start the programme.

f you select a new programme by turning the programme selection knob while your machine is running, then the current programme is cancelled and new programme information is displayed.

6.17 Adding/removing laundry in standby mode

In order to add or take out laundry after the start-up of the programme;

1. Press the "Start/Pause/Cancel" button to switch the machine to "Pause" mode. Drying process will stop.
2. Open the door at Pause position and close it again after adding or taking out laundry.
3. Press "Start/Pause/Cancel" button to start the programme.

i	Any laundry added after the drying process was started may cause the already dried clothes in the machine intermingle with wet clothes and the result will be wet laundry after the drying process is over.
i	Laundry may be added or taken out as much as desired during a drying process, but as this process will interrupt drying continuously, it will extend the programme duration and increase energy consumption. Therefore, it is recommended to add laundry before the drying programme has started.
i	If you select a new programme by turning the programme selection knob while your machine is in standby, then the current programme is cancelled and new programme information is displayed.

6.18 Child-proof lock

There is a child-proof lock to prevent any programme interruption due to the pressing of button while the programme is running. The loading door and all button except the "On/Off" button on the panel are deactivated when the child-proof lock is active.

In order to activate the child-proof lock, press on the "audio warning" and "anti-creasing" buttons simultaneously for 3 seconds.

To start a new programme after the programme is over or to interrupt the programme, the child-proof lock should be deactivated. Press the same buttons for 3 sec. again to deactivate the child-proof lock.

Lock symbol will appear on the screen when the childproof lock is activated.

Child-proof lock will also be deactivated when the machine is restarted by pressing the on/off button.

When the child-proof lock is activated:

• Display icons will not change even if the position of programme selection knob is changed while the machine is running or inhalt.
• If the child-proof lock is deactivated after changing the position of the programme selection knob while your machine is running, your machine stops and new programme information is displayed

Selecting a Programme and Operating Your Machine

6.19 Ending the programme through cancelling

A new programme can be selected and started after "Programme cancel" is activated in order to change the drying programme.

To cancel any selected programme: Press "Start/Pause/Cancel" button for about 3 seconds. "Lint filter cleaning" and "Water tank" warning symbols light up and "End" label appears on the screen as a reminder at the end of this period.

As the inside of the machine will be excessively hot when you cancel the programme while the machine is running, activate the ventilation programme to cool it down.

If you change the position of programme selection knob while your machine is running, then the machine stops, current programme is cancelled and new programme information is displayed.

6.20 End of programme

"Filter cleaning" and "Water tank" warning symbols light up and "End" label appears on the screen in the programme follow-up indicator when the programme ends. The door can be opened and the machine becomes ready for a second cycle.

Press "On/Off" button to turn off the dryer.

When selected, the 2-hour anti creasing programme will be activated to prevent laundry from creasing if you do not take the laundry out after the programme has come to an end.

Clean the filter after each drying (please see, Filter cleaning).

Drain the water tank after each drying (please see, Water tank)

7 Maintenance and cleaning

Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals.

7.1 Cleaning Lint Filter / Loading Door Inner Surface

Lint and fibre released from the laundry to the air during the drying cycle are collected in the Lint Filter.

i	Such fibre and lint are generally formed during wearing and washing.
!	Always clean the lint filter and the inner surfaces of the loading door after each drying process.
i	You can clean the lint filter housing with a vacuum cleaner.

To clean the lint filter:

• Open the loading door.
• Remove the lint filter by pulling it up and open the lint filter.
• Clean lint, fibre, and cotton raveling by hand or with a soft piece of cloth.
• Close the lint filter and place it back into its housing.

• A layer can build up on the filter pores that can cause clogging of the filter after using the dryer for a while. Wash the lint filter with warm water to remove the layer that builds up on the lint filter surface. Dry the lint filter completely before reinstalling it.

• Clean the entire inner surface of the loading door and loading door gasket with a soft damp cloth.

Maintenance and cleaning

7.2 Cleaning the sensor

There are dampness sensors in the dryer that detect whether the laundry is dry or not.

To clean the sensors:

• Open the loading door of the dryer.
• Allow the machine to cool down if it is still hot due to the drying process.
• Wipe the metal surfaces of the sensor with a soft cloth, dampened with vinegar and dry them.

i	Clean metal surfaces of the sensors 4 times a year.
i	Do not use metal tools when cleaning metal surfaces of the sensors.
!	Never use solvents, cleaning agents or similar substances for cleaning due to the risk of fire and explosion!

7.3 Draining the water tank

Dampness of the laundry is removed and condensed during drying process and the water that arises accumulates in the water tank. Drain the water tank after each drying cycle.

!	Condensed water is not drinkable!
!	Never remove the water tank when the programme is running!

If you forget to drain the water tank, the machine will stop during the subsequent drying cycles when the water tank is full and the Water Tank warning symbol will flash. If this is the case, drain the water tank and press Start / Pause button to resume the drying cycle. To drain the water tank:

Pull the drawer and remove the water tank carefully.

• Drain the water in the tank.

• If there is lint accumulation in the funnel of the water tank, clean it under running water.
• Place the water tank into its seat.

If the direct water draining is used as an option, there is no need to empty the water tank.

Maintenance and cleaning

7.4 For the condenser

Hot and humid air in the condenser is cooled with the cold air from the room. Thus, the humid air circulating in your dryer is condensed and then pumped into the tank.

Clean the condenser after every 30 drying cycles or once a month.

To clean the condenser:

1. If a drying process has been carried out, open the door of the machine and wait until it cools down.

1. Unlock the 2 condenser locks after opening the kick plate.

1. Pull out the condenser.

1. Clean the condenser by applying pressurized water with a shower head and wait until the water drains.

1. Place the condenser in its housing. Fasten the 2 locks and make sure that they are seated securely.

1. Close the kick plate cover.

8 Suggested solutions for problems

Drying process takes too much time

• Meshes of the filter may be clogged. Wash with water.

Laundry comes out wet at the end of drying.

• Meshes of the filter may be clogged. Wash with water. • Excessive laundry might have been loaded in. Do not load the dryer in excess.

Dryer does not switch on or the programme does not start. Dryer is not activated when set.

• It might have not been plugged in. Make sure that the machine is plugged in. • The loading door may be ajar. Make sure that the loading door is properly closed. • Programme might have not been set or the "Start/Pause/Cancel" button might have not been pressed. Make sure that the programme has been set and it is not in "Pause" mode. • "Childproof lock" might have been activated. Deactivate the childproof lock.

Programme has been interrupted without any cause.

• The loading door may be ajar. Make sure that the loading door is properly closed. • Electricity may be cut off. Press "Start/Pause/Cancel" button to start the programme.

Laundry has shrunk, become piled or deteriorated.

• A programme suitable for the laundry type might have not been used. Dry only the laundry which is suitable for drying in dryer after checking the labels on your clothes. • Select a programme with suitable low temperature for the laundry type to dry your clothes.

Drum lightning does not come on.

• Dryer might have not been started by using the "On/Off" button. Make sure that the dryer is on. • Bulb may have blown. Call the authorised service to replace the bulb.

"Final / Anti-creasing" symbol flashes.

• The 2-hour anti creasing programme to prevent laundry from creasing might have been activated. Turn off the dryer and take out the laundry.

"Final / Anti-creasing" symbol is on.

• Programme has come to an end. Turn off the dryer and take out the laundry.

For products with a condenser:

"Water tank" warning symbol is on.

• Water may be full. • Anti-creasing programme might be running. Drain the water in the tank.

"Filter cleaning" symbol is on.

• Filter might have not been cleaned. Clean the cover filter.

"Condenser cleaning" symbol is on.

• Filter drawer/Condenser might have not been cleaned. Clean the filters in the condenser/filter drawer under the kick plate.

Call an authorised service if the problem persists.

9

Guarantee

Your new Blomberg product is guaranteed against the cost of breakdown repairs for 3 years from the date of the original purchase.

9.1 What is covered?

• Repairs necessary as a result of faulty materials, defective components or manufacturing defect.
• The cost of functional replacement parts, but excluding consumable items.
• The labour costs of a Blomberg approved repairer to carry out the repair.

9.2 What is not covered?

• Transit, delivery or accidental damage or misuse and abuse.
• Cabinet or appearance parts, including knobs, flaps, handles or container lids.
• Accessories or consumable items including but not limited to, ice trays, scrapers, cutlery baskets, filters and light bulbs.
• Repairs required as a result of unauthorised repair or inexpert installation that fails to meet the requirements contained in the user instruction book.
• Repairs to products used on commercial or non-residential household premises.
• Loss of frozen food in freezers or fridge/freezers. (Food loss insurance is often included within your household contents insurance policy, or may be available separately from your retailer).

9.3 Important notes.

• Your Blomberg product is designed and built for domestic household use only.
• The guarantee will be void if the product is installed or used in commercial or non-residential domestic household premises.
• The product must be correctly installed, located and operated in accordance with the instructions contained in the User Instructions Booklet provided.
  Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing Machines, Dishwashers and Electric Cookers
  Gas Cookers must only be installed by a Gas Safe (or BORD GAI5) registered Gas Installer.
• The guarantee is given only within the boundaries of the United Kingdom and the Republic of Ireland.
• The guarantee is applicable only to new products and is not transferable if the product is resold.
• Blomberg disclaims any liability for incidental or consequential damages.
• The guarantee does not in anyway diminish your statutory or legal rights.

Should you experience any difficulty in obtaining service please contact the Blomberg Customer Help-Line.

Tel: [phone]

10 Service

Please keep your purchase receipt or other proof of purchase in a safe place; you will need to have it should the product require attention under guarantee.

You should also complete the details below; it will help us assist you when requesting service. (The model number is printed on the Instruction Booklet and the serial number is printed on the Rating Label affixed to the appliance)

Model No:

Serial No:

Retailer:

Date of purchase:

Before requesting service please check the trouble-shooting guide in the Operating Instructions as a charge may be levied where no fault is found even though your product may still be under guarantee.

Service once the manufacturers guarantee has expired.

If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be obtained at a charge.

Should you experience any difficulty in obtaining service please contact the Blomberg Customer Help-Line.

Tel: [phone]

Blomberg, 1 Greenhill Crescent, Watford, WD18 8QU

Tel: [phone]

email: [e-mail]

Fax: [phone],

www.blomberguk.com
