| Product Type | Air Conditioner |
| Brand | Orima |
| Model | ORTT-24-R32 |
| Refrigerant | R32 |
| Cooling Capacity | 24000 BTU |
| Power Supply | 220-240V, 50Hz |
| Dimensions (W x H x D) | 450 x 750 x 350 mm |
| Weight | 30 kg |
| Energy Efficiency Ratio (EER) | 12.5 |
| Airflow Rate | 600 m³/h |
| Noise Level | 52 dB(A) |
| Functions | Cooling, Fan, Dehumidification |
| Thermostat Control | Electronic with Remote |
| Timer | 24-hour programmable |
| Filter Type | Washable mesh filter |
| Maintenance | Clean filter every 2 weeks |
| Safety Features | Overheat protection, auto shut-off |
| Installation | Portable, includes window kit |
| Reparability | Spare parts available via authorized service |
| Warranty | 2 years |
Frequently Asked Questions - ORTT-24-R32 Orima
How do I install the air conditioner?
The unit is portable. Attach the exhaust hose to the window kit and secure it in an open window. Plug into a grounded outlet.
How often should I clean the filter?
Clean the filter every two weeks to maintain efficiency. Remove, wash with mild detergent, dry completely before reinserting.
The unit is not cooling enough. What should I check?
Ensure the filter is clean, the exhaust hose is not blocked, and the room is properly sealed. Also check that the set temperature is lower than room temperature.
Can I use an extension cord?
No, do not use an extension cord. Plug directly into a dedicated outlet rated for the unit's power requirements.
What does the timer function do?
The timer can set the unit to turn on or off after a specified time, up to 24 hours. Use the remote to program it.
How do I drain the water?
In high humidity, the unit collects water which may need draining. Remove the drain plug at the back and allow water to flow into a container.
The remote control is not working. What do I do?
Replace the batteries with new ones. Ensure nothing is blocking the sensor on the unit. If still not working, contact support.
Is the air conditioner also a heater?
No, this model only provides cooling, fan, and dehumidification functions. It does not have a heating mode.
What should I do if the unit displays an error code?
Refer to the manual's troubleshooting section. Common codes indicate issues like sensor failure or blockage. Turn off and unplug before checking.
Can I leave the unit on when I'm not home?
Yes, but it's recommended to use the timer or set a moderate temperature. Ensure nothing obstructs airflow and the filter is clean.
User questions about ORTT-24-R32 Orima
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Air conditioner in PDF format for free! Find your manual ORTT-24-R32 - Orima and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. ORTT-24-R32 by Orima.
USER MANUAL ORTT-24-R32 Orima
eletrodomésticos
MANUAL DE INSTRUÇÕES
INSTRUCTION MANUAL LIVRE D'INSTRUCTIONS LIBRO DE INSTRUCCIONES
facebook.com/orima.pt
AR CONDICIONADO
Air Conditioner | Aire Acondicionado | Climatiseur
I FEEL
Liga/desliga o ecrã LED no painel.
Função 8°C heating (Opcional)
Função Gentle Wind (Vento Suave) (Opcional)
Função Health LUZ UVC – (Opcional)
Simple line drawing of an open book with a wrench on the cover (no text or symbols)
