INN-604 - Hair Dryer Innoliving - Free user manual and instructions

Product Type	Hair Dryer
Brand	Innoliving
Model	INN-604
Rated Power	2000 W
Voltage	220-240 V
Frequency	50/60 Hz
Heat Settings	3 (Low, Medium, High)
Speed Settings	2 (Low, High)
Ion Technology	Yes
Concentrator Nozzle	Included
Diffuser	Not included
Weight	0.5 kg (approx.)
Cable Length	1.8 m
Housing Material	Plastic
Overheat Protection	Yes
Hang Loop	Yes
Cleaning	Remove dust from air intake regularly
Storage	Store in a dry place, unplug after use
Warranty	2 years

Frequently Asked Questions - INN-604 Innoliving

How do I turn on the Innoliving INN-604 hair dryer?

Slide the power switch to the desired speed setting (I for low, II for high). Then select the heat setting using the second switch.

Can I use the hair dryer on wet hair?

Yes, but it is recommended to towel-dry your hair first to reduce drying time and prevent heat damage.

How do I clean the air intake filter?

Ensure the dryer is unplugged and cool. Remove the back cover or use a brush to gently remove dust and lint from the intake grille.

What does the cool shot button do?

The cool shot button releases a burst of cool air to help set your hairstyle and add shine. Press and hold it while styling.

Is the INN-604 suitable for all hair types?

Yes, with multiple heat and speed settings, it can be used on fine, medium, and thick hair. Use lower heat for fine hair.

Can I use the dryer with a voltage converter abroad?

The dryer is designed for 220-240V. If used in countries with 110-120V, a suitable step-up converter is required. Check the rating before use.

How do I attach the concentrator nozzle?

Simply snap the nozzle onto the front of the dryer. To remove, pull it off while pressing the release button if available.

Does the hair dryer have automatic shut-off?

Yes, the INN-604 is equipped with overheat protection. If it becomes too hot, it will automatically turn off to prevent damage.

Can I use the dryer in the bathroom?

Avoid using near water or in very humid areas. Keep the dryer away from bathtubs, showers, or sinks to reduce electric shock risk.

What is the warranty period for the Innoliving INN-604?

The standard warranty is 2 years from the date of purchase. Keep your receipt as proof.

USER MANUAL INN-604 Innoliving

INN-604

MANUALE D'USO

USER MANUAL

UPORABNIŠKA NAVODILA

ASCIUGACAPELLI PROFESSIONAL 2100

I

ISTRUZIONI PER L'USO

Color palette bar with grayscale swatches and a white square at the bottom (no text or symbols)

non si bagnino.

Thank you for purchasing the hair dryer INN-604, equipped with concentrator and diffuser it allows to quickly and easily realize different types of hair set and drying.

Read carefully all the instructions before using the unit and maintain this manual for future references.

WARNINGS AND IMPORTANT SAFETY INSTRUCTIONS

• Do not use the appliance for purposes different from those indicated in this instruction manual. Any other use is considered improper and therefore dangerous.
• For hygienic reasons, do not share the product with others. In case of infections or health problems to the ear or nose, which require special treatment, you should use the device with extreme caution and after consultation with the attending physician.
• This product is intended for household use only.
• Remove the packaging before use. Keep all packaging (plastic bags, cardboard, etc.) out of reach of children

as they are potentially dangerous and should be disposed of as required by law.

• Before connecting the device to the power outlet, make sure the voltage on the rating label corresponds to the local mains voltage.
• If the power cord is damaged it must be replaced by the manufacturer or by the after sales service or a similarly qualified person in order to avoid any risks.
• When the hair dryer is used in the bathroom, unplug it after use since water represents a risk even when the hairdryer is switched off.

For additional protection, we recommend installing a residual current device (RCD) with a rated residual operating current not exceeding 30 mA in the electrical circuit supplying the bathroom. Ask your installer.

• CAUTION - Do not use this appliance near bathtubs, showers, basins or

other water container.

- The use, cleaning or maintenance of the device made by children older than eight years, or by anyone who does not have knowledge, experience or who have reduced physical, mental, sensory must not be carried out without having first received appropriate instructions and under the supervision of an adult responsible for their safety and have fully learned the associated risks.

• Cleaning and maintenance shall not be made by children without supervision
• Do not use outdoors.
  • Always unplug the hair dryer from the power supply when not in use and before cleaning.
• Do not immerse the device in water or other liquids to avoid any risk of electrical shock.
• Do not spray aerosol products when the dryer is running.

GB

• Do not leave the dryer on when not in use. Do not leave the appliance unattended when it is plugged in.
• Use the appliance only with the originally supplied accessories.
• Do not block the ventilation points to prevent the unit from overheating.
• If the airflow is inadvertently obstructed during use, the appliance switches off automatically. The hair dryer is automatically reactivated after a few minutes after cooling.
• Store in a cool, dry place. Do not use it with wet hands.
• Place the unit only on heat resistant surfaces.
  • Take care that the plug and cord do not get wet.
• Do not tamper with the product trying to repair or replace damaged parts. All repairs should be performed only by authorized personnel; otherwise the

warranty is void.

• Do not weave or twist the cord or wrap it around the appliance.
• Keep the product and its accessories away from heat sources.
• Do not store the product if operating under a blanket or pillow.
  • Always turn off the product after use.
• Do not immerse the device in liquids and do not use it near the bathtub, sink or other container filled with water.
• This product is not a toy. Children should not play with the appliance.
• Do not recover the device if it has fallen into water. Disconnect the product from the electrical outlet. Do not use it again until the product has been inspected and approved by a qualified electrician.

How to use

1. Insert the plug into the socket.
2. Switch on the appliance by selecting the desired speed / temperature settings using the two switches.

After drying, you can use the (cool) button to fix the hair set with a continuous flow of fresh air.

Color palette bar with grayscale swatches and a color swatch labeled 'GB' (no other text or symbols)

Styling Accessory

Concentrator

The concentrator allows you to direct the air flow on the lock of hair you are drying. Place the concentrator on the dryer. Remove it, pulling outward.

Diffuser

The diffuser allows a more gentle drying. It is particularly suitable for curly hair, reduces frizz and helps to maintain the softness of the curly defining the shape.

Place the diffuser on the unit, remove it by pulling outward.

Cleaning

1. The external device can be cleaned with a damp cloth and dry with a soft cloth.
2. The accessories can be cleaned with a damp cloth or rinse with water. Make sure the accessories are completely dry before use and store them.

Do not immerse the device in water.

Storage

When the unit is not in use, disconnect from the mains.

Allow the device to cool down and store it in a dry place. This hair dryer is equipped with hanging hook. Do not wrap the cord around the appliance to prevent damage to the cable

RATING LABEL

Innoliving Spa

Via Merloni 9 - 60131 Ancona - Italy INN-604 ASCIUGACAPELLI - HAIR DRYER 220-240V\~50/60Hz 1800-2100W

This product complies with all applicable European directives.

Appliance with electrical insulation class II

Do not immerse the device in liquids and do not use it near the bathtub. Do not place it on flat surfaces or where it could fall into the sink or other container filled with water.

INFORMATION TO USERS according to Legislative Decree No. 49 of March 14, 2014 "2012/19/UE Implementation of the Directive on Waste Electrical and Electronic Equipment (WEEE)"

The crossed-out dustbin symbol indicates that the product at the end of its life must be collected separately from other waste.

The user should, therefore, take the equipment with the essential components at the end of its useful life to the separate collection center of electronic and electrical waste, or return it to the retailer when purchasing new equipment of equivalent type, in ratio of one to one, or one to zero for devices with larger side less than 25 CM. The separate collection for the decommissioned equipment for recycling, treatment and environmentally compatible disposal contributes to avoid possible negative effects on the environment and human health and promotes recycling of the materials. Improper disposal of the product by the user entails the application of administrative sanctions according to Legislative Decree No. 49 of 14 March 2014.

NAVODILA ZA UPORABO

Zahvaljujemo se vam za nakup sušilnika za lase modela INN-604, kateremu sta priložena disuzor in koncentrato za hitro sušenje, urejanje in oblikovanje pričeske po vašem okusu.

Color palette bar with grayscale swatches and a central crosshair (no text or symbols)

innoliving easy tech, easy life

Innoliving Spa

Via Merloni, 9

60131 Ancona Italy

Tel 199.188.335

www.innoliving.it

CE

Rev. 02_11.2017
