AMP 600 - Receiver Glemm - Free user manual and instructions

Product Type	Audio/Video Receiver
Brand	Glemm
Model	AMP 600
Power Output	100 W per channel (8 ohms, 20 Hz-20 kHz, 0.08% THD)
Frequency Response	20 Hz - 20 kHz
Audio Inputs	4 x RCA, 1 x Optical, 1 x Coaxial
Audio Outputs	Speaker terminals (2 channels), Subwoofer pre-out, Headphone jack
Tuner	AM/FM with memory presets
Dimensions (W x H x D)	430 mm x 140 mm x 350 mm
Weight	8.0 kg
Power Supply	AC 230 V, 50 Hz
Power Consumption	350 W (max)
Standby Power Consumption	< 0.5 W
Features	Volume, bass, treble, balance controls; source selection; sleep timer; remote control included
Cleaning Instructions	Wipe with a soft, dry cloth. Do not use solvents or abrasive cleaners.
Safety Warnings	Do not expose to rain or moisture. Unplug during storms or when not in use.
Spare Parts & Reparability	Contact authorized service center for repairs. User-replaceable fuse.

Frequently Asked Questions - AMP 600 Glemm

How do I connect speakers to the AMP 600?

Connect bare wires or banana plugs to the speaker terminals. Ensure positive (+) to positive and negative (-) to negative. Tighten the binding posts securely.

Why is there no sound from the speakers?

Check that the receiver is turned on, the correct input is selected, volume is turned up, and speakers are properly connected. Also ensure the speaker A or B outputs are enabled.

Can I use the AMP 600 with a TV?

Yes, connect your TV's audio output (optical, coaxial, or RCA) to the corresponding input on the receiver. Select that input on the receiver to hear TV audio through your speakers.

How do I set up the FM/AM tuner?

Connect the included antenna to the AM/FM antenna terminals. Use the TUNING buttons to scan frequencies. Press MEMORY then a preset number to save a station.

What is the maximum power output per channel?

The AMP 600 delivers 100 watts per channel into 8 ohms, with less than 0.08% total harmonic distortion.

Does the receiver have a headphone jack?

Yes, a 6.3mm headphone jack is located on the front panel. Plugging in headphones automatically mutes the speaker outputs.

How do I clean the receiver?

Use a soft, dry cloth to wipe the exterior. Avoid using liquids or spray cleaners. For ventilation grilles, use a vacuum cleaner with a brush attachment.

The remote control is not working. What should I do?

Replace the batteries with new ones. Ensure the remote sensor on the receiver is not obstructed. Test the remote by pointing it at a smartphone camera to see if it emits infrared light.

Can I connect a subwoofer to the AMP 600?

Yes, use the SUBWOOFER PRE-OUT jack on the rear panel to connect an active subwoofer via a standard RCA cable.

What should I do if the receiver shuts off unexpectedly?

This may trigger the protection circuit. Ensure proper ventilation, check speaker connections for shorts, and reduce volume. If it persists, consult a qualified technician.

USER MANUAL AMP 600 Glemm

Front view of a GLEMM audio amplifier front panel with control knobs and power ports (no readable text beyond branding)

Simple black-and-white icon of a portable electronic device with buttons and indicator lights (no text or symbols)

AMPLIFICATORE
Amplifier

Icon of an open book with a gear symbol, no text or symbols present

MANUALE
Manual

AMP SERIES

SPECIFICHE TECNICHE - TECHNICAL SPECIFICATIONS

AMP 200 AMP 400 AMP 600 AMP 1200

The manufacturer, in order to improve its products, reserves the right to modify their characteristics whether technical or aesthetic, at any time and without notice.

GRAZIE PER IL VOSTRO ACQUISTO

The product you have purchased is the result of careful planning by specialized engineers. High quality materials were used for its construction, to ensure its functioning over time. The product is manufactured in compliance with the strict regulations imposed by the European Union, a guarantee of reliability and safety.

Please read this manual carefully before starting using the device in order to take advantage of its full potential. Hoping that you will be satisfied of your purchase, we thank you again for your trust in our brand and we invite you to visit our website www.glemm.eu where you will find the whole range of our products, along with useful information and updates.

CAUTIONS AND WARNINGS

Before making any connection check that the unit is turned off and unplugged from the electrical outlet.

• Read carefully the instructions provided in this manual and follow them strictly.
• Keep this manual for future reference and include it if you give the product to another user.
  This device works with dangerous 230V mains power. Do not open, do not disassemble and don't try to operate inside. In case of wrong use an electric shock may occur.
• The installation of this product must be carried out exclusively by specialized technicians, skilled in electric and audio systems. In case of wrong installation or connections, the manufacturer doesn't take any responsibility for damages to people or objects.
  • The product is conceived for professional use.
• When you connect the fixture always check that the power outlet's voltage corresponds to the unit's operating voltage.
• The product is not suitable for outdoor use. To avoid the risk of shortcircuits don't expose it to high temperatures (above 40^ ), rain or humidity.
• Do not allow flammable liquids, water or objects to enter the product.
• Don't touch the product with wet hands.
• Do not place any recipients filled with liquids, such as vases, on top of or directly next to the appliance.
  • Install the product in a stable and ventilated position, far from heat sources and don't obstruct the air vents.
  • Use the fixture and its controls with due accuracy, avoiding falls, vibrations or impacts.
  • In the event of a serious operating problem, stop using the product immediately. Never try to repair it by yourself, but contact the authorized technical service center. Repairs carried out by unskilled persons could lead to serious damages both to the fixture and to people.
• Disconnect the unit from power when it is not used.
• Wait for the product to cool and disconnect it before cleaning or maintenance.
• If the product doesn't turn on, check the fuse and if necessary replace it with one of the same type and rating, after disconnecting the fixture from power.
• Do not turn the product on and off at short intervals, it may reduce the life of the device.
• Never disconnect the product from the power source by pulling on the cord.
• Do not cut, kink, otherwise damage nor modify the power supply cord and periodically check that it is in good condition.
  • To clean the product, use only a damp cloth, avoiding solvents or detergents of any kind.
• Keep away from children's reach.

SHIPMENT AND COMPLAINTS

When purchasing or receiving the product, open the box and carefully check the content, to make sure that all parts are present and in good condition. Report any transport damage suffered by the device to the seller immediately. If you send the product for repair, it must be shipped with complete original packaging: we therefore recommend to keep it, along with the invoice or the purchase receipt.

CAUTION: RISK OF ELECTRIC SHOCK, DO NOT OPEN

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER. NO USER SERVICEABLE PARTS INSIDE. TURN TO QUALIFIED PERSONNEL

This symbol alerts you of the presence of important operating and maintenance instructions, in the manual or in the documentation accompanying the product

This symbol alerts you to the presence of uninsulated dangerous voltage within the product's enclosure that might be of sufficient magnitude to constitute a risk of electric shock. Do not open the product's case.

To prevent possible hearing damage, do not listen at high volume levels for long periods.

The CE mark indicates that this product complies with the applicable European directives and their related standards. Compliance documentation in complete form is available at the company Karma Italiana Srl

Directive 2012/19/UE regarding electric and electronic equipment waste (WEEE).

The symbol of the crossed-out dustbin indicates that the product at the end of its life must be collected separately from other waste. The user must, therefore, confer the fixture complete with all the essential components to an authorized disposal center for collection of electronic and electrical waste, or return it to the dealer when buying new equipment of equivalent type, at a rate of one to one, or one to zero if external dimension is less than 25cm. Appropriate separate collection to send the decommissioned equipment to recycling, treatment and environmentally compatible disposal helps to prevent negative impact on the environment and human health and promotes recycling of the materials making up the product. In Italy illegal dumping of the product by the user entails the application of administrative sanctions pursuant to Legislative Decree n. 49 (14/03/2014).

WARRANTY CONDITIONS

The product is covered by warranty according to current national and European regulations.

• The warranty covers manufacturing defects and faults occurred in the first 2 years from the date of purchase. In case of purchase with invoice, the warranty is limited to 1 year.
• Damages caused by negligence or wrong use of the device are not covered by warranty.
• The warranty is no longer effective if the item is modified or disassembled by not authorized people.
- This warranty doesn't necessarily envisage the product's replacement.
• External components, batteries, knobs, switches and any removable or subject to wear and tear parts are excluded from warranty.
- Shipment for the return of faulty items is at expense and risk of the owner.
• For all intents and porpuses the warranty is effective only upon exhibition of the invoice or of the purchase receipt.

For detailed warranty conditions and for instructions on how to submit RMA requests please refer to our website www.glemm.eu.

AMP 200 / 400 / 600 / 1200

AMP 200 / 400 / 600

AMP 1200

1. POWER SOCKET

Connect the included power cord to this socket and to a 220V power outlet.

2. SCREW TERMINALS FOR SPEAKERS

Connect here with the specific cables the right and left speakers for 8 Ohm operation.

3. SPEAKON CONNECTORS FOR SPEAKERS

Connect here the right and left speakers for 8 Ohm operation using speakon cables.

4. XLR INPUT SOCKETS

Sockets for right and left input signals via XLR connectors

5. MODE SELECTOR

Useful to select the operating mode: stereo, parallel or bridge.

6. COOLING FANS

They operate automatically and at variable speeds.

7. 6,3mm INPUT SOCKETS

Sockets for right and left input signals via 6,3mm jack connectors

8. GROUND LIFT

When set on LIFT position it disconnects the amplifier's ground to prevent noise from ground loops.

9. FUSE HOLDER

Present only on models AMP 200/400/600. It contains the protection fuse.

10. BRIDGE CONNECTORS

If bridge mode is set, the power of the two channels will add up in a single output. Use these connectors if you have set this operation mode.

11. LIMITER

It limits the amplified signal's level.

12. RESET

When pressed it restes the amplifier's overload protection status.

13. RCA INPUT CONNECTORS

RCA connectors for left and right input signals.

14. SENSITIVITY

It adjust the input signals' sensitivity.

15. VOLUME

These are two independent controls for the left and right channel. They adjust the volume of the amplified signal sent to the speakers.

16. SIGNAL

They indicate the presence of an input signal on left and right signal.

17. POWER LED

It indicates that the amplifier is powered and correctly operating.

18. FAULT

It indicates, for left and right channels, that the amplifier went into protection mode because of a signal overload. In this case lower the volumes, press the reset button (AMP 1200) or turn off the amplifier for some seconds.

19. CLIP

This leds indicate signal peaks. If they flash from time to time it can be considered normal. On the contrary if they remain constantly on, it is necessary to lower immediately the volumes to avoid the risk of damaging the fixture. They are independent for right and left channels.

20. POWER BUTTON

It's the amplifier's on/off button.

21. RACK MOUNT HOLES

For mounting in standard 19" racks.

GLEMM
