| Product Type | Range Hood |
| Brand | Balay |
| Model | 3BC978HX |
| Width | 90 cm |
| Depth | 50 cm |
| Height | 60 cm |
| Weight | 12 kg |
| Power Supply | 220-240 V, 50 Hz |
| Lighting | 2 x 20 W halogen |
| Extraction Power | 650 m³/h |
| Number of Speeds | 3 speeds + intensive |
| Control Type | Electronic push buttons |
| Grease Filter Type | Aluminum washable filter |
| Charcoal Filter | Optional, replaceable |
| Noise Level | 50 dB (A) at normal speed |
| Energy Efficiency Class | A |
| Ducting Diameter | 150 mm |
| Safety Features | Overheat protection |
| Maintenance | Filters washable every 2 months |
| Spare Parts | Filters, lamps, motor |
Frequently Asked Questions - 3BC978HX BALAY
How do I clean the grease filter?
Remove the filter and wash it with warm water and detergent, or in the dishwasher at low temperature. Ensure it is completely dry before reinserting.
How often should I replace the charcoal filter?
Replace the charcoal filter every 3 to 6 months, depending on usage. The hood will be less effective if the filter is saturated.
The hood is very noisy. What can I do?
Check if the filters are clean and properly installed. Reduce the speed setting. If noise persists, motor or bearings may need professional inspection.
Can I use the hood without a charcoal filter?
Yes, if the hood is vented to the outside. The charcoal filter is only needed for recirculation mode.
How do I replace the light bulb?
Disconnect power. Remove the light cover and replace with a bulb of the same type and wattage (e.g., 20W halogen). Tighten securely.
The hood is not extracting properly. What should I check?
Ensure filters are clean. Check that the duct is not blocked. Verify that the hood is correctly vented and the outlet is open.
What is the recommended installation height above the hob?
For electric hobs, between 65-75 cm; for gas hobs, between 75-85 cm for optimal performance.
Does this hood have a remote control?
No, the 3BC978HX model is controlled via push buttons on the front panel.
Can I use an extension cord?
Avoid extension cords. If necessary, use a heavy-duty cord rated for the appliance's power (minimum 10A). Ensure proper grounding.
How do I register the warranty?
Register your product on the Balay website within 30 days of purchase. Keep your purchase receipt as proof.
