| Product Type | Clamp Meter |
| Brand | Fluke |
| Model | 301B |
| AC Current Range | 0 to 600 A |
| AC Voltage Range | 0 to 600 V |
| DC Voltage Range | 0 to 600 V |
| Resistance Range | 0 to 40 MΩ |
| Capacitance Range | 0 to 100 µF |
| Frequency Range | 0 to 1 kHz |
| Continuity Test | Yes, with beeper |
| Diode Test | Yes |
| Display | LCD, 4000 counts |
| Backlight | Yes |
| Data Hold | Yes |
| Auto Range | Yes |
| Jaw Opening | 30 mm |
| Safety Rating | CAT III 600 V |
| Power Supply | 2 x AA batteries |
| Dimensions | 200 x 66 x 38 mm |
| Weight | Approx. 260 g |
| Accessories Included | Test leads, batteries, manual |
| Cleaning | Wipe with a damp cloth; do not use solvents |
| Battery Replacement | User-replaceable; see manual for instructions |
Frequently Asked Questions - 301B FLUKE
How do I measure AC current with the Fluke 301B?
Set the rotary switch to the AC current range (A~). Open the clamp jaws and place them around a single conductor. The display shows the current value. Ensure the clamp is fully closed for accurate readings.
How do I measure voltage?
Connect the test leads: black to COM, red to VΩ. Set the rotary switch to V~ for AC voltage or V⎓ for DC voltage. Touch the probes to the test points and read the display.
How do I test continuity?
Turn the dial to the continuity position (usually a diode symbol with sound waves). Connect the test leads across the circuit. A continuous beep indicates a closed circuit (low resistance).
How do I replace the batteries?
Turn off the meter and remove the test leads. Use a screwdriver to open the battery compartment door on the back. Replace the two AA batteries, observing polarity. Close the door securely.
What is the safety rating of the Fluke 301B?
The Fluke 301B is rated CAT III 600 V. This means it can safely measure on circuits up to 600 V AC/DC in distribution level installations.
How do I use the Data Hold function?
Press the HOLD button to freeze the current reading on the display. Press again to release and return to live measurement. Useful for capturing readings in hard-to-see areas.
What does 'OL' on the display mean?
OL stands for Over Load. It indicates the measured value exceeds the selected range. Switch to a higher range or check if the input is within the meter's limits.
How do I clean the Fluke 301B?
Wipe the exterior with a damp cloth and mild detergent if necessary. Do not use abrasive cleaners or solvents. Ensure the meter is dry before use.
How do I measure resistance?
Set the rotary switch to the Ω range. Connect the test leads across the resistor or component. The display shows the resistance value. For accurate low-resistance measurements, ensure good contact.
What is the warranty period for the Fluke 301B?
Fluke typically offers a limited lifetime warranty for defects in materials and workmanship. For specific terms, refer to the product manual or contact Fluke support.
