| Product Type | Portable Air Conditioner |
| Brand | Orima |
| Model | ORTT-12-R32 |
| Refrigerant | R32 |
| Cooling Capacity | 12000 BTU |
| Power Supply | 220-240V ~ 50Hz |
| Power Consumption (Cooling) | 1100W |
| Dimensions (W x D x H) | 45 x 35 x 70 cm |
| Weight | 28 kg |
| Noise Level (Low/High) | 52 / 56 dB(A) |
| Airflow Volume | 420 m³/h |
| Dehumidification Capacity | 1.5 L/h |
| Functions | Cooling, Dehumidifying, Fan, Auto, Sleep, Timer |
| Remote Control | Yes, included |
| Filter Type | Washable mesh filter |
| Installation | Window kit included for exhaust hose |
| Maintenance | Clean filter every 2 weeks |
| Safety Features | Auto restart, overheat protection, child lock |
| Spare Parts Available | Filter, remote control, exhaust hose |
| Repairability Index | 7.5 / 10 |
Frequently Asked Questions - ORTT-12-R32 Orima
How do I install the ORTT-12-R32 air conditioner?
Follow the installation instructions in the manual. Typically, connect the exhaust hose to the window kit, insert the bracket in the window, and plug in the unit. Ensure proper sealing for efficiency.
What does the error code E1 mean?
Error code E1 indicates a problem with the room temperature sensor. Try resetting the unit by unplugging for 5 minutes. If persists, contact service.
How often should I clean the filter?
Clean the washable filter every two weeks under normal use. More frequently in dusty environments. A dirty filter reduces efficiency.
Can the remote control be replaced?
Yes, you can order a replacement remote from Orima or compatible universal remotes. The model is usually ORTT-RC12.
What is the appropriate room size for this unit?
The ORTT-12-R32 is suitable for rooms up to 25-30 m² (270-320 sq ft) depending on insulation and sun exposure.
Does the air conditioner have a heating function?
No, this model is a cooling-only portable air conditioner. It does not provide heating.
How do I use the timer function?
Press the Timer button on the remote or control panel. Use + or - to set the desired hours (1-24). Confirm to schedule auto on/off.
What refrigerant does it use?
The ORTT-12-R32 uses R32 refrigerant, which is more environmentally friendly than older R410A. Service must be done by qualified technicians.
Why is water leaking from the unit?
During dehumidification, water collects in the internal tank. If leaking, ensure the drain plug is tight. Empty the tank when full or connect a continuous drain hose.
How do I reset the filter indicator?
After cleaning the filter, press and hold the Filter button for 3 seconds until the indicator light turns off. This resets the reminder.
User questions about ORTT-12-R32 Orima
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Air conditioner in PDF format for free! Find your manual ORTT-12-R32 - Orima and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. ORTT-12-R32 by Orima.
USER MANUAL ORTT-12-R32 Orima
eletrodomésticos
MANUAL DE INSTRUÇÕES
INSTRUCTION MANUAL LIVRE D'INSTRUCTIONS LIBRO DE INSTRUCCIONES
facebook.com/orima.pt
AR CONDICIONADO
Air Conditioner | Aire Acondicionado | Climatiseur
I FEEL
Liga/desliga o ecrã LED no painel.
Função 8°C heating (Opcional)
Função Gentle Wind (Vento Suave) (Opcional)
Função Health LUZ UVC – (Opcional)
Simple line drawing of an open book with a wrench resting on it (no text or symbols)
