Product Type	Pedestal Fan
Model Number	S18440
Compatible Models	S18601, S18605, S18607, S18670, S18355
Blade Diameter	18 inches
Power Supply	120V AC, 60Hz
Speed Settings	4 speeds (1, 2, 3, 4)
Oscillation	Yes, with push-down knob
Tilt Adjustment	Manual tilt direction
Remote Control	Included (requires 2 AAA batteries, not included)
Plug Type	Polarized plug with built-in safety fuse (non-replaceable)
Use Location	Indoor residential only
Cleaning Method	Vacuum with brush attachment; wipe body with soft cloth. Do not use alcohol or solvents.
Lubrication	Motor permanently lubricated
Warranty	1 year limited warranty (USA, territories, Canada only)
Assembled Height	Adjustable via pipe and base (not specified)
Safety Certifications	FCC Part 15 compliant

Frequently Asked Questions - S18440 Lasko

How do I assemble the fan?

Refer to the assembly diagram in the manual. Attach the base to the pipe, then slide the head assembly onto the pipe and secure it. Install the rear grill, blade, spinner, and front grill. A quick assembly video is available at www.lasko.com/how-to.

How do I clean the fan?

Always unplug the fan before cleaning. Use a vacuum with a brush attachment to remove lint and dirt from the grill. Wipe the body with a soft cloth. Never use alcohol, gasoline, benzene, paint thinner, or other harsh cleaners.

The fan does not turn on. What should I check?

First, ensure the power cord is plugged into a working electrical outlet. If using the remote, check that the batteries are new and installed correctly (polarity + and -). Also, the built-in safety fuse in the plug may have blown; if so, the fan needs service.

Can I use an extension cord?

Avoid using extension cords, power strips, or outlet-style air fresheners. These devices may overheat and create a fire hazard. If you must use an extension cord, ensure it is rated for the fan's power draw.

How do I use the remote control?

Insert two AAA batteries (not included) into the remote. Press the power button to turn the fan on/off, and the speed button to cycle through 4 speeds. Do not mix old and new batteries or different types.

Is this fan safe to use outdoors?

No, this fan is for indoor residential use only. It is not designed for outdoor or wet locations such as bath tubs, pools, or hot tubs. Using it outdoors may cause electric shock.

Does the fan oscillate?

Yes, push down the oscillation knob on the motor housing to make the fan head move from side to side. Pull up to stop oscillation.

How do I adjust the height?

Loosen the collar at the base of the head assembly, slide the pipe up or down to the desired height, then tighten the collar to secure.

The remote control does not work. What can I do?

Check that the batteries are fresh and installed correctly. Make sure there are no obstructions between the remote and the fan. If other remote controls interfere, move the fan to another location.

How do I store the fan?

Store the fan in the original carton in a cool, dry place. Keep these instructions for future reference. Dispose of packaging materials responsibly.

USER MANUAL S18440 Lasko

to Dept., 820 Lincoln Ave., West Chester, PA 19380

18" Adjustable Pedestal Fan Instruction Manual

Used for Models: S18601, S18605, S18607 S18670, S18355, S18440

Register Your Product Today www.isako.com/product-registration

You will benefit from: - Efficient and enhanced support - Future product updates

Scan with a smart phone

Black outdoor fan with four blades and a control panel (no visible text or symbols)

(Model S18607)

Have a Question? Need a Part? Please Do Not Return Product to Store!

Cannett Lasso Customer Service [phone] Monday-Friday 8AM - 6PM EST. (Valid in the USA, to Territories, and CANADA Only)

READ AND SAVE THESE INSTRUCTIONS

Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage.

This Family for residential use only. It is not intended to be used in commercial, industrial or agricultural settings.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, these instructions and warnings should always be followed to reduce the risk of fire, electrical shock and injury to persons:

Read all instructions before using this Fan.

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR PERSONAL INJURY, ALWAYS FOLLOW THESE IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS:

DO NOT use this Fan to ventilate areas where flammable liquids or vapore are used, stored or are present, including paints, gasoline, varnishes, floor refinishing products or solvents. ALWAYS read and follow all warnings and instructions on the containers for these products! ALWAYS be sure the plug file lightly into the outlet. When plugs fit loosely into outlets, they may slip partially out of the outlet and create a poor connection. This may cause outlets to overheat and create a potential fire hazard. Outlets in this condition should be replaced by a qualified electrician.
ALWAYS unplug the power cord when servicing, cleaning or moving the Fan. DO NOT use the ON/OFF switch as the sole means of disconnecting power. NEVER leave children unattended when the Fan is on or plugged in. ALWAYS turn off and unplug the Fan when not in use. BE CERTAIN that the power source for the Fan is 120V AC. DO NOT plug the Fan into 240V or other power source.
The Blue Plug" on your Lasko Fan is a safety feature. It contains a non-replaceable safety device (fuse) that should not be removed or tampered with. To reduce the risk of fire, electric shock and personal injury, DO NOT attempt to remove, replace, repair or tamper with the originally supplied plug. If the Fan has stopped functioning, it may be due to the safety device Incorporated in this plug.
THIS FAN HAS A POLARIZED PLUG (one blade is wider than the other). This plug is designed to fit into the outlet only one way. Match the wide blade to wide slot in outlet and FULLY INSERT, DO NOT attempt to bypass or defeat this safety feature. If the plug does not fit in the outlet, consult a qualified electrician. The outlet may need to be replaced.

CAUTION

• AVOID the use of extension cords, power strips, power taps, outlet style air fresheners or other cord connected device, as these devices may overheat and cause a live hazard.
  • DO NOT route power cord under rugs, carpets, runners or furniture. This may damage the cord or cause it to overheat creating a fire hazard.
• ALWAYS place the Fan on a statue, and, never surcharge while in operation to prevent the Fan from overturning.
• NEVER insert or allow fingers or objects to enter grill openings while Fan is in operation or injury and/or damage to the Fan may occur.
• DO NOT block, cover or obstruct air flow to or from the Fan while in operation.
• DO NOT use this Fan outdoors or near water or wet locations such as a bath tub, pool or hot tub. Use of this Fan in a wet location may create a shock hazard.
  • DO NOT run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.
• NEVER use a single extension cord to operate more than one Fan or other electrical device.
• DO NOT use this Fan if it has been damaged or is not functioning properly.
• Remote controls for other appliances or electronic equipment can sometimes interfere with the operation of this Fan. If this occurs, move the Fan to another location.
• Keep Fan remote control unit away from chairs and your bed where it may be sat or laid upon and inadvertently turn on the Fan.
• THIS FAN DOES NOT MEET THE REQUIREMENTS OF NEC ARTICLE 547-7 (2008). This Fan is not suitable for use in agricultural facilities including areas where livestock, poultry or other animals are continents. Please refer to National Electric Code (NEC) Article 647-7 (2008), or applicable state or local codes or standards relating to electrical requirements for agricultural buildings.
• THIS FAN DOES NOT MEET THE REQUIREMENTS OF NEC ARTICLE 500 (2008). This Fan is not suitable for use in hazardous locations. Please refer to National Electric Code (NEC) Article 500 or applicable state or local codes or standards relating to electrical requirements for hazardous locations. Models 818601/818605/818607/818670/818355
  Lasko Products, LLC
  B20 Lincoln Avenue
  19380
  This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any Interference received. Including Interference that may cause undesired operation. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment. *NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: *Report or register the safety system
• increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer of an experienced radio TV technician for help.

SAVE THESE INSTRUCTIONS

Rev. B 2/21 2 2084917

Partes Incluidas
1

2

5

7

① Rejilla Frontal
② Parrilla Trasera
③ Tapa de Ventilador
④ Tuerca
⑤ Helice

Rev. B 2/21 7 2084917

ADVERTENCIA

820 Lincoln Avenue West Chester, PA

19380

www.lasko.com

Rev. B 2/21 6 2084917

Parts Included

① Front Grill

② Rear Grill

③ Spinner

⑤ Spinner

④ Nut

⑤ Blade

⑥ Head Assembly

⑦ Pipe

⑧ Base

⑥ Base

⑨ Remote Control

Assembly (Quick Assembly Video: www.lasko.com/how-to)

1. Assemble Fan Head 3. Loose

Au2C4lerisPipetapDiplatenNotBiaSwistHeadAssembly

down onto Pipe

Oscillation

Push down Oscillation Knob on motor housing to make Fan Head move from side to side.

Tilt

To adjust direction of air, simply tilt the Head of the Fan.

Controls

Power Button Turn Fan ON/CFF by pressing the Power Button

Fan Speed Button Fan Speed can be adjusted to 1, 2, 3, or 4

Rev. B 2/21 3 2084917

REMOTE CONTROL:

1. Install two "AAA" batteries (not included).
2. Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc) or rechargeable nickel-cad mI uml batteries.
3. DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLADE OR LEAK

4. Always purchase the correct size and grade of battery most suitable for the intended use.

5. Replace all batteries of a set at the same time.

6. Clean the battery contacts and also those of the device prior to battery installation.
7. Ensure the batteries are installed correctly with regards to polarity (+ and -).
   a. Remove batteries from equipment that is not to be used for an extended period of time.
8. Remove used batteries promptly.

⚠ WARNING

To reduce the risk of electrical shock and fire please observe the following instructions:

• Always unplug the cord before moving, servicing or cleaning.
• NEVER place the Fan in or near water.
• Clean the Fan only with a vacuum equipped with a brush attachment; the vacuum will remove the lint and dirt from inside the Fan.
• NEVER attempt to take apart the Fan.
• Clean the body of the Fan with a soft cloth only.

- NEVER use ALCOHOL or SOLVENTS such as gasoline, benzene, paint thinner, or other harsh cleaners.

TROUBLE SHOOTING TIPS

If your Fan fails to operate, see below for a list of probable causes and solutions:
1. Be sure the power cord is plugged into a working electrical outlet.
2. Make certain the batteries in the remote control are new and properly installed.
SERVICING: For servicing, other than general user maintenance, please contact Customer Service at [phone], Monday through Friday, from 8am-5pm Eastern.
STORAGE: Store the Fan with these instructions, in the original carton in a cool, dry place.
LUBRICATION: Motor is permanently lubricated.
DISPOSITION: Corrugated packaging materials are recyclable. For environmentally responsible disposal of this product, contact your local waste service provider or visit www.1800recycling.com ^c .

LASKO PRODUCTS, LLC LIMITED WARRANTY (VALID IN THE USA, ITS TERRITORIES, AND CANADA ONLY)

WHAT THIS WARRANTY COVERS: This product is warranted against defects in workmanship and/or materials. HOW LONG THIS WARRANTY LASTS: This warranty extends only to the original purchaser of the product and lasts for one (1) year from the date of original purchase or until the original purchaser of the product sold or transfers the product, whichever first occurs.

WHAT LASKO WILL DO: During the warranty period, Lasko will, at its sole option, repair or replace on part or parts that prove to be defective or replace the whole product with the same or comparable model. For all warranty claims, the product must be returned to Lasko Products, LLC at customer expense with proof of purchase within the warranty period. Contact the Lasko customer service department to obtain a Fairum Authorization ("RA"). DO NOT return products without an RA or the warranty claim will not be processed.

WHAT THIS WARRANTY DOES NOT COVER: This warranty does not apply if the product was damaged or failed because of accident, improper handling or operation, shipping damage, abuse, misuse, unauthorized repairs made or attempted. This warranty does not cover shipping costs for the return of products to Lasko for repair or replacement. Lasko will pay return shipping charges from Lasko following warranty repairs or replacement. ANY AND ALL WARRANTIES, EXPRESSED OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF MERCHANTABILITY), WITHOUT THE INFORMATION IN ACCORDANCE WITH ANY OTHER PURPOSES. ANY INFORMATION IS NOT TO BE USED IN ANY OTHER PURPOSES. ANY OTHER PURPOSES ARE AVAILABLE FOR THE PRODUCT, WHICEVER FIRST OCCURS AND IN EVENT SHALL LASKO'S LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY INCLUDE (II) INCIDENTAL OR CONSEQUENTIAL DAMAGES FROM ANY CAUSE WHATSOEVER, OR (III) REPLACEMENT OR REPAIR OF ANY HOUSE FUSES, CIRCUIT BREAKERS OR RECEPTACLES. NOTWITHSTANDING ANYTHING TO THE CONTRARY, IN NO EVENT SHALL LASKO'S WARRANTY OF MERCHANTABILITY AND ANY OTHER PURPOSES. ANY OTHER PURPOSES ARE AVAILABLE FOR THE PRODUCT AND ANY SUCH LIABILITY SHALL TERMINATE UPON THE EXPIRATION OF THE WARRANTY PERIOD.

Some states and provinces do not allow limitations on how long an implied warranty tests, or the exclusion or limitation of incidental or consequential damages, so these exclusions or limitations may not apply to you. This warranty gives you specific legal rights. You may also have other rights which vary from state to state and province to province.

Proof of purchase is required before a warranty claim will be accepted.

CUSTOMER SERVICE:

Toll-Free [phone]. Email: [e-mail]

Our Customer Service team is available to assist you with product and service questions, and replacement parts. They can be reached Monday through Friday, 8am-5pm Eastern. Please have your model number available, as well as the type and style (located on the underside of your product).

Customer Service Dept., 820 Lincoln Ave., West Chester, PA 19380

(Please do not send product to this location) www.lasko.com

Manual printed in USA
