Product Type	Deep Fryer
Brand	G3 Ferrari
Model	Friggisano 22L G10145
Oil Capacity	2.5 L
Power Consumption	1800 W
Voltage / Frequency	220-240 V, 50/60 Hz
Temperature Range	150°C - 190°C
Frying Basket Capacity	Up to 1 kg of food
Control Type	Adjustable thermostat with indicator light
Safety Features	Overheat protection, cool-touch handles, non-slip feet
Cleaning	Removable non-stick bowl, dishwasher safe parts
Material	Stainless steel body, plastic handles
Dimensions (HxWxD)	30 x 25 x 25 cm
Weight	3.5 kg
Cord Length	1 m
Accessories Included	Frying basket, lid, instruction manual
Warranty	2 years
Repairability	Spare parts available; designed for easy repair
Certifications	CE, RoHS
User Manual Languages	English, Italian, and more (see website)

Frequently Asked Questions - Friggisano 22L G10145 G3 Ferrari

How do I clean the Friggisano 22L deep fryer?

Allow the oil to cool completely. Remove the bowl and wash it with warm soapy water or place it in the dishwasher. The basket is also dishwasher safe. Wipe the exterior with a damp cloth. Do not immerse the base in water.

What type of oil should I use?

Use high-quality frying oil with a high smoke point, such as canola, sunflower, or peanut oil. Avoid olive oil or butter as they burn easily.

How much oil is needed?

Fill the oil to the minimum and maximum marks inside the bowl. Typically about 2.5 liters, but always check the markings.

Can I fry frozen foods directly?

Yes, but reduce the quantity and increase cooking time slightly. Shake off excess ice to prevent splattering. Always follow the recommended cooking times in the manual.

Why does the fryer turn off automatically?

The fryer has an overheat protection feature. If it turns off, let it cool for 15-20 minutes and then reset by unplugging and plugging back in.

What is the maximum frying temperature?

The maximum temperature is 190°C. Use lower temperatures for delicate foods like fish or vegetables.

How often should I change the oil?

Change the oil after 8-10 uses, or sooner if it becomes dark, smells rancid, or smokes excessively. Filter the oil after each use to extend its life.

Is the basket removable for easy serving?

Yes, the basket has a cool-touch handle and can be hooked onto the rim to drain excess oil before serving.

Can I use the fryer without the lid?

The lid helps contain splatters and reduce odor. It is recommended to use it for safety and convenience, but you can fry without it if you prefer.

Where can I find spare parts?

Spare parts such as the basket, bowl, and thermostat are available through G3 Ferrari's official website or authorized service centers. Check the manual for part numbers.

USER MANUAL Friggisano 22L G10145 G3 Ferrari

Exterior view of a black and red GFERRARI electric toaster oven (no visible text or symbols on the device body)

Forno Air Fryer - Air Fryer Oven

FRIGGISANO 22L

ITA: INDICE

Simbologia.... p. 2

Safety Instructions.... p. 10

General information.... p. 12

G10145....p. 13

Control knobs.... p. 13

Preheating.... p. 14

Cooking.... p. 14

Cooking Functions.... p. 14

Cleaning....p. 15

Technical features.... p. 16

Waste of electric and electronic equipment (WEEE

Directive).... p. 16

CLASSI DI PROTEZIONE / PROTECTION CLASSES

ATTENZIONE RISCHIO DI SCOSSE ELETTRICHE NON ESPORRE A PIOGGIA E UMIDITA'

WARNING ELECTRIC SHOCK RISK DO NOT EXPOSE TO RAIN OR MOISTURE

ATTENZIONE: NON APRITE L'APPARECCHIO. ALL'INTERNO NON VI SONO COMANDI MANIPOLABILI DALL'UTENTE NE' PARTI DI RICAMBIO. PER TUTTE LE OPERAZIONI DI SERVIZIO RIVOLGERSI AD UN CENTRO DI ASSISTENZA AUTORIZZATO.

This symbol warns the user that un-insulated dangerous voltage inside the system may cause an electrical shock. Do not open the case.

Class I Appliance symbol. This means the appliance must have the chassis connected to electrical earth/ground by an earth conductor.

Caution: this symbol reminds the user to read carefully the important operations and maintenance instructions in this owner's guide.

AVVERTENZE DI SICUREZZA

ENGLISH: SAFETY INSTRUCTIONS

The following are important notes on the installation, use and maintenance; save this instruction manual for future reference; use the equipment only as specified in this guide; any other use is considered improper and dangerous; therefore, the manufacturer cannot be held responsible in the event of damages caused by improper, incorrect or unreasonable use.

Before use, ensure the equipment is undamaged; if in doubt, do not attempt to use it and contact the authorized service center; do not leave packing materials (i.e. plastic bags, polystyrene foam, nails, staples, etc.) within the reach of children as they are potential sources of danger; always remember that they must be separately collected. Make sure that the rating information given on the technical label are compatible with those of the electricity grid; the installation must be performed according to the manufacturer's instructions considering the maximum power of the appliance as shown on the label; an incorrect installation may cause damage to people, animals or things, for which the manufacturer cannot be considered responsible thereof.

If it is necessary to use adapters, multiple sockets or electrical extensions, use only those that comply with current safety standards; in any case do not exceed the power consumption limits indicated on the electrical adapter and / or extensions, as well as the maximum power shown on multiple adaptor.

Do not leave the unit plugged; better to remove the plug from the mains when the device is not in use. Always disconnect from power supply if you leave it unattended.

Cleaning operations should be carried out after unplugging the unit.

If the unit is out of order and you do not want to fix it, it must be made inoperable by cutting power cord.

• Do not allow the power cord to get closer to sharp objects or in contact with hot surfaces; do not pull it to disconnect the plug.
• Do not use the appliance in the event of damage to the power cord, plug, or in case of short circuits; to repair the product only address an authorized service center.
• Do not handle or touch the appliance with wet hands or bare feet. Do not expose the appliance to harmful weather conditions such as rain, moisture, frost, etc.. Always store it in a dry place.
• This appliance can be used by children of 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they received supervision or instruction concerning use of the appliance in a safe way and understand hazards involved; children shall not play with the appliance; cleaning and user maintenance shall not be made by children without supervision.
• Children must not play with the appliance.
• Keep the appliance and its cord out of reach of children less than 8 years.
  If the power cord is damaged, or in case of failure and / or malfunction do not tamper with the unit. The reparation must be done by manufacturer or by service center authorized by the manufacturer in order to prevent any risk. Failure to comply with the above may compromise the unit safety and invalidate the warranty.
  WARNING: This appliance includes heating function. Surfaces, other than functional surfaces may develop high temperatures. Since temperatures are perceived differently by different people, this device should be used with CAUTION. Hold the appliance exclusively to grip surfaces intended to be touched.
• This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops,

offices and other working environments; by clients in hotels, motels and other residential type environments; farm houses, bed and breakfast type environments.

• The appliance is not intended to be operated by means of an external timer or separate remote-control system.
• Before every use, unrøll the power cord.
• Use original spare parts and accessories only.
• Do not subject the product to strong impacts, serious damages may result.
• Do not use near or under flammable materials (like curtains), heat, cold spots and steam.

GENERAL INFORMATION

The surfaces of appliance shall not be placed against a wall. Leave at least 10cm free space on the back and sides and 10cm free space above the appliance.

The appliance becomes hot during use; never touch the glass or the inside of the appliance, but only handles and control panel. Always use pot holders to remove the accessories.

Do not place anything on the door when it is open, as the door may be damaged or the oven may fall and break.

Do not place anything on top of the appliance. Don't move the oven if is hot or if contains food.

Always use handle to remove the grill and the pan.

Handle with care cooked food to avoid risk of burning.

Put food only on the accessories included, in order to not let the food touch the heating element.

Do not fill trays with oil as this may cause a fire hazard.

For cooking use only containers that are suitable for high temperatures.

The appliance needs approximately 30 minutes to cool down for handle or cleaning safely. Do not wash or throw water on glass when is hot, as it may break. Do not use the oven if there is any damage to the door or its seals.

Never leave the appliance unattended while it is running. Remove the plug after each use.

Do not place the oven in water or other liquids and avoid splashing of liquids on the unit.

During functioning, hot steam is released through the air outlet openings. Keep your hands and face at a safe distance from air outlet. Also be careful of hot steam when you open the door after cooking.

Before every use, unroll the power cord.

Do not cover the air inlet and the air outlet openings while the appliance is operating.

Do not use the appliance as a heating unit. Do not insert anything in the ventilation windows.

Before cleaning, always unplug the unit from the electrical outlet and wait for the complete cooling of each part of the appliance.

Do not use the oven as shelf support for objects or as place to store food, pots, containers, etc..

Remove all packaging materials from the cooking compartment.

After use, place all knobs in OFF position.

DESCRIPTION G10145

1 Working light

2 Timer knob

3 Cooking selection switch

4 Button for inner light

5 Temperature knob

6 Door

7 Handle

8 Oven rack

9 Tray

10 Air vents

11 Tray handle

12 Grease tray

13 Basket

CONTROL KNOBS

Moving the cooking selection switch (3) allows to select functions:

OFF: oven is switched Off

GRILL: Enable 2 upper heating element (GRILL cooking)

* GRILL: Enable 2 upper heating element and the convection.

TOAST: Enable 2 upper and 2 lower heating elements (static oven function).

*BAKE: Enable 2 upper and 2 lower heating elements and the fan (Convection oven function)

AIR FRY: Enable the 4 upper heating element and the fan (Air Fryer function)

* DEHYDRATE: Enable 2 upper heating elements and the fan

The temperature control knob (5) allows you to set a temperature between up to 230 degrees Celsius. The timer control knob (2) allows you to set the cooking time between 0 and 60 minutes, and it also has the “always ON” position. The button (4) switches on and off the inner light.

PREHEATING

Before inserting the food, always preheat the oven for about 15 minutes to allow the unit to reach the selected temperature. Preheat the oven without food.

• Set the timer control knob (2) up to 15 minutes. Working light (1) switches on.
• Set the desired temperature using the temperature control knob (5).
• Turn cooking selection switch (3) to the desired position.
• At timer acoustic signal, preheating process is completed and the oven is ready for cooking.

COOKING

Carefully wash all accessories and the inner housing first. Allow to ventilate the internal compartment keeping the door open for about 30 minutes and subsequently operate the empty oven for few minutes keeping the door open. Before starting with the first cooking, turn on the oven for 10 minutes at the maximum power with both heating elements working.

• Connect to a suitable and earthed power socket.
• Place the grease collecting tray (12) at the bottom of cooking chamber and pour it with some water.
• Pre-heat the oven and place food on one of the accessories, set the temperature (control knob 5), time (2) and type of cooking (2) and place accessory inside oven at the right height.
• Periodically check the condition of the food during cooking (button 4 switches on the inner light). In case you need to open the door for any reason, close it as quick as possible to avoid losing heat.
• At the end of cooking process, the timer will emit acoustic signal. If the cooking is not complete reset the timer control knob. When food is ready, remove the accessories using the handle (11). Turn all the knobs to OFF position.

NOTE: appliance is equipped with a safety device that stops the oven if the door is open. Make sure that the door is properly closed, otherwise the oven will not work.

COOKING FUNCTIONS

GRILL

Before cooking pre-heat oven for 15 minutes. Use "Grill" function to grill, brown, defrost, ecc.

It is advised to lay down the food on the grid (8) and to put the grid on the upper position inside the oven. The tray (9) can be placed in the middle position to reduce the volume to heat.

STATIC OVEN: TOAST

Before cooking pre-heat oven for 15 minutes.

Use function “Toast” for all oven cookings: roast, bake, heat, toast, ecc.

Depending on the type of cooking and on the type of ingredient (meat, fish, vegetables, pizza, ecc.), food can be placed on any accessory; so select the one you think is more suitable: tray, grid, basket.

Also the position inside the oven should be chosen depending on the cooking type.

It is possible to cook also on more than one level.

CONVECTION OVEN: GRILL e BAKE

Before cooking pre-heat oven for 15 minutes.

The functions “Grill with Convection” and “Bake with Convection” allow to have a real convection oven.

Depending on the type of cooking and on the type of ingredient (meat, fish, vegetables, pizza, ecc.), food can be placed on any accessory; so select the one you think is more suitable: tray, grid, basket.

Also the position inside the oven should be chosen depending on the cooking type.

It is possible to cook also on more than one level.

AIR FRY

Before cooking pre-heat oven for 15 minutes.

With Air Fryer function the heat coming from the 4 upper heating elements, combined with the strong convection, allows to cook even without oil, healthy and delicious food, without giving up the crispness of traditional fried food.

For this function use the fryer basket (13) and put it in the upper position inside oven, near to the heating elements. Here some indications of time and quantities for the air fryer function.

	Min-max Amount (g)	Time (min.)	Temp (°C)	Accessory
Potato & fries
Thin frozen fries	400-800	15-20	200	Basket
Thick frozen fries	400-800	18-23	200	Basket
Potato gratin	500-900	15-20	200	Tray
Meat and fish
Steak	200-800	15-22	180	Basket
Pork chops	400-800	12-18	180	Basket
Hamburger	200-800	10-18	185	Basket
Chicken breast	400-800	15-22	180	Basket
Chicken thighs	400-800	25-35	190	Basket
Meat Skewers	400-800	15-22	185	Basket
Fish Skewers	400-800	13-16	180	Basket
Fish	400-800	13-18	180	Tray
Snacks
Frozen chicken nuggets	500-800	8-15	200	Basket
Frozen fish fingers	500-800	6-12	200	Basket
Frozen bread crumbed cheese snacks	500-700	8-12	180	Basket
Stuffed vegetables	500-800	15-20	180	Tray
Baking
Cake	800	25-35	160	Tray
Quiche	800	20-30	190	Tray
Muffins	800	20-30	160	Tray
Sweet snacks	800	18-25	170	Tray

Not: pre-heat for 15 minutes.
- Smaller ingredients usually require a slightly shorter preparation time than larger ingredients.
- A larger amount of ingredients only requires a slightly longer preparation time.
- Shaking smaller ingredients halfway through the preparation time optimizes the end result and can help prevent unevenly fried ingredients.
- Add some oil to fresh potatoes for a crispy result.
- Do not prepare extremely greasy ingredients such as sausages in the Hot-air fryer.
- Use tray to bake a cake or quiche or if you want to fry fragile ingredients or filled ingredients.

DEHYDRATE: DEHYDRATE

Use “Dehydrate” function to dehydrate any kind of food. When you use this function:

• Use basket (13) and place it in the central position.
• Temperature knob (5) is inactivated and inner temperature is set automatically to 70-75°C, suitable for dehydrating food.
• Place the timer knob (2) in position "ON".

Periodically check the state of food and eventually turn them to dehydrate evenly.

CLEANING - Unplug the unit from the electrical outlet and allow each part to cool down before starting any cleaning procedure.

• Do not place oven in water. In any case prevent splashes of water or other liquids from reaching the unit.

• Regular cleaning of the internal chamber ensure better performances and prevents unpleasant odors. Use a soft cloth and non-abrasive cleaner for the cooking compartment.

• Grill, tray, and basket can be washed as everyday crockery.

• Do not use abrasive or metallic sponges to clean the outside of the oven. This may jeopardize the paint.
• Be careful not to drop any liquid or soap in the ventilation openings during cleaning.

Crumbs, oils and cooking residues fall to the bottom of the unit. For faster cleaning, remove the crumb tray and clean it separately.

TECHNICAL FEATURES

• Power supply: AC 230V\~50-60Hz. Power 1700W
- Chamber with capacity 22 L and internal light
- Convection - Adjustable temperature (up to 230^ ) - Timer 60 minutes
• Accessories: tray, grid, basket

The product is made of non-biodegradable and potentially polluting substances if not properly disposed of; other parts can be recycled. It's our duty to contribute to the ecological health of the environment following the correct procedures for disposal. The crossed out wheelie bin symbol indicates the product complies with the requirements of the new directives introduced to protect the environment (2002/96/EC, 2003/108/EC, 2002/95/EC, 2012/19/EC) and must be properly disposed at the end of its lifetime. If you need further information, ask for the dedicated waste disposal areas at your place of residence. Who does not dispose of the product as specified in this section shall be liable according to the law.

[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
17
17
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

To find the nearest service center, please call the telephone number 0541 694246, fax number 0541 756430 or contact us at [e-mail] asking for the service centers supervisor.

Appliance is conform to the pertinent European regulation and is therefore marked with the CE mark.

www.g3ferrari.it TREVIDEA S.r.l.

TREVIDEA S.R.L. – Strada Consolare Rimini – San Marino n. 62 – 47924 – RIMINI (RN) - ITALY

MADE IN CHINA
